The Journal of Organic Chemistry
Note
5H), 4.47 (ABq, J = 11.3 Hz, 2H), 4.33 (dd, J = 11.3, 6.1 Hz, 1H), 3.76
(d, J = 1.5 Hz, 3H), 3.74 (d, J = 1.5 Hz, 3H), 3.53 (td, J = 6.1,1.5 Hz,
2H), 3.12 (s, 1H), 3.05 (s, 1H), 2.79 (d, J = 6.0 Hz, 2H), 1.84−1.66
(m, 2H), 0.85 (s, 9H), 0.04 (d, J = 6.5 Hz, 6H); 13C NMR (75 MHz,
CDCl3) δ 200.6, 138.2, 128.2, 127.5, 127.4, 72.8, 66.3, 66.2, 52.9, 52.8,
51.3, 43.2, 41.5, 37.0, 25.7, 17.8; MS (ESI) m/z 445 [M + H]+; HRMS
(ESI, TOF) calcd for C21H37O6PSiNa [M + Na]+ 467.1994, found
467.1974.
(3S,9R,11S,13S,E)-1,13-Bis(benzyloxy)-3-(tert-butyldimethyl-
silyloxy)-11-methoxy-9-methylhexadec-6-en-5-one (18). To a
solution of 16 (200 mg, 0.66 mmol) in CH2Cl2 (4 mL) was added
DIBAL-H (1 M, 1.4 mL, 1.4 mmol) at −78 °C, and the mixture was
stirred for 1 h at the same temperature. Then it was quenched with 3
N aqueous NaOH solution (1.45 mL) and stirred for an additional 1 h
at 0 °C. The reaction mixture was diluted with CH2Cl2 (6 mL),
washed with water and brine, dried (Na2SO4), and concentrated in
vacuo. The aldehyde 6 (Rf = 0.3; SiO2, 10% EtOAc in hexane) thus
obtained was directly used after flash chromatography for the next
reaction.
To compound 5 (340 mg, 0.76 mmol) in anhydrous CH3CN (6
mL) were added LiCl (33 mg, 0.76 mmol) and DIPEA (1.3 mL, 7.6
mmol) sequentially at room temperature, and the reaction mixture was
stirred for 30 min. Aldehyde 6 (179 mg, 0.58 mmol) was transferred to
the reaction mixture as a solution of CH3CN under a nitrogen
atmosphere, and the resulting mixture was stirred at the same
temperature for 12 h. CH3CN was evaporated on a rotary evaporator,
and the residue was dissolved in EtOAc, washed with a saturated
aqueous solution of NH4Cl, water, and brine, dried (Na2SO4), and
concentrated in vacuo. Purification by column chromatography (SiO2,
one (19B). To a stirred solution of compound 4 (66 mg, 0.12 mmol)
in anhydrous CH2Cl2 (3 mL) was added Pd(CH3CN)4BF4 (6 mg, 10
mol %) at room temperature under an argon atmosphere, and the
mixture was stirred at room temperature for 12 h. The reaction
mixture was then diluted with Et2O and filtered through a short pad of
silica gel. The solvent was removed in vacuo to give the crude
products, which were further purified by column chromatography
(SiO2, 8% EtOAc in hexane) to afford compound 19A as a colorless oil
(32 mg, 48%) and (SiO2, 9% EtOAc in hexane) 19B (8 mg, 12%).
Analytical data for compound 19A: Rf = 0.5 (SiO2, 20% EtOAc in
hexane); [α]D24 = +3.47° (c 0.835, CHCl3); IR νmax 2923, 2861, 1718,
1
1456, 1369, 1092, 738, 629 cm−1; H NMR (500 MHz, CDCl3) δ
7.35−7.17 (m, 10H), 4.56 and 4.42 (two d, J = 12.0 Hz, 2H), 4.44 (s,
2H), 3.74 (m, 1H), 3.65−3.48 (m, 4H), 3.40 (m, 1H), 3.21 (s, 3H),
2.36−2.23 (m, 2H), 2.21−2.09 (m, 2H), 1.92−1.74 (m, 2H), 1.70−
1.22 (m, 10H), 1.17 (m, 1H), 0.97−0.82 (m, 6H); 13C NMR (75
MHz, CDCl3) δ 207.4, 139.0, 138.3, 128.4, 128.3, 127.7, 127.6, 127.4,
75.8, 75.7, 74.6, 73.8, 70.9, 66.3, 56.4, 48.4, 47.9, 43.9, 42.4, 40.2, 36.6,
36.5, 25.9, 19.7, 18.3, 14.3; MS (ESI) m/z 353 [M + Na]+; HRMS
(ESI, TOF) calcd for C32H46O5Na [M + Na]+ 533.3242, found
533.3229.
Analytical data for compound 19B: Rf = 0.45 (20% EtOAc in
hexane); [α]D24 = −6.99° (c 0.30, CHCl3); IR νmax 2923, 2855, 2362,
1
1718, 1459, 1273, 1027, 709 cm−1; H NMR (500 MHz, CDCl3) δ
7.35−7.16 (m, 10H), 4.60−4.36 (m, 4H), 4.25 (m, 1H), 4.13 (m, 1H),
3.64−3.45 (m, 3H), 3.41 (m, 1H), 3.21 (s, 3H), 2.52−2.40 (m, 2H),
2.21(dd, J = 14.0, 7.0 Hz, 1H), 2.14 (dd, J = 14.0, 6.0 Hz, 1H), 1.84
(m, 1H), 1.78−1.68 (m, 2H), 1.66−1.22 (m, 9H), 1.08 (m, 1H),
0.98−0.82 (m, 6H); 13C NMR (125 MHz, CDCl3) δ 207.6, 138.9,
138.3, 129.5, 128.3, 127.8, 127.6, 127.5, 75.9, 75.6, 73.0, 72.2, 70.9,
69.0, 66.2, 47.2, 46.9, 41.7, 40.2, 37.2, 34.6, 25.9, 22.6, 20.4, 18.5, 14.3;
MS (ESI) m/z 353 [M + Na]+; HRMS (ESI, Orbitrap) calcd for
C32H46O5Na [M + Na]+ 533.32375, found 533.32605.
5% EtOAc in hexane) afforded pure compound 18 as a colorless oil
24
(271.6 mg, 77%): Rf = 0.6 (SiO2, 10% EtOAc in hexane); [α]D
=
+21.20° (c 2.90, CHCl3); IR νmax 3030, 2953, 2927, 2859, 1669,1627,
1
1459, 1369, 1252, 1091, 836, 777, 738, 698 cm−1; H NMR (500
MHz, CDCl3) δ 7.38−7.26 (m, 10H), 6.76 (m, 1H), 6.08 (d, J = 15.9
Hz, 1H), 4.59 (d, J = 10.9 Hz, 1H), 4.52−4.43 (m, 2H), 4.38 (dt, J =
11.9, 5.9 Hz, 1H), 3.62−3.51 (m, 4H), 3.45 (m, 1H), 3.25 (s, 3H),
2.77 (dd, J = 6.9, 5.9 Hz, 1H), 2.62 (dd, J = 5.9, 4.9 Hz, 1H), 2.21 (m,
1H), 2.03 (m, 1H), 1.88−1.75 (m, 3H), 1.67−1.45 (m, 5H), 1.44−
1.35 (m, 2H), 1.20 (m, 1H), 0.98−0.90 (m, 6H), 0.85 (s, 9H), 0.03 (d,
J = 20.9 Hz, 6H); 13C NMR (75 MHz, CDCl3) δ 198.9, 146.1, 138.8,
138.4, 132.6, 128.3, 127.8, 127.5, 127.4, 75.7, 75.6, 72.8, 70.9, 66.8,
66.5, 56.4, 47.8, 41.6, 40.2, 40.1, 37.5, 36.4, 29.6, 29.1, 25.7, 19.7, 18.2,
17.9, 14.3; MS (ESI) m/z 648 [M + Na]+; HRMS (ESI, TOF) calcd
for C38H60O5SiNa [M + Na]+ 647.4107, found 647.4107.
(2R,6S)-2-((2S,4S,6S)-6-Hydroxy-4-methoxy-2-methylnonyl)-
6-(2-hydroxyethyl)dihydro-2H-pyran-4(3H)-one (3). To a sol-
ution of 19A (28 mg, 0.05 mmol) in EtOAc (8 mL) was added Pd−C
(10%), and the mixture was hydrogenated using a H2-filled balloon for
2 h. It was then filtered through a short pad of Celite, and the filter
cake was washed with EtOAc. The filtrate and washings were
combined and concentrated in vacuo. Purification by column
chromatography (SiO2, 60% EtOAc in hexane) afforded compound
3 as a colorless oil (17.1 mg, 95%): Rf = 0.5 (100% EtOAc); [α]24
=
D
+3.38° (c 1.95, CHCl3); IR νma1x 3406, 2924, 2286, 1713, 1459, 1373,
1329, 1239, 1136, 1083 cm−1; H NMR (500 MHz, CDCl3) δ 3.94−
3.76 (m, 4H), 3.71 (m, 1H), 3.54 (m, 1H), 3.37 (s, 3H), 2.41−2.21
(m, 4H), 1.92−1.66 (m, 6H), 1.53−1.32 (m, 4H), 1.31−1.18 (m, 3H),
0.94 (dd, J = 13.8, 6.9 Hz, 6H); 13C NMR (75 MHz, CDCl3) δ 206.7,
77.5, 75.9, 75.5, 68.5, 60.0, 56.8, 48.3, 47.6, 43.8, 41.2, 40.1, 39.6, 38.2,
26.7, 20.0, 18.7, 14.0; MS (ESI) m/z 331 [M + H]+, 353 [M + Na]+;
HRMS (ESI, Orbitrap) calcd for C18H35O5 [M + H]+ 331.24790,
found 331.24827.
(1R,5S,7S,9S,11R)-7-Methoxy-9-methyl-5-propyl-4,15-
dioxabicyclo[9.3.1]pentadecane-3,13-dione (2). BAIB (12.8 mg,
0.04 mmol) was added to a solution of 3 (12 mg, 0.036 mmol) and
TEMPO (0.56 mg, 0.003 mmol) in CH2Cl2 (1 mL) at 0 °C. After the
reaction mixture was stirred at room temperature for 5 h, the mixture
was diluted with CH2Cl2 (2 mL), washed with saturated aqueous
Na2S2O3 solution, and extracted with CH2Cl2. The combined organic
layers were washed with aqueous NaHCO3 solution and brine, dried
(Na2SO4), and concentrated. The crude aldehyde was immediately
used for the next reaction.
The conversion of crude aldehyde to seco acid followed by its
macrolactonization, leading to the formation of compound 2 (7 mg,
64%) from 3, was carried out according to the reported
procedure.3a,2e,f
Analytical data for compound 2: Rf = 0.45 (20% EtOAc in
hexane); [α]D24 = +17.12° (c 0.80, CHCl3); IR νmax 2923, 1726, 1250,
1091 cm−1; 1H NMR (500 MHz, CDCl3) δ 5.21 (m, 1H), 4.04 (tt, J =
10.8, 2.9 Hz, 1H), 3.58 (m, 1H), 3.50 (dt, J = 9.8, 2.9 Hz, 1H), 3.33 (s,
3H), 2.71 (dd, J = 14.8, 3.9 Hz, 1H), 2.51 (dd, J = 14.8, 9.8 Hz, 1H),
(3S,9R,11S,13S,E)-1,13-Bis(benzyloxy)-3-hydroxy-11-me-
thoxy-9-methylhexadec-6-en-5-one (4). To a solution of
compound 18 (150 mg, 0.24 mmol) in anhydrous CH3CN (1 mL)
was added HF-py complex (40%, 0.1 mL) at 0 °C. The mixture was
warmed to room temperature and stirred for 18 h. The reaction
mixture was cautiously poured into aqueous NaHCO3 solution and
extracted with EtOAc. The combined organic layers were washed with
water and brine, dried (Na2SO4), and concentrated in vacuo.
Purification by column chromatography (SiO2, 16% EtOAc in hexane)
afforded compound 4(104 mg, 80%) as a colorless oil: Rf = 0.4 (30%,
24
EtOAc in hexane); [α]D = +22.73° (c 4.35, CHCl3); IR νmax 3441,
1
2926, 2869, 2363, 1659, 1456, 1367, 1090, 739, 698 cm−1; H NMR
(500 MHz, CDCl3) δ 7.33−7.18 (m, 10H), 6.75 (m, 1H), 6.03 (d, J =
15.82 Hz, 1H), 4.56 and 4.40 (ABq, J = 11.86 Hz, 2H), 4.48 (s, 2H),
4.21 (m, 1H), 3.63 (m, 2H), 3.54 (m, 1H), 3.43−3.28 (m, 2H), 3.20
(s, 3H), 2.65 (d, J = 5.93 Hz, 2H), 2.20 (m, 1H), 2.03 (m, 1H), 1.84−
1.69 (m, 3H), 1.62−1.32 (m, 7H), 1.17 (m, 1H), 0.97−0.89 (m, 6H);
13C NMR (75 MHz, CDCl3) δ 200.2, 147.0, 139.0, 138.0, 132.0, 128.3,
128.2, 127.7, 127.6, 127.4, 75.7, 75.8, 73.1, 71.0, 67.8, 66.4, 56.4, 46.2,
41.6, 40.2, 40.1, 36.3, 36.1, 29.0, 19.8, 18.1, 14.2; MS (ESI) m/z 511
[M + H]+; HRMS (ESI, TOF) calcd for C32H46O5Na [M + Na]+
533.3242, found 533.3240.
(2R,6S)-2-((2S,4S,6S)-6-(Benzyloxy)-4-methoxy-2-methyl-
nonyl)-6-(2-(benzyloxy)ethyl)dihydro-2H-pyran-4(3H)-one
(19A) and (2S,6S)-2-((2S,4S,6S)-6-(Benzyloxy)-4-methoxy-2-
methylnonyl)-6-(2-(benzyloxy)ethyl)dihydro-2H-pyran-4(3H)-
9844
dx.doi.org/10.1021/jo301425c | J. Org. Chem. 2012, 77, 9840−9845
