Chemistry - A European Journal
10.1002/chem.201603955
COMMUNICATION
[2]
a) J. Charpentier, N. Früh, A. Togni, Chem. Rev. 2014, 115, 650-
682; b) Y. Li, D. P. Hari, M. V. Vita, J. Waser, Angew. Chem. Int.
Ed. 2016, 55, 4436-4454; c) E. A. Merritt, B. Olofsson, Angew.
Chem. Int. Ed. 2009, 48, 9052-9070; d) M. S. Yusubov, A. V.
Maskaev, V. V. Zhdankin, ARKIVOC 2011, (i), 370-409; e) B.
Olofsson, Top. Curr. Chem. 2016, 373, 135-166; f) V. V. Zhdankin,
Hypervalent Iodine Chemistry, Wiley, Chichester, UK, 2014.
M. Ochiai, T. Sueda, K. Miyamoto, P. Kiprof, V. V. Zhdankin,
Angew. Chem. Int. Ed. 2006, 45, 8203-8206.
a) P. Eisenberger, S. Gischig, A. Togni, Chem. Eur. J. 2006, 12,
2579-2586; b) V. V. Zhdankin, C. J. Kuehl, A. P. Krasutsky, M. S.
Formaneck, J. T. Bolz, Tetrahedron Lett. 1994, 35, 9677-9680.
a) J. P. Brand, J. Charpentier, J. Waser, Angew. Chem. Int. Ed.
2009, 48, 9346-9349; b) R. Frei, J. Waser, J. Am. Chem. Soc.
2013, 135, 9620-9623; c) R. Frei, T. Courant, M. D. Wodrich, J.
Waser, Chem. Eur. J. 2015, 21, 2662 – 2668.
a) D. Holt, M. J. Gaunt, Angew. Chem. Int. Ed. 2015, 54, 7857-
7861; b) M. G. Suero, E. D. Bayle, B. S. L. Collins, M. J. Gaunt, J.
Am. Chem. Soc. 2013, 135, 5332-5335; c) E. Cahard, N.
Bremeyer, M. J. Gaunt, Angew. Chem. Int. Ed. 2013, 52, 9284-
9288; d) E. Skucas, D. W. C. MacMillan, J. Am. Chem. Soc. 2012,
134, 9090-9093.
M. Ochiai, J. Organomet. Chem. 2000, 611, 494-508.
a) T. Kitamura, T. Fukuoka, Y. Fujiwara, Synlett 1996, 659-660; b)
R. Frei, M. D. Wodrich, D. P. Hari, P.-A. Borin, C. Chauvier, J.
Waser, J. Am. Chem. Soc. 2014, 136, 16563-16573; During the
submission of this manuscript, a Pd-catalyzed addition to EBX-
type reagents to form VBX products appeared, see: c) J. Wu, X.
Deng, H. Hirao, N. Yoshikai, J. Am. Chem. Soc. 2016, 138, 9105-
9108.
a) M. Bielawski, J. Malmgren, L. M. Pardo, Y. Wikmark, B.
Olofsson, ChemistryOpen 2014, 3, 19-22; b) M. J. Bouma, B.
Olofsson, Chem. Eur. J. 2012, 18, 14242-14245; c) E. A. Merritt, V.
M. T. Carneiro, L. F. Silva, Jr., B. Olofsson, J. Org. Chem. 2010,
75, 7416-7419; d) M. Zhu, N. Jalalian, B. Olofsson, Synlett 2008,
2008, 592-596; e) M. Bielawski, D. Aili, B. Olofsson, J. Org. Chem.
2008, 73, 4602-4607; f) M. Bielawski, M. Zhu, B. Olofsson, Adv.
Synth. Catal. 2007, 349, 2610-2618; g) M. Bielawski, B. Olofsson,
Chem. Commun. 2007, 2521-2523; h) E. A. Merritt, B. Olofsson,
Eur. J. Org. Chem. 2011, 3690-3694.
M. Ochiai, M. Toyonari, T. Nagaoka, D.-W. Chen, M. Kida,
Tetrahedron Lett. 1997, 38, 6709-6712.
M. Ochiai, K. Sumi, Y. Takaoka, M. Kunishima, Y. Nagao, M. Shiro,
E. Fujita, Tetrahedron 1988, 44, 4095-4112.
T. M. Kasumov, N. S. Pirguliyev, V. K. Brel, Y. K. Grishin, N. S.
Zefirov, P. J. Stang, Tetrahedron 1997, 53, 13139-13148.
J. P. Brand, J. Waser, Synthesis 2012, 1155-1158.
calculated using 1,3,5-trimethoxybenzene as internal standard, n.d. = not
detected. [c] See SI for details. [d] 2 equiv. DPE added.
The change in product distribution indicates a mechanistic
difference between reactions with VBX 6a and acyclic salt 7.
Styryliodonium salt 7 has been used in metal-free reactions to
deliver internal alkenes by thermal solvolysis with acetic
acid.[2d,30] The formation of terminal alkenes has been reported in
halogenations of 7, and was assumed to proceed via addition of
HBr to in situ formed phenylacetylene.[31] This type of
mechanism seems unlikely in reactions with nitrocyclohexane,
and we are currently investigating the mechanism of the reaction.
[3]
[4]
[5]
[6]
In conclusion,
a straightforward one-pot synthesis of
vinylbenziodoxolones (VBX) has been developed. The cyclic
structure is supported by X-ray analysis of the styrylbenz-
iodoxolone 6a. A preliminary study into the reactivity of this
novel class of vinylation reagents showed that reaction between
VBX and nitrocyclohexane result in regioselective formation of
terminal alkene 9, which is opposite to the regioselectivity
observed with acyclic vinyliodonium salt 7. The unusual product
distribution indicates a different mechanistic pathway, which is
currently under investigation in our lab. The related ethynyl-
benziodoxolones (EBX) have recently proven superior to acyclic
alkynyliodonium salts in several applications, and the VBX
reagents are currently being explored as powerful reagents in
organic synthesis.
[7]
[8]
[9]
Experimental Section
[10]
[11]
[12]
Synthesis of Vinylbenziodoxolones 6
2-Iodobenzoic acid 1 (99.0 mg, 0.40 mmol, 1 equiv) was added to a
microwave vial. CH2Cl2 (2 mL) was added, followed by mCPBA (0.44
mmol, 1.1 equiv). The mixture was cooled to 0 °C and TfOH (0.40-0.60
mmol, 1-1.5 equiv) was added. The solution was stirred at RT for 15 min,
and then cooled down to 0 °C. The boronic acid 2 (0.56-0.80 mmol, 1.4-
2.0 equiv) was added in one portion and rinsed down with CH2Cl2 (0.5
mL) and the mixture was left to stir at RT or 50 °C for 1-3 h. Saturated
NaHCO3 (2 mL) was then added and the mixture was stirred vigorously
at RT for 1 h. The reaction mixture was diluted with CH2Cl2 and H2O and
the layers were separated. The aqueous phase was extracted with
CH2Cl2 and the combined organic phases were washed with water and
brine. The solution was dried over Na2SO4, filtered and concentrated.
After precipitation with Et2O the formed solid was filtered off and washed
with Et2O to obtain vinylbenziodoxolone 6 as a white solid.
[13]
[14]
[15]
For details, see the Supporting Information.
The cyclization to 6a proved highly efficient despite that
vinyl(aryl)iodonium salts are known to be easily deprotonated even
by weak bases, see: M. Ochiai, K. Uemura, Y. Masaki, J. Am.
Chem. Soc. 1993, 115, 2528-2529.
A. R. Katritzky, J. K. Gallos, H. D. Durst, Magn. Reson. Chem.
1989, 27, 815-822.
a) L. I. Dixon, M. A. Carroll, T. J. Gregson, G. J. Ellames, R. W.
Harrington, W. Clegg, Org. Biomol. Chem. 2013, 11, 5877-5884; b)
P. D. Chaudhuri, R. Guo, H. C. Malinakova, J. Organomet. Chem.
2008, 693, 567-573.
V. V. Zhdankin, C. J. Kuehl, A. P. Krasutsky, J. T. Bolz, A. J.
Simonsen, J. Org. Chem. 1996, 61, 6547-6551.
[16]
[17]
[18]
[19]
CCDC 1481493 contains the supplementary crystallographic data
for this paper. These data can be obtained free of charge from The
Cambridge Crystallographic Data Centre.
[20]
[21]
M. S. Yusubov, R. Y. Yusubova, V. N. Nemykin, V. V. Zhdankin, J.
Org. Chem. 2013, 78, 3767-3773.
Acknowledgements
The trans influence is correlated to the Hammett inductive constant,
which is similar for vinyl and phenyl groups, see ref 3 and a) P. K.
Sajith, C. H. Suresh, Inorg. Chem. 2013, 52, 6046-6054; b) C.
Hansch, A. Leo, R. W. Taft, Chem. Rev. 1991, 91, 165-195.
S. Thielges, P. Bisseret, J. Eustache, Org. Lett. 2005, 7, 681-684.
M. Ochiai, T. Shu, T. Nagaoka, Y. Kitagawa, J. Org. Chem. 1997,
62, 2130-2138.
N. Ono, The Nitro Group in Organic Synthesis, Wiley-VCH, New
York, 2001.
C. J. Parkinson, J. T. Pinhey, M. J. Stoermer, J. Chem. Soc.,
Perkin Trans. 1 1992, 1911-1915.
Iris R. M. Tébéka is kindly acknowledged for early work on
synthesis of acyclic vinyliodonium salts. The Swedish Research
Council (2011-3608, 2015-04404) and Carl Trygger Foundation
(CTS 11:343, 14:359) are acknowledged for financial support.
[22]
[23]
[24]
[25]
Keywords: benziodoxolones • hypervalent iodine • structure
analysis • synthetic methods • vinylation
[26]
[27]
C. Che, H. Zheng, G. Zhu, Org. Lett. 2015, 17, 1617-1620.
a) D. A. Anderson, J. R. Hwu, J. Org. Chem. 1990, 55, 511-516; b)
Y. Chen, C. Zhong, X. Sun, N. G. Akhmedov, J. L. Petersen, X.
Shi, Chem. Commun. 2009, 5150-5152.
[1]
a) A. Yoshimura, V. V. Zhdankin, Chem. Rev. 2016, 116, 3328-
3435; b) T. Wirth, in Top. Curr. Chem., Vol. 373, Springer
International Publishing, Cham, 2016.
[28]
C. Dey, E. Lindstedt, B. Olofsson, Org. Lett. 2015, 17, 4554-4557.
