Catalytic Synthesis of N-Aryl-1,5,3-dithiazocanes

Article abstract of DOI:10.1134/S107042802003029X

Abstract: An efficient procedure has been developed for the synthesis of N-aryl-1,5,3-dithiazocanes and1,1′-biphenylenebis(1,5,3-dithiazocanes) by heterocyclization of N¹,N¹,N⁷,N⁷-tetramethyl-2,6-dithiaheptane-1

Full text of DOI:10.1134/S107042802003029X

ISSN 1070-4280, Russian Journal of Organic Chemistry, 2020, Vol. 56, No. 3, pp. 544–547. © Pleiades Publishing, Ltd., 2020.
Russian Text © The Author(s), 2020, published in Zhurnal Organicheskoi Khimii, 2020, Vol. 56, No. 3, pp. 475–479.
SHORT
COMMUNICATIONS
Catalytic Synthesis of N-Aryl-1,5,3-dithiazocanes
E. B. Rakhimovaa,*, I. V. Ozdena, and A. G. Ibragimova
a Institute of Petrochemistry and Catalysis, Ufa Federal Research Center, Russian Academy of Sciences,
Ufa, 450075 Russia
*e-mail: rakhimovaelena@mail.ru
Received October 15, 2019; revised January 13, 2020; accepted January 20, 2020
Abstract—An efficient procedure has been developed for the synthesis of N-aryl-1,5,3-dithiazocanes and
1,1′-biphenylenebis(1,5,3-dithiazocanes) by heterocyclization of N1,N1,N7,N7-tetramethyl-2,6-dithiaheptane-
1,7-diamine with aromatic amines or 4,4′-methylene(or sulfonyl)dianiline in the presence of Sm(NO3)3·6H2O as
catalyst.
Keywords: catalysis, heterocyclization, dithiaheptanediamine, arylamines, 1,5,3-dithiazocanes
DOI: 10.1134/S107042802003029X
Saturated S,N-containing heterocycles are basic
structural fragments of many biologically active
compounds [1–4]. A classical method of synthesis of
N-substituted 1,5,3-dithiazocanes is based on the cy-
clocondensation of primary amines with formaldehyde
and propane-1,3-dithiol [5]. We previously demon-
strated [6] the possibility of obtaining N-substituted
1,5,3-dithiazocanes by catalytic recyclization of 1-oxa-
3,7-dithiocane with primary amines. In continuation
of our studies [7–13] in the field of synthesis of
S,N-containing heterocycles, herein we focused on the
development of an efficient method for the preparation
of practically important N-substituted 1,5,3-dithiazo-
canes. For this purpose, N1,N1,N7,N7-tetramethyl-2,6-
dithiaheptane-1,7-diamine (1) was involved in hetero-
cyclization with primary aromatic amines. Preliminary
experiments showed that the uncatalyzed reaction of
o-aminophenol with an equimolar amount of diamine
in EtOH–CHCl3 (20°C, 3 h) produced less than 15% of
2-(1,5,3-dithiazocan-3-yl)phenol (2). In order to im-
prove the yield of 2, the reaction of 1 with o-amino-
phenol was carried out in the presence of catalysts
based on transition metal and rare earth salts (Ni, Co,
Fe, Cu, Ni, Sm); the yield of 2 increased in the
following series of catalysts: NiCl2·6H2O (32%) <
CoCl2·6H2O (35%) < FeCl3·6H2O (40%) < CuCl2·
6H2O (45%) < Cp2TiCl2 (48%) < SmCl3·6H2O
(55%) < Sm(NO3)3·6H2O (58%). o- and p-Amino-
Scheme 1.
S
S
S
S
S
RNH2
R
N
N
R
R
N
or
S
2–6, 8
7
Me2N
S
S
NMe2
1
S
S
H2N–X–NH2
N
X
N
S
S
9, 10
i: 5 mol % Sm(NO3)3·6H2O, EtOH–CHCl3, room temperature, 3 h.
2, R = 2-HOC6H4 (58%); 3, R = 4-HOC6H4 (66%); 4, R = 3-HOC(O)C6H4 (63%); 5, R = 4-HOC(O)C6H4 (71%); 6, R = 4-HSC6H4
(78%); 7, R = 3-HSC6H4 (45%); 8, R = 1,5-dimethyl-3-oxo-2-phenyl-1H-pyrazol-4-yl (57%); 9, X = methylenebis(1,4-phenylene)
(65%); 10, X = sulfonylbis(1,4-phenylene) (82%).
544

CATALYTIC SYNTHESIS OF N-ARYL-1,5,3-DITHIAZOCANES
545
Heterocyclization of N1,N1,N7,N7-tetramethyl-
2,6-dithiaheptane-1,7-diamine (1) with aromatic
amines and dianilines (general procedure). A mixture
of 0.22 g (1 mmol) [or 0.44 g (2 mmol) in the reactions
with dianilines] of compound 1 [14], 10 mL of chloro-
form, and 0.022 g (0.05 mmol) of Sm(NO3)3·6H2O
was stirred for 30 min at room temperature, and
1 mmol of the corresponding amine or diamine in
10 mL of ethanol was added dropwise. The mixture
was stirred for 3 h at ~20°C and evaporated, and the
residue was purified by silica gel column chroma-
tography.
phenols reacted with an equimolar amount of 1 in
EtOH–CHCl3 in the presence of 5 mol % Sm(NO3)3·
6H2O (20°C, 3 h) to afford 2- and 4-(1,5,3-dithiazocan-
3-yl)phenols 2 and 3, respectively, in 58–66% yields
with high selectivity (Scheme 1). Increase of the
amount of the catalyst to 10 mol % did not lead to
a significant improvement of the yield. The solvent
system ethanol–chloroform was chosen taking into
account good solubility of the initial reactants therein.
The reactions of 1 with isomeric aminobenzoic acids
selectively produced 63–71% of 3- and 4-(1,5,3-di-
thiazocan-3-yl)benzoic acids 4 and 5. Likewise,
4-(1,5,3-dithiazocan-3-yl)benzenethiol (6) was ob-
tained by the heterocyclization of 1 with p-aminoben-
zenethiol under the given conditions. However, the
reaction of 1 with an equimolar amount of m-amino-
benzenethiol followed the [2+2]-cyclocondensation
pathway to form tetrathiadiazacyclohexadecane (7)
whose structure was confirmed by the presence of
the molecular ion peak with m/z 515 [M + H]+ in the
MALDI TOF/TOF mass spectrum. By reacting com-
pound 1 with a heterocyclic amine, 4-amino-1,5-
dimethyl-2-phenyl-1,2-dihydro-3H-pyrazole-3-one, we
obtained 4-(1,5,3-dithiazocan-3-yl)-substituted deriva-
tive 8 in 57% yield.
2-(1,5,3-Dithiazocan-3-yl)phenol (2). Yield 0.14 g
(58%), colorless oil, nD20 = 1.5673, Rf 0.80 (CHCl3–
EtOAc–hexane, 1:5:1). The spectral characteristics of
2 were identical to those reported in [6].
4-(1,5,3-Dithiazocan-3-yl)phenol (3). Yield 0.16 g
(66%), colorless oil, nD20 = 1.6037, Rf 0.85 (PhMe–
EtOAc–Me2CO, 4:1:1). The spectral characteristics of
3 were identical to those reported in [6].
3-(1,5,3-Dithiazocan-3-yl)benzoic acid (4). Yield
0.17 g (63%), colorless crystals, mp 189–191°C, Rf 0.5
(CHCl3–Me2CO, 1:2). 1H NMR spectrum (DMSO-d6),
δ, ppm: 1.66 br.s (2H, 7-H), 2.60 br.s (2H, 6-H, 8-H),
4.85 br.s (4H, 2-H, 4-H); 7.11 br.s (1H), 7.37 br.s
(2H), and 7.43 br.s (1H) (Harom). 13C NMR spectrum
(DMSO-d6), δC, ppm: 28.5 (C6, C8), 32.3 (C7), 55.6
(C2, C4); 114.3, 118.3, 119.4, 129.6, 131.8, 143.8
(Carom); 168.2 (C=O). Mass spectrum: m/z 270
(Irel 100%) [M + H]+. Found, %: C 53.45; H 5.58;
N 5.15; S 23.76. C12H15NO2S2. Calculated, %:
C 53.50; H 5.61; N 5.20; S 23.81.
The results obtained with aromatic amines prompted
us to study heterocyclization of 1 with diamines.
Compound 1 reacted with 4,4′-methylenedianiline and
4,4′-sulfonyldianiline at a ratio of 2:1 under the above
conditions [5 mol % Sm(NO3)3·6H2O, EtOH–CHCl3,
20°C, 3 h] to give 3,3′-[methylenebis(1,4-phenylene)]-
bis(1,5,3-dithiazocane (9) and 3,3′-[sulfonylbis(1,4-
phenylene)]bis(1,5,3-ditiazocane) (10), respectively, in
65–82% yield (Scheme 1).
4-(1,5,3-Dithiazocan-3-yl)benzoic acid (5). Yield
0.19 g (71%), colorless crystals, mp 202–204°C, Rf 0.4
(PhH–EtOH, 9:1). The spectral characteristics of 5
were identical to those reported in [6].
1
The H NMR spectra of compounds 2–6 and 8–10
characteristically showed three signals at δ 1.65–1.84,
2.54–2.72, and 3.84–4.89 ppm due to methylene
protons of the 1,5,3-dithiazocane fragment. The corre-
sponding carbon signals were located in the 13C NMR
spectra at δC 23.5–32.4, 27.9–32.3, and 55.0–57.0 ppm.
The signals were assigned using homo- and hetero-
nuclear correlation techniques. The product structure
was also confirmed by their MALDI TOF/TOF mass
spectra (positive ionization mode) which contained the
molecular ion peaks with expected m/z values.
4-(1,5,3-Dithiazocan-3-yl)benzenethiol (6). Yield
0.20 g (78%), colorless crystals, mp 273–274°C, Rf 0.8
(PhMe–EtOAc–Me2CO, 8:1:1). The spectral character-
istics of 6 were identical to those reported in [6].
3,3′-(1,5,9,13-Tetrathia-3,11-diazacyclohexa-
decane-3,11-diyl)bis(benzenethiol) (7). Yield 0.23 g
(45%), colorless oil, Rf 0.9 (PhH–EtOH, 9:1). 1H NMR
spectrum (CDCl3), δ, ppm: 1.79–1.84 m (4H, 7-H,
15-H), 2.70 br.s (8H, 6-H, 8-H, 14-H, 16-H), 3.51 br.s
(2H, SH), 4.73 br.s (8H, 2-H, 4-H, 10-H, 12-H), 6.70–
6.83 m (6H, 2′-H, 4′-H, 6′-H), 7.10–7.28 m (2H, 5′-H).
13C NMR spectrum (CDCl3), δC, ppm: 29.0 (C6, C8,
C14, C16), 32.0 (C7, C15), 56.5 (C2, C4, C10, C12), 110.9
Thus, Sm(NO3)3·6H2O-catalyzed heterocyclization
of N1,N1,N7,N7-tetramethyl-2,6-dithiaheptane-1,7-di-
amine with aromatic amines and dianilines provides
an efficient method of synthesis of N-aryl-1,5,3-dithia-
zocanes and bis(1,5,3-ditihazocanes).
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 56 No. 3 2020

RAKHIMOVA et al.
546
(C6′), 113.9 (C2′), 119.9 (C4′), 129.8 (C5′), 131.8 (C1′),
143.9 (C3′). Mass spectrum: m/z 515 (Irel 100%)
[M + H]+. Found, %: C 51.28; H 5.84; N 5.37;
S 37.30. C22H30N2S6. Calculated, %: C 51.32; H 5.87;
N 5.44; S 37.37.
was performed using KSK silica gel (100‒200 μm).
Commercially available reagents were purchased from
Sigma–Aldrich and Acros Organics.
ACKNOWLEDGMENTS
4-(1,5,3-Dithiazocan-3-yl)-1,5-dimethyl-2-
phenyl-1,2-dihydro-3H-pyrazole-3-one (8). Yield
0.19 g (57%), colorless oil, nD20 = 1.5557, Rf 0.7
The spectral and analytical data were obtained using the
facilities of the Agidel joint center (Institute of Petro-
chemistry and Catalysis, Ufa Federal Research Center,
Russian Academy of Sciences).
1
(CHCl3–Me2CO, 1:2). H NMR spectrum (CDCl3), δ,
ppm: 1.80–1.83 m (2H, 6-H, 8-H), 2.18–2.22 m
(3H, 5′-CH3), 2.57–2.68 m (4H, 6-H, 7-H, 8-H), 2.95–
2.98 m (3H, 1′-CH3), 4.35–4.39 m (4H, 2-H, 4-H);
7.22 br.s (1H), 7.32 br.s (2H), and 7.38 br.s (2H)
(Harom). 13C NMR spectrum (CDCl3), δC, ppm: 11.0
(CH3), 23.5 (C7), 29.5 (C6, C8), 36.4 (CH3), 55.5
(C2, C4), 119.1, 123.5, 126.3, 129.0, 135.0, 151.7,
163.0 (C=O). Found, %: C 57.22; H 6.26; N 12.49;
S 19.10. C16H21N3OS2. Calculated, %: C 57.28;
H 6.30; N 12.53; S 19.12.
FUNDING
This study was performed in accordance with the
research program of the Institute of Petrochemistry and
Catalysis (Ufa Federal Research Center, Russian Academy
of Sciences; project no. AAAA-A19-119022290010-9 for
2019–2021 “Metal Complex and Heterogeneous Catalysis
in the Synthesis of Macroheterocycles and Heteroatom Com-
pounds”), as well as under financial support by the Ministry
of Science and Education of the Russian Federation (project
no. 2019-05-595-000-058).
3,3′-[Methylenebis(1,4-phenylene)]bis(1,5,3-di-
thiazocane) (9). Yield 0.30 g (65%), colorless crystals,
mp 175–176°C, Rf 0.9 (PhMe–EtOAc–Me2CO, 8:1:1).
The spectral characteristics of 9 were identical to those
reported in [6].
CONFLICT OF INTEREST
The authors declare the absence of conflict of interest.
REFERENCES
3,3′-[Sulfonylbis(1,4-phenylene)]bis(1,5,3-dithia-
zocane) (10). Yield 0.42 g (82%), colorless crystals,
mp 101–103°C, Rf 0.5 (CHCl3–Me2CO, 1:2). 13C NMR
spectrum (DMSO-d6), δ, ppm: 1.65 br.s (4H, 7-H),
2.60 br.s (8H, 6-H, 8-H), 4.86 br.s (8H, 2-H, 4-H),
6.70–6.75 m and 7.56–7.63 m (4H each, Harom).
13C NMR spectrum (DMSO-d6), δC, ppm: 28.5
(C6, C8), 32.3 (C7), 55.4 (C2, C4); 113.7, 128.3, 147.2,
151.0 (Carom). Found, %: C 51.48; H 5.47; N 5.40;
S 31.22. C22H28N2O2S5. Calculated, %: C 51.53;
H 5.50; N 5.46; S 31.27.
1. Pozharskii, A.F., Soldatenkov, A.T., and Katritzky, A.R.,
Heterocycles in Life and Society, Chichester: Wiley, 2011,
2nd ed.
2. Katritzky, A.R. and Pozharskii, A.F., Handbook of
Heterocyclic Chemistry, Amsterdam: Elsevier, 2000,
2nd ed.
3. Mashkovskii, M.D., Lekarstvennye sredstva (Medicines),
Moscow: Novaya Volna, 2008, 15th ed., p. 1119.
4. Bioactive Heterocycles: Synthesis and Biological
Evaluation, Ameta, K.L., Pawar, R.P., and Domb, A.J.,
New York: Nova Biomedical, 2013.
5. Akhmetova, V.R. and Rakhimova, E.B., Russ. J. Org.
Chem., 2014, vol. 50, p. 1711.
1
The H and 13C NMR spectra were recorded on
a Bruker Avance 500 spectrometer at 500.17 and
125.78 MHz, respectively, using tetramethylsilane as
internal standard. The mass spectra (MALDI
TOF/TOF, positive ion detection) were recorded on
a Bruker AutoflexTM III Smartbeam instrument using
2,5-dihydroxybenzoic acid as matrix. The elemental
analyses were obtained on a Carlo Erba 1106 analyzer.
The melting points were measured with a PHMK
80/2617 melting point apparatus. The refractive indices
(nD20) were determined on an IRF-22 refractometer.
The progress of reactions was monitored by TLC on
Sorbfil PTSKh-AF-V plates; spots were visualized by
treatment with iodine vapor. Column chromatography
https://doi.org/10.1134/S107042801412001X
6. Rakhimova, E.B., Vasilieva, I.V., Khalilov, L.M.,
Ibragimov, A.G., and Dzhemilev, U.M., Chem. Heterocycl.
Compd., 2012, vol. 48, p. 1050.
https://doi.org/10.1007/s10593-012-1098-8
7. Niatshina, Z.T., Murzakova, N.N., Vasilieva, I.V.,
Rakhimova, E.B., Akhmetova, V.R., and Ibragimov, A.G.,
Arkivoc, 2011, vol. 2011, part (viii), p. 141.
https://doi.org/10.3998/ark.5550190.0012.810
8. Murzakova, N.N., Rakhimova, E.B., Vasilieva, I.V.,
Prokof’yev, K.I., Ibragimov, A.G., and Dzhemilev, U.M.,
Tetrahedron Lett., 2011, vol. 52, p. 4090.
https://doi.org/10.1016/j.tetlet.2011.05.097
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 56 No. 3 2020

CATALYTIC SYNTHESIS OF N-ARYL-1,5,3-DITHIAZOCANES
547
9. Rakhimova, E.B., Vasilieva, I.V., Khalilov, L.M.,
Ibragimov, A.G., and Dzhemilev, U.M., Russ. J. Org.
Chem., 2011, vol. 47, p. 1300.
12. Rakhimova, E.B., Ozden, I.V., Ibragimov, A.G., and
Dzhemilev, U.M., Russ. J. Org. Chem., 2016, vol. 52,
p. 571.
https://doi.org/10.1134/S1070428011090065
https://doi.org/10.1134/S1070428016040175
10. Rakhimova, E.B., Meshcheryakova, E.S., Khali-
lov, L.M., Ibragimov, A.G., and Dzhemilev, U.M., Russ.
J. Org. Chem., 2014, vol. 50, p. 1613.
13. Rakhimova, E.B., Ozden, I.V., and Ibragimov, A.G.,
Russ. J. Org. Chem., 2018, vol. 54, p. 961.
https://doi.org/10.1134/S1070428018070011
https://doi.org/10.1134/S1070428014110128
14. Khairullina, R.R., Akmanov, B.F., Tyumkina, T.V.,
Kunakova, R.V., and Ibragimov, A.G., Russ. J. Org.
Chem., 2012, vol. 48, p. 175.
11. Rakhimova, E.B., Ozden, I.V., Meshcheryakova, E.S.,
Khalilov, L.M., and Ibragimov, A.G., Russ. J. Org.
Chem., 2015, vol. 51, p. 1788.
https://doi.org/10.1134/S1070428015120222
https://doi.org/10.1134/S1070428012020042
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 56 No. 3 2020
