1552
P. Zajdel et al. / Bioorg. Med. Chem. 20 (2012) 1545–1556
6.2. General procedure for the preparation of compounds 13–26
(Method A)
6.2.5. N-{4-[4-(3-Chlorophenyl)-piperazin-1-yl]-butyl}-6-
chloro-3-quinolinesulfonamide (17)
The compound was prepared by the general method A in 72%
yield as oli; tR = 1.56; MS calcd for [M+H]+: C23H26ClN4O2S m/z:
492.1, found 493.3. 1H NMR (CDCl3) d (ppm) 1.64 (br s, 4H),
2.41–2.44 (t, 2H), 2.62–2.65 (m, 4H), 3.03–3.05 (m, 2H), 3.25–
3.28 (m, 4H), 6.76–6.79 (dd, 1H), 6.84–6.89 (m, 2H), 7.16–7.21 (t,
1H) 7.76–7.80 (m, 2H), 8.09–8.12 (dd, 2H), 8.52–8.53 (d, 1H,
J = 2.1 Hz), 9.19–9.20 (dd, 1H, J = 4.1 Hz, J = 2.0 Hz). Compound
17ÁHCl mp 168.9–169.9 °C. Anal. (C23H26ClN4O2SÁHCl) C, H, N.
The starting N-(
10) and N-( -aminoalkyl)-4-chlorophenylpiperazines (11, 12)
were synthesized according to the Gabriel method. A mixture of
the appropriate N-( -aminoalkyl)-3-chlorophenylpiperazine or
N-( -aminoalkyl)-4-chlorophenylpiperazine (1.2 mmol) in CH2Cl2
(7 mL), and DIEA (2.4 mmol) was cooled down (ice bath), and
azinesulfonyl (1–6) or naphthalenesulfonyl chloride (7, 8)
(1.3 mmol) was added at 0 °C in one portion. The reaction mixture
was stirred for 2–6 h under cooling. Then, the solvent was evapo-
rated and the sulfonamides were separated by column chromatog-
raphy using SiO2 and a mixture of CH2Cl2/MeOH = 9/1 or 9/0.7, as
an eluting system. Free bases were then converted into the hydro-
chloride salts by treatment of their solution in anhydrous ethanol
with 4 M HCl in dioxane.
x-aminoalkyl)-3-chlorophenylpiperazines (9,
x
x
x
6.2.6. N-{4-[4-(3-Chlorophenyl)-piperazin-1-yl]-butyl}-6-
quinolinesulfonamide (18)
The compound was prepared by the general method A in 72%
yield as yellow oil; tR = 1.19; MS calcd for [M+H]+: C23H27ClN4O2S
m/z: 458.2, found 459.3. 1H NMR (CDCl3) d (ppm) 1.63 (br s, 4H),
2.39–2.43 (t, 2H), 2.60–2.64 (m, 4H), 3.03–3.07 (m, 2H), 3.24–
3.27 (m, 4H), 6.77–6.83 (td, 1H, J = 6.2 Hz, J = 1.1 Hz), 6.86–6.87
(m, 1H), 7.15–7.2 (t, 1H) 7.63–7.68 (m, 1H), 7.82–7.89 (m, 2H),
8.16–8.19 (d, 1H), 8.55 (br s, 1H), 8.63–8.64 (d, 1H), 9.22–9.23 (d,
1H, J = 2.3 Hz). Compound 18ÁHCl mp 205.2–206.6 °C. Anal.
(C23H27ClN4O2SÁHCl) C, H, N.
6.2.1. N-{3-[4-(3-Chlorophenyl)-piperazin-1-yl]-propyl}-3-
quinolinesulfonamide (13)
The compound was prepared by the general method A in 72%
yield as yellow oil; tR = 1.21; MS calcd for [M+H]+:
C22H25ClN4O2S m/z: 444.2, found 445.2. 1H NMR (CDCl3)
d
(ppm) 1.63 (br s, 4H), 2.60–2.63 (m, 4H), 3.02–3.06 (m, 2H),
3.23–3.26 (m, 4H), 6.77–6.83 (td, 1H), 6.86–6.87 (m, 1H), 7.15–
7.19 (t, 1H) 7.63–7.68 (m, 1H), 7.82–7.89 (m, 2H), 8.16–8.19
(d, 1H), 8.55 (br s, 1H), 8.63–8.64 (d, 1H), 9.22–9.23 (d, 1H).
Compound 13ÁHCl mp 172.1–174.2 °C. Anal. (C22H25ClN4O2SÁHCl)
C, H, N.
6.2.7. N-{4-[4-(3-Chlorophenyl)-piperazin-1-yl]-butyl}-8-
quinolinesulfonamide (19)
The compound was prepared by the general method A in 72%
yield as yellow oil; tR = 1.40; MS calcd for [M+H]+: C23H27ClN4O2S
m/z: 458.2, found 459.3. 1H NMR (CDCl3) d (ppm) 1.48–1.52 (m,
4H), 2.26–2.31 (t, 2H), 2.48–2.50 (m, 4H), 2.91–2.92 (m, 2H),
3.12–3.15 (m, 4H), 6.46 (br s, 1H), 6.74–6.85 (m, 3H), 7.13–7.18
(t, 1H, J = 8.2 Hz), 7.54–7.58 (q, 1H), 7.64–7.69 (q, 1H), 8.04–8.08
(dd, 1H, J = 8.2 Hz, J = 1.5 Hz), 8.27–8.30 (d, 1H, J = 8.2 Hz,
J = 1.8 Hz), 8.43–8.46 (dd, 1H, J = 7.4 Hz, J = 1.3 Hz), 9.01–9.03 (dd,
1H, J = 4.4 Hz, J = 1.8 Hz). Compound 19ÁHCl mp 212.4–213.2 °C.
Anal. (C23H27ClN4O2SÁHCl) C, H, N.
6.2.2. N-{3-[4-(4-Chlorophenyl)-piperazin-1-yl]-propyl}-3-
quinolinesulfonamide (14)
The compound was prepared by the general method A in 77%
yield as white powder, mp 190.6–191.5 °C; tR = 1.23; MS calcd
for [M+H]+: C22H25ClN4O2S m/z: 444.2, found 445.2. 1H NMR
(CDCl3) d (ppm) 1.68–1.76 (m, 2H), 2.48–2.52 (m, 2H), 2.58–2.61
(m, 4H), 3.15–3.21 (m, 6H), 6.81–6.87 (m, 2H), 7.19–7.26 (m,
3H), 7.19–7.67 (m, 1H), 7.86–7.96 (m, 2H), 8.18–8.21 (d, J = 8.46,
1H), 8.68–8.69 (d, J = 2.31, 1H), 9.23–9.24 (d, J = 2.31, 1H).
Compound 14ÁHCl mp 186–187 °C. Anal. (C22H25ClN4O2SÁHCl) C,
H, N.
6.2.8. N-{4-[4-(4-Chlorophenyl)-piperazin-1-yl]-butyl}-3-
quinolinesulfonamide (20)
The compound was prepared by the general method A in 69%
yield as yellow oil; tR = 1.39; MS calcd for [M+H]+: C23H27ClN4O2S
m/z: 458.2, found 459.3. Compound 20ÁHCl: 1H NMR (DMSO) d
(ppm) 1.42–1.47 (m, 2H), 1.70 (br s, 2H), 2.82–2.88 (m, 2H),
2.99–3.07 (m, 4H), 3.41–3.47 (m, 2H), 3.69–3.74 (m, 4H), 6.97–
7.00 (m, 2H), 7.25–7.28 (m, 2H), 7.75–7.80 (td, 1H), 7.93–7.99
(td, 1H), 8.07–8.15 (dd, 1H), 8.24–8.26 (dd, 1H), 8.89–8.90 (dd,
1H), 9.20–9.21 (dd, 1H), 10.82 (br s, 1H). Compound 20ÁHCl Mp
190.1–192.3 °C. Anal. (C23H27ClN4O2SÁHCl) C, H, N.
6.2.3. N-{3-[4-(4-Chlorophenyl)-piperazin-1-yl]-propyl}-4-
isoquinolinesulfonamide (15)
The compound was prepared by the general method A in 72%
yield as white powder, mp 170.3–171.7 °C; tR = 1.09; MS calcd for
[M+H]+: C22H25ClN4O2S m/z: 444.2, found 445.3. 1H NMR (CDCl3)
d (ppm) 1.67–1.73 (m, 2H), 2.46–2.50 (m, 2H), 2.56–2.59 (t,
J = 4,87, 4H), 3.16–3.20 (m, 7H), 6.81–6.86 (m, 2H), 7.18–7.23 (m,
2H), 7.53–7.57 (m, 1H), 7.92–7.98 (m, 2H), 8.21–8.25 (m, 1H),
8.64 (s, 1H), 9.03–9.05 (m, 1H). Compound 15ÁHCl mp 145.2–
145.7 °C. Anal. (C22H25ClN4O2SÁHCl) C, H, N.
6.2.9. N-{4-[4-(4-Chlorophenyl)-piperazin-1-yl]-butyl}-6-
quinolinesulfonamide (21)
The compound was prepared by the general method A in 68%
yield as yellow oil; tR = 1.20; MS calcd for [M+H]+: C23H27ClN4O2S
m/z: 458.2, found 459.3. 1H NMR (CDCl3) d (ppm) 1.57–1.65 (br s,
4H), 2.37–2.42 (t, 2H), 2.59–2.63 (m, 4H), 3.02–3.06 (m, 2H),
3.16–3.20 (m, 4H), 6.79–6.85 (dt, 2H), 7.19–7.24 (dt, 2H), 7.47–
7.51 (q, 1H), 8.01–8.04 (dd, 1H), 8.09–8.12 (dd, 1H), 8.17 (s, 1H),
8.20 (s, 1H), 8.35–8.36 (d, 1H), 9.02–9.04 (dd, 1H). Compound
21ÁHCl mp 204.1–205.4 °C. Anal. (C23H27ClN4O2SÁHCl) C, H, N.
6.2.4. N-{4-[4-(3-Chlorophenyl)-piperazin-1-yl]-butyl}-3-
quinolinesulfonamide (16)
The compound was prepared by the general method A in 72%
yield as white oil, which solids upon standing; tR = 1.41; MS
calcd for [M+H]+: C23H27ClN4O2S m/z: 458.2, found 459.3. 1H
NMR (CDCl3) d (ppm) 1.63 (br s, 4H), 2.39–2.43 (t, 2H), 2.60–
2.64 (m, 4H), 3.03–3.07 (m, 2H), 3.24–3.27 (m, 4H), 6.77–6.83
(td, 1H, J = 6.2 Hz, J = 1.1 Hz), 6.86–6.87 (m, 1H), 7.15–7.2 (t,
1H) 7.63–7.68 (m, 1H), 7.82–7.89 (m, 2H), 8.16–8.19 (d, 1H),
8.55 (br s, 1H), 8.63–8.64 (d, 1H), 9.22–9.23 (d, 1H, J = 2.3 Hz).
Compound 16ÁHCl mp 183.5–185.0 °C. Anal. (C23H27ClN4O2SÁHCl)
C, H, N.
6.2.10. N-{4-[4-(4-Chlorophenyl)-piperazin-1-yl]-butyl}-7-
quinolinesulfonamide (22)
The compound was prepared by the general method A in 68%
yield as pale yellow oil; tR = 1.24; MS calcd for [M+H]+:
C
23H27ClN4O2S m/z: 458.2, found 459.3. 1H NMR (CDCl3) d (ppm)
1.60–1.62 (m, 4H), 2.38–2.42 (t, 2H), 2.60–2.64 (m, 4H), 3.04–
