Supramolecular Architectures from Bent-Core Dendritic Molecules**
Miguel Cano, Antoni Sꢀnchez-Ferrer, Josꢁ Luis Serrano, Nꢁlida Gimeno,* and M. Blanca Ros*
Abstract: Control of the self-assembly of small molecules to
generate architectures with diverse shapes and dimensions is
a challenging research field. We report unprecedented results
on the ability of ionic, bent dendritic molecules to aggregate in
water. A range of analytical techniques (TEM, SEM, SAED,
and XRD) provide evidence of the formation of rods, spheres,
fibers, helical ribbons, or tubules from achiral molecules. The
compact packing of the bent-core structures, which promotes
the bent-core mesophases, also occurs in the presence of a poor
solvent to provide products ranging from single objects to
supramolecular gels. The subtle balance of molecule/solvent
interactions and appropriate molecular designs also allows the
transfer of molecular conformational chirality to morpholog-
ical chirality in the overall superstructure. Functional motifs
and controlled morphologies can be combined, thereby open-
ing up new prospects for the generation of nanostructured
materials through a bottom-up strategy.
applications such as chiral resolution, nonlinear optics, and
photovoltaics are claimed.[4g–i,5] Thus, in addition to the stated
functional properties,[5] BCLCs offer high potential in both
supramolecular chemistry and materials science.
Interestingly, Ho, Hsu, and co-workers[6] reported the
ability of bent-core molecules to promote supramolecular
chirality by self-assembly in a solvent. Thus, an achiral bent-
core molecule formed hierarchical helical superstructures in
a THF/water solution.[6a] They proposed the molecular
conformational chirality as the origin of such superstructures.
Control over the self-assembly of small molecules to
generate architectures with diverse shapes and dimensions by
supramolecular chemistry is still a topical, challenging, and
dynamic research field.[7,8] Systems ranging from the nano-
and micrometer scales to macroscopic dimensions, along with
diverse morphologies with shapes and structures that can
influence the physical properties, are considered in this field,
with applications in nanotechnology to biotechnology.[7,8]
However, many such systems are still difficult to synthe-
size, especially in the case of aqueous systems, which could
give rise to breakthroughs in biological, medical, and
materials science. The prediction of structural features from
noncovalent interactions is still in its infancy and, despite
interest in new approaches, systematic studies on the self-
assembly of bent-core molecules in solution have not been
published to date, despite their mesomorphic abilities.
Herein, we report major advances in the potential of the
bent-core packing to generate controlled aggregates in water.
The choice of ionic bent-core/PPI-based (PPI = polypro-
pyleneimine molecules to achieve this target arose not only
because they form BCLCs,[9] but also because their inherent
amphiphilicity could favor segregation effects in solvents,
including water.[10] Thus, we explored how pathways to create
aggregates of bent-core molecules affected their final supra-
molecular structure by changing the molecular design. The
effect of changing the length of the flexible tails, either in an
inner (m: 4, 10) or an outer (n: 8, 14) position was evaluated
initially with first generation dendrimers PPI1-B1-m-
n (Scheme 1). We then extended our research to further
ionic dendrimers by incorporating intrinsic chirality into the
molecules (PPI1-B1-4-7* and PPI1-B1-4-8*) with the aim of
controlling the supramolecular chirality. Furthermore, an
isomeric rod-core dendrimer (PPI1-C1-4-8) was studied to
demonstrate the exclusivity of the bent-core design to induce
supramolecular chirality (Scheme 1).
B
ent molecules are the origin of bent-core liquid crystals
(BCLCs), which have properties different to those of classical
mesophases.[1] Their molecular geometry forces the molecules
to adopt a compact packing, which restricts their rotational
freedom and leads to novel and intriguing polar mesophases.
A distinctive feature of this class of mesogen is the possibility
of the formation of mesophases with spontaneous macro-
scopic chirality from achiral molecules.[1e,f,l,2] Their formation
mechanisms are still under debate,[1e,f,2a,b,d,3,4] but potential
[*] Dr. M. Cano, Dr. N. Gimeno, Prof. Dr. M. B. Ros
Instituto de Ciencia de Materiales de Aragꢀn
Departamento de Quꢁmica Orgꢂnica. Facultad de Ciencias
Universidad de Zaragoza-CSIC
Campus San Francisco. 50009-Zaragoza (Spain)
E-mail: bros@unizar.es
Dr. A. Sꢂnchez-Ferrer
ETH Zurich
Department of Health Sciences and Technology, IFNH
Schmelzbergstrasse 9, LFO, E29, 8092 Zurich (Switzerland)
Prof. Dr. J. L. Serrano
Instituto de Nanociencia de Aragꢀn
Departamento de Quꢁmica Orgꢂnica
Facultad de Ciencias, Universidad de Zaragoza
Campus San Francisco, 50009-Zaragoza (Spain)
[**] We greatly appreciate financial support from the Spanish Govern-
ment (MICINN-FEDER projects MAT2012-38538-C03-01 and
CTQ2012-35692) and Aragon’s Government (GA) (project E04).
Support from Prof. R. Mezzenga is greatly appreciated. We are also
grateful to Juan de la Cierva-MICINN, JAEDOC-CSIC (N.G.), and to
GA (M.C.) fellowship programs for support. Thanks are given also
to the nuclear magnetic resonance, mass spectra, and thermal
analysis services from the ICMA (Uni. Zaragoza-CSIC) and the LMA
from INA (Uni. Zaragoza) for SEM and TEM equipment.
It is demonstrated here that these ionic dendrimers are
suitable molecules not only to obtain different bent-core
mesophases, but that they also aggregate to form a variety of
useful architectures in water. However, the presence of
a bent-core structure alone is not sufficient to provide
either aggregates or similar morphologies, including helical
structures.
