Tracking the Structural Changes in a Series of Cholesterol Solvates
Rhona J. Galloway,† Syed A. Raza,† Robert D. Young,† and Iain D. H. Oswald*,†
†Strathclyde Institute of Pharmacy and Biomedical Sciences, University of Strathclyde, 161 Cathedral Street, Glasgow G4 0RE, U.K.
S
* Supporting Information
ABSTRACT: This article describes the isolation of seven new
solvates of cholesterol using solvents of varying carbon chain
length and overall size from propanol through to phenyl-
ethanol. The structural similarities that exist between these
novel solid forms and also those cocrystals and solvates already
observed are discussed.
Despite the functional use of cholesterol in the body, it has
received notoriety in the press for being a contributing factor in
causing heart disease if present in high levels in the
bloodstream. Cholesterol is also a major component of
gallstones as the anhydrous form as well as in the form of
the monohydrate, and so there have been a number of studies
relating to the growth of this phase onto calcium carbonate, the
other main contributor to gallstones.4−7 Further theoretical
studies of cholesterol have been made investigating formation
of nanoparticles and also the applicability of the GROMOS
force field, designed primarily for biological systems, to model
the crystalline structures of smaller membrane sterols.8,9 At the
heart of all these studies, is the investigation of how cholesterol
molecules interact with one another and surrounding materials.
Further investigation of the solid-state forms of cholesterol and
how the molecules interact with one another in these systems
can contribute to our understanding of cholesterol in these
other environments.
INTRODUCTION
■
Cholesterol is one of the major steroids within mammalian cells
and forms an integral part of the cell membranes. The
molecular structure of cholesterol is ideally suited to these
surroundings, as it consists of a hydroxyl group, that interacts
with the polar headgroup of the phospholipid, and a tetracyclic
steroid body bonded to an eight carbon alkyl chain that
interacts with the hydrophobic fatty acid chains of the
phospholipid bilayer of the cell membrane (Scheme 1).
Scheme 1. Molecular Structure of Cholesterol
In the solid-state, cholesterol crystallizes in a number of
different forms in addition to the two anhydrous phases.10−14
In the Cambridge Structural Database (CSD),15,16 there is a
monohydrate (CSD refcode: CHOLES20),17 a hemimethanol
solvate (CHOLME02),18 two hemiethanol solvates (CHOLEU01,
CHOLEU10),19 an isobutylphosphocholine/tert-butanol coc-
rystal (MEQKAU),20 and finally a cocrystal with 4-iodophenol
(WOMHAI).21 The structures of all these compounds can be
broadly categorized into two distinct molecular architectures
depending on the size of the additional solvent or coformer. The
majority of these compounds crystallize in a bilayer struc-
ture with alternating hydrophobic and hydrophilic regions.
The molecules of cholesterol are positioned end-to-end such
that the isopropyl groups at the end of the alkyl chains interact
with one another. The second architecture is more compact,
Once orientated within the membrane, one of the roles of
cholesterol is to alter the physicochemical properties of the cell
membrane by subtly altering the interactions of the
surrounding fatty acid chains. It has been shown through
DSC and X-ray diffraction measurements that the addition of
cholesterol to the membrane structure causes changes in the
physical behavior of the phospholipid layers with respect to
temperature. Pure lipid layers possess a gel/liquid-crystal
transition at elevated temperatures whereby the chains “melt”
and become less ordered. The addition of >40 mol %
cholesterol causes the disappearance of this phase transition,
resulting in an “intermediary” structure that possesses a bilayer
thickness between that of the gel and liquid-crystal states.1,2
Furthermore, a study by Lund-Katz et al. demonstrated, using
surface pressure measurements, that the addition of cholesterol
to a membrane causes it to become more condensed and
hence harder which has an effect on the functioning of trans-
membrane proteins.3
Received: July 27, 2011
Revised: December 1, 2011
Published: December 5, 2011
© 2011 American Chemical Society
231
dx.doi.org/10.1021/cg200971f | Cryst. Growth Des. 2012, 12, 231−239

Crystal Growth & Design
Article
Figure 1. Crystal morphologies of the seven new cocrystals compared to the morphology of the methanol and ethanol solvates. Solvates of
cholesterol with (a) propanol, (b) butanol, (c) pentanol, (d) hexanol, (e) phenol, (f) benzyl alcohol·water, (g) phenylethanol, (h) methanol, or (i)
ethanol.
Phase IdentificationX-ray Powder Diffraction. A small
where the cholesterol molecules from neighboring chains are
quantity (1−50 mg) of each recrystallized sample was analyzed
using transmission foil XRPD data collected on a Bruker AXS D8-
Advance transmission diffractometer equipped with a θ/θ geometry,
primary monochromated radiation (Cu Kα1, λ = 1.54056 Å), a Bruker
Vantec 1D position sensitive detector (PSD), and an automated
multiposition x−y sample stage.22 Samples were mounted on a 28
position sample plate supported on a polyimide (Kapton, 7.5 μm
thickness) film. Data were collected from each sample in the range
4−35° 2θ with a 0.015° 2θ step size and a 1 s·step−1 count time.
Figure ES2 of the Supporting Information contains the X-ray powder
diffraction patterns of all the bulk samples and confirms the identity of
the cocrystals. Slight differences in the diffraction patterns can be
attributed to the data collection temperature (293 K cf. 123 K for the
single crystal experiments) and preferred orientation.
intercalated with one another in a head-to-tail arrangement. In
this study we have attempted to systematically investigate the
effect of the size and rigidity of the solvent on the final crystal
structure so that a comparison can be made with those struc-
tures already found in the CSD.
EXPERIMENTAL SECTION
■
Sample Preparation. Cholesterol and solvents were purchased
from Sigma Aldrich and used as received.
Formation of Compounds 1−7. These compounds were
obtained from a 1:1 mixture of diethylether and the target solvent
(propanol, butanol, etc.). Cholesterol (103 mg, 0.266 mmol for 1; 100
mg, 0.259 mmol for 2; 98 mg for 3; 106 mg, 0.275 mmol for 4; 101
mg, 0.261 mmol for 5; 151 mg, 0.391 mmol for 6; and 256 mg, 0.663
mmol for 7) was dissolved in 3 cm3 of the 1:1 mixture of diethyl ether
and target solvent. The solvent was left to evaporate, allowing crystals
to form. In the case of propanol, after a few days, some small crystals
appeared on the side of the vial which were pushed into the mother
liquor in order to grow a suitable crystal for single crystal X-ray
diffraction. For compound 5, an excess of phenol was added (44 mg,
0.468 mmol) to 3 cm3 of dietheyl ether. The cocrystals from pentanol
and hexanol needed further addition of cholesterol in order to form
the precipitate on evaporation of the diethyl ether.
Crystal Morphology. Figure 1 shows the morphology of the
crystals from each of the crystallizations. The crystals from propanol,
butanol, and benzyl alcohol show a needle-like morphology whereas
the crystals from the other solvents possessed a lathe or plate
morphologythese are compared with the crystals of the methanol
and ethanol solvates.
Differential Scanning Calorimetry. DSC plots were obtained
using dynamic DSC (DSC 822e, Mettler Toledo, U.K.). Samples were
prepared by carefully weighing between 2.31 and 6.03 mg of each
sample into a 40 μL aluminum pan, which was then hermetically
sealed with a pinhole in the lid. An empty pin-holed 40 μL aluminum
pan was used as a reference. Both pans were subjected to a nitrogen
atmosphere. The pans were then heated at a rate of 10 °C/min from
293 to 463 K (well above the melting point of cholesterol). The
temperature and heat flow of the DSC instrument were calibrated with
indium and zinc. The results were analyzed using Mettler STAR
software. Figure ES1 of the Supporting Information shows the DSC
and TGA traces for each of the samples.
Thermal Gravimetric Analysis. TGA measurements were
performed on a Mettler Toledo TGA 751e. Each sample (7.86−
22.48 mg) was placed in a ceramic pan. An empty ceramic pan was
used as a reference, and both pans were subjected to a nitrogen atmo-
sphere. The pans were then heated from 303 to 463 K at 10°/min.
The results were analyzed using Mettler STAR software.
Crystal Structure Determination. X-ray diffraction intensities
were collected with Mo Kα radiation on a Bruker KAPPA Apex II
CCD diffractometer equipped with an Oxford Cryosystems Cryo-
stream-Plus variable-temperature device operating at 123 K.23
Absorption corrections were carried out using the multiscan procedure
SADABS (Sheldrick, 2004, based on the procedure described by
Blessing, 1995).24,25 The structures were solved by direct methods and
refined by full-matrix least-squares against F2 using all data
(SHELX).26 Due to the wavelength of the X-ray source (0.71073 Å),
the absolute configuration of the cholesterol molecule was not deter-
mined but the absolute structure was chosen to reflect the chirality
observed for the vast majority of structures in the literature in order to
make a direct comparison of the crystal structures. All hydrogen atoms
attached to carbon atoms were geometrically placed, and those partici-
pating in hydrogen bonding, i.e. hydroxyl hydrogens, were found in the
difference map. All non-H atoms were modeled with anisotropic dis-
placement parameters. Where disorder was present, the bond lengths
and angles were restrained to values found in the CSD.
Additional programs used included Materials Mercury 2.4,27
PLATON as incorporated in WINGX.28,29 Mercury, ChemBioDraw
12.0, and GIMP 2.630 were used in the production of the figures.
RESULTS AND DISCUSSION
■
Cholesterol was crystallized with seven alcoholic solvents of increas-
ing size: propanol, butanol, pentanol, hexanol, phenol, benzyl
alcohol, and phenylethanol. The descriptions of the crystal
structures follow, and the crystallographic parameters for the
compounds under study and also those of previous studies
can be found in Tables 1 and 2.
Thermal Analysis. Figure ES1 of the Supporting Informa-
tion shows the thermal analysis plots for each of the cocrystals.
It can be observed that each of the cocrystals 1−4 shows a
desolvation event followed by the melting of the cholesterol at
∼423 K. The desolvations of the propanol and butanol solvates
