One-Pot Syntheses
Multistep One-Pot Synthesis of Enantioenriched Polysubstituted
Cyclopenta[b]indoles**
Biao Xu, Zhi-Lei Guo, Wan-Yan Jin, Zhi-Ping Wang, Yun-Gui Peng, and Qi-Xiang Guo*
The development of asymmetric methodologies for the
synthesis of chiral indoles has been a long-standing project
in organic synthesis. Indole skeletons are heterocyclic systems
and are present in numerous alkaloid products, pharmaceut-
icals, and agrochemicals.[1] Cyclopenta[b]indole skeletons can
be found in a number of indole alkaloids,[2] but have not been
extensively reported. Compounds that contain such a unit
exhibit a wide range of biological activities.[3] For example,
2-aminocyclopenta[b]indoles,[4a] cyclopenta[b]indole-substi-
Scheme 1. General strategy for the multistep one-pot synthesis of
chiral cyclopenta[b]indoles.
tuted acetic acids,[4b] and a series of yuehchukene analogues[5]
have been successfully synthesized and used in medicinal
chemistry. Although a number of methods have been
developed for the synthesis of cyclopenta[b]indoles,[6] only
few of them are asymmetric and especially catalytic asym-
metric methods.[7] To the best of our knowledge, there is only
one example of the synthesis of chiral cyclopenta[b]indoles by
asymmetric catalysis with acceptable enantioselectivities.[8]
The development of efficient methods for the construction
of cyclopenta[b]indole units is therefore highly desirable. As a
continuation of the work of our research group toward the
catalytic asymmetric a-alkylation of carbonyl compounds,[9]
we rationally designed a one-pot[10] three-step reaction, which
consisted of the a-alkylation of an aldehyde, catalyzed by a
primary-amine-substituted thiourea,[11] and two consecutive
Brønsted acid catalyzed Friedel–Crafts reactions of an
indole,[12] to construct chiral polysubstituted cyclopenta[b]in-
doles (Scheme 1). Herein, we report these consecutive
organocatalyzed reactions, which gave structurally diverse
cyclopenta[b]indoles in high yields (up to 85%), and with
excellent diastereoselectivities (up to > 99:1) and enantiose-
lectivities (up to 99% ee).
aldehydes have not been used as donors. For the method
reported herein, a,a-disubstituted aldehydes were very
important precursors because they could produce aldehydes
5 (Scheme 1), which could not be enolated during the
following Friedel–Crafts alkylations; thus, there were fewer
side reactions in this method. Several amine-based catalysts
were investigated in the a-alkylation reaction of aldehyde 4a.
As shown in Table 1, primary-amine-substituted thioureas
were good catalysts for promoting this a-alkylation reaction
(Table 1, entries 1–7). Catalyst 1h, which was used by Chen
and co-workers,[7c] was not a suitable choice for the reaction
(Table 1, entry 8). Thiourea 1a was chosen as the catalyst for
the a-alkylation because good yields and high enantioselec-
tivities could be obtained (Table 1, entry 1). After examining
various solvents, we found that CHCl3 was the best solvent
with regard to yield and enantioselectivity (Table 1, entry 1).
The number of equivalents of isobutylaldehyde 4a also
greatly influenced the yield. For example, the yield increased
significantly when the number of equivalents of 4a was
reduced to 1.2 (Table 1, entry 12 versus entry 1). The impact
of different acids was also examined. The compatibility
between the primary amine and the chiral acid was inves-
tigated first. Both (S,S)-1b and (R,R)-1i could cooperate with
(R)-2d to promote the alkylation efficiently, but the enantio-
selectivities were worse than that obtained with p-nitro-
benzoic acid 2a (Table 1, entries 13, 14, and 15). After
screening the compatibilities of acid additives with both 1a
and 1b (see the Supporting Information), the combination of
thiourea 1a and N-Boc-protected amino acid 2e turned out to
be the best choice of catalyst for this a-alkylation with regard
to yield (71%) and enantioselectivity (90% ee; Table 1,
entry 16).
The reactions shown in Scheme 1 were realized in three
stages. In the first stage, we examined the a-alkylation of
isobutylaldehyde 4a with 3-indolylmethanol 3a (step 1)
under catalysis by chiral amines 1 and acids 2. Although
several methods for the asymmetric amine-based catalysis
have been used in similar a-alkylation reactions of aldehydes
with diarylmethanol compounds,[11] to date a,a-disubstituted
[*] B. Xu, Z.-L. Guo, W.-Y. Jin, Z.-P. Wang, Prof. Y.-G. Peng,
Prof. Q.-X. Guo
Education Ministry Key Laboratory on Luminescence and
Real-Time Analysis, School of Chemistry and Chemical Engineering
Southwest University
Chongqing 400715 (China)
After establishing the optimal reaction conditions for the
a-alkylation of the aldehyde (Scheme 1, step 1), we examined
the feasibility of Brønsted acid catalyzed consecutive Friedel–
Crafts alkylations in steps 2 and 3. For these transformations,
we first chose N-Bn-protected indole 6a as the nucleophile,
4-methylbenzenesulfonic acid (p-TsOH) as the catalyst, and
E-mail: qxguo@swu.edu.cn
[**] We are grateful for financial support from the NSFC (20902074) and
the Fundamental Research Funds for the Central Universities
(XDJK2011C054).
Supporting information for this article is available on the WWW
Angew. Chem. Int. Ed. 2012, 51, 1059 –1062
ꢀ 2012 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
1059
