Y. Yokota et al. / Tetrahedron 58 (2002) 7075–7080
7079
and the solvent was removed. Purification by flash
chromatography gave the esters as oils.
Et2O (5 mL). To this was added an ,0.25 M solution of
diazomethane in Et2O (30 mL, 7.50 mmol). After 15 min,
the reaction was quenched with a few drops of AcOH until
the yellow color disappeared and then the solvent was
removed under reduced pressure.
3.3.1. 1,4-Dioxaspiro[4.4]nonane-8-azido-7-carboxylic
acid, methyl ester (13a). Rf 0.59 (7:3, EtOAc/hexanes);
1
IR (CHCl3) nmax 3020, 2956, 2890, 2108, 1735 cm21; H
NMR (300 MHz, CDCl3) d 4.19 (q, J¼8.0 Hz, 1H), 3.87–
3.95 (m, 4H), 3.74 (s, 3H), 2.86–2.92 (m, 1H), 2.24–2.34
(m, 2H), 2.06–2.11 (m, 1H), 1.87–1.92 (m, 1H); 13C NMR
(125 MHz, CDCl3) d 173.2, 113.8, 64.6, 64.5, 61.3, 52.2,
48.0, 41.7, 38.6; EI HRMS calcd for C9H13O4N3 [MþNa]
250.0804, found 250.0834.
The crude azide 15 was dissolved in MeOH (5 mL) and then
5% Pd/C (320 mg, 0.15 mmol) and (Boc)2O (0.65 g,
3.00 mmol) were added. The reaction mixture was placed
under a hydrogen atmosphere (1 atm, H2 balloon) and
stirred for 2 h. The reaction mixture was filtered through a
plug of Celite, washed with MeOH and concentrated to give
a white solid. The crude product was chromatographed to
give transpentacin derivative 16 (0.19 g, 54%) as a white
3.3.2. 1,4-Dioxaspiro[4.4]nonane-8-phenylthio-7-car-
boxylic acid, methyl ester (13b). Rf 0.65 (7:3, EtOAc/
hexanes); IR (CHCl3) nmax 3005, 2979, 2880, 1732, 1439,
1325 cm21; 1H NMR (300 MHz, CDCl3) d 77.20–7.44 (m,
5H), 3.84–3.95 (m, 5H), 3.60 (s, 3H), 2.90 (app q,
J¼9.0 Hz, 1H), 2.38–2.45 (m, 1H), 2.24–2.32 (m, 1H),
2.09–2.17 (m, 1H), 1.87–1.95 (m, 1H); 13C NMR
(125 MHz, CDCl3) d 173.7, 133.7, 132.3, 128.8, 127.2,
115.0, 64.5, 64.5, 52.0, 48.8, 46.4, 43.4, 40.2; EI HRMS
calcd for C15H18O4S4 [MþLi] 301.1086, found 301.1058.
1
solid: Rf¼0.43 (hexane/EtOAc¼7:3); H NMR (300 MHz,
CDCl3) d 4.61 (s, 1H), 4.08 (m, 1H), 3.67 (s, 3H), 2.56 (q,
J¼7.8 Hz, 1H,), 1.60–2.20 (m, 6H), 1.44 (s, 9H). The
spectral data matched that previously reported in the
literature.
3.3.6. N-(tert-Butyloxycarbonyl)-trans-(1S,2S)-2-amino-
cyclopentanecarboxylic acid methyl ester 16. Compound
(1S,2S)-16 (40 mg, 49%) was prepared from (1R,2S)-4a
(35 mg, 0.36 mmol) according to the method described
above for the preparation of the racemate: [a ]2D5¼þ39.98 (c
1.2, CHCl3); lit. [a]2D5¼þ44.68 (c 1.2, CHCl3).10
3.3.3. S-[1,4-Dioxaspiro[4.4]nonane-7-carboxylate]-N-
[(1,1-dimethylethoxy)carbonyl]-L-cysteine dimethyl
ester (13c). Rf 0.67 (7:3, EtOAc/hexanes); IR (CHCl3)
1
nmax 2979, 2874, 1732, 1710 cm21; H NMR (500 MHz,
CDCl3) d 5.35 (m, 1H), 4.51 (m, 1H), 4.21 (app q,
J¼7.5 Hz, 2H), 3.84–3.94 (m, 4H), 3.73 (s, 3H), 3.47 (app
q, J¼8.5 Hz, 1H), 2.97–3.07 (m, 2H), 2.80–2.85 (m, 1H),
2.37–2.42 (m, 1H), 2.23–2.27 (m, 1H), 2.07–2.12 (m, 1H),
1.82–1.87 (m, 1H), 1.45 (s, 9H), 1,29 (t, J¼7.0 Hz, 3H); 13C
NMR (125 MHz, CDCl3) d 173.7, 170.6, 155.5, 114.9, 80.3,
65.8, 64.6, 64.5, 61.8, 53.2, 52.2, 49.5, 44.1, 43.9, 40.2,
34.1, 28.4, 15.4, 14.2; ESI HRMS calcd for C19H31NO8S
[MþH] 434.1848, found 434.1861.
Acknowledgments
Support of this work by the NSF (CAREER Award CHE-
9624532 and 0104457), the Robert A. Welch Foundation
(A-1280), Zeneca and Pfizer is gratefully acknowledged.
D. R. is an Alfred P. Sloan Fellow and a Camille-Henry
Dreyfus Teacher-Scholar. The NSF (CHE-0077917) also
provided funds for purchase of NMR instrumentation. Dr
Shane Tichy and use of instrumentation in the
TAMU/LBMS Applications Laboratory are acknowledged.
3.3.4. 1,4-Dioxaspiro[4.4]nonane-8-dihydrocinnamoyl-7-
carboxylic acid, methyl ester (13d). IR (CHCl3) nmax
3026, 1733 cm21; 1H NMR (500 MHz, CDCl3) d 7.25–7.30
(m, 2H), 7.18–7.22 (m, 3H), 5.35 (app dt, J¼5.5, 8.0 Hz,
1H), 3.88–3.92 (m, 4H), 3.68 (s, 3H), 2.97 (ddd, J¼6.4, 9.7,
18.6 Hz, 1H), 2.93 (t, J¼7.8 Hz, 2H), 2.63 (app dt, J¼0.7,
7.5 Hz, 2H), 2.44 (ddd, J¼0.7, 8.2, 9.2 Hz, 1H), 2.22 (ddd,
J¼2.0, 8.8, 13.7 Hz, 1H), 2.08 (ddd, J¼1.1, 9.9, 13.5 Hz,
1H), 1.85 (d, J¼1.8, 5.5, 14.5 Hz, 1H); 13C NMR
(125 MHz, CDCl3) d 173.1, 172.2, 140.3, 128.4, 128.2,
126.2, 114.4, 74.3, 64.6, 64.4, 52.0, 47.9, 42.0, 38.2, 35.7,
30.8; ESI/TOF HRMS calcd for C18H22O6 [MþNa]
357.1314, found 357.1416.
References
1. For a general review of b-lactones, see: Pommier, A.; Pons,
J.-M. Synthesis 1993, 441.
2. (a) Yang, H. W.; Romo, D. Tetrahedron 1999, 55, 6403.
(b) Nelson, S. G.; Peelen, T. J.; Wan, Z. J. Am. Chem. Soc.
1999, 121, 9742. (c) Evans, D. A.; Janey, J. M. Org. Lett. 2001,
3, 2125.
3. (a) Cortez, G. S.; Tennyson, R.; Romo, D. J. Am. Chem. Soc.
2001, 123, 7945. (b) Cortez, G. S.; Oh, S.-H.; Romo, D.
Synthesis 2001, 1731.
3.3.5. N-(tert-Butyloxycarbonyl)-trans-2-aminocyclo-
pentanecarboxylic acid methyl ester 16. NaN3 (0.98 g,
15.0 mmol) was added to a solution of cis-6-oxabicyclo-
[3.2.0]heptan-7-one 4a (150 mg, 1.50 mmol) in DMF
(10 mL). The mixture was stirred at 258C for 48 h. Water
(150 mL) was added and the pH was adjusted to ,8 with
saturated aq. NaHCO3 solution, and then extracted
with EtOAc. The aqueous solution was acidified to pH¼2
with 1N HCl solution, and then extracted with Et2O. The
combined Et2O layers were dried over MgSO4, filtered, and
concentrated to give azido acid 14, which was dissolved in
4. Yang, H. W.; Romo, D. J. Org. Chem. 1999, 64, 7657.
5. Alcohol (þ)-10 was employed in the synthesis of (þ)-
aristeromycin, the enantiomer of the natural product, see:
Roberts, S. M.; Shoberu, K. A. J. Chem. Soc., Perkin Trans. 1
1991, 2605.
6. Shao, H.; Wang, S. H. H.; Lee, C.-W.; Osapay, G.; Goodman,
M. J. Org. Chem. 1995, 60, 2956.
7. Barchi, J. J.; Huang, X.; Appella, D. H.; Christianson, L. A.;
Durell, S. R.; Gellman, S. H. J. Am. Chem. Soc. 2000, 122,
2711 and references cited.
