Dioxothietanylation of Heterocycles 1. N-(1,1-Dioxothietan-3-yl)-1,2,4- triazoles

Article abstract of DOI:10.1007/s10593-013-1159-7

3,5-Substituted 1-(1,1-dioxothietan-3-yl)-1,2,4-triazoles have been prepared by treating NH-1,2,4-tri-azole sodium salts with 3,5-dibromo-1-(1,1- dioxothietan-3-yl)-1,2,4-triazole (a novel dioxothietanylating reagent). The reactions occur regioselectively at the position 2 for 5-bromo-1,2,4-triazoles containing ethoxy-, isopropoxy-, or phenoxy groups at the position 3 and at position 1 for 3-methylsulfanyl-1,2,4-tri-azole. The reaction occurs nonselectively at positions 1 and 2 in the case of 3-methylsulfonyl-1,2,4-tri- azole and 5-bromo-3-(piperidin-1-yl)-1,2,4-triazole, to give the isomeric 3-R-5-R¹- and 5-R-3-R¹-1-(1,1-di-oxothietan-3-yl)-1,2,4- triazoles.

Full text of DOI:10.1007/s10593-013-1159-7

Chemistry of Heterocyclic Compounds, Vol. 48, No. 10, January, 2013 (Russian Original Vol. 48, No. 10, October, 2012)
DIOXOTHIETANYLATION OF HETEROCYCLES
1. N-(1,1-DIOXOTHIETAN-3-YL)-1,2,4-TRIAZOLES
E. E. Klen1*, N. N. Makarova1, and F. A. Khaliullin1
3,5-Substituted 1-(1,1-dioxothietan-3-yl)-1,2,4-triazoles have been prepared by treating NH-1,2,4-tri-
azole sodium salts with 3,5-dibromo-1-(1,1-dioxothietan-3-yl)-1,2,4-triazole (a novel dioxothietanylating
reagent). The reactions occur regioselectively at the position 2 for 5-bromo-1,2,4-triazoles containing
ethoxy-, isopropoxy-, or phenoxy groups at the position 3 and at position 1 for 3-methylsulfanyl-1,2,4-tri-
azole. The reaction occurs nonselectively at positions 1 and 2 in the case of 3-methylsulfonyl-1,2,4-tri-
azole and 5-bromo-3-(piperidin-1-yl)-1,2,4-triazole, to give the isomeric 3-R-5-R1- and 5-R-3-R1-1-(1,1-di-
oxothietan-3-yl)-1,2,4-triazoles.
Keywords: thietane 1,1-dioxide, 1,2,4-triazole, dioxothietanylation.
Methods have been reported in the literature for the preparation of N-(1,1-dioxothietan-3-yl)-
1,2,4-triazoles by oxidative reactions of N-(thietan-3-yl)- and N-(1-oxothietan-3-yl)-1,2,4-triazoles [1], inferring
a preliminary alkylation of 1,2,4-triazoles by 2-chloromethylthiirane and subsequent nucleophilic substitution
[2-4].
In continuation of our studies [5], we propose a novel method for the introduction of a thietane-
1,1-dioxide ring into 3,5-substituted NH-1,2,4-triazoles, which is based on the use of 3,5-dibromo-1-(1,1-dioxo-
thietan-3-yl)-1,2,4-triazole (1) as the dioxothietanylating reagent [6].
It was found that reaction of the NH-1,2,4-triazoles 2a-g with compound 1 in tert-butanol in the
presence of sodium tert-butoxide gave the N-dioxothietanylation products N-(1,1-dioxothietan-3-yl)-
1,2,4-triazoles 3-9 in 39-64% yields. Evidently the reaction of the 3,5-dibromo-1-(1,1-dioxothietan-3-yl)-
1,2,4-triazole (1) with sodium tert-butoxide occurs with elimination of thietane 1,1-dioxide, which takes part in a
Michael addition of the NH-1,2,4-triazoles. It is known that thietane 1,1-dioxides are used as Michael acceptors
and readily add ethanol, hydrogen sulfide, thiophenol and amines in the presence of bases to give high yields of
3-substituted thietane 1,1-dioxides [7].
The composition and structure of compounds 3-9 were confirmed from elemental analysis data, IR and
1H NMR spectroscopy, and also by a counter synthesis.
The reactions of compound 1 with the sodium salts of unsymmetrical 1,2,4-triazoles can occur at the
positions 1, 2, and 4 of the triazole ring. In the reaction of 3,5-dibromo-1-(1,1-dioxothietan-3-yl)-1,2,4-triazole
(1) with the unsubstituted 1,2,4-triazole (2a), addition occurs at the N-1 atom to give 1-(1,1-dioxothietan-3-yl)-
1,2,4-triazole (3). The product of dioxothietanylation at the N-4 atom was not observed [5].
_______
*To whom correspondence should be addressed, e-mail: khaliullin_ufa@yahoo.com.
1Bashkir State Medical University, 3 Lenin St., Ufa 450000, Russia.
________________________________________________________________________________________
Translated from Khimiya Geterotsiklicheskikh Soedinenii, No. 10, pp. 1583-1586, October, 2012.
Original article submitted January 19, 2012.
0009-3122/13/4810-1473©2013 Springer Science+Business Media New York
1473

O
O
S
t-BuONa
t-BuOH
Na+
Br
O
S
N
N
N
N
O
+
Br
N
10
Br
Br
N
1
O
O
H
N
N
O
O
S
S
R1
R
N
2a–g
+
N
N
N
N
R1
R1
4, 5, 6, 8b, 9b
R
R
N
N
3, 7, 8a, 9a
2a, 3 R = R1 = H; 2b, 4 R = OEt, R1 = Br; 2c, 5 R = O(Pr-i), R1 = Br; 2d, 6 R = OPh, R1 = Br;
2e, 7 R = SMe, R1 = H; 2f, 8a,b R = SO2Me, R1 = H; 2g, 9a,b R = piperidin-1-yl, R1 = Br
In the case of the 5-bromo-3-ethoxy- (2b), 5-bromo-3-isopropoxy- (2c), and 5-bromo-3-phenoxy-
1,2,4-triazoles (2d) reactions occur regioselectively at the position 2, giving the 3-bromo-1-(1,1-dioxothietan-
3-yl)-5-ethoxy- (4), 3-bromo-1-(1,1-dioxothietan-3-yl)-5-isopropoxy- (5), and 3-bromo-1-(1,1-dioxothietan-
3-yl)-5-phenoxy-1,2,4-triazoles (6), respectively. Compounds 4-6 did not depress the melting points when
mixed with those samples obtained by known methods [1, 4] via oxidation of 3-bromo-1-(thietan-3-yl)-
5-ethoxy-, 3-bromo-5-isopropoxy-1-(thietan-3-yl)- and 3-bromo-1-(thietan-3-yl)-5-phenoxy-1,2,4-triazoles.
Their IR spectra were also in full agreement.
Reaction of compound 1 with 3-methylsulfanyl-1,2,4-triazole (2e) gave only the 1-(1,1-dioxothietan-
3-yl)-3-methylsulfanyl-1,2,4-triazole (7) in 63% yield. The 1H NMR spectrum of compound 7 showed signals in
the regions typical for the thietanedioxide ring [8] and methylsulfanyl residue protons. The singlet for the =CH
proton of the triazole ring was observed at 8.16 ppm, confirming the formation of the 3-methylsulfanyl isomer
[9].
Dioxothietanylation of the 3-methylsulfonyl-1,2,4-triazole (2f) gave a mixture of two compounds:
1-(1,1-dioxothietan-3-yl)-3-methylsulfonyl- (8a) and 1-(1,1-dioxothietan-3-yl)-5-methylsulfonyl-1,2,4-triazoles
(8b). In the 1H NMR spectrum of the isomer mixture the 5-methylsulfonyl isomer has triazole ring =CH proton
singlet at 9.05 ppm, while the singlet for the 3-methylsulfonyl isomer is found at lower field at 9.65 ppm, which
is in agreement with literature data [9, 10]. The ratio of 3-methylsulfonyl- and 5-methylsulfonyl isomers 8a and
8b was judged to be 1:2 from the integrated intensities of the NCH group proton signals.
The reaction of compound 1 with 5-bromo-3-(piperidin-1-yl)-1,2,4-triazole (2g) leads to a mixture of
isomeric 5-bromo-1-(1,1-dioxothietan-3-yl)-3-(piperidin-1-yl)- (9a) and 3-bromo-1-(1,1-dioxothietan-3-yl)-
1
5-piperidin-1-yl)-1,2,4-triazoles (9b). Doubling of the H NMR signals for the thietanedioxide ring and the
piperidine residue in the mixture of compounds 9a and 9b led us to conclude that they are formed in a 2:1 ratio
(according to the integrated intensities). The assignment of the proton signals to the 3- and 5-isomers was made
1
on the basis of H NMR spectrum of the 5-piperidinyl isomer 9b synthesized earlier by treating 3,5-dibromo-
1-(1,1-dioxothietan-3-yl)-1,2,4-triazole with piperidine [1, 9].
Hence the dioxothietanylation occurs regioselectively at the position 2 for the 5-bromo-1,2,4-triazoles
containing ethoxy-, isopropoxy- or phenoxy groups in position 3, but at position 1 of the triazole ring for the
3-methylsulfanyl-1,2,4-triazole. Reactions of 3-methylsulfonyl-1,2,4-triazole and 5-bromo-3-(piperidin-1-yl)-
1,2,4-triazole with 3,5-dibromo-1-(1,1-dioxothietan-3-yl)-1,2,4-triazole occur nonselectively at the positions 1
and 2, to yield the isomeric 3-R-5-R1- and 5-R-3-R1-1-(1,1-dioxothietan-3-yl)-1,2,4-triazoles. The ratio of
isomers depends on the nature of the substituents at positions 3 and 5 of the triazole ring.
1474

EXPERIMENTAL
1
IR spectra were recorded on an Infralum FT-02 instrument for KBr pellets. H NMR spectra were
recorded on a Bruker AM-300 instrument (300 MHz) with the residual solvent signals as standard (7.26 ppm for
CDCl3 and 2.50 ppm for DMSO-d6). Elemental analysis was performed on a Euro3000 Hekatech CHNS-
analyzer. Melting points were determined on a PTP instrument.
3,5-Dibromo-1-(1,1-dioxothietan-3-yl)-1H-1,2,4-triazole (1) was prepared by method [1] and 1-(1,1-di-
oxothietan-3-yl)-1H-1,2,4-triazole (3) by method [5].
Preparation of Compounds 4-7, 9a,b (General Method). Sodium metal (0.08 g, 3.3 mmol) was added
to t-BuOH (30 ml) and heated until evolution of gas bubbles ceased. Compound 2a-g (3.0 mmol) and
3,5-dibromo-1-(1,1-dioxothietan-3-yl)-1H-1,2,4-triazole (1) (0.99 g, 3.0 mmol) were then added. The reaction
mixture was refluxed for 2 h, the solvent was evaporated to dryness in vacuo, and water was added to the
residue. The precipitate was filtered off and dried.
3-Bromo-1-(1,1-dioxothietan-3-yl)-5-ethoxy-1H-1,2,4-triazole (4). Yield 0.57 g (64%); mp
169-170ºC (EtOH) (mp 166-167ºC [1]). The spectroscopic data agreed with the literature [1].
3-Bromo-1-(1,1-dioxothietan-3-yl)-5-isopropoxy-1H-1,2,4-triazole (5). Yield 0.36 g (39%), mp
154-155ºC (EtOH) (mp 150-151.5ºC [1]). IR spectrum, , cm-1: 1295, 1493, 1551 (C=N), 1143, 1342 (SO2). 1H
NMR spectrum (CDCl3), , ppm (J, Hz): 1.41 (6H, d, J = 6.2, CH(CH3)2); 4.40-4.58 (2H, m) and 4.64-4.81 (2H,
m, CH2SCH2); 4.96-5.20 (2H, m, OCH, NCH).
3-Bromo-1-(1,1-dioxothietan-3-yl)-5-phenoxy-1H-1,2,4-triazole (6). A. Yield 0.48 g (46%); mp
1
246-248ºC (n-BuOH). IR spectrum, , cm-1: 1292, 1487, 1528 (C=N, C=C), 1142, 1323 (SO2). H NMR
spectrum (DMSO-d6), , ppm (J, Hz): 4.69-4.89 (4H, m, CH2SCH2); 5.35-5.47 (1H, m, NCH); 7.28-7.35 (1H,
m, H Ph); 7.38-7.43 (2H, m, H Ph), 7.45-7.51 (2H, m, H Ph). Found, %: C 38.45; H 2.81; N 12.18.
C11H10BrN3O3S. Calculated, %: C 38.39; H 2.93; N 12.21.
B. A 37% solution of H2O2 (2.76 g, 30 mmol) was added to a solution of the 3-bromo-1-(thietan-3-yl)-
5-phenoxy-1,2,4-triazole [4] (0.94 g, 3.3 mmol) in glacial acetic acid (7 ml). The reaction mixture was refluxed
for 2 hours and then cooled. The precipitate formed was filtered off and dried. Yield 0.65 g (57%), mp
249-250ºC (n-BuOH). The spectroscopic data agreed with that for compound 6 prepared by method A.
1-(1,1-Dioxothietan-3-yl)-3-methylsulfanyl-1H-1,2,4-triazole (7). Yield 0.41 g (63%); mp 147-148ºC
1
(EtOH). H NMR spectrum (CDCl3), , ppm: 2.62 (3H, s, SCH3); 4.56-4.66 (2H, m) and 4.74-4.83 (2H, m,
CH2SCH2); 5.15-5.25 (1H, m, NCH); 8.16 (1H, s, H-5). Found, %: C 32.87; H 4.19; N 19.33. C6H9N3O2S2.
Calculated, %: C 32.86; H 4.14; N 19.16.
5-Bromo-1-(1,1-dioxothietan-3-yl)-3-(piperidin-1-yl)-1H-1,2,4-triazole (9a) and 3-Bromo-1-(1,1-di-
oxothietan-3-yl)-5-(piperidin-1-yl)-1H-1,2,4-triazole (9b). Yield 0.53 g (53%) as a mixture of compounds 9a
and 9b (isomer ratio 2:1); mp 160-162ºC (EtOH). 1H NMR spectrum (CDCl3), , ppm: 1.55-1.78 (6H, m, 3,4,5-CH2
piperidine (9a+9b)); 3.01-3.12 (1.32H, m, 2,6-CH2 piperidine (9b)); 3.32-3.45 (2.68H, m, 2,6-CH2 piperidine
(9a)); 4.41-4.55 (2H, m) and 4.75-4.91 (2H, m, CH2SCH2 (9a+9b)); 4.96-5.06 (0.33H, m, NCH (9b)); 5.10-
5.21 (0.67H, m, NCH (9a)). Found, %: C 35.90; H 4.55; N 16.69. C10H15BrN4O2S. Calculated, %: C 35.83; H
4.51; N 16.71.
1-(1,1-Dioxothietan-3-yl)-3-methylsulfonyl-1H-1,2,4-triazole (8a) and 1-(1,1-Dioxothietan-3-yl)-
5-methylsulfonyl-1H-1,2,4-triazole (8b). Sodium metal (0.08 g, 3.3 mmol) was added to t-BuOH (40 ml) and
heated until evolution of gas bubbles ceased. 3-Methylsulfonyl-1H-1,2,4-triazole (2f) (0.44 g, 3 mmol),
3,5-dibromo-1-(1,1-dioxothietan-3-yl)-1H-1,2,4-triazole (1) (0.99 g, 3 mmol) and DMF (25 ml) were added,
and the mixture was refluxed for 2 h. The solution was evaporated to dryness in vacuo, and the residue was
treated with water. The precipitate was filtered off and dried. Yield 0.34 g (45%) as a mixture of compounds 8a
1
and 8b (isomer ratio 1:2); mp 163-167ºC (n-BuOH). H NMR spectrum (DMSO-d6), , ppm: 3.38 (0.67H, s,
SO2CH3 (8b)); 3.55 (0.33H, s, SO2CH3 (8a)); 4.65-4.94 (4H, m, CH2SCH2 (8a+8b)); 5.40-5.51 (0.33H, m, NCH
1475

(8a)); 5.51-5.63 (0.67H, m, NCH (8b)); 9.05 (0.67H, s, H-3 (8b)); 9.65 (0.33H, s, H-5 (8a)). Found, %:
C 28.62; H 3.65; N 16.67. C6H9N3O4S2. Calculated, %: C 28.68; H 3.61; N 16.72.
REFERENCES
1.
2.
3.
F. A. Khaliullin and E. E. Klen, Zh. Org. Khim., 45, 138 (2009).
E. E. Klen, F. A. Khaliullin, and G. F. Iskhakova, Zh. Org. Khim., 41, 1881 (2005).
E. E. Klen, I. L. Nikitina, F. A. Khaliullin, G. F. Iskhakova, E. K. Alekhin, and O. A. Ivanova, Vopr.
Biol. Med. i Farm. Khim., No. 7, 42 (2010).
4.
5.
E. E. Klen, N. N. Makarova, F. A. Khaliullin, E. K. Alekhin, I. L. Nikitina, O. A. Ivanova, and
R. A. Gabidullin, Bashk. Khim. Zh., 15, No. 4, 112 (2008).
E. E. Klen, N. N. Makarova, and F. A. Khaliullin, Khim. Geterotsikl. Soedin., 625 (2011). [Chem.
Heterocycl. Compd., 47, 519 (2011)].
6.
7.
F. A. Khaliullin, E. E. Klen, and N. N. Makarova, Zh. Org. Khim., 44, 1729 (2008).
A. N. Butkevich, V. V. Sokolov, A. A. Tomashevskii, and A. A. Potekhin, Khim. Geterotsikl. Soedin.,
655 (2007). [Chem. Heterocycl. Compd., 43, 544 (2007)].
8.
E. Block, in: A. R. Katritzky and C. W. Rees (editors), Comprehensive Heterocyclic Chemistry II, Vol.
7, Elsevier, Oxford, New York (1997), p. 403.
9.
E. E. Klen and F. A. Khaliullin, Zh. Org. Khim., 46, 694 (2010).
10.
V. V. Saraev, T. P. Kanakina, M. S. Pevzner, E. L. Golod, B. I. Ugrak, and V. V. Kachala, Khim.
Geterotsikl. Soedin., 1078 (1996). [Chem. Heterocycl. Compd., 32, 928 (1996)].
1476
