MHz, CDCl3) δ 9.07 (s, 2H), 4.00 (t, J = 5 Hz, 4H), 3.79 (t, J = 5 Hz,
4H); 13C NMR (125.8 MHz, CDCl3) δ 161.5, 154.8, 133.6, 66.6, 44.8;
IR (neat) 2359, 1601, 1548, 1329, 1109, 790 cm−1; HRMS (ESI) m/z
calcd. for C8H11N4O2 (M + H)+ 195.0882, found 195.0884.
2,6-Dimethoxy-3-nitrosopyridine (3g). General procedure B was
employed using potassium (2,6-dimethoxypyridin-3-yl)trifluoroborate
(245 mg, 1 mmol) and NOBF4 (120 mg, 1.03 mmol). The reaction
was complete in 30 s. The desired pure product was obtained in 72%
yield (121 mg, 0.72 mmol) as a green solid, mp 95−97 °C, after
column chromatography with CH2Cl2 as eluent: 1H NMR (500 MHz,
CDCl3) δ 6.87 (d, J = 8.5 Hz, 1H), 6.23 (d, J = 8.5 Hz, 1H), 4.37 (s,
3H), 4.11 (s, 3H); 13C NMR (125.8 MHz, CDCl3) δ 168.3, 165.6,
151.2, 122.1, 103.3, 54.8; IR (neat) 1588, 1384, 1286, 1001, 825 cm−1;
HRMS (ESI) m/z calcd. for C7H9N2O3 (M + H)+ 169.0613, found
169.0618.
(methoxycarbonyl)phenyl)borate (242 mg, 1 mmol) in CH3CN (3
mL, 0.33 M) was added NOBF4 (120 mg, 1.03 mmol, 1.03 equiv) in
one portion. After 30 s, the solvent was removed and EtOH was added
(3.5 mL, 0.3 M), followed by (NH4)2SO4 (1 g, 5 mmol, 5 equiv) and
NaBH4 (661 mg, 3 mmol, 3 equiv). The flask was then capped
(exothermic reaction) and stirred at rt for 30 min. The reaction
mixture changed from green to yellow. To the crude mixture were
added H2O (20 mL) and EtOAc (10 mL). The layers were separated,
and the aqueous layer was extracted with EtOAc (3 × 10 mL). The
combined organic layers were dried (Na2SO4), filtered, and
concentrated under reduced pressure. Purification by filtration through
a short plug of silica topped with Celite using EtOAc afforded the pure
product in 87% yield (137 mg, 0.44 mmol) as a yellow solid, mp 135−
137 °C (lit.46 135 °C): 1H NMR (500 MHz, CDCl3) δ 8.96 (d, J = 2
Hz, 1H), 8.77 (t, J = 2 Hz, 1H), 8.51 (m, 1H), 8.42 (m, 1H), 8.25 (d, J
= 7.5 Hz, 1H), 8.07 (d, J = 7.5 Hz, 1H), 7.61 (t, J = 7.5 Hz, 1H), 7.57
(t, J = 7.5 Hz, 1H), 3.99 (s, 3H), 3.96 (s, 3H); 13C NMR (125.8 MHz,
CDCl3) δ 166.5, 165.8, 148.4, 143.9, 132.9, 131.4, 131.1, 130.8, 129.6,
129.3, 129.0, 127.2, 126.7, 123.7, 52.7, 52.5; IR (neat) 1726, 1466,
1301, 1267, 1083, 753 cm−1; HRMS (ESI) m/z calcd. for C16H15N2O5
(M + H)+ 315.0981, found 315.0981.
5-Nitrosoisoquinoline (3h). General procedure B was employed
using potassium trifluoro(isoquinolin-5-yl)borate (235 mg, 1 mmol)
and NOBF4 (120 mg, 1.03 mmol). The reaction was complete in 30 s.
The desired pure product was obtained in 62% yield (NMR yield) as a
yellow solid that upon exposure to air becomes black after column
1
chromatography with EtOAc/CH2Cl2 (1:1) as eluent: H NMR (500
MHz, CDCl3) δ 9.49 (s, 1H), 9.41 (d, J = 6 Hz, 1H), 8.97 (d, J = 6 Hz,
1H), 8.40 (d, J = 8 Hz, 1H), 7.73 (t, J = 8 Hz, 1H), 7.14 (q, J = 1 and 8
Hz, 1H); 13C NMR (125.8 MHz, CDCl3) δ 157.7, 152.6, 147.2, 136.4,
131.5, 129.6, 126.2, 116.2, 114.0.
Procedure for Formation of Nitro Compounds: Synthesis of
Methyl 3-Nitrobenzoate (5b).50 Adapted from a previously
reported method.15b To a 20 mL glass microwave vial containing
potassium trifluoro(3-(methoxycarbonyl)phenyl)borate (242 mg, 1
mmol) in CH3CN (3 mL, 0.33 M) was added NOBF4 (120 mg, 1.03
mmol, 1.03 equiv) in one portion. After 30 s, the crude mixture was
filtered through a plug of silica topped with Celite using CH2Cl2, the
solvent was removed, and acetone/H2O (1:1, 5 mL) was added. To
the solution was then added Oxone (461 mg, 1.5 mmol, 1.5 equiv).
The flask was then capped and stirred at 60 °C for 2 h. The reaction
solution changed from green to yellow. To the crude mixture were
added H2O (20 mL) and EtOAc (10 mL). The layers were separated,
and the aqueous layer was extracted with EtOAc (3 × 10 mL). The
combined organic layers were dried (Na2SO4), filtered, and
concentrated under reduced pressure. Purification by filtration through
a short plug of silica topped with Celite using EtOAc afforded the pure
product in 86% yield (156 mg, 0.86 mmol) as a yellow solid, mp 75−
General Procedure C: One-Pot Nitrosation/Diels−Alder.
Adapted from a previously reported method.15a To a 20 mL glass
microwave vial containing a solution of potassium organotrifluor-
oborate (1 mmol) in CH3CN (3 mL, 0.33 M) was added 1,3-
cyclohexadiene (114 μL, 1.2 mmol, 1.2 equiv). To the mixture was
added NOBF4 (120 mg, 1.03 mmol, 1.03 equiv) in one portion. The
flask was then capped (exothermic reaction) and stirred for 2 h. To the
crude mixture were added H2O (20 mL) and EtOAc (10 mL). The
layers were separated, and the aqueous layer was extracted with EtOAc
(3 × 10 mL). The combined organic layers were dried (Na2SO4),
filtered, and concentrated under reduced pressure. The product was
purified by column chromatography using EtOAc/hexanes.
3-(Isoquinolin-5-yl)-2-oxa-3-azabicyclo[2.2.2]oct-5-ene (4c). Gen-
eral procedure C was employed using potassium trifluoro(isoquinolin-
5-yl)borate (235 mg, 1 mmol), 1,3-cyclohexadiene (114 μL, 1.2 mmol,
1.2 equiv), and NOBF4 (120 mg, 1.03 mmol). The desired pure
product was obtained in 65% yield (155 mg, 0.65 mmol) as a yellow
solid, mp 68−70 °C, after column chromatography with EtOAc/
hexanes (1:1) as eluent: 1H NMR (500 MHz, CDCl3) δ 9.19 (s, 1H),
8.51 (d, J = 6 Hz, 1H), 7.91 (d, J = 6 Hz, 1H), 7.64 (d, J = 8 Hz, 1H),
7.45 (t, J = 8 Hz, 1H), 7.37 (m, 1H), 6.75 (d, J = 2 and 6.5 Hz, 1H),
5.96 (t, J = 6.5 Hz, 1H), 4.82 (m, 1H), 4.34 (m, 1H), 2.51 (m, 1H),
2.36 (m, 1H), 1.60 (m, 1H), 1.50 (m, 1H); 13C NMR (125.8 MHz,
CDCl3) δ 152.6, 146.1, 142.5, 132.1, 129.1, 129.1, 128.9, 126.8, 123.1,
120.5, 116.0, 69.5, 56.9, 23.7, 22.0; IR (neat) 1579, 1371, 1271, 932,
838, 768 cm−1; HRMS (ESI) m/z calcd. for C15H15N2O (M + H)+
239.1184, found 239.1183.
77 °C (lit.48 77−79 °C): H NMR (500 MHz, CDCl3) δ 8.87 (t, J =
1
1.5 Hz, 1H), 8.42 (m, 1H), 8.37 (m, 1H), 7.67 (t, J = 8.5 Hz, 1H),
3.99 (s, 3H); 13C NMR (125.8 MHz, CDCl3) δ 164.9, 148.3, 135.2,
131.9, 129.6, 127.4, 124.6, 52.8; IR (neat) 3098, 1718, 1527, 1350,
1290, 1269, 1134, 720 cm−1.
One-Pot Procedure for Formation of Aniline Compounds:
Synthesis of Methyl 3-Aminobenzoate (5c).51 Adapted from a
previously reported method.52 To a 20 mL glass microwave vial
containing potassium trifluoro(3-(methoxycarbonyl)phenyl)borate
(242 mg, 1 mmol) in CH3CN (3 mL, 0.33 M) was added nitrosonium
tetrafluoroborate (120 mg, 1.03 mmol, 1.03 equiv) in one portion.
EtOH (2 mL) and SnCl2·2H2O (1.13 g, 5 mmol, 5 equiv) were added
after 30 s. The flask was then capped, and the reaction was stirred at 80
°C for 2 h. To the crude mixture was added 5% NaHCO3 (3 mL, or
enough to make the pH slightly basic, 7−9). The resulting emulsion
was filtered, and the solid was washed with H2O (10 mL) and EtOAc
(10 mL). The layers of the filtrate were separated, and the aqueous
layer was extracted with EtOAc (3 × 10 mL). The combined organic
layers were dried (Na2SO4), filtered, and concentrated under reduced
pressure. Purification by filtration through a short plug of silica topped
with Celite using EtOAc afforded the pure product as a yellow oil in
72% yield (109 mg, 0.72 mmol): 1H NMR (500 MHz, CDCl3) δ 7.42
(m, 1H), 7.35 (t, J = 2 Hz, 1H), 7.21 (t, J = 8 Hz, 1H), 6.85 (m, 1H),
3.89 (s, 3H), 3.79 (brs, 2H); 13C NMR (125.8 MHz, CDCl3) δ 167.4,
146.6, 131.3, 129.4, 119.8, 119.5, 115.9, 52.2; IR (neat) 3372, 2951,
1710, 1603, 1239, 753 cm−1; HRMS (ESI) m/z calcd. for C8H10NO2
(M + H)+ 152.0712, found 152.0713.
Methyl 3-(2-Oxa-3-azabicyclo[2.2.2]oct-5-en-3-yl)benzoate (5d).
General procedure C was employed using potassium trifluoro(3-
(methoxycarbonyl)phenyl)borate (242 mg, 1 mmol), 1,3-cyclo-
hexadiene (114 μL, 1.2 mmol, 1.2 equiv), and NOBF4 (120 mg,
1.03 mmol). The desired pure product was obtained in 82% yield (201
mg, 0.82 mmol) as a yellow solid, mp 87−89 °C, after column
1
chromatography with EtOAc/hexanes (5:1) as eluent: H NMR (500
MHz, CDCl3) δ 7.66 (s, 1H), 7.58 (m, 1H), 7.26 (t, J = 8 Hz, 1H),
7.19 (m, 1H), 6.57 (m, 1H), 6.12 (m, 1H), 4.73 (m, 1H), 4.48 (m,
1H), 3.88 (s, 3H), 2.29−2.22 (m, 2H), 1.57 (m, 1H), 1.38 (m, 1H);
13C NMR (125.8 MHz, CDCl3) δ 167.3, 152.7, 131.9, 130.5, 129.9,
128.6, 123.3, 122.1, 118.4, 69.5, 56.6, 52.2, 24.0, 21.4; IR (neat) 1719,
1439, 1270, 944, 759 cm−1; HRMS (ESI) m/z calcd. for C14H16NO3
(M + H)+ 246.1130, found 246.1130.
One-Pot Procedure for Formation of Azoxy Compound:
Synthesis of 1,2-Bis(3-(methoxycarbonyl)phenyl)diazene
Oxide (5a).48 Adapted from a previously reported method.49 To a
20 mL glass microwave vial containing potassium trifluoro(3-
4411
