ACS Catalysis
Letter
and 20 mol % thiophenol as a hydrogen atom donor in DCE,
furnishing the desired addition product in good yields (see S9
for full optimization details).
trans diastereomer was isolated and carried through a three-
step sequence to give the final orexin antagonist, 5c.
Though preliminary, we propose that the mechanism for
dehydrogenation commences with a photoinduced electron
transfer event (PET) between nitrate anion (Eox= +1.97 V vs
SCE)48,52 and Mes-Acr-BF4* (+ 2.10 V vs SCE), leading to
the formation of nitryl radical.53 The radical then abstracts a
hydrogen atom from the α-piperidinyl C−H position. Either
an inner sphere or outer sphere oxidation of the α-amino
radical by Cu(II) affords the desired ene-carbamate. The
reduced catalyst, Mes-Acr•, is oxidized by an additional
equivalent of Cu(II) acetate to turn over the catalytic cycle and
produce Cu(I). Substoichiometric use of copper acetate was
found to be optimal in these reactions. Disproportionation of
Cu(I) to Cu(0) and Cu(II) or by oxidation of Cu(I) by Mes-
Acr-BF4* could be the mechanism whereby the required
Cu(II) species is regenerated.54 The hydrofunctionalization
begins by an oxidation of the ene-carbamate from Mes-Acr-
BF4*. We have studied the mechanism of alkene anti-
Markovnikov hydrofunctionalization and invoke a similar
mechanism in this instance.39,55 Since both transformations
utilize the same photooxidation catalyst, we attempted a one-
pot direct C−H functionalization; however, only α-substituted
adducts were observed. We believe this is likely attributed to a
copper-mediated coupling of the nucleophile with the α-radical
that is formed. Studies to achieve this one-pot transformation
are ongoing.
In conclusion, we have developed a two-step protocol for the
synthesis of β-functionalized aza-heterocycles using an
acridinium salt as the photooxidant. First, a copper-mediated
photoredox-catalyzed dehydrogenation of saturated aza-hetero-
cycles provides access to an array of ene-carbamates. A
subsequent photoredox-catalyzed hydrofunctionalization of the
ene-carbamates produces a range of C−O, C−C, and C−N β-
substituted aza-heterocycles. We anticipate this route will
greatly simplify the synthesis of hetero β-substituted aza-
heterocycles, which we hope will find utility for the rapid
synthesis of bioactive molecules.
Examining the scope of this transformation, we observed
that both N-Cbz and N-Boc ene-carbamates yielded the
acetylated products 2a and 2b in moderate to good yields
(Chart 2). In addition to piperidine, the corresponding
pyrrolidine and azepine ene-carbamates produced the desired
acetylated products 2c and 2d, respectively. Alkylated
piperidines substituted at positions 2−4 yielded the benzoy-
lated products 2e−2h as a mixture of diastereomers with little
relative stereocontrol. Interestingly, 5-methyl-3,4-dihydropyr-
idine afforded the quaternary β-functionalized piperidine 2h,
despite this being the more substituted position of the alkene,
albeit in lower yield.
A variety of oxygen, nitrogen, and carbon nucleophiles were
also assessed in this reaction (Chart 2). Cyanide and azide
nucleophiles (TMSCN and TMSN3, respectively) produced
the desired β-cyano or azido aza-heterocycles 3a and 3b in
good and moderate yields, respectively. The β-trifluormethy-
lated adduct, 3c, was isolated in 45% yield using the Langlois
reagent; however, some α-functionalization was also observed
(22% yield). Carboxylic acids such as benzoic acid and N-Boc
phenylalanine were also found to be suitable nucleophilic
partners, affording 3d−3e in good yields. Azole-derived
nucleophiles gave the heterocyclic products 3f−3h in 31−
36% yields. Primary amines were effective reaction partners,
producing the β-aminated products, 3i and 3j, in modest
yields. Amino acids such as phenylalanine can add either via N-
or O- simply by selection of the protecting groups, furnishing
either the aminated or acetylated products, 3j and 3e, but
unfortunately, the resident amino acid chirality does not
control stereoselectivity in the addition step. The direct β-
amine product, 3k, can be synthesized using ammonium
carbamate as the source of amine. Trifluoromethyl and methyl
sulfonamide derivatives were also competent nucleophiles
giving the desired products 3l and 3m in moderate yields.
Finally, pharmaceutical-derived nucleophiles successfully
underwent the β-amination and acetylation with Rimantidine
and Gabapentin derivatives 3n and 3o, respectively. With this
methodology, a besifloxacin precursor, 3p, was formed from
the azepine with ammonium carbamate in good yield.
With a two-step procedure for the β-functionalization of
saturated aza-heterocycles defined, we sought to demonstrate
the utility of this sequence for the synthesis of active
pharmaceutical intermediates. A 2016 patent from Merck
examined orexin antagonists synthesized via nucleophilic
substitution of 3-hydroxypiperidines which gave access to β-
pyrazole substituted benzoyl piperidine derivatives.50,51 The
synthesis of these derivatives would be greatly simplified using
the two-step dehydrogenation and β-functionalization se-
quence, which would begin with the simple methyl substituted
piperidine rather than the prefunctionalized 2-methyl-3-
hydroxypiperidine. Subjecting (R)-(2-methylpiperidin-1-yl)-
(phenyl)methanone to the copper mediated dehydrogenation
gave the desired ene-carbamate, 4a, in 25% yield. The
photoredox-catalyzed hydrofunctionalization of the ene-
carbamate with 2-(1H-pyrazol-4-yl)propan-2-ol as the nucle-
ophile gave the desired product, 4b, as a mixture of 2:1 trans:cis
diastereomers in two steps. A related orexin antagonist, 5c, was
prepared in five steps through hydrofunctionalization of 5a
with methyl 1H-pyrazole-4-carboxylate which gave a 2:1
mixture of trans:cis diastereomers of 5b in 63% yield. The
ASSOCIATED CONTENT
■
sı
* Supporting Information
The Supporting Information is available free of charge at
1
Experimental procedures and supporting H and 13C
AUTHOR INFORMATION
■
Corresponding Author
David A. Nicewicz − Department of Chemistry, University of
North Carolina at Chapel Hill, Chapel Hill, North Carolina
Authors
Natalie Holmberg-Douglas − Department of Chemistry,
University of North Carolina at Chapel Hill, Chapel Hill,
North Carolina 27599-3290, United States
Younggi Choi − Alkermes, Inc, Waltham, Massachusetts
02451-1420, United States
Brian Aquila − Alkermes, Inc, Waltham, Massachusetts
02451-1420, United States
3156
ACS Catal. 2021, 11, 3153−3158
