phototoxicity in cardiomyocytes, allowing up to 10 min of
continuous illumination without disrupting the waveform of
action potentials.7 Thus, we were curious whether the new
vinyl-fluorene hybrids, with their enhanced voltage sensitivity
compared to fluorene-only indicators, would behave more like
fVF 2 or VF2.1.Cl in terms of phototoxicity. We continuously
illuminated hiPSC-CM monolayers stained with indicators,
making 10 second recordings every minute to monitor action
potential morphology. Indicators with 2v-fVF substitution
appear extremely phototoxic: action potential morphology
changes after just 1 (2v-fVF 1, Figure 3a) to 3 (2v-fVF 2,
Figure 3b) minutes of illumination. Shortly after, the hiPSC-
CMs stopped beating (Figure 3a,b). This degree of toxicity was
fVF 2 throughout the experimentsabove 100:1 after
illuminating 7v-fVF 2 for 9 minpermitting long-term
recordings of electrical activity in cardiomyocyte monolayers
The precise molecular mechanisms governing the reduced
phototoxicity of the 7v-fVF scaffold compared to VF2.1.Cl
remain elusive, but experimental evidence points to the
involvement of reactive oxygen species (ROS). One hypothesis
is that differential dye accumulation in cellular membranes
leads to a range of effective dye concentrations and different
levels of ROS production and toxicity. However, v-fVF dyes
show only small differences in cellular brightness (Figure S6,
Table 1), and fluorescence intensity alone cannot be used as a
quantitative measure of dye concentration.8 Rates of photo-
bleaching in cell membranes are complex (Figure S7),
consistent with studies of fluorescein photobleaching, which
indicate multiple photobleach pathways, including dye−oxygen
and dye−dye interactions, and show that bleach rates depend
strongly on whether the dye is in solution or localized on a
surface (such as a plasma membrane).16 7v-fVF indicators have
slower rates of photobleaching and an initial plateau phase
S8). Under low O2 environments, the initial photobleach rate
for VF2.1.Cl, 2v-fVF, and 7v-fVF increases, while the rate for
fVF 2the only dye lacking a vinyl spacerremains
unchanged, but large (Figure S8). Origins of phototoxicity
seem unlikely to be photothermal because irradiation of VF
dyes does not increase solution temperature (Figure S9).
Instead, phototoxicity may arise from ROS production. Both
2v-fVF and 7v-fVF induce lower levels of ROS than VF2.1.Cl,
whether measured after illumination (using the nonspecific
ROS indicator dihydroethidium,17 Figure S10) or during
illumination (using lipid-associated BODIPY 581/591 C11,18
Figure S11). Currently, we lack the resolution to conclusively
say whether cellular toxicity is mediated by ROS produced by
cells in response to illumination in the presence of VF dyes
(Figure S10) or whether it is ROS produced directly by VF
dyes within the lipid membrane (Figure S11) that drive
toxicity. Studies are underway to investigate these elementary
steps in higher detail.
In summary, we developed four new voltage indicators. All
four vinylene-fluorene VoltageFluor indicators show higher
voltage sensitivity than their cognate fluorene VoltageFluor
dyes. We found that a vinyl spacer between the electron-
donating aniline and the fluorene in the molecular wire (7v-
fVFs) increased sensitivity by about 3-fold compared to fVF
dyes. For 7v-fVF 2 (18), voltage sensitivity was higher (30%
ΔF/F) than the sensitivity of VF2.1.Cl (25% ΔF/F). More
importantly, 7v-fVF indicators remain less phototoxic in
cardiomyocytes relative to VF2.1.Cl, while maintaining higher
SNR throughout extended recordings. Vinyl-fluorene Voltage-
Fluors represent an improvement over the fluorene Voltage-
Fluor scaffold and are an attractive alternative to the traditional
VF2.1.Cl for prolonged recordings of electrical activity in cells.
Figure 3. Extended imaging with vinyl-fluorene VoltageFluors in
hiPSC-iCM monolayers under constant illumination. Monolayers
were stained with v-fVF indicators and illuminated constantly. Every
minute, 10 s optical recordings of voltage dynamics were acquired.
Representative traces are shown for (a) 2v-fVF 1 (3), (b) 2v-fVF 2
(4), (c) 7v-fVF 1 (17), and (d) 7v-fVF 2 (18). (e) Plot of the ratio of
cAPD90/cAPD30, which is the action potential duration at 90% and
30% of the repolarization, corrected for beat rate by Fridericia’s
formula. Initial recordings start with a ratio between 1.2 and 1.4,
regardless of the indicator used. Increases in the ratio indicate a
change in action potential morphology. (f) Plot of SNR per action
potential vs total minutes of illumination.
