Characterization: TEM images of GNPs were taken by using a JEOL
1200 EX transmission electron microscope (JEOL, Tokyo, Japan) at
80 kV. The images were acquired by using an AMT 2k CCD camera. The
dynamic diameter of the GNPs was measured by using the Dynapro
Titan system (Wyatt Technology, Santa Barbara, CA). FTIR spectra were
recorded on a Nicolet 6700 FT-IR spectrometer (Thermo Scientific). The
stock solution (3.0 mL) was dried under vacuum by using GeneVac sol-
vent evaporator. The dry samples were collected for FTIR analysis. Then
z potentials of GNPs were measured in a Malvern Nano Z Zetasizer.
GNPs were suspended in water. Each material was tested three times.
The UV/Vis absorption spectra of the GNPs were obtained with
a Varian 5000 UV/Vis spectrometry (Varian, Santa Clara, CA). All the
spectra had subtracted background with baseline correction by the ab-
sorption of deionized water. The MFGNPs used for characterization and
following cellular uptake experiments did not contain Dox.
GNPs did not show any clear signs of toxicity. However,
with the same dose of X-ray irradiation, HeLa cells treated
with MFGNP-I underwent 85% cell death and those treated
with MFGNP-II only showed 25% cell death (Figure 4).
Our data show that MFGNP-I significantly enhanced cell
death; this was caused by the combination of the therapeu-
tic drug and X-ray irradiation in FR positive cells.
In summary, we have demonstrated an accelerated synthe-
sis of a multifunctionalized drug-delivery nanosystem by
using Ugi MCR. To our knowledge, this is the first report of
the application of MCR in assembling a multifunctionalized
nanosystem. The nanosystem enhanced cancer cell targeting
selectivity and greatly improved cancer cell killing by com-
bining the effects of the therapeutic drug with those of radi-
ation. We expect that this expedited synthesis method will
break the bottleneck for preparation of a wide range of
MFNPs for biomedical applications.
Cell culture: HeLa cells were grown in Eagleꢀs minimum essential
medium (MEM, Invitrogen, IL). A549 cells were grown in RPMI 1640
(Gibco, Invitrogen, IL). Each cell culture medium was supplemented
with fetal bovine serum (FBS, 10%), penicillin (10 UmLÀ1) and strepto-
mycin (10 mgmLÀ1).
TEM experiments with cells: TEM images of cells were taken by using
a
JEOL 1200 EX transmission electron microscope (JEOL, Tokyo,
Japan) at 80 kV. The images were acquired by using an AMT 2k CCD
camera. To obtain the TEM images, both cell lines were cultured in 6-
well plates with a density of 100000 cells per well. Cultures were incubat-
ed at 378C under a humidified atmosphere with CO2 (5%). After 24 h in-
cubation, old medium was removed and fresh medium containing GNPs
(50 mgmLÀ1) was added. The cells were incubated with GNPs for 8 h and
washed three times with cold PBS to remove unbound GNPs. The cells
were fixed with glutaraldehyde (2.5%) in Na-cacodylate buffer (0.1m,
Tousimis Research Corporation) for 30 min at room temperature. The
fixed cells were collected for TEM study.
Experimental Section
Synthesis of ligand I: FA-Et-NH2 (4-1, 20 mg, 0.05 mmol) was dissolved
in MeOH (1 mL). 6-O-(4-Formylphenyl)-b-CD (2, 40 mg, 0.03 mmol) was
dissolved in deionized H2O (1 mL) and was mixed with the solution of
FA-Et-NH2. The mixture was stirred at room temperature for 1 h. Thio-
ctic acid (15 mg, 0.07 mmol) and 1-isocyanocyclohexane (10 mL,
0.07 mmol) were dissolved in MeOH (1 mL) and added to the mixture in
sequence. The resulting solution was stirred at room temperature for
2 days until the completion of the reaction. The mixture was evaporated
under vacuum and the final oil was poured into acetone (20 mL). The
precipitate was collected by centrifugation at 4000 rpm for 5 min and
washed twice with acetone. The crude product was purified by reversed-
phase flash chromatography using 20% acetonitrile/water as eluent to
give ligand I (31 mg, 43.6%). 1H NMR (400 MHz, [D6]DMSO with one
drop of [D2]H2O, 25 8C): d=9.85 (s, 1H), 8.69–8.29 (m, 1H), 7.85 (d, J=
8.5 Hz, 2H), 7.72–7.52 (m, 2H), 7.13 (d, J=8.6 Hz, 2H), 6.96 (d, J=
8.0 Hz, 1H), 6.69–6.52 (m, 1H), 5.79 (m, 1H), 4.95–4.74 (m, 7H), 4.52 (d,
J=31.1 Hz, 1H), 4.27 (d, J=40.2 Hz, 2H), 3.99 (d, J=9.6 Hz, 2H), 3.84–
3.57 (m, 29H), 3.31 (m, 16H), 3.14 (dt, J=24.6, 6.0 Hz, 3H), 2.81 (m,
2H), 2.41 (dd, J=12.7, 6.3 Hz, 2H), 2.20 (t, J=7.2 Hz, 3H), 1.87 (dq, J=
13.4, 6.5 Hz, 3H), 1.74–1.45 (m, 8H), 1.44–1.25 ppm (m, 6H).
Cellular uptake of GNPs: Both cell lines were cultured in 12-well plates
with a density of 50000 cells per well. Cultures were maintained at 378C
under a humidified atmosphere with CO2 (5%). After 24 h incubation,
the cells were washed once with cold PBS, and the solutions of GNPs
(50 mgmLÀ1) were added. The cells were incubated with GNPs for 8 h
and then washed three times with cold PBS to remove unbound GNPs.
The cells were detached with trypsin-EDTA solution (0.25% trypsin,
1 mm EDTA). The detached cells were counted by using Cellometer cell
counter Auto T4 (Nexcelom Bioscience, Lawrence, MA) and then pre-
pared for ICP-MS. Each experiment was repeated three times.
ICP-MS sample preparation and measurements: All ICP-MS measure-
ments were performed on a Varian 820. GNPs were incubated with dif-
ferent cell lines separately, as described above. After detaching and
counting the cells, the resulting cell lysate (100 mL) was digested for 4 h
at 378C by adding Aqua Regia (200 mL). The solution (50 mL) was dilut-
ed to 5.0 mL with a 209Bi internal standard (50 ppb) solution in HNO3
(1.0%) and used for ICP-MS measurements. Cellular uptake experiments
with each GNP were repeated three times, and each replicate was mea-
sured five times by ICP-MS. A series of gold standard solutions (1000,
500, 100, 50, 10, 5, and 1 ppb) with 209Bi internal standard (50 ppb) were
prepared before each measurement. The resulting calibration curve was
used to calculate the gold concentration taken up by the different cell
lines. Two injections of 209Bi internal standard solution in HNO3 were
used to wash the instrument between analyses to remove trace amounts
of gold.
Synthesis of ligand II: Ligand II was synthesized by treatment of 4-2, 6-
O-(4-formylphenyl)-b-CD (2), thioctic acid, and 1-isocyanocyclohexane
according to the procedure described above; yield 56.2%. 1H NMR
(400 MHz, [D4]MeOD, 258C): d=7.27 (d, J=8.1 Hz, 2H), 7.01 (d, J=
8.9 Hz, 2H), 5.86 (s, 1H), 4.96 (m, 7H), 4.57 (m, 7H), 4.26–4.03 (m, 2H),
3.90–3.65 (m, 23H), 3.65–3.37 (m, 15H), 3.25–2.98 (m, 3H), 2.70–2.40 (m,
3H), 1.98–1.58 (m, 8H), 1.47 (s, 9H), 1.46–1.10 ppm (m, 6H).
Synthesis of multifunctionalized GNPs: In a typical experiment, water
(1.0 mL) containing chloroauric acid (15.0 mg, 0.038 mmol) was added to
a solution of either ligand I or II (15.0 mg) in water (8.0 mL). After being
stirred for 15 min at room temperature, NaBH4 (6.0 mg, 0.15 mmol) in
water (6.0 mL) was added to the mixture dropwise. The solution turned
red immediately and was stirred for 4 h at room temperature. HCl (1N)
was added to the reaction mixture dropwise to neutralize the excess
sodium tetrahydroborate until the pH reached 7.0. To remove the free
ligand from the nanoparticles, the reaction mixture was centrifuged at
4000 rpm for 30 min with Millipore centrifugal filters with molecule
weight cut-off 10 k (50 mL tube). The colorless supernatant was decanted
and the solid was dissolved in deionized water (10 mL) and centrifuged
again at 4000 rpm for 30 min. This wash/centrifugation cycle was repeat-
ed five times. After the final washing step, the GNPs were dissolved in
Millipore water (5–10 mL) and used as stock solution. The gold concen-
tration of the stock solution was determined by ICP-MS method.
X-ray irradiation: Cells were cultured in 96-well plates with a density of
5000 cells per well. After 24 h incubation, the cells were washed once
with cold PBS. Dox and GNP–Dox solutions were added with a specified
final Dox concentration (500 nm). The cells were incubated for 8 h and
then washed three times with cold PBS to remove unbound GNPs. Fresh
medium (100 mL) was then added to the plates. The AXR Minishot 160
X-ray cabinet irradiator working with 1 mm aluminum at 160 kV and
3 mA, and yielding a mean dose rate of 27.0 RminÀ1 was used for X-ray
irradiation. The cells were exposed to X-ray irradiation with a total dose
of 5 Gy; this corresponds to an irradiation time of 18.5 min. The XTT
measurements were performed 48 h after X-ray irradiation to test cell vi-
