2314
P. Hommes et al.
LETTER
2002, 1831. (e) Ye, B.-H.; Tong, M.-L.; Chen, X.-M. Coord.
Chem. Rev. 2005, 249, 545.
during N-acylation or chromatography of the b-keto-
enamides 7 is currently unclear.
(8) For reviews, see: (a) Kröhnke, F. Synthesis 1976, 1.
(b) Summers, L. A. The Bipyridines, In Advances in
Heterocyclic Chemistry, Vol. 35; Katritzky, A. R., Ed.;
Academic Press: Orlando, FL, 1984, 281. (c) Chelucci, G.;
Thummel, R. P. Chem. Rev. 2002, 102, 3129. (d) Varela,
J. A.; Saá, C. Chem. Rev. 2003, 103, 3787. (e) Newkome,
G. R.; Patri, A. K.; Holder, E.; Schubert, U. S. Eur. J. Org.
Chem. 2004, 235. (f) Hapke, M.; Brandt, L.; Lützen, A.
Chem. Soc. Rev. 2008, 37, 2782.
(9) Selected recent examples: (a) Altuna-Urquijo, M.; Gehre,
A.; Stanforth, S. P.; Tarbit, B. Tetrahedron 2009, 65, 975.
(b) Gutz, C.; Lützen, A. Synthesis 2010, 85. (c) Kremer, C.;
Lützen, A. Synthesis 2011, 210. (d) Duric, S.; Tzschucke,
C. C. Org. Lett. 2011, 13, 2310.
(12) 2-PyCOBt = 1H-1,2,3-benzotriazol-1-yl(pyrid-2-yl)-
methanone; for its preparation, see: (a) Katritzky, A. R.; He,
H.-Y.; Suzuki, K. J. Org. Chem. 2000, 65, 8210. For a
review on N-acylbenzotriazoles, see: (b) Katritzky, A. R.;
Suzuki, K.; Wang, Z. Synlett 2005, 1656.
(13) Takaya, H.; Naota, T.; Murahashi, S.-I. J. Am. Chem. Soc.
1998, 120, 4244.
(14) For a review on aryl and alkenyl nonaflates, see:
Högermeier, J.; Reissig, H.-U. Adv. Synth. Catal. 2009, 351,
2747.
(15) Representative Procedure for the Cyclization of
b-Ketoenamides Followed by Nonaflation of the Crude
Product – 5-Ethoxycarbonyl-6-phenyl-2,2¢-bipyrid-4-yl
Nonaflate (9a)
(10) Representative Procedure for the N-Acylation of a-Acyl-
b-enamino Esters with 2-Picolyl Chloride: Ethyl 3-oxo-2-
[phenyl(picolinamido)methylene]butanoate (7a)
TMSOTf (0.94 mL, 5.17 mmol) was added dropwise to a
solution of b-ketoenamide 7a (350 mg, 1.03 mmol) and
DIPEA (0.68 mL, 4.14 mmol) in DCE (25 mL) under argon.
The mixture was stirred for 5 d at 90 °C in a sealed tube. All
volatile components were removed under reduced pressure,
the crude product was dissolved in THF (15 mL) and treated
with an excess of NaH (309 mg, 7.73 mmol, 60% in mineral
oil, washed with hexane prior to use). After addition of Nf2O
(778 mg, 1.34 mmol) the mixture was stirred overnight at r.t.
and then quenched by slow addition of sat. aq NH4Cl
solution (20 mL). The layers were separated, and the
aqueous layer was extracted three times with CH2Cl2 (20
mL). The combined organic layers were dried with Na2SO4,
and after filtration the solvent was removed under reduced
pressure. Purification of the crude product by flash
chromatography (silica gel, hexane–EtOAc = 40:1 → 20:1)
afforded 434 mg (70%) of 9a as colorless oil. IR (ATR):
3070 (=CH), 2985, 2940–2930, 2905 (CH), 1735 (C=O),
1600, 1575, 1545 (C=C, C=N) cm–1. 1H NMR (500 MHz,
CDCl3): d = 1.15 (t, J = 7.1 Hz, 3 H, CH3), 4.26 (q, J = 7.1
Hz, 2 H, OCH2), 7.40 (ddd, J = 7.8, 4.7, 0.8 Hz, 1 H, 5¢-H),
7.47–7.50, 7.71–7.74 (2 m, 3 H, 2 H, Ph), 7.85 (td, J = 7.8,
1.3 Hz, 1 H, 4¢-H), 8.49 (s, 1 H, 3-H), 8.54 (dbr, J = 7.8 Hz,
1 H, 3¢-H), 8.74 (ddd, J = 4.7, 1.3, 0.8 Hz, 1 H, 6¢-H) ppm.
13C NMR (126 MHz, CDCl3): d = 13.5 (q, CH3), 62.6 (t,
OCH2), 111.2 (d, C-3), 121.7 (d, C-5), 121.9 (s, C-3¢), 125.1
(d, C-5¢), 128.5, 128.6, 129.6 (3 d, Ph), 137.2 (d, C-4¢), 138.5
(s, Ph), 149.4 (d, C-6¢), 153.5, 155.0, 159.1, 159.4 (4 s, C-2,
C-2¢, C-4, C-6), 164.2 (s, CO2Et) ppm. 19F NMR (471 MHz,
CDCl3): d = –125.6 (td, J = 13.7, 4.4 Hz, 2 F, CF2), –120.5
(mc, 2 F, CF2), –108.7 (t, J = 13.7 Hz, 2 F, CF2), –80.5 (t,
J = 9.7 Hz, 3 F, CF3) ppm. HRMS (ESI-TOF): m/z calcd for
C23H16F9N2O5S [M + H]+: 603.0636; found: 603.0629. Anal.
calcd for C23H15F9N2O5S (602.4): C, 45.86; H, 2.51; N, 4.65;
S, 5.32. Found: C, 45.75; H, 2.51; N, 4.69; S, 5.47.
(16) Nf2O = nonafluorobutanesulfonic acid anhydride;
nonaflation employing nonafluorobutanesulfonyl fluoride
(NfF) was slow and incomplete.
SOCl2 (0.29 mL, 4.00 mmol) was added dropwise to a
solution of 2-picolinic acid (492 mg, 4.00 mmol), and Et3N
(0.55 mL, 4.00 mmol) in CH2Cl2 (13 mL) under an argon
atmosphere. After addition of catalytic amounts of DMF the
mixture was stirred for 4 h at r.t. A solution of a-acyl-b-
enamino ester 3a (467 mg, 2.00 mmol) in CH2Cl2 (7 mL)
was added at 0 °C. While stirring overnight the mixture was
allowed to warm up to r.t. (in some cases conversion of the
starting material was complete after a few hours) and sat. aq
NaHCO3 solution (20 mL) was added. The layers were
separated, and the aqueous layer was extracted three times
with CH2Cl2 (20 mL). The combined organic layers were
dried with Na2SO4, and after filtration the solvent was
removed under reduced pressure. Purification of the crude
product by flash chromatography (silica gel, hexane–
EtOAc = 4:1 → 2:1) afforded 590 mg (87%) of 7a (major/
minor isomer ca. 3.5:1) as brownish oil. IR (ATR): 3170
(NH), 3060 (=CH), 2980, 2930 (CH), 1710 (C=O), 1650,
1550 (C=C, C=N) cm–1. Chemical shifts are listed for the
major isomer only.1H NMR (500 MHz, CDCl3): d = 0.83 (t,
J = 7.1 Hz, 3 H, CH3), 2.39 (s, 3 H, COCH3), 3.84 (q, J = 7.1
Hz, 2 H, OCH2), 7.33–7.44 (m, 5 H, Ph), 7.48 (ddd, J = 7.7,
4.5, 1.0 Hz, 1 H, 5¢-H), 7.82 (td, J = 7.7, 1.7 Hz, 1 H, 4¢-H),
8.04 (dbr, J = 7.7 Hz, 1 H, 3¢-H), 8.78 (dbr, J = 4.5 Hz, 1 H,
6¢-H) ppm; the NH signal could not be detected. 13C NMR
(126 MHz, CDCl3): d = 13.4 (q, CH3), 29.7 (q, COCH3),
61.2 (t, OCH2), 116.7 (s, CCOCH3), 123.2 (d, C-3¢), 127.0
(d, C-5¢), 127.5, 127.9, 129.3, 134.5 (3 d, s, Ph), 137.4 (d, C-
4¢), 148.8 (d, C-6¢), 149.2 (s, C-2¢), 153.4 (s, CNH), 163.3 (s,
CONH), 168.0 (s, CO2Et), 197.3 (s, COCH3) ppm. HRMS
(ESI-TOF): m/z calcd for C19H18N2O4Na [M + Na]+:
361.1164; found: 361.1166. Anal. calcd for C19H18N2O4
(338.4): C, 67.44; H, 5.36; N, 8.28; found: C, 66.80; H, 5.28;
N, 8.16.
(11) Whether already the a-acyl-b-enamino esters 3 were isolated
as mixtures of E and Z isomers (no isomerization could be
detected by NMR spectroscopy), or isomerization occurred
(17) Cacchi, S.; Ciattini, P. G.; Morera, E.; Otar, G. Tetrahedron
Lett. 1986, 27, 5541.
Synlett 2011, No. 16, 2311–2314 © Thieme Stuttgart · New York
