Synthesis of pyrido[3',2':4,5]thieno[3,2-d]-[1,3,2]diazaphosphorine derivatives

Article abstract of DOI:10.1007/s10593-013-1220-6

Refluxing 3-aminothieno[2,3-b]pyridine-2-carboxamides with P ₄S₁₀ in dry pyridine gave the substituted 2-mercapto-2,3-dihydropyrido[3',2':4,5]thieno[3,2-d][1,3,2]diazaphosphorin-4(1H) -one-2-thiones and/or -2,4(1H)-dithiones as 1:1 c

Full text of DOI:10.1007/s10593-013-1220-6

Chemistry of Heterocyclic Compounds, Vol. 48, No. 12, March, 2013 (Russian Original Vol. 48, No. 12, December, 2012)
SYNTHESIS OF PYRIDO[3',2':4,5]THIENO[3,2-d]-
[1,3,2]DIAZAPHOSPHORINE DERIVATIVES
V. V. Dotsenko1* and S. G. Krivokolysko1
Refluxing 3-aminothieno[2,3-b]pyridine-2-carboxamides with P4S10 in dry pyridine gave the substituted
2-mercapto-2,3-dihydropyrido[3',2':4,5]thieno[3,2-d][1,3,2]diazaphosphorin-4(1H)-one-2-thiones
and/or -2,4(1H)-dithiones as 1:1 complexes with pyridine.
Keywords: 1,3,25-diazaphosphorines, tetraphosphorus decasulfide, thieno[2,3-b]pyridines, thiophos-
phorylation.
Thieno[2,3-b]pyridines form a very numerous and accessible group of compounds with a broad
spectrum of useful properties [1-4], which includes anti-inflammatory, antibacterial, anticancer and other types
of activity. In recent times, thieno[2,3-b]pyridines have been actively used in the preparation of condensed
analogs and of different functionalized derivatives [1-4]. 1,3,25-Diazaphosphorines are a relatively little
studied class of compounds [5, 6]. They principally attract interest as aza analogs of known 1,3,2-oxaza-
phosphorine series anticancer drugs (cyclophosphamide, trofosfamide and its derivatives [7-9]). The data
concerning the antitumor activity of 1,3,2-diazaphosphorines [9, 10] points to the possibility of promising
developments in this area. In addition, condensed 1,3,2-diazaphosphorines have been seldom reported in the
literature. Accessible 3-aminothieno[2,3-b]pyridine-2-carboxamides are convenient substrates for
phosphorylation reactions, but similar reactions of thienopyridines have not been described, and phosphorus
containing thieno[2,3-b]pyridine derivatives have not been reported to the current time.
R2
R2
SH
P
R1
R1
· Py
H
NH2
N
S
0.25–2.00 equiv. P4S10
NH
NH2
Py, 
R
R
N
N
S
1a–d
S
X
O
2, 3 a–d
1–3 a R+R1 = (CH2)3, R2 = 2-furyl; b R+R1 = (CH2)4, R2 = 4-BnOC6H4;
c R+R1 = (CH2)4, R2 = H; d R = R2 = Me, R1 = H; 2a–d X = O, 3a–d X = S
_______
*To whom correspondence should be addressed, e-mail: victor_dotsenko@bigmir.net.
1"ChemEx" Laboratory, Vladimir Dal' East Ukrainian National University, 20-A/7 Molodyozhnyi Kv, Lugansk
91034, Ukraine.
________________________________________________________________________________________
Translated from Khimiya Geterotsiklicheskikh Soedinenii, No. 12, pp. 1987-1991, December, 2012.
Original article submitted June 25, 2012.
0009-3122/13/4812-1863©2013 Springer Science+Business Media New York
1863

We have found that the 3-aminothienopyridine-2-carboxamides 1a,b,d are readily thiophosphorylated
using 0.25 equivalents of P4S10 in refluxing absolute pyridine, to form the tetrahydropyrido[3',2':4,5]thieno-
[3,2-d][1,3,2]diazaphosphorines 2a,b,d, representing a novel heterocyclic system. The reaction was not
conducted with compound 1c under these conditions.
Using an excess of P4S10 led to a mixture of compounds 2a-d and the thionation products 3a-d in
variable proportions. It should be noted that the thiophosphorylation of ortho-aminocarboxamides with excess
P4S10 was almost always accompanied by full thionation, and products with a carbonyl function were very rarely
found [11]. Full thionation in this case clearly required the use of at least equimolar amount of P4S10.
Compounds 2, 3a-d form stable 1:1 solvates with pyridine, which agrees well with known data for
benzo[1,3,2]diazaphosphorine derivatives [12]. Compounds 2, 3a-d are insoluble in ether and acetone, poorly
soluble in pyridine, cold water, and ethanol, but soluble in DMSO and in hot water.
Hence treatment of 3-aminothieno[2,3-b]pyridine-2-carboxamides with P4S10 in pyridine opens up
possibilities for preparing pyrido[3',2':4,5]thieno[3,2-d][1,3,2]diazaphosphorine derivatives. The use of an
excess of P4S10 also provides an option for thionation of the substrate carbonyl group.
EXPERIMENTAL
1
The H NMR spectra were recorded on Bruker DPX-400 (400 MHz) and DRX-500 (500 MHz)
instruments using DMSO-d6 with TMS as internal standard. The 13C NMR spectra were recorded in
heteronuclear decoupling mode on a Bruker DRX-500 (125 MHz) instrument using DMSO-d6 with TMS as
31
internal standard. The P NMR spectra were recorded on a Varian VXR-300 (121 MHz) using 85% H3PO4 as
external standard. HPLC-MS analysis was performed for compounds 2a and 3c using an Agilent 1100
chromato-mass spectrometer with diode array (UV, 215, 254, and 265 nm) and Agilent LC/MSD SL mass
selective detectors with a Zorbax SB-C18 analytical column and with electrospray ionization at atmospheric
pressure. HPLC-MS analysis of compounds 2b,d and the mixtures of compounds 2b+3b and 2d+3d was
performed on a Shimadzu LC-10AD liquid chromatograph with Shimadzu SP D-10A UV-Vis (254 nm) and
Sedex 75 ELSD detectors combined with a PE SCIEX API 150EX mass spectrometer. Elemental analysis was
carried out using a Carlo-Erba 1106 Elemental Analyzer. Melting points were determined on a Kofler hot stage
apparatus, and were not corrected. The purity of the obtained compounds was monitored on Silufol UV-254
plates with acetone–hexane (1:1) as eluent and visualized using UV light and iodine vapor. Compounds 1c,d
have been reported in the literature [13, 14] and were prepared by alkylation of the corresponding 3-cyano-
pyridine-2(1H)-thiones with 2-chloroacetamide with subsequent Thorpe–Ziegler cyclization of the S-alkyl
derivatives using KOH in DMF.
3-Amino-4-(2-furyl)-6,7-dihydro-5H-cyclopenta[b]thieno[3,2-e]pyridine-2-carboxamide (1a). A 10%
aqueous KOH solution (2.3 ml, 4.40 mmol) was added to a suspension of the 4-(2-furyl)-2-thioxo-2,5,6,7-tetra-
hydro-1H-cyclopenta[b]pyridine-3-carbonitrile [15] (1.0 g, 4.13 mmol) in DMF (5 ml) and stirred at 70-80°C to
full dissolution. 2-Chloroacetamide (0.4 g, 4.28 mmol) was added as a single aliquot to this solution, stirred for
30 min at 25°C, and heated to reflux. A further amount of the 10% aqueous KOH (2.3 ml, 4.40 mmol) was
added, and the obtained mixture was refluxed with stirring for 2-3 min, cooled, diluted with EtOH (10 ml), and
left overnight. The precipitate that formed was filtered off and washed with EtOH and water. Yield 0.8 g (65%).
1
Fine, yellow-brown crystals. Mp >260ºC (decomp.). H NMR spectrum (400 MHz), , ppm (J, Hz): 2.07-2.12
(2Н, m, СН2); 2.90-2.94 (2Н, m, СН2); 3.04-3.08 (2Н, m, СН2); 6.34 (2H, br. s, NН2); 6.77-6.80 (1H, m, Н-4
Fur); 6.91 (1Н, br. d, J = 2.5, Н-3 Fur); 7.20 (2H, br. s, CONH2); 7.98 (1H, m, Н-5 Fur). Found, %: C 60.34;
H 4.30; N 14.19. C15H13N3O2S. Calculated, %: C 60.19; H 4.38; N 14.04.
3-Amino-4-[4-(benzyloxy)phenyl]-5,6,7,8-tetrahydrothieno[2,3-b]quinoline-2-carboxamide
(1b)
was prepared by modification of method [16]. A suspension of the 4-[4-(benzyloxy)phenyl]-2-thioxo-
1,2,5,6,7,8-tetrahydroquinoline-3-carbonitrile (1.00 g, 2.69 mmol) in DMF (6 ml) was treated with 10%
1864

aqueous KOH (1.5 ml, 2.89 mmol), and 2-chloroacetamide (0.26 g, 2.78 mmol) was added to the solution
obtained. The suspension of the S-alkylated derivative was stirred for 1 h at 40°C, a further 10% aqueous KOH
(1.5 ml) was added, and the mixture was refluxed with stirring for 3 min. The reaction mixture was maintained
for 24 h at 20°C, the precipitate formed was filtered off and washed successively with EtOH, water, EtOH, and
Et2O. Yield 1.06 g (93%). Light-yellow powder. Mp 248-250°C. 1H NMR spectrum (400 MHz), , ppm (J, Hz):
1.65-1.69 (2Н, m, СН2); 1.77-1.84 (2Н, m, СН2); 2.34-2.37 (2Н, m, СН2); 2.95-2.99 (2Н, m, СН2); 5.18 (2H,
br. s, OCH2); 5.62 (2H, br. s, NH2); 7.07 (2H, br. s, CONH2); 7.20 (2H, d, J = 8.7, H Ar); 7.26 (2H, d, J = 8.7,
H Ar); 7.34-7.38 (1H, m, Н-4 Ph); 7.42 (2H, dd, J = 7.3, J = 7.3, Н-3,5 Ph); 7.50 (2H, d, J = 7.3, Н-2,6 Ph).
Found, %: C 70.04; H 5.47; N 9.89. C25H23N3O2S. Calculated, %: C 69.91; H 5.40; N 9.78.
Synthesis of Tetrahydropyrido[3',2':4,5]thieno[3,2-d][1,3,2]diazaphosphorines 2, 3 (General
Method). Finely powdered thienopyridine 1a-d (1-3 mmol) was dissolved with heating in absolute pyridine
(4-5 ml). The indicated amount of P4S10 was added in one aliquot to the solution obtained. The reaction mixture
was refluxed for 1 h. Generally, even after 5-7 min a yellow, crystalline product began to precipitate. The
suspension was cooled, poured into EtOH (15-20 ml), stirred for 3 h, filtered, and repeatedly washed with EtOH
and acetone.
10-(2-Furyl)-2-mercapto-2-thioxo-2,3,8,9-tetrahydrocyclopenta[5',6']pyrido[3',2':4,5]thieno[3,2-d]-
[1,3,2]diazaphosphorin-4(1H)-one, 1:1 Complex with Pyridine (2a). Obtained from the thienopyridine 1a
(563 mg, 1.88 mmol) and P4S10 (210 mg, 0.47 mmol). Yield 443 mg (50%). Yellow-brown, fine crystalline
1
powder. Mp >250ºC (decomp.). H NMR spectrum (500 MHz), , ppm (J, Hz): 2.08-2.18 (2Н, m, СН2);
2.98-3.12 (4Н, m, 2СН2); 6.86-6.91 (1H, m, Н-4 Fur); 7.03-7.08 (2Н, m, Н-3 Fur, 1-NН); 7.73 (2Н, dd, J = 7.5,
J = 5.0, H-3,5 Py); 8.04-8.10 (1H, m, Н-5 Fur); 8.20 (1Н, dt, J = 7.5, J = 1.7, H-4 Py); 8.75 (2H, br. d, J = 5.0, H-2,6
Py); 9.97 (1H, d, JH–P = 13.1, 3-NН). Signals for the SH protons were not observed, probably because of
deuterium exchange. 13C NMR spectrum, , ppm: 23.4 (С-8); 30.8 (С-9); 34.5 (С-7); 108.8 (C Ar); 113.8
(C Ar); 114.8 (C Ar); 127.3 (C-3,5 Py); 130.0 (C Ar); 133.4 (C-4 Py); 138.8 (C Ar); 143.6 (C-2,6 Py); 145.2
(C Ar); 145.6 (C Ar); 147.4 (C Ar); 150.8 (C Ar); 160.4 (C Ar); 161.5 (C Ar); 167.5 (C=O). 31P NMR spectrum
(DMSO-d6), , ppm (J, Hz): 78.9 (dd, JP–H = 8.9, JP–H = 13.1). Mass spectrum, m/z: 394.0 [М-Py+H]+, 392.0
[М-Py-H]-. Found, %: C 51.06; H 3.70; N 11.99. C20H17N4O2PS3. Calculated, %: C 50.84; H 3.63; N 11.86.
According to the HPLC-MS data, the purity was 94.5%. The product contained an impurity of the
starting compound 1a (m/z 300.2 [M+H]+) and the thionation product 10-(2-furyl)-2-mercapto-2,3,8,9-tetra-
hydrocyclopenta[5',6']pyrido[3',2':4,5]thieno[3,2-d][1,3,2]diazaphosphorine-2,4(1H)-dithione (3a) (1:1
complex with pyridine) (m/z 410.0 [M-Py+H]+, 407.8 [M-Py-H]-).
11-[4-Benzyloxy)phenyl]-2-mercapto-2-thioxo-2,3,7,8,9,10-hexahydro[1,3,2]diazaphosphorino-
[4',5':4,5]thieno[2,3-b]quinolin-4(1H)-one, 1:1 Complex with Pyridine (2b). Obtained from the thieno-
pyridine 1b (421 mg, 1.02 mmol) and P4S10 (113 mg, 0.26 mmol). Yield 213 mg (38%). Yellow crystals. Mp
1
225-240°C (decomp.). H NMR spectrum (500 MHz), , ppm (J, Hz): 1.66-1.70 (2Н, m, СН2); 1.79-1.84 (2Н,
m, СН2); 2.39-2.42 (2Н, m, СН2); 2.98-3.01 (2Н, m, СН2); 5.06 (1H, d, JH–P = 12.6, NН-1); 5.22 (2H, br. s,
3
3
OCH2); 7.26 (2H, d, J = 8.7, H Ar); 7.30 (2H, d, J = 8.7, H Ar); 7.36 (1H, t, 3J = 7.3, H-4 Ph); 7.43 (2Н, dd,
3J = 7.3, J = 7.3, H-3,5 Ph); 7.52 (2H, d, J = 7.3, H-2,6 Ph); 8.00 (2Н, dd, J = 7.9, J = 6.7, H-3,5 Py); 8.52
(1H, t, J = 7.9, H-4 Py); 8.89-8.93 (3H, m, 3-NН, H-2,6 Py). Signals for the SH protons were not observed,
probably because of deuterium exchange. 13C NMR spectrum, , ppm: 22.7, 22.8 (С-8,9); 26.7 (С-10); 33.6
(С-7); 70.1 (OCH2); 108.4 (C Ar); 115.8 (C Ar); 116.2 (C Ar); 126.4 (C-3,5 Py); 126.6 (C Ar); 128.2 (C Ar);
128.3 (C Ar); 128.4 (2C Ar); 129.0 (C Ar); 130.2 (C Ar); 130.4 (C-4 Py); 137.2 (C Ar); 142.6 (C Ar); 145.6
(C Ar); 145.7 (C-2,6 Py); 157.9 (C Ar); 159.4 (C Ar); 161.2 (C=O). 31P NMR spectrum (DMSO-d6), , ppm
3
3
(J, Hz): 80.1 (dd, JP–H = 12.6, JP–H = 13.4). Mass spectrum, m/z: 524.3 [M-Py+H]+, 1046.8 [2M-2Py+H]+.
3
3
Found, %: C 60.06; H 4.60; N 9.49. C30H27N4O2PS3. Calculated, %: C 59.78; H 4.52; N 9.30.
Using a 1.5-fold excess of P4S10 (170 mg, 0.38 mmol) gave a mixture (288 mg), which according to
1
HPLC-MS and H NMR spectroscopy contains compounds 2b and 11-[4-(benzyloxy)phenyl]-2-mercapto-
2,3,7,8,9,10-hexahydro[1,3,2]diazaphosphorino[4',5':4,5]thieno[2,3-b]quinoline-2,4(1H)-dithione (3b) in
1865

~4:1 ratio. Compound 3b (as 1:1 complex with pyridine) was identified from the minor peaks in the 1H, 13C, and
31P NMR spectra. 1H NMR spectrum (500 MHz), , ppm (J, Hz): 5.38 (1H, d, 3JH–P = 13.1, 1-NH); 10.47 (1H, d,
3JH–P = 15.6, 3-NH). 13C NMR spectrum, , ppm: 194.6 (C=S). 31P NMR spectrum (DMSO-d6), , ppm (J, Hz):
73.7 (dd, 3JP–H = 13.1, 3JP–H = 15.6). Mass spectrum, m/z: 540.0 [M-Py+H]+.
2-Mercapto-7,9-dimethyl-2-thioxo-2,3-dihydropyrido[3',2':4,5]thieno[3,2-d][1,3,2]diazaphosphorin-
4(1H)-one, 1:1 Complex with Pyridine (2d). Obtained from the thienopyridine 1d (625 mg, 2.82 mmol) and
P4S10 (314 mg, 0.71 mmol). Yield 591 mg (53%). Yellow-green, fine crystalline powder. Mp >300°C (decomp.).
1H NMR spectrum (400 MHz), , ppm (J, Hz): 2.54 (3Н, s, СН3); 2.76 (3Н, s, СН3); 7.13 (1Н, s, Н-8); 7.53 (2Н,
ddd, J = 7.5, J = 5.8, J = 1.7, H-3,5 Py); 7.95 (1Н, dt, J = 7.5, J = 1.3, H-4 Py); 8.56 (1H, d, JH–P = 12.1, 1-NН);
8.61 (2H, dd, J = 5.8, J = 1.3, H-2,6 Py); 10.04 (1H, d, JH–P = 15.8, 3-NН). Signals for the SH protons were not
observed, probably because of deuterium exchange. 31P NMR spectrum (D2O), , ppm (J, Hz): 79.7 (dd, JP–H = 11.1,
JP–H = 15.8). Mass spectrum, m/z: 316.0 [M-Py+H]+, 631.0 [2M-2Py+H]+, 945.8 [3M-3Py+H]+. Found, %:
C 45.96; H 3.80; N 14.48. C15H15N4OPS3. Calculated, %: C 45.67; H 3.83; N 14.20.
The use of 2.0 equivalents of P4S10 (625 mg, 1.41 mmol) gave a mixture (490 mg), which according to
1
HPLC-MS and H NMR spectroscopy consisted of compound 2d and 2-mercapto-7,9-dimethyl-2,3-dihydro-
pyrido[3',2':4,5]thieno[3,2-d][1,3,2]diazaphosphorine-2,4(1H)-dithione (3d) in a ~6:1 ratio. Compound 3d
(as a 1:1 pyridine complex) was identified from the minor peaks. 1H NMR spectrum (400 MHz), , ppm (J, Hz):
2.73 (3H, s, CH3); 7.11 (1H, s, H-8); 8.15 (1H, br. pseudo-s, 1-NH); 11.10 (1H, br. pseudo-s, 3 NH). Mass
spectrum, m/z: 332.0 [M-Py+H]+, 665.3 [2M-2Py+H]+.
2-Mercapto-2,3,7,8,9,10-hexahydro[1,3,2]diazaphosphorino[4',5':4,5]thieno[2,3-b]quinoline-
2,4(1H)-dithione, 1:1 Complex with Pyridine (3c). Obtained from the thienopyridine 1c (340 mg,
1.38 mmol) and P4S10 (611 mg, 1.38 mmol). Yield 455 mg (79%). Dark-yellow, fine crystalline powder. Mp
>250°C (decomp.). 1H NMR spectrum (500 MHz), , ppm (J, Hz): 1.78-1.94 (4Н, m, 8,9-СН2); 2.86-2.98 (4Н, m,
7,10-СН2); 7.39-7.50 (3H, m, H-11, H-3,5 Py); 7.87 (1H, t, 3J = 8.3, H-4 Py); 8.23 (1H, d, JH–P = 13.2, 1-NН); 8.61
(2H, br. d, H-2,6 Py). Signals for the SH and 3-NH protons were not observed, probably because of deuterium
exchange. 13C NMR spectrum, , ppm: 22.7, 22.8 (С-8,9); 28.8 (С-10); 30.1 (С-7); 125.2 (C-3,5 Py); 126.0 (C Ar);
129.3 (C Ar); 132.5 (C Ar); 134.8 (C Ar); 137.4 (C Ar); 138.9 (C-4 Py); 148.3 (C-2,6 Py); 151.4 (C Ar); 159.8
(C Ar); 215.6 (C=S). 31P NMR spectrum (DMSO-d6), , ppm (J, Hz): 73.7 (dd, JP–H = 13.2, JP–H = 15.6). Mass
spectrum, m/z: 358.0 [М-Py+H]+, 356.0 [М-Py-H]-. Found, %: C 47.03; H 4.01; N 12.98. C17H17N4PS4.
(M 436.58). Calculated, %: C 46.77; H 3.92; N 12.83.
According to HPLC-MS data, the purity of the obtained compound 3c was ~96%. The product
contained an impurity (~4%) of the 2-mercapto-2-thioxo-2,3,7,8,9,10-hexahydro[1,3,2]diazaphosphorino-
[4',5':4,5]thieno[2,3-b]quinolin-4(1H)-one (2c) (1:1 complex with pyridine). Mass spectrum, m/z: 342.0
[M-Py+H]+, 339.8 [M-Py-H]+.
REFERENCES
1.
2.
V. P. Litvinov, V. V. Dotsenko, and S. G. Krivokolysko, Izv. Akad. Nauk, Ser. Khim., 847 (2005).
V. P. Litvinov, V. V. Dotsenko, and S. G. Krivokolysko, Chemistry of Thienopyridines and Related
Systems [in Russian], Nauka, Russian Academy of Sciences, Moscow (2006), p. 6.
E. A. Bakhite, Phosphorus, Sulfur Silicon Relat. Elem., 178, 929 (2003).
V. P. Litvinov, V. V. Dotsenko, and S. G. Krivokolysko, in: A. R. Katritzky (editor), Advances in
Heterocyclic Chemistry, Vol. 93, Academic Press (2007), p. 117.
3.
4.
5.
K. Gholivand, Z. Shariatinia, F. Afshar, H. Faramarzpour, and F. Yaghmaian, Main Group Chem., 6,
231 (2007).
6.
7.
Z. Zalan, T. A. Martinek, L. Lázár, and F. Fülöp, Tetrahedron, 59, 9117 (2003).
T. Martinek, E. Forró, G. Günther, R. Sillanpää, and F. Fülöp, J. Org. Chem., 65, 316 (2000).
1866

8.
9.
Z. Fei, I. Neda, H. Thonnessen, P. G. Jones, and R. Schmutzler, Phosphorus, Sulfur Silicon Relat.
Elem., 131, 1 (1997).
K. Gholivand, F. Ghaziani, Z. Shariatinia, N. Dorosti, M. Mirshahi, and S. Sarikhani, Med. Chem. Res.,
21, 2185 (2012).
10.
11.
12.
J. H. Billman, J. L. Meisenheimer, and R. F. May, J. Med. Chem., 9, 772 (1966).
D. B. Nilov and V. G. Granik, Mendeleev Commun., 13, 78 (2003).
R. M. Acheson, C. T. Lines, M. R. Bryce, Z. Dauter, C. D. Reynolds, and A. Schmidpeter, J. Chem.
Soc., Perkin Trans. 2, 1913 (1985).
13.
14.
15.
16.
G. Wagner, H. Vieweg, S. Leistner, N. Boehm, U. Krasselt, V. Hanfeld, J. Prantz, and R. Gruppe,
Pharmazie, 45, 102 (1990).
A. M. Kamal El-Dean, R. Shaker, A. A. Abo El-Hassan, and F. F. Abdel Latif, J. Chin. Chem. Soc., 51,
335 (2004).
V. P. Litvinov, V. K. Promonenkov, Yu. A. Sharanin, A. M. Shestopalov, L. A. Rodinovskaya,
V. Yu. Mortikov, and V. S. Bogdanov, Izv. Akad. Nauk SSSR, Ser. Khim., 2101 (1985).
H. Vieweg, S. Leistner, and G. Wagner, Pharmazie, 43, 358 (1988).
1867
