Exploring Diverse-Ring Analogues on Combretastatin
A4 (CA-4) Olefin as Microtubule-Targeting Agents
Ming-Yu Song 1,†, Qiu-Rui He 1,†, Yi-Lin Wang 2, Hao-Ran Wang 2, Tian-Cheng Jiang 3,
Jiang-Jiang Tang 1,* and Jin-Ming Gao 1
1
Shaanxi Key Laboratory of Natural Products & Chemical Biology, College of Chemistry & Pharmacy,
Northwest A&F University, Yangling 712100, China; mingyusong@nwsuaf.edu.cn (M.-Y.S.);
heqiurui@nwsuaf.edu.cn (Q.-R.H.); jinminggao@nwsuaf.edu.cn (J.-M.G.)
College of Innovation and Experiment, Northwest A&F University, Yangling 712100, China;
2
yilinwang1997@hotmail.com (Y.-L.W.); 2015014887@nwafu.edu.cn (H.-R.W.)
College of Food Science and Engeering, Northwest A&F University, Yangling 712100, China;
3
jtc990329@163.com
*
Correspondence: tangjiang11@nwsuaf.edu.cn; Tel.: +86-2987-09-2662
†
These authors contributed equally to this work.
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 15 February 2020; Accepted: 4 March 2020; Published: 6 March 2020
Abstract: Combretastatin-4 (CA-4) as a tubulin polymerization inhibitor draws extensive attentions.
However, due to its weak stability of cis-olefin and poor metabolic stability, structure modifications
on cis-configuration are being performed. In this work, we constructed a series of novel CA-4
analogues with linkers on olefin containing diphenylethanone, cis-locked dihydrofuran, α-substituted
diphenylethanone, cyclobutane and cyclohexane on its cis-olefin. Cytotoxic activity of all analogues
was measured by an SRB assay. Among them, compound 6b, a by-product in the preparation of
diphenylethanone analogues, was found to be the most potent cytotoxic agents against HepG2 cells
with IC50 values of less than 0.5 µM. The two isomers of 6b induced cellular apoptosis tested by
Annexin V-FITC and propidium iodide (PI) double staining, arrested cells in the G2/M phase by PI
staining analysis, and disrupted microtubule network by immunohistochemistry study in HepG2
cells. Moreover, 6b-(E) displayed a dose-dependent inhibition effect for tubulin assembly in in vitro
tubulin polymerization assay. In addition, molecular docking studies showed that two isomers of 6b
could bind efficiently at colchicine binding site of tubulin similar to CA-4.
Keywords: combretastatin-4; tubulin polymerization; diphenylethanone; cis-locked dihydrofuran;
α-substituted diphenylethanone; cyclobutane; cyclohexane
1. Introduction
The natural product combretastatin A-4 (CA-4, Figure 1) was first isolated from the South African
tree Combretum caffrum in 1989 [
the polymerization of tubulin with the colchicine binding site [
such as CA-4P (fosbretabulin and zybrestat) [ ] and AVE8062 (ombrabulin) [
trials for the treatment of anaplastic thyroid cancer and other solid tumors in both USA and Europe [
1
,
2
] and was serendipitously discovered in 1998 by strongly blocking
]. CA-4 and its water-soluble prodrugs
] have entered clinical
].
3
4
5
6
Due to its small molecular weight and simple structure, an impressive number of synthetic research
was carried out over the past decades [7–10].
The structure–activity relationships (SARs) have made clearly important features of maintaining
the tubulin interaction for CA-4. The presence of 3,4,5-trimethoxy groups at ring-A, 4‘-methoxy
group at ring-B and cis-configuration of olefin are the indispensability for inhibiting tubulin
assembly [11]. Nevertheless, the Z-restricted configuration can rapidly convert into 100-fold less
Int. J. Mol. Sci. 2020, 21, 1817; doi:10.3390/ijms21051817
www.mdpi.com/journal/ijms

Int. J. Mol. Sci. 2020, 21, 1817
2 of 17
active trans-isomerization under the conditions of suffering from heat, light and protic media [12].
Meanwhile, the poor metabolic stability caused by the olefinic bridge and the weak water solubility
of CA-4 resulted in restrictions for its exploitation [13]. Thus, an extensive focus of research was
directed towards the rational modifications of the unstable olefinic bond as the main pursued strategy.
Various olefinic linkers including silicon [14], butadiene [15], cyclopropane [16], cyclopropyl [17],
chiral-lactam [18], furan [19], furazan [20], imidazole [21], 2,3-diarylthiophene [22], isoxazole and
terphenyl [23], triazoles [24,25], thiazole [26,27] and 1,2,4-triazolo-4,3-b-pyridazines [28] has unveiled
novel agents endowed with cytotoxic activity.
MeO
A
MeO
MeO
OH
CA-4
CA-4P
X = OH
X = OPO3Na2
MeO
B
OMe
OMe
AVE8062 X = NH-serine HCl
X
OMe
OMe
iso
CA-4
This work
Previous work
R2
R
O
O
HO
MeO
MeO
MeO
R1
X
MeO
OMe
O
*
MeO
MeO
OH
OMe
OMe
OH
OTBS
OMe
OMe
OMe
O
MeO
X = C, N
Inhibit tubulin polymerization
MeO
OH
MeO
MeO
R
MeO
OMe
OMe
OMe
OH
OMe
Figure 1. The structures of CA-4 and synthetic prodrugs, isoCA-4 and designed analogues.
Isocombretastatin A-4 (isoCA-4, Figure 1), an unexpectedly synthesized isomer of CA-4 found
by Alami [29], exhibited a very strong inhibition on cancer cell growth similar to that of CA-4.
The synthetic method is simple without the control of cis-configuration [30,31]. The Alami group have
completed plentiful studies on the modification of 1,1-diaryl double bond scaffold using naphthenic [32],
naphthalene [33], arylchromenes [34], azaisoerianin [35], arylbenzoxepins [36], etc. In our previous
works [37], dihydrofuran and dihydroisoxazole analogues of isoCA-4 were prepared through [3+2]
reactions and could inhibit tubulin polymerization.
In our endeavor aiming at finding novel potential rigid analogues of CA-4 and isoCA-4,
we hypothesized that the replacement of the unstable olefinic bond of CA-4 with cis-locked dihydrofuran,
α-substituted, cyclobutane and cyclohexane nucleuses (Figure 1) could be a good strategy to unravel
a novel class of antitubulin agents. Indeed, different number rings are widely used as a molecular
scaffold in natural products and medicinal chemistry because of their favorable pharmacokinetic
features and their ability to act as a privileged structure when properly decorated. In this work,
we present the synthesis through the modification of olefin scaffold with diphenylethanone, cis-locked
dihydrofuran, α-substituted diphenylethanone, cyclobutane and cyclohexane. Subsequently, their
cytotoxic activity was evaluated against HepG2 cells, and the most potent cytotoxic compound was
selected to carry out mechanism studies including apoptosis, cell cycle analysis, immunohistochemistry,
tubulin polymerization assay and molecular docking.

Int. J. Mol. Sci. 2020, 21, 1817
3 of 17
2. Results and Discussion
2.1. Chemistry
5-bromo-2-methoxyphenol was firstly converted into the key intermediate
4
by four steps in total
65% yield referred to our previous report [37]. Subsequently, 4 was oxidized with rearrangement of
olefinic bond through iodobenzene acetate (PhI(OAc)2) to afford the key compound 5a. The synthetic
conditions were optimized in Scheme 1. In the synthesis of 5a, NaHSO4 was used as the initial activator
of PhI(OAc)2. However, the conversion of
as shown in entry 1 and 2, and the yield of 5a was only about 10% when the ratio of
NaHSO4 was 1:1:1. As the ratio of PhI(OAc)2 and NaHSO4 continued to increase, the conversion rate
of was indeed greatly improved when the reaction adopted MeCN-H2O (5:1) as the solvent in entry 3
and 4. When both of PhI(OAc)2 and NaHSO4 reached 2 equivalent (entry 5), could react completely,
but the yield of 5a was still only about 10% or even lower. After the NaHSO4 was replaced with H2SO4
(50% methanol solution), the reaction was completed with a 61% yield at -20 ◦C, while the ratio of
4
was always very low in the presence or absence of solvent
4, PhI(OAc)2 and
4
4
4
,
PhI(OAc)2, and H2SO4 was 1:1.1:1.1 in entry 6. Accidentally, a by-product 6a was given under the
condition of entry 6 with 30% yield, and 6b was prepared from 6a using tetrabutyl ammonium fluoride
(TBAF) to remove the protection group in 95% yield. To the formation of the by-product 6a, MeOH may
attack the intermediate of PhI(OAc)2 and H2SO4 in reaction kinetics and through following elimination
reaction to trigger the formation of 6a. The possible reaction mechanism was shown as Scheme S1 in
the Supplementary Material. Furthermore, the HPLC analysis and 13C NMR spectrum of 6b revealed
that the ratio of (Z)/(E) isomers was about 1:1. To explore biological activities of different isomers,
6b-(Z) and 6b-(E) were separated by preparative HPLC. The assignment of the olefin geometry of
6b-(Z) was determined using NOESY NMR experiments. Specifically, NOESY signals of 6b-(Z) were
readily apparent between the proton of phenyl ring and the proton attached to the olefin in Figure 2
(see Supplementary data).
1
Entry
Activator
NaHSO4
NaHSO4
NaHSO4
NaHSO4
NaHSO4
Equivalent
1: 1: 1
Solvent
free
MeCN-H2O
MeCN-H2O
MeCN-H2O
MeCN
Conversion (%) Yield (%) of 5a
1
2
3
4
5
30
25
10
8
12
10
< 5
61
2
1: 1: 1
1: 1.3: 1.3
1: 1.5: 1.5
1: 2: 2
88
90
100
100
3
6
1
H2SO4
1: 1.1: 1.1
MeOH
2
3
Equivalent represents the ratio of 4: PhI(OAc)2: activator; MeCN-H2O is 5:1 (v/v); H2SO4 is 50%
methanol solution; 6a was obtained under the condition of the Entry 6 with 30% yield. 6b was
4
prepared from 6a in 95% yield.
Scheme 1. Synthesis of compounds 5a, 5b and 6a, 6b. Synthetic conditions optimization of 5a. i) TBAF,
THF, 30 min.

Int. J. Mol. Sci. 2020, 21, 1817
4 of 17
Figure 2. 6b-(Z) and 6b-(E) after HPLC preparation. Selected NOE correlations of 6b-(Z).
With 5a in hands, dihydrofuran analogues were prepared by [3 + 2] cycloaddition in Scheme 2.
A free-radical reaction between 5a and conjugated diolefinic compounds was catalyzed by a
single-electron oxidant Cu(OAc)2, and following by TBAF to remove the TBS group of the phenolic
hydroxyl to provide the dihydrofuran 7a and 7b. In this free-radical reaction, Mn(OAc)3 as the initial
oxidant gave extremely low yield, perhaps the single-electron oxidation energy of Mn (III) (1.5 V)
could still be too high for this reaction. Thus, Cu (II) with one-electron oxidation energy of only 0.16 V
was employed for this reaction and the conditions were optimized by using Cu(OAc)2 as the catalyst
and the acetophenone as the conjugated olefin. It was found that when the ratio of 5a, Cu(OAc)2 and
acetophenone was 1:3:3, 5a could react completely in 12 h. However, a large amount of by-products
would appear after 4 h. Therefore, the optimal reaction time should be 4 h, while the conversion rate of
5a was about 70%, and the yield of 7a was 65%. Using this condition, dihydrofuran compound 7b was
also synthesized using isoprene, and the two steps yield was 45%.
However, under the above condition, an addition reaction between 5a and pentenone occurred to
give compound 8a with a conversion yield of 74% (Scheme 2). The reason that 8a did not cyclize into a
dihydrofuran ring might be the electron-withdrawing effect of the carbonyl group. 8b was afforded
by deprotection of the TBS group similar to the above method. Next, the structure of 1,5-dione of
8a gave us a new idea to synthesize cyclobutane and cyclohexane analogues of CA-4 through Aldol
condensation. For example, cyclobutane analogue
and TsCl at −78 ◦C in a 40% yield (Scheme 2).
9
was prepared under the conditions of LiHMDS
OMe
O
O
MeO
MeO
OTBS
i), ii)
MeO
MeO
5a
OMe
O
OMe
OH
OMe
7a (65%)
i)
OMe
OR
O
O
MeO
MeO
MeO
MeO
*
OMe
OMe
OH
O
OMe
8a (R = TBS) (74%)
8b (R = H) (95%)
7b (45%)
ii)
O
HO
MeO
MeO
iii)
8a
OMe
OTBS
OMe
9 (40%)
Scheme 2. Synthesis of 7a, 7b, 8a, 8b and
0.5 h; iii) LiHMDS, TsCl, −78 ◦C.
9
. Condition: i) Cu(OAc)2, DCE, 110 ◦C, 4 h; ii) TBAF, THF,

Int. J. Mol. Sci. 2020, 21, 1817
5 of 17
For synthesis of cyclohexane analogues, the Aldol condensation of 8a was not smooth due to the
not very stable TBS protecting group under a strong base condition. On the one hand, strong alkalinity
can promote the reaction to proceed forward. However, on the other hand, it would cause the removal
of TBS under the action of too strong bases, then reduce the number of substrate and push the reverse
reaction. Therefore, it is very important to choose a base with moderate alkalinity.
The condition optimization of Aldol condensation is shown in Scheme 3. At first, the reaction
was performed with KOH in methanol under reflux, 8a was completely converted quickly, but there
was no expected product 10a or 8b in entry 1. Then, three inorganic bases: KOH, NaOH and LiOH
(entry 2-4) were selected and methanol was employed as the solvent at 0 ◦C. After the three bases were
added, the reaction occurred immediately, and 10a was obtained in the beginning period. However,
10 min later, the reactions of KOH and NaOH began to generate 8b. After another 20 min, all 10a
and 8a were turned into 8b. However, the reaction of LiOH (entry 4) started to generate 8b after
30 min, while the conversion yield of 10a is 65%. Under the action of K2CO3 (1 eq, entry 5), 8a could
rapidly generate a mixture of 10a, 8b and a little deprotected product of 10a at room temperature.
Yet, when the temperature fell to 0 ◦C, 8a was completely unreactive even increasing the equivalent
of K2CO3 to 10 eq (entry 6). NaOMe also could not make 8a react in solvent of benzene in entry 8.
In organic bases, 1,8-diazabicyclo[5.4.0]undec-7-ene (DBU) could make 8a to turn into 8b within 30 min
at room temperature, and lithium diisopropylamide (LDA) could give a 10% yield of 10a at
78 ◦C,
−
in entry 9 and 10, respectively. To sum up, LiOH, 0 ◦C, and 30 min were the optimized conditions
with a conversion yield of 65% for 10a. After 10a was deprotected by TBAF, a cyclohexane-based CA-4
analogue 10b was obtained (Scheme 3).
Yield (%)
Temperature
Time
(min)
30
30
30
30
30
60
60
Entry
Base
Equivalent Solvent
(°C)
90
0
0
0
rt
0
0
rt
rt
-78
10a
8b
1
2
3
4
5
6
7
8
9
KOH
KOH
NaOH
LiOH
K2CO3
K2CO3
Na2CO3
NaOMe
DBU
10
10
10
10
1
MeOH
MeOH
MeOH
MeOH
MeOH
MeOH
MeOH
Benzene
CH3CN
THF
-
-
-
65
20
-
> 95
> 95
-
15
10
10
10
5
No reaction
No reaction
No reaction
45
30
60
-
10
> 95
-
10
LDA
2
Scheme 3. Synthetic conditions optimization of compound 10a.
In order to enhance the polarity and water solubility of 10b, carbonyl group of 10a was reduced
by sodium borohydride (NaBH4) to a HO group (Scheme 4). After deprotection of the TBS group by
TBAF, 11 was obtained in two steps with a 66% yield. Moreover, LiHMDS was employed to remove
the hydroxyl hydrogen of 10a, and then p-toluenesulfonyl chloride (TsCl) and the DMAP-Et3N system
were used to eliminate the sulfonyl group. Finally, the TBS group was deprotected by TBAF to give

Int. J. Mol. Sci. 2020, 21, 1817
6 of 17
another cyclohexane analogue 12 (Scheme 4). The total yield of the three steps was 28%. It was noted
that 12 was unable to react under the action of NaBH4 to afford 11.
Scheme 4. Synthesis of 11 and 12. Condition: (a
) i) NaBH4, DCE, 0 ◦C, 1 h; ii) TBAF, THF, 30 min and
(b) i) LiHMDS, TsCl, -78 ◦C; ii) Et3N, DMAP, DMF, 80 ◦C and iii) TBAF, THF, 30 min.
2.2. Biological Activity
New synthesized CA-4 analogues were in vitro screened for anticancer activity against HepG-2
(human liver cancer cell line) with CA-4 and isoCA-4 as reference drugs using the sulforhodamine
B (SRB) assay [38]. The IC50 values (the concentration to cause 50% inhibition of cell viability) were
summarized in Table 1. It could be seen that these CA-4 analogues diphenylethanone 5b, cis-locked
dihydrofuran analogues 7a 7b
cyclohexane analogues 10a 10b and 11 showed weak cytotoxic activity with IC50 values over 10
Another cyclohexane analogue 12 exhibited a good cytotoxic activity with IC50 of 3.67 M, but with far
less than IC50 of CA-4 and isoCA-4 (0.013 M and 0.017 M, respectively). These results suggested
,
α
-substituted diphenylethanones 8a
,
8b, cyclobutane analogue
9,
,
µM.
µ
µ
µ
that introductions of ethanone, four or five or six-membered rings on the cis-double bond of CA-4
were not a good synthetic strategy for optimizing anticancer activity. However, it was worth to note
that isoCA-4 analogue 6b displayed strongest activity with IC50 of < 0.5
µM among all compounds.
Notably, the IC50 results of 6b-(Z) with IC50 of 0.30 M and 6b-(E) with IC50 of 0.23
µ
µM on HepG2
cells indicated no obvious gap in cytotoxic activity between cis–trans isomers.
Table 1. Cytotoxic activities (IC50) of compounds against HepG2 cells.
Compd
IC50 (µM) 1
Compd
IC50 (µM)
5b
6b-(Z)
6b-(E)
7a
> 10
0.30 ± 0.05
0.23 ± 0.07
> 10
9
10a
10b
> 10
> 10
> 10
11
> 10
7b
8a
8b
> 10
> 10
> 10
12
CA-4
isoCA-4
3.67± 0.16
0.013 ± 0.003
0.017 ± 0.002
1
The IC50 values represent the concentration that causes 50% inhibition of cell viability measured by SRB assay.
Cells were treated with the compounds for 48 h. All data (mean
HepG-2: human liver cancer cells.
±
SD) are the average of three determinations.
Apoptosis induction is characteristic of many known anticancer agents. To determine whether the
inhibition of 6b-(Z) and 6b-(E) on cell growth was related to cell apoptosis, a flow cytometric analysis
by staining cells with Annexin V-FITC and propidium iodide (PI) was performed on HepG-2 cells.
The result showed that treatment with 0.05
late apoptotic cells, respectively (Figure 3). Similar apoptosis induced by CA-4 has been reported
previously [ ]. After treatment with compounds 6b-(Z) and 6b-(E) at 0.3 M, the early and late
µM CA-4 for 48 h induced 26.5% and 13.4% early and
3
µ
apoptosis rates were significantly increased from 5.0% and 3.5% (for control group) to 19.2% and 16.1%
(for 6b-(Z) group), and 24.1% and 19.4% (for 6b-(E) group), respectively. The results indicated that
both analogues could cause cellular apoptosis.

Int. J. Mol. Sci. 2020, 21, 1817
7 of 17
Figure 3. Induction of apoptosis by 6b-(Z), 6b-(E) and CA-4 at the indicated concentrations on HepG-2
cells. After treatment for 48 h, the cells were stained with PI and Annexin V-FITC and viable, apoptotic
and necrotic cells were analyzed by flow cytometry. Cells in lower left quadrants are alive, in the lower
right quadrants are in early apoptosis, in the upper right quadrants are in late apoptosis and in the
upper left quadrants are necrotic. Percentage of the total signal within the quadrant is indicated. Each
experiment was performed in triplicate.
A striking character of anticancer activity of CA-4 and isoCA-4 is to induce cell cycle arrest at the
G2/M phase [3,39]. To confirm whether the biological mechanism of these two isomers was caused
by cell cycle accumulation at a G2/M phase, the cell cycle distribution of HepG2 cells was evaluated
with PI staining by flow cytometry [40]. As shown in Figure 4, following treatment with 6b-(Z) and
6b-(E) for 24 h at concentrations of 0.3 µM and 1.0 µM, the percentages of cells in the G2/M phase at
different concentrations were 18.5% and 89.8% for 6b-(Z) and 12.8% and 88.5% for 6b-(E), respectively,
as compared to 12.2% in control cells, suggesting that these two isomers caused an obvious G2/M
arrest with a similar mechanism to that of CA-4.
Figure 4. Analysis of cell cycle distribution in HepG-2 cells by flow cytometry. The cultured cells
were treated with 6b-(Z)
, 6b-(E) and CA-4 at the indicated concentrations for 24 h, then harvested,
and analyzed using a FACS Calibur (BD Biosciences).

Int. J. Mol. Sci. 2020, 21, 1817
8 of 17
To visualize the tubulin polymerization inhibition of these compounds in cells,
immunofluorescence analysis was investigated on microtubule network in HepG2 cells. As shown in
Figure 5, control cells displayed a normal distribution of microtubular network with a slim and fibrous
shape. However, cells treated with CA-4 and 6b-(E) showed a disrupted microtubule network (green)
becoming short and wrapped around cell nucleus, demonstrating that 6b-(E) could inhibit the cellular
tubulin polymerization.
Figure 5. Immunofluorescence effects of 6b-(E) (0.3
polymerization in HepG-2 cells. After treatment for 48 h, the cells were stained with DAPI (blue, left
panel) for nucleus and an anti- -tubulin antibody (TRITC, green, middle panel) for microtubules.
µM) and CA-4 (0.02 µM) on inhibition of tubulin
α
The right panel represents a merge of the corresponding left and middle panels. Images were acquired
with an Olympus fluorescence microscope using a 20× objective.
Furthermore, to investigate whether there is such an interaction of the active analogues with
tubulin responsible for the activity, tubulin polymerization in vitro was measured for 50 min at 37 ◦C
with paclitaxel as a promoting-assembly control and CA-4 as a depolymerization control. As shown
in Figure 6, paclitaxel promoted the assembly of tubulin, while CA-4 inhibited it well. Compound
6b-(E) displayed an inhibition effect for tubulin polymerization in a dose-dependent manner. From
these results, it could be concluded that 6b-(E) could inhibit the assembly of tubulin, and the cellular
activities of 6b-(E) might be generated from this interaction with tubulin.
Figure 6. Effects of 6b-(E) on tubulin polymerization in vitro. Tubulin (10 mg/mL) was incubated
M) for 50 min at 37 ◦C. Paclitaxel (3
with 6g-(E) (5, 20 and 40 µ µM) and CA-4 (3 µM) were used as
positive controls. The fluorescence intensity was monitored every minute for characterization of tubulin
polymerization at a 360 nm excitation wavelength and 460 nm emission wavelength.

Int. J. Mol. Sci. 2020, 21, 1817
9 of 17
2.3. Molecular Docking
To elucidate the binding model of the analogues 6b-(Z) and 6b-(E) with the tubulin colchicine
binding site, the X-ray crystal structure (PDB:1SA0) was employed for performing the docking studies
using the Surflex-Dock program in the Sybyl-X 2.0 software. Figure 7a,b exhibits the docking studies of
6b-(Z) and 6b-(E) with the tubulin colchicine binding site of tubulin, respectively. Figure 7a shows that
the meta-methoxy groups on alkene of 6b-(E) formed a hydrogen bond with the key amino acid Ser178
about 1.96 Å bond distance, and the oxygen atoms of the hydroxyl groups on ring-B of 6b-(Z) formed a
hydrogen bond with the key amino acid Cys241 about 2.35 Å. Figure 7b exhibits that the meta-methoxy
groups on ring-A of 6b-(E) formed a hydrogen bond with the key amino acid Cys241 about 1.93 Å,
while the oxygen atoms of the hydroxyl groups on ring-B formed a hydrogen bond with the key amino
acid Thr193 about 2.06 Å. From the simulated bond distance results, it can be concluded that 6b-(E)
should have a better biological activity than 6b-(Z), consisting with cytotoxicity test results. These
docking studies suggested that the binding site of 6b-(Z) and 6b-(E) might be the tubulin colchicine
binding site.
(a)
(b)
Figure 7. Molecular docking simulations obtained at lowest energy conformation, highlighting potential
hydrogen contacts of ( 6b-(Z) and (b) 6b-(E) with the colchicine’s binding site of tubulin (PDB code:
a)
1SA0). Surrounding key amino acid residues are labeled, and hydrogen bonds are shown by orange
dashed lines.
3. Materials and Methods
3.1. Chemistry
3.1.1. General
All the compounds were recorded by a 500 MHz Bruker NMR spectrometer (Bruker Daltonics
Inc., Bremen, Germany) with 1H, 13C and DEPT135 NMR in CDCl3 solution with TMS as internal
standard for protons. The 2D NOSEY experiment was carried out in the 500 MHz Bruker NMR
spectrometer with 32 of the scans number. Chemical shift values are mentioned in
δ (ppm) and
coupling constants (J) in Hz. MS (ESI) was measured on an ESI-Thermo Fisher LTQ Fleet instrument
spectrometer (Thermo Fisher Scientific Inc., Waltham, MA)The reaction progress was supervised by
thin-layer chromatography (TLC), spots were observed under UV light (254 nm and 365 nm) and
colorized with 5% phosphomolybdic acid. Silica gels (300-400 mesh, Qingdao Marine Chemical Ltd.,

Int. J. Mol. Sci. 2020, 21, 1817
10 of 17
Qingdao, China) were used for column chromatography. Waters 1525 series equipped with a PDA
detector (Waters Corporation, Milford, MA) was used for analytical HPLC, and YMS-pack ODS-A
column (250 mm
×
10 mm, 5 µm) was used for semipreparation. All reagents were purchased from
commercial sources, and purifications and desiccations of available solvents were accomplished by
standard techniques prior to use. Positive control drug CA-4 was purchased from Sigma, and isoCA-4
was obtained refer to the previous report [37]. The purity of all compounds was confirmed to be greater
than 95% through analytical HPLC.
3.1.2. Synthesis of Diphenylethanone Analogue 5a, 5b and by-Products 6a, 6b
Preparation of compound 4 refers to our previous report method [37]. To a solution of 4 (11.2 g,
26 mmol, 1 eq) in MeOH (85 mL) was added PhI(OAc)2 (8.8 g, 27.3 mmol, 1.05 eq) at -20 ◦C. Then, 50%
H2SO4 in MeOH (85 mL) was added by drops. The mixture was stirred for 30 min. The reaction was
then quenched with saturated aqueous NaHCO3, and diluted by H2O (100 mL). The resulting mixture
was extracted with EtOAc (3
Mg2SO4, filtered and concentrated under reduced pressure. The residue was purified by flash column
chromatography on silica gel with petroleum ether/EtOAc (15:1) to give 5a and 6a.
×
100 mL). The combined organic layers were dried over anhydrous
5a or 6a with the TBS protective group was dissolved in THF (2 mL), and treated with 1.0 M TBAF
(1.1 eq) in THF. The mixture was stirred for 0.5 h and diluted by H2O (10 mL), and extracted with
EtOAc (3
×
10 mL). The combined organic layers were dried over anhydrous Na2SO4, filtered and
concentrated under reduced pressure. The residue was purified by flash column chromatography on
silica gel with petroleum ether/EtOAc (4:1) to give compounds 5b or 6b, respectively. The mixture 6a
was separated by preparative HPLC to afford 6b-(Z) and 6b-(E) with ratio of 1:1. 6b-(Z): tR = 18.6 min,
purity = 90.4%; 6b-(E): tR = 20.6 min, purity = 91.8% at 220 nm, 30 min gradient, 40% MeOH: 60% H2O
to 100% MeOH.
2-(3-((tert-butyldimethylsilyl)oxy)-4-methoxyphenyl)-1-(3,4-dimethoxyphenyl)ethan-1-one
(5a):
1
yellow viscosity liquid, 61% yield. H NMR (500 MHz, CDCl3):
δ 7.28 (s, 2H), 6.83 (s, 2H), 6.79 (d,
J = 1.0 Hz, 1H), 4.16 (s, 2H), 3.93 (s, 3H), 3.91 (s, 6H), 3.81 (s, 3H), 1.00 (s, 9H), 0.15 (s, 6H); 13C NMR
(125 MHz, CDCl3): 196.77, 153.00 (2C), 149.96, 145.15, 142.47, 131.79, 127.35, 122.30, 122.01, 112.33,
δ
106.31 (2C), 60.93, 56.25 (2C), 55.52, 45.04, 25.72 (3C), 18.45, -4.62 (2C).
2-(3-hydroxy-4-methoxyphenyl)-1-(3,4,5-trimethoxyphenyl)ethan-1-one (5b): yellow solid, 95%
yield. 1H NMR (500 MHz, CDCl3):
δ
7.24 (s, 2H), 6.83 (d, J = 2.1 Hz, 1H), 6.76 (d, J = 8.3 Hz,
1H), 6.71 (dd, J = 8.3, 2.1 Hz, 1H), 5.67 (s, 1H), 4.50–4.46 (m, 1H), 3.85 (s, 3H), 3.84 (s, 6H), 3.82 (s, 3H),
2.40–2.31 (m, 5H), 2.08 – 2.02 (m, 1H), 1.01 (t, J = 7.3 Hz, 3H); 13C NMR (126 MHz, CDCl3):
211.39,
δ
198.28, 152.90 (2C), 146.08, 145.82, 142.35, 132.55, 131.74, 119.70, 114.42, 111.10, 106.43 (2C), 60.86, 56.22
(2C), 55.93, 51.66, 39.53, 35.96, 27.64, 7.86; MS (ESI): m/z calcd for C18H21O6+ [M+H] + 333.13, found
333.34.
(Z)-2-methoxy-5-(2-methoxy-1-(3,4,5-trimethoxyphenyl)vinyl)phenol (6b-(Z)): a yellow solid. 1H
NMR (500 MHz, CDCl3):
δ 6.76 (d, J = 2.1 Hz, 1H), 6.71 (d, J = 8.3 Hz, 1H), 6.64 (d, J = 2.1 Hz, 1H), 6.54
(s, 2H), 6.32 (s, 1H), 3.82 (s, 3H), 3.79 (s, 3H), 3.72 (s, 6H), 3.68 (s, 3H); 13C NMR (126 MHz, CDCl3):
δ
152.74 (2C), 145.49, 145.35, 140.12, 136.79, 133.73, 133.16, 120.14, 119.89, 114.39, 110.48, 107.28 (2C),
60.85, 56.10 (2C), 56.02, 50.89; MS (ESI): m/z calcd for C19H23O6+ [M+H]+ 347.15, found 347.05.
(E)-2-methoxy-5-(2-methoxy-1-(3,4,5-trimethoxyphenyl)vinyl)phenol (6b-(E)): a yellow solid. 1H
NMR (500 MHz, CDCl3):
δ
7.06 (d, J = 2.1 Hz, 1H), 6.90
−
6.86 (m, 1H), 6.81 (d, J = 8.4 Hz, 1H), 6.43 (s,
+
2H), 6.35 (s, 1H), 3.89 (s, 3H), 3.85 (s, 3H), 3.81 (s, 6H), 3.76 (s, 3H); MS (ESI): m/z calcd for C19H23O6
[M+H] + 347.15, found 347.06.

Int. J. Mol. Sci. 2020, 21, 1817
11 of 17
3.1.3. Synthesis of Cis-Locked Dihydrofuran Analogues 7a
8a, 8b
,
7b and
α
-Substituted Diphenylethanones
To a solution of compound 5a (1.0 eq) and Cu(OAc)2 (3.0 eq) in DCE was added olefin (3.0 eq),
then the mixture was heated to 110 ◦C, and stirred for 4 h. The reaction was filtered by diatomite,
and diluted by H2O. The resulting mixture was extracted with EtOAc. The combined organic layers
were dried over anhydrous Na2SO4, filtered and concentrated under reduced pressure. The residue
was purified by flash column chromatography on silica gel with petroleum ether/EtOAc to give target
compounds with the TBS protective group. Next, compound with TBS group was dissolved in THF
(2 mL), and treated with 1.0 M TBAF (1.1 eq) in THF. The mixture was stirred for 0.5 h. The reaction
was diluted by H2O (10 mL), and extracted with EtOAc (3
×
10 mL). The combined organic layers were
dried over anhydrous Na2SO4, filtered, and concentrated under reduced pressure. The residue was
purified by flash column chromatography on silica gel with petroleum ether/EtOAc (4:1) to give 7a
and 7b.
2-methoxy-5-(5-phenyl-2-(3,4,5-trimethoxyphenyl)-4,5-dihydrofuran-3-yl)phenol (7a): yellow solid.
Two steps yield: 65%.1H NMR (500 MHz, CDCl3):
δ 7.48 (d, J = 7.7 Hz, 2H), 7.39 (t, J = 7.5 Hz, 2H),
7.32 (t, J = 7.0 Hz, 1H), 6.90 (s, 1H), 6.83 (s, 2H), 6.76 (q, J = 8.4 Hz, 2H), 5.67 (t, J = 9.5 Hz, 1H), 5.54 (s,
1H), 3.86 (s, 3H), 3.86 (s, 3H), 3.72 (s, 6H), 3.54 (dd, J = 15.0, 10.4 Hz, 1H), 3.17 (dd, J = 15.0, 8.6 Hz, 1H);
13C NMR (125 MHz, CDCl3):
δ 152.89 (2C), 148.74, 145.44, 145.13, 143.02, 128.62 (2C), 127.78, 126.91,
125.79 (2C), 119.65, 114.01, 110.58, 108.88, 105.40 (2C), 80.42, 60.91, 56.04 (3C), 44.85; MS (ESI): m/z calcd
for NaC26H26O6 [M+Na]+ 457.16, found 457.49.
2-methoxy-5-(5-methyl-2-(3,4,5-trimethoxyphenyl)-5-vinyl-4,5-dihydrofuran-3-yl)phenol
(7b):
1
yellow solid. Two steps yield: 45%. H NMR (500 MHz, CDCl3):
δ 6.85 (s, 1H), 6.76 (s, 2H), 6.73 (s,
2H), 6.11 (dd, J = 17.3, 10.7 Hz, 1H), 5.52 (s, 1H), 5.34 (dd, J = 17.3, 1.1 Hz, 1H), 5.12 (dd, J = 10.7, 1.1 Hz,
1H), 3.86 (s, 3H), 3.84 (s, 3H), 3.72 (s, 6H), 3.09 (d, J = 14.9 Hz, 1H), 2.98 (d, J = 14.9 Hz, 1H), 1.58 (s, 3H);
13C NMR (125 MHz, CDCl3):
δ 152.87 (2C), 147.82, 145.36, 144.94, 142.49, 138.31, 129.50, 127.40, 119.46,
113.83, 112.23, 110.53, 108.37, 105.36 (2C), 83.41, 60.90, 56.04, 56.03 (2C), 48.00, 26.27; MS (ESI): m/z calcd
for NaC23H26O6 [M+Na]+ 421.16, found 421.67.
2-(3-((tert-butyldimethylsilyl)oxy)-4-methoxyphenyl)-1-(3,4,5-trimethoxyphenyl)heptane-1,5-dione
1
(8a): yellow viscosity liquid, 36% yield. H NMR (500 MHz, CDCl3):
δ 7.22 (s, 2H), 6.77 (s, 2H), 6.71 (s,
1H), 4.46 (s, 1H), 3.85 (s, 3H), 3.84 (s, 6H), 3.75 (s, 3H), 2.40–2.32 (m, 5H), 2.04 (d, J = 7.2 Hz, 1H), 1.02 (s,
3H), 0.95 (s, 9H), 0.09 (s, 6H); 13C NMR (125 MHz, CDCl3 ):
δ
211.40, 198.48, 152.89 (2C), 150.14, 145.39,
142.28, 131.90, 131.87, 121.33, 120.91, 112.47, 106.41 (2C), 60.87, 56.21 (2C), 55.46, 51.56, 39.50, 35.96,
27.61, 25.69 (3C), 18.44, 7.87, -4.460, -4.61; MS (ESI): m/z calcd for SiC29H43O7 [M+H]+ 531.28, found
531.62.
2-(3-hydroxy-4-methoxyphenyl)-1-(3,4,5-trimethoxyphenyl)heptane-1,5-dione (8b): white solid, 95%
1
yield. H NMR (500 MHz, CDCl3):
δ 7.24 (s, 2H), 6.83 (d, J = 2.1 Hz, 1H), 6.76 (d, J = 8.3 Hz, 1H), 6.71
(dd, J = 8.3, 2.1 Hz, 1H), 5.67 (s, 1H), 4.50–4.46 (m, 1H), 3.85 (s, 3H), 3.84 (s, 6H), 3.82 (s, 3H), 2.40–2.31
(m, 5H), 2.08–2.02 (m, 1H), 1.01 (t, J = 7.3 Hz, 3H); 13C NMR (125 MHz, CDCl3):
δ
211.39, 198.28, 152.90
(2C), 146.08, 145.82, 142.35, 132.55, 131.74, 119.70, 114.42, 111.10, 106.43 (2C), 60.86, 56.22 (2C), 55.93,
51.66, 39.53, 35.96, 27.64, 7.86; MS (ESI): m/z calcd for NaC23H28O7 [M+Na]+ 439.17, found 439.46.
3.1.4. Synthesis of Cyclobutane Analogue 9
To a solution of 8a (0.5 mmol, 1.0 eq) ◦in dry THF (10 mL) was added 1 M LiHMDS solution
in THF (1.0 mL, 1.0 mmol, 2.0 eq) at
reaction was added p-toluensulfonyl chloride (TsCl, 191 mg, 1.88 mmol, 2.0 eq) solution in THF (2 mL).
−
78 C under argon atmosphere. After stirred for 1 h, the
The reaction stirred overnight, and quenched with saturated aqueous NH4Cl, diluted by H2O (10 mL).
The resulting mixture was extracted with EtOAc (3
×
10 mL). The combined organic layers were

Int. J. Mol. Sci. 2020, 21, 1817
12 of 17
dried over anhydrous Mg2SO4, filtered, and concentrated under reduced pressure. The flash column
chromatography on silica gel with petroleum ether/EtOAc (8:1) gave 9.
1-(3-(3-((tert-butyldimethylsilyl)oxy)-4-methoxyphenyl)-2-hydroxy-2-(3,4,5-trimethoxyphenyl)
cyclobutyl)propan-1-one (9): yellow solid, 40% yield. 1H NMR (500 MHz, CDCl3):
δ 6.70 (d,
J = 0.8 Hz, 2H),6.63 (s, 1H), 6.45 (s, 2H), 3.80 (s, 3H), 3.78 (s, 6H), 3.73 (s, 3H), 3.69 (d, J = 3.4 Hz, 1H),
3.50 (dd, J = 12.1, 3.3 Hz, 1H), 2.72–2.52 (m, 4H), 2.10 (s, 1H), 0.92 (s, 12H), 0.03 (s, 6H); 13C NMR
(126 MHz, CDCl3):
δ 213.47, 152.69 (2C), 150.01, 144.79, 139.75, 136.98, 132.28, 122.09, 122.02, 111.97,
103.82 (2C), 80.85, 0.81, 56.89, 56.17 (2C), 55.42, 47.27, 38.30, 27.28, 25.66 (3C), 18.36, 12.99,
MS (ESI): m/z calcd for SiC29H43O7 [M+H]+ 531.28, found 531.74.
−
4.66, 4.72;
−
3.1.5. Synthesis of Cyclohexane Analogue 10a, 10b and 11, 12
To a solution of 8a (1.87 g, 35.2 mmol, 1.0 eq) in MeOH (10 mL) was added LiOH (844 mg,
35.2 mmol, 1.0 eq) at 0 ◦C. After stirring for 0.5 h, the solution was quenched with saturated aqueous
NH4Cl, diluted by H2O (20 mL). The resulting mixture was extracted with EtOAc (3
×
20 mL).
The combined organic layers were dried over anhydrous Na2SO4, filtered, and concentrated under
reduced pressure. The residue was purified by flash column chromatography on silica gel with
petroleum ether/EtOAc (10: 1) to give 560 mg compounds 10a.
To a solution of 10a (20 mg, 0.38 mmol, 1.0 eq) in THF (2 mL) was added 1.0 M TBAF (42
0.42 mmol, 1.1 eq) in THF. The mixture was stirred for 0.5 h. The reaction was diluted by H2O (10 mL),
and extracted with EtOAc (3 10 mL). The combined organic layers were dried over anhydrous
µL,
×
Na2SO4, filtered and concentrated under reduced pressure. The residue was purified by flash column
chromatography on silica gel with petroleum ether/EtOAc (4:1) to give 15 mg compounds 10b.
To a solution of 10a (30 mg, 56
mol, 2.0 eq) at 0 ◦C. After stirred for 2 h, the reaction was then quenched with saturated aqueous
NH4Cl, and diluted by H2O (5 mL). The resulting mixture was extracted with EtOAc (5 10 mL).
The combined organic layers were dried over anhydrous Mg2SO4, filtered and concentrated under
reduced pressure. The residue was redissolved in THF (3 mL), and treated with 1.0 M TBAF (62 L,
62 mol, 1.1 eq) in THF. The mixture was stirred for 0.5 h. The reaction was diluted by H2O (5 mL),
and extracted with EtOAc (3 5 mL). The combined organic layers were dried over anhydrous
µmol, 1.0 eq) in dry DCM (5 mL) was added NaBH4 (7.6 mg,
113
µ
×
µ
µ
×
Na2SO4, filtered and concentrated under reduced pressure. The residue was purified by flash column
chromatography on silica gel with petroleum ether/EtOAc (2: 1) to give 10 mg compounds 11.
To a solution of 10a (500 mg, 0.94 mmol, 1.0 eq) in dry THF (10 mL) was added 1 M LiHMDS
solution in THF (1.88 mL, 1.88 mmol, 2.0 eq) at -78 ◦C under argon atmosphere. After being stirred for
1 h, the reaction was added to TsCl (360 mg, 1.88 mmol, 2.0 eq) solution in THF (3 mL). The reaction
stirred overnight, and quenched with saturated aqueous NH4Cl, diluted by H2O (10 mL). The resulting
mixture was extracted with EtOAc (3
Mg2SO4, filtered and concentrated under reduced pressure. The residue was redissolved in DMF
(3 mL), and added DMAP (12 mg, 94 mol, 0.1 eq) and Et3N (1.3 mL, 9.4 mmol, 10 eq). The reaction was
heated to 80 ◦C, and stirred overnight, then quenched with saturated aqueous NH4Cl, diluted by H2O
(30 mL). The resulting mixture was extracted with EtOAc (3 20 mL). The combined organic layers
were dried over anhydrous Na2SO4, filtered and concentrated under reduced pressure. The residue
was redissolved in THF (5 mL), and treated with 1.0 M TBAF (940 L, 0.94 mmol, 1.0 eq) in THF.
The mixture was stirred for 0.5 h. The reaction was diluted by H2O (10 mL), and extracted with
EtOAc (3 10 mL). The combined organic layers were dried over anhydrous Na2SO4, filtered, and
×
10 mL). The combined organic layers were dried over anhydrous
µ
×
µ
×
concentrated under reduced pressure. The residue was purified by flash column chromatography on
silica gel with petroleum ether/EtOAc (4:1) to give 93 mg compounds 12 as a white solid.
4-(3-((tert-butyldimethylsilyl)oxy)-4-methoxyphenyl)-3-hydroxy-2-methyl-3-(3,4,5-trimethoxyphenyl)
1
cyclohexan-1-one (10a): white solid, 65% yield. H NMR (500 MHz, CDCl3 ):
δ 6.56 (d, J = 7.9 Hz,
1H), 6.48 (d, J = 8.3 Hz, 2H), 3.77 (s, 3H), 3.68 (s, 3H), 3.35 (d, J = 11.2 Hz, 1H), 3.08 (d, J = 6.5 Hz, 1H),

Int. J. Mol. Sci. 2020, 21, 1817
13 of 17
2.72 – 2.52 (m, 3H), 2.09 (d, J = 11.8 Hz, 1H), 1.97 (s, 1H), 0.92 (s, 9H), 0.80 (d, J = 6.3 Hz, 3H), 0.02 (s,
3H), -0.02 (s, 3H); 13C NMR (125 MHz, CDCl3 ):
210.40, 149.77, 144.33, 140.22, 136.61, 132.41, 121.77,
δ
121.76, 111.50, 82.95, 60.84, 56.18, 56.16, 55.48, 53.62, 52.88, 41.56, 28.97, 25.67 (3C), 18.36, 8.15, -4.75,
-4.84; MS (ESI): m/z calcd for SiC29H43O7 [M+H]+ 531.28, found 531.63.
3-hydroxy-4-(3-hydroxy-4-methoxyphenyl)-2-methyl-3-(3,4,5-trimethoxyphenyl)cyclohexan-1-one
1
(10b): white solid, 95% yield. H NMR (500 MHz, DMSO-D6):
δ 8.49 (s, 1H), 6.57 (d, J = 1.5 Hz, 1H),
6.55 (d, J = 8.3 Hz, 1H), 6.35 (d, J = 8.2 Hz, 1H), 4.94 (s, 1H), 3.62 (s, 3H), 3.56 (s, 3H), 3.39 (dd, J = 12.6,
3.3 Hz, 1H), 3.34 - 3.31 (m, 1H), 2.71 (td, J = 13.3, 6.6 Hz, 1H), 2.46 2.31 (m, 2H), 1.90–1.83 (m, 1H),
0.66 ppm (d, J = 6.7 Hz, 3H); 13C NMR (125 MHz, DMSO-D6 ):
211.12, 146.07, 145.68, 141.49, 135.85,
−
δ
135.35, 120.18, 116.97, 111.59, 82.75, 60.42, 55.96, 53.75, 52.64, 41.40, 29.85, 8.79; MS (ESI): m/z calcd for
NaC23H28O7 [M+Na]+ 439.17, found 439.59.
6-(3-hydroxy-4-methoxyphenyl)-2-methyl-1-(3,4,5-trimethoxyphenyl)cyclohexane-1,3-diol
(11):
1
white solid, two steps yield: 66%. H NMR (500 MHz, CDCl3):
δ 7.66 (dd, J = 259.2, 6.5 Hz, 1H), 6.52
(s, 1H), 6.50 (s, 2H), 6.20 (d, J = 6.9 Hz, 1H), 6.11 (s, 1H), 5.48 (s, 1H), 3.90 (s, 3H), 3.84 (d, J = 10.0 Hz,
1H), 3.79 (s, 3H), 3.76 (s, 3H), 3.54 (s, 3H), 2.86 (d, J = 12.1 Hz, 1H), 2.48 (s, 1H), 2.24 (dd, J = 27.5, 12.3
Hz, 2H), 1.98 (s, 1H), 1.63 (dd, J = 23.6, 11.6 Hz, 2H), 0.86 (s, 3H); 13C NMR (125 MHz, CDCl3):
δ 145.10,
144.96, 141.62, 136.48, 134.03, 130.25, 127.08, 120.49, 114.73, 110.00, 103.80, 101.65, 79.72, 72.37, 60.92,
56.38, 56.09, 55.86, 53.40, 48.04, 35.44, 26.56, 11.48; MS (ESI): m/z calcd for NaC23H30O7 [M+Na]+ 441.19,
found 441.68.
5-(3-hydroxy-4-methoxyphenyl)-1-methyl-6-(3,4,5-trimethoxyphenyl)-7-oxabicyclo[4.1.0]heptan-2-
one (12): white solid, three steps yield: 28%. 1H NMR (500 MHz, CDCl3):
δ
6.80 (s, 1H), 6.60 (t,
J = 5.6 Hz, 2H), 6.32 (s, 2H), 5.48 (s, 1H), 3.79 (s, 3H), 3.76 (s, 3H), 3.43 (d, J = 10.9 Hz, 1H), 2.73 (d,
J = 15.3 Hz, 1H), 2.44 – 2.29 (m, 2H), 1.91 – 1.84 (m, 1H), 1.13 (s, 3H); 13C NMR (125 MHz, CDCl3):
δ
205.58, 152.78 (2C), 145.34, 145.26, 137.09,134.93, 132.67, 119.84, 114.35, 110.31, 72.21, 65.16, 60.82, 56.19,
55.84 (2C), 45.67, 37.13, 26.33, 13.05; MS (ESI): m/z calcd for NaC23H26O7 [M+Na]+ 437.16, found 437.34.
3.2. Biological Activity Evaluation
3.2.1. Cell Culture
The HepG2 cell line was originally acquired from Shanghai Institute of Biochemistry and Cell
Biology, Chinese Academy of Sciences. This cell line was grown in RPMI-1640 (Gibco) including 10%
(v/v) thermally inactivated fetal bovine serum (FBS), penicillin (100 KU/L) and streptomycin (100 KU/L)
at 37 ◦C in a 5% CO2 humidified incubator.
3.2.2. Cytotoxic Activity (SRB Assay)
In vitro cytotoxic activity was evaluated by using the SRB colorimetric assay as previous
methods [38,41]. HepG2 cells were treated with analogues for 48 h at various concentrations.
3.2.3. Apoptosis-Inducing Activity (PI/Annexin V-FITC Assay)
The apoptosis in HepG2 cells was detected with a propidium iodide (PI)/Annexin V-FITC apoptosis
detection kit (KeyGEN Biotech, Nanjing, China) as described previously [42]. After the treatment of
6b-(Z)
,
6b-(E) and CA-4 at the indicated concentrations for 48 h, HepG-2 cells were stained with PI
L of binding buffer. Flow cytometric analysis
and Annexin V-FITC and then were resuspended in 400
µ
(FACS Calibur; Becton-Dickinson, San Jose, CA, US) was performed. A total of 10000 cells were
acquired per sample and data were analyzed using Cellquest software (Becton-Dickinson, San Jose,
CA, US).

Int. J. Mol. Sci. 2020, 21, 1817
14 of 17
3.2.4. Cell Cycle Distribution (PI Staining Assay)
Cell cycle distribution on HepG2 cells was assessed by flow cytometry. PI staining assay (Sigma)
was used for the cell cycle arrest of cells as described previously [40]. After treatment with test
compound
1
at the indicated concentrations for 24 h, cells were centrifuged and fixed in 70% ethanol
L RNase A and 400 L PI.
at 4 ◦C overnight and subsequently resuspended in PBS containing 100
µ
µ
Cellular DNA content, for cell cycle distribution analysis, was measured using a FACS Calibur flow
cytometer (Becton-Dickinson, San Jose, CA, US) and analyzed using a CellQuest software package
(Becton-Dickinson, San Jose, CA, US). Twenty thousand events were collected per sample. Mean
values from 3 independent experiments are presented. The results were analyzed using Modfit LT
3.0 software.
3.2.5. Immunofluorescence Analysis (DAPI /α-Tubulin-TRITC Assay)
Immunofluorescence effects of 6b-(E) and CA-4 on the inhibition of tubulin polymerization in
HepG-2 cells were measured as described previously [37]. HepG-2 cells were incubated in 8-well cell
slide (Eppendorf AG, Hauppauge, NY). After treatment for 48 h at the indicated concentrations of
6b-(E) (0.3
µM) and CA-4 (0.02
µM), the cells was fixed with 4% paraformaldehyde, blocked with
PBS containing 5% BSA and incubated with anti-
α
-tubulin-TRITC antibodies (1:500, Abcam Trading
Company Ltd., Shanghai, China) and the secondary antibody (goat anti-rabbit IgG, 1:500, ZSGB-BIO
Inc., Beijing, China). At the last step, the cells were stained with DAPI. Images of cells were acquired
using an Olympus fluorescence microscope with a 20× objective.
3.2.6. Tubulin Polymerization Assay
Tubulin polymerization assay were performed in the light of the fluorescence based tubulin
polymerization assay kit’s protocol (Cat. #BK011P, Cytoskeleton Inc., Denver, CO). Simplify, tubulin
(10 mg/mL) containing buffer 1, tubulin glycerol buffer and GTP stock (100 mM) were incubated with
6b-(E) (5, 20 and 40 µM), paclitaxel (3 µM), CA-4 (3 µ
M) and DMSO for 50 min at 37 ◦C. The fluorescence
increase was monitored every minute for the characterization of tubulin polymerization at 360 nm
excitation wavelength and 460 nm emission wavelengths by microplate spectrophotometer (Synergy
HTX, BioTek Instruments, Inc., Winooski, VT).
3.2.7. Statistics Analysis
All the data were shown as mean
determinations with three duplicates. Statistical analysis was performed using GraphPad Prism
±
standard deviation (SD) from at least three separate
software with the 2-tailed Student t-test.
3.3. Molecular Docking
All docking analysis was performed by using the Surflex-Dock program in the Sybyl-X 2.0 software
(Tripos Inc., St. Louis, MO). The X-ray crystal structure of tubulin protein (PDB ID: 1SA0) was acquired
from the RSCB Protein Data Bank (http://www.rcsb.org/pdb). All bound waters and ligands were
eliminated from the protein and the polar hydrogen was added to the proteins. Compounds 6b-(Z)
and 6b-(E) were drawn and optimized automatically in the Sybyl-X 2.0 software, and saved as a mol2
file. Default parameters were used for Docking. The analysis of results was carried out by USCF
Chimera software, which was downloaded from http://www.cgl.ucsf.edu/chimera.
4. Conclusions
In this work, we constructed a series of novel CA-4 analogues on the cis-double bond
containing diphenylethanone, cis-locked dihydrofuran, α-substituted diphenylethanone, cyclobutane
and cyclohexane. Yet, most compounds exhibited weak cytotoxic activity against HepG2 cells.
Unexpectedly, a by-product 6b (cis–trans isomers) in the preparation of diphenylethanone analogues

Int. J. Mol. Sci. 2020, 21, 1817
15 of 17
was found to be the most potent cytotoxic agents against HepG2 cells with IC50 values of less than
0.5 M. The two isomers of 6b both induced cellular apoptosis, significantly arrested cells in the G2/M
µ
phase, severely disrupted microtubule network in HepG2 cells. An in vitro tubulin polymerization
assay revealed that 6b-(E) was a dose-dependent and effective inhibitor of the tubulin assembly.
In addition, molecular docking showed that two stereoisomers of 6b bound similarly and efficiently at
the colchicine binding site on tubulin well with CA-4 in similar distorted conformations. Although
the anticancer activity of all novel compounds did not behave as excellently as CA-4, these results
provided fundamental data for new developments of tubulin inhibitors. Additional insight on 6b will
expand our research of olefin modification of CA-4 or isoCA-4 as tubulin polymerization agents.
Supplementary Materials: Supplementary materials can be found at http://www.mdpi.com/1422-0067/21/5/1817/
s1.
Author Contributions: Conceptualization, M.-Y.S. and J.-J.T.; methodology, M.-Y.S., Y.-L.W., H.-R.W. and Q.-R.H.;
software, M.-Y.S.; validation, J.-M.G.; formal analysis, Q.-R.H. and Y.-L.W.; investigation, H.-R.W. and T.-C.J.;
resources, J.-J.T.; data curation, M.-Y.S. and T.-C.J.; writing—original draft preparation, M.-Y.S.; writing—review
and editing, J.-J.T.; supervision, J.-J.T. and J.-M.G.; project administration, Q.-R.H.; funding acquisition, J.-M.G.
All authors have read and agreed to the published version of the manuscript.
Funding: This research was funded by the National Natural Science Foundation of China (21542016) and Yangling
Demonstration Zone Science and Technology Plan Project (2017NY-07), China.
Acknowledgments: This work was given some technical support by Instrument Shared Platform of Northwest
A&F University.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Pettit, G.R.; Singh, S.B.; Hamel, E.; Lin, C.M.; Alberts, D.S.; Garciakendall, D. Isolation and structure of
the strong cell growth and tubulin inhibitor combretastatin A-4. Experientia 1989, 45, 209–211. [CrossRef]
[PubMed]
2.
3.
4.
5.
Hamel, E. Antimitotic natural products and their interactions with tubulin. Med. Res. Rev. 1996, 16, 207–231.
[CrossRef]
Woods, J.A.; Hadfield, J.A.; Pettit, G.R.; Fox, B.W.; Mcgown, A.T. The Interaction with Tubulin of a Series of
Stilbenes Based on Combretastatin a-4. Brit. J. Cancer 1995, 71, 705–711. [CrossRef]
Young, S.L.; Chaplin, D.J. Combretastatin A4 phosphate: Background and current clinical status. Expert
Opin. Investig. Drugs 2004, 13, 1171–1182. [CrossRef] [PubMed]
Hori, K.; Saito, S. Microvascular mechanisms by which the combretastatin A-4 derivative AC7700 (AVE8062)
induces tumour blood flow stasis. Br. J. Cancer 2003, 89, 1334–1344. [CrossRef] [PubMed]
Available online: www.mateon.com (accessed on 15 February 2020).
Lipeeva, A.V.; Shults, E.E.; Shakirov, M.M.; Pokrovsky, M.A.; Pokrovsky, A.G. Synthesis and Cytotoxic
Activity of a New Group of Heterocyclic Analogues of the Combretastatins. Molecules 2014, 19, 7881–7900.
[CrossRef]
6.
7.
8.
9.
Jin, Y.H.; Qi, P.; Wang, Z.W.; Shen, Q.R.; Wang, J.; Zhang, W.G.; Song, H.R. 3D-QSAR Study of Combretastatin
A-4 Analogs Based on Molecular Docking. Molecules 2011, 16, 6684–6700. [CrossRef]
Piekus-Slomka, N.; Mikstacka, R.; Ronowicz, J.; Sobiak, S. Hybrid cis-stilbene Molecules: Novel Anticancer
Agents. Int. J. Mol. Sci. 2019, 20, 1300. [CrossRef]
10. Schmitt, F.; Gosch, L.C.; Dittmer, A.; Rothemund, M.; Mueller, T.; Schobert, R.; Biersack, B.; Volkamer, A.;
Hopfner, M. Oxazole-Bridged Combretastatin A-4 Derivatives with Tethered Hydroxamic Acids:
Structure-Activity Relations of New Inhibitors of HDAC and/or Tubulin Function. Int. J. Mol. Sci.
2019, 20, 383. [CrossRef]
11. Tron, G.C.; Pirali, T.; Sorba, G.; Pagliai, F.; Busacca, S.; Genazzani, A.A. Medicinal Chemistry of Combretastatin
A4: Present and Future Directions. J. Med. Chem. 2006, 49, 3033–3044. [CrossRef]
12. Nam, N.H. Combretastatin A-4 analogues as antimitotic antitumor agents. Curr. Med. Chem. 2003, 10,
1697–1722. [CrossRef] [PubMed]

Int. J. Mol. Sci. 2020, 21, 1817
16 of 17
13. Aprile, S.; Del Grosso, E.; Tron, G.C.; Grosa, G. In vitro metabolism study of combretastatin A-4 in rat and
human liver microsomes. Drug Metab. Dispos. 2007, 35, 2252–2261. [CrossRef] [PubMed]
14. Nakamura, M.; Kajita, D.; Matsumoto, Y.; Hashimoto, Y. Design and synthesis of silicon-containing tubulin
polymerization inhibitors: Replacement of the ethylene moiety of combretastatin A-4 with a silicon linker.
Bioorg. Med. Chem. 2013, 21, 7381–7391. [CrossRef]
15. Pang, Y.Q.; Yan, J.; An, B.J.; Huang, L.; Li, X.S. The synthesis and evaluation of new butadiene derivatives as
tubulin polymerization inhibitors. Bioorg. Med. Chem. 2017, 25, 3059–3067. [CrossRef] [PubMed]
16. Chen, H.; Li, Y.; Sheng, C.; Lv, Z.; Dong, G.; Wang, T.; Liu, J.; Zhang, M.; Li, L.; Zhang, T.; et al. Design
and synthesis of cyclopropylamide analogues of combretastatin-A4 as novel microtubule-stabilizing agents.
J. Med. Chem. 2013, 56, 685–699. [CrossRef] [PubMed]
17. Ty, N.; Pontikis, R.; Chabot, G.G.; Devillers, E.; Quentin, L.; Bourg, S.; Florent, J.C. Synthesis and biological
evaluation of enantiomerically pure cyclopropyl analogues of combretastatin A4. Bioorg. Med. Chem. 2013
21, 1357–1366. [CrossRef]
,
18. Zhou, P.; Liu, Y.; Zhou, L.; Zhu, K.; Feng, K.; Zhang, H.; Liang, Y.; Jiang, H.; Luo, C.; Liu, M.; et al. Potent
Antitumor Activities and Structure Basis of the Chiral beta-Lactam Bridged Analogue of Combretastatin A-4
Binding to Tubulin. J. Med. Chem. 2016, 59, 10329–10334. [CrossRef]
19. Theeramunkong, S.; Caldarelli, A.; Massarotti, A.; Aprile, S.; Caprioglio, D.; Zaninetti, R.; Teruggi, A.;
Pirali, T.; Grosa, G.; Tron, G.C.; et al. Regioselective Suzuki coupling of dihaloheteroaromatic compounds
as a rapid strategy to synthesize potent rigid combretastatin analogues. J. Med. Chem. 2011, 54, 4977–4986.
[CrossRef]
20. Pirali, T.; Busacca, S.; Beltrami, L.; Imovilli, D.; Pagliai, F.; Miglio, G.; Massarotti, A.; Verotta, L.; Tron, G.C.;
Sorba, G.; et al. Synthesis and cytotoxic evaluation of combretafurans, potential scaffolds for dual-action
antitumoral agents. J. Med. Chem. 2006, 49, 5372–5376. [CrossRef]
21. Assadieskandar, A.; Amini, M.; Ostad, S.N.; Riazi, G.H.; Cheraghi-Shavi, T.; Shafiei, B.;
Shafiee, A. Design, synthesis, cytotoxic evaluation and tubulin inhibitory activity of 4-aryl-5-(3,4,5-
trimethoxyphenyl)-2-alkylthio-1H-imidazole derivatives. Bioorg. Med. Chem. 2013, 21, 2703–2709. [CrossRef]
22. Wang, Z.; Yang, Q.; Bai, Z.; Sun, J.; Jiang, X.; Song, H.; Wu, Y.; Zhang, W. Synthesis and biological evaluation
of 2,3-diarylthiophene analogues of combretastatin A-4. Med. Chem. Commun. 2015, 6, 971–976. [CrossRef]
23. Simoni, D.; Grisolia, G.; Giannini, G.; Roberti, M.; Rondanin, R.; Piccagli, L.; Baruchello, R.; Rossi, M.;
Romagnoli, R.; Invidiata, F.P.; et al. Heterocyclic and phenyl double-bond-locked combretastatin analogues
possessing potent apoptosis-inducing activity in HL60 and in MDR cell lines. J. Med. Chem. 2005, 48, 723–736.
[CrossRef] [PubMed]
24. Li, Y.H.; Zhang, B.; Yang, H.K.; Li, Q.; Diao, P.C.; You, W.W.; Zhao, P.L. Design, synthesis, and biological
evaluation of novel alkylsulfanyl-1,2,4-triazoles as cis-restricted combretastatin A-4 analogues. Eur. J. Med.
Chem. 2017, 125, 1098–1106. [CrossRef] [PubMed]
25. Subba Rao, A.V.; Swapna, K.; Shaik, S.P.; Lakshma Nayak, V.; Srinivasa Reddy, T.; Sunkari, S.; Shaik, T.B.;
Bagul, C.; Kamal, A. Synthesis and biological evaluation of cis-restricted triazole/tetrazole mimics of
combretastatin-benzothiazole hybrids as tubulin polymerization inhibitors and apoptosis inducers. Bioorg.
Med. Chem. 2017, 25, 977–999. [CrossRef]
26. Salehi, M.; Amini, M.; Ostad, S.N.; Riazi, G.H.; Assadieskandar, A.; Shafiei, B.; Shafiee, A. Synthesis, cytotoxic
evaluation and molecular docking study of 2-alkylthio-4-(2,3,4-trimethoxyphenyl)-5-aryl-thiazoles as tubulin
polymerization inhibitors. Bioorg. Med. Chem. 2013, 21, 7648–7654. [CrossRef] [PubMed]
27. Wang, F.; Yang, Z.; Liu, Y.; Ma, L.; Wu, Y.; He, L.; Shao, M.; Yu, K.; Wu, W.; Pu, Y.; et al. Synthesis and biological
evaluation of diarylthiazole derivatives as antimitotic and antivascular agents with potent antitumor activity.
Bioorg. Med. Chem. 2015, 23, 3337–3350. [CrossRef]
28. Xu, Q.; Wang, Y.; Xu, J.; Sun, M.; Tian, H.; Zuo, D.; Guan, Q.; Bao, K.; Wu, Y.; Zhang, W. Synthesis and
Bioevaluation of 3,6-Diaryl-[1,2,4]triazolo[4,3-b] Pyridazines as Antitubulin Agents. ACS Med. Chem. Lett.
2016, 7, 1202–1206. [CrossRef]
29. Messaoudi, S.; Treguier, B.; Hamze, A.; Provot, O.; Peyrat, J.F.; De Losada, J.R.; Liu, J.M.; Bignon, J.;
Wdzieczak-Bakala, J.; Thoret, S.; et al. Isocombretastatins a versus combretastatins a: The forgotten isoCA-4
isomer as a highly promising cytotoxic and antitubulin agent. J. Med. Chem. 2009, 52, 4538–4542. [CrossRef]

Int. J. Mol. Sci. 2020, 21, 1817
17 of 17
30. Tréguier, B.; Hamze, A.; Provot, O.; Brion, J.-D.; Alami, M. Expeditious synthesis of 1,1-diarylethylenes
related to isocombretastatin A-4 (isoCA-4) via palladium-catalyzed arylation of N-tosylhydrazones with aryl
triflates. Tetrahedron Lett. 2009, 50, 6549–6552. [CrossRef]
31. Stocker, V.; Ghinet, A.; Leman, M.; Rigo, B.; Millet, R.; Farce, A.; Desravines, D.; Dubois, J.; Waterlot, C.;
Gautret, P. On the synthesis and biological properties of isocombretastatins: A case of ketone homologation
during Wittig reaction attempts. Rsc Adv. 2013, 3, 3683–3696. [CrossRef]
32. Aziz, J.; Brachet, E.; Hamze, A.; Peyrat, J.F.; Bernadat, G.; Morvan, E.; Bignon, J.; Wdzieczak-Bakala, J.;
Desravines, D.; Dubois, J.; et al. Synthesis, biological evaluation, and structure-activity relationships of tri-
and tetrasubstituted olefins related to isocombretastatin A-4 as new tubulin inhibitors. Org. Biomol. Chem.
2013, 11, 430–442. [CrossRef] [PubMed]
33. Rasolofonjatovo, E.; Provot, O.; Hamze, A.; Rodrigo, J.; Bignon, J.; Wdzieczak-Bakala, J.; Desravines, D.;
Dubois, J.; Brion, J.D.; Alami, M. Conformationnally restricted naphthalene derivatives type isocombretastatin
A-4 and isoerianin analogues: Synthesis, cytotoxicity and antitubulin activity. Eur. J. Med. Chem. 2012, 52,
22–32. [CrossRef] [PubMed]
34. Renko, D.; Provot, O.; Rasolofonjatovo, E.; Bignon, J.; Rodrigo, J.; Dubois, J.; Brion, J.D.; Hamze, A.;
Alami, M. Rapid synthesis of 4-arylchromenes from ortho-substituted alkynols: A versatile access to
restricted isocombretastatin A-4 analogues as antitumor agents. Eur. J. Med. Chem. 2015, 90, 834–844.
[CrossRef] [PubMed]
35. Soussi, M.A.; Provot, O.; Bernadat, G.; Bignon, J.; Wdzieczak-Bakala, J.; Desravines, D.; Dubois, J.; Brion, J.D.;
Messaoudi, S.; Alami, M. Discovery of azaisoerianin derivatives as potential antitumors agents. Eur. J. Med.
Chem. 2014, 78, 178–189. [CrossRef]
36. Rasolofonjatovo, E.; Provot, O.; Hamze, A.; Rodrigo, J.; Bignon, J.; Wdzieczak-Bakala, J.; Lenoir, C.;
Desravines, D.; Dubois, J.; Brion, J.-D.; et al. Design, synthesis and anticancer properties of 5-arylbenzoxepins
as conformationally restricted isocombretastatin A-4 analogs. Eur. J. Med. Chem. 2013, 62, 28–39. [CrossRef]
37. Song, M.Y.; Cao, C.Y.; He, Q.R.; Dong, Q.M.; Li, D.; Tang, J.J.; Gao, J.M. Constructing novel dihydrofuran
and dihydroisoxazole analogues of isocombretastatin-4 as tubulin polymerization inhibitors through [3+2]
reactions. Bioorgan. Med. Chem. 2017, 25, 5290–5302. [CrossRef]
38. Skehan, P.; Storeng, R.; Scudiero, D.; Monks, A.; McMahon, J.; Vistica, D.; Warren, J.T.; Bokesch, H.; Kenney, S.;
Boyd, M.R. New colorimetric cytotoxicity assay for anticancer-drug screening. J. Natl. Cancer Inst. 1990, 82,
1107–1112. [CrossRef]
39. Simoni, D.; Romagnoli, R.; Baruchello, R.; Rondanin, R.; Rizzi, M.; Pavani, M.G.; Alloatti, D.; Giannini, G.;
Marcellini, M.; Riccioni, T.; et al. Novel combretastatin analogues endowed with antitumor activity. J. Med.
Chem. 2006, 49, 3143–3152. [CrossRef]
40. Tang, J.J.; Fan, G.J.; Dai, F.; Ding, D.J.; Wang, Q.; Lu, D.L.; Li, R.R.; Li, X.Z.; Hu, L.M.; Jin, X.L.; et al.
Finding more active antioxidants and cancer chemoprevention agents by elongating the conjugated links of
resveratrol. Free Radic. Biol. Med. 2011, 50, 1447–1457. [CrossRef]
41. Dong, S.; Tang, J.-J.; Zhang, C.-C.; Tian, J.-M.; Guo, J.-T.; Zhang, Q.; Li, H.; Gao, J.-M. Semisynthesis and
in vitro cytotoxic evaluation of new analogues of 1-O-acetylbritannilactone, a sesquiterpene from Inula
britannica. Eur. J. Med. Chem. 2014, 80, 71–82. [CrossRef]
42. Tang, J.J.; Dong, S.; Han, Y.Y.; Lei, M.; Gao, J.M. Synthesis of 1-O-acetylbritannilactone analogues from
Inula britannica and in vitro evaluation of their anticancer potential. Med. Chem. Comm. 2014, 5, 1584–1589.
[CrossRef]
©
2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
