Asymmetric Catalysis
A Palladium-Catalyzed Enantioselective Addition of Arylboronic
Acids to Cyclic Ketimines**
Guoqiang Yang and Wanbin Zhang*
The construction of chiral quaternary stereocenters by
asymmetric catalysis remains a challenging proposition for
chemists.[1,2] Chiral a-tertiary amines reside within a wide
assortment of potent drugs and bioactive natural products,
therefore considerable effort has been directed toward their
asymmetric synthesis.[2] Among reactions involving the con-
struction of chiral a-tertiary amines,[3–9] asymmetric addition
to ketimines is a powerful strategy. Organocatalytic and chiral
Lewis acid catalyzed nucleophilic additions to ketimines have
been reported for the synthesis of chiral a-tertiary amines.[4,5]
Another convenient method involves the transition metal
catalyzed enantioselective addition of organometallic nucle-
ophiles. Despite the great advances in asymmetric transition
metal catalyzed additions of organometallic reagents to
imines,[10,11] the development of such reactions towards the
construction of chiral a-tertiary amines has had limited
success because of the steric and electronic factors.[2,6–9]
Several reports have described the copper- or zirconium-
catalyzed asymmetric addition of allylboronates or dialkyl-
zinc reagents to ketimines.[7] Alternatively, Hayashi and co-
workers pioneered rhodium-catalyzed asymmetric additions
for several kinds of ketimines and arylboron reagents with
various functional groups.[8,9] Although valuable progress has
been made, the asymmetric addition of arylboron reagents to
ketimines to give chiral a-diaryl alkyl amines (important
components of potent drugs)[12] suffers from limited substrate
scope.[8a,b] The asymmetric addition of arylboronic acids to
ketimines, is therefore still highly desired.
carbene palladium catalysts have shown excellent catalytic
activity.[14e] However, there are still no reports concerning the
palladium-catalyzed addition of arylboronic acids to keti-
mines (including the reaction producing racemic products),
and this may be due to the less nucleophilic nature of the
arylpalladium species compared with that of the arylrhodium
species.[15] Herein, we report the first ligand- and solvent-
assisted palladium-catalyzed addition of arylboronic acids to
ketimines, thus representing a practical enantioselective
synthesis of chiral a-diaryl alkyl amines under either an air
or oxygen atmosphere.
Recently, saccharin-derived cyclic ketimines bearing aryl
or carboxy substituents have been studied in the rhodium-
catalyzed addition of arylboron reagents because of the stable
[8c,d]
=
geometry and low electron density of the C N bond.
However, the addition of boronic acids to the slightly
electron-donating, alkyl-substituted, saccharin-derived cyclic
ketimines has never been explored. Additionally the sultam
products are an intriguing class of synthetic targets.[16] Thus,
the alkyl-substituted ketimine 1 was chosen as the substrate
for our palladium-catalyzed addition reaction. Using the n-
butyl-substituted 1a as the standard substrate, reaction
conditions for the palladium-catalyzed enantioselective addi-
tion of phenylboronic acid to the cyclic ketimine were
investigated (Table 1). Initial solvent screening showed that
catalysis in MeOH provided the most promising result
(entry 1; and see the Supporting Information). This may be
due to the beneficial effect MeOH has on the rate of the
transmetalation and protonation steps of the catalytic
cycle.[13m,p] Palladium black was formed in most of the other
tested solvents. Subsequently, different chiral pyridine-oxazo-
line-type ligands were screened (entries 1–8). iPr-Pyrox
provided the best results compared to iPr-Quinox and iPr-
Pyrim (entry 1 versus entries 2 and 3). The highest enantio-
selectivity was achieved when a tBu substituent was attached
to the oxazoline ring of Pyrox (92% ee), however reaction
yield was poor because of the steric hindrance (entry 7 versus
entries 1 and 4–6). It has been reported that an electron-
deficient ligand may improve palladium-catalyzed addition
reactions.[13q,14d] Therefore, tBu-Nicox was tested and a slightly
higher ee value and yield were obtained (entry 8).[17] Consid-
ering the formation of palladium black was due to the low rate
of the addition reaction and high rate of homocoupling, two
simple methods were considered to resolve this problem. One
method involved using oxygen to oxidize the Pd0 species to
regenerate the catalyst PdII with the help of a pyridine-
oxazoline-type ligand.[3i,18] The other method involved per-
forming the catalysis in the more polar and protic solvent,
TFE, which can stabilize the intermediates and transition
state of addition by decreasing the charge density, and
Palladium catalysis is a very attractive area for both
academia and industry. Although it has been applied to
conjugate addition reactions involving arylboron reagents,[13]
the palladium-catalyzed addition of arylboronic acids to
imines has become feasible only recently.[14] Subsequently,
several asymmetric approaches have been developed for
aldimine substrates,[14c–h] and chiral bidentate N-heterocyclic
[*] Dr. G. Yang, Prof. W. Zhang
School of Chemistry and Chemical Engineering
Shanghai Jiao Tong University
800 Dongchuan Road, Shanghai 200240 (China)
E-mail: wanbin@sjtu.edu.cn
[**] We thank Prof. Tsuneo Imamoto and Dr. Masashi Sugiya for helpful
discussion. This work was partially supported by the National
Natural Science Foundation of China (Nos. 21172143 and
21232004) and Science and Technology Commission of Shanghai
Municipality (No. 09JC1407800), and Nippon Chemical Industrial
Co., Ltd. Our thanks also go to the Instrumental Analysis Center of
Shanghai Jiao Tong University.
Supporting information for this article is available on the WWW
