Mono- and bis-alkylation of glyoxal-bridged tetraazamacrocycles
using mechanochemistry
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Bassim H. Abdulwahaab†, Benjamin P. Burke†,‡, Juozas Domarkas†,‡, Jon D. Silversides†,
Timothy J. Prior† and Stephen J. Archibald†,‡*
†Department of Chemistry, University of Hull, Cottingham Road, Hull, HU6 7RX, United Kingdom.
‡Positron Emission Tomography Research Centre, University of Hull, Cottingham Road, Hull HU6 7RX, United Kingdom.
Keywords: Mechanochemistry, chelator, macrocycle, cyclam, cyclen, CB-TE2A, copper-64
ABSTRACT: Glyoxalꢀbridged bisaminal tetraazamacrocyclic derivatives of 1,4,7,10ꢀ
tetraazacyclododecane (cyclen) and 1,4,8,11ꢀtetraazacyclotetradecane (cyclam) can be Nꢀfunctionalized
to incorporate coordinating groups or for conjugation to biomolecules. Herein, we present an improved
Nꢀfunctionalization methodology using mechanochemistry which reduces reaction times in comparison
with conventional synthetic routes. A range of six alkyl halides were reacted with cyclen and cyclam
bisaminal derivatives in various ratios to form monoꢀ and bisꢀfunctionalized quaternary ammonium
salts. Crossꢀbridged cyclam, a key intermediate for CBꢀTE2A, a commonly used chelator in positron
emission tomography medical imaging with 64Cu, has been synthesized using nonꢀconventional synthetꢀ
ic methodologies (grinding and microwave heating) with intermediates characterized by 2DꢀNMR and
single crystal XRD. The overall synthesis time of CBꢀTE2A from cyclam could be shortened to 5 days
from the 35 days required for the conventional synthesis.
