Heterorotaxanes, one class of topological organic structures, have attracted increasing interesting during the past two decades. In general, two types of heterorotaxane structures exist, one in which two or more different macrocycles are threaded onto one dumbbell-shaped molecule and the other where one macrocycle is threaded onto two or more different dumbbell-shaped molecules. In comparison to these traditional types, another family of topologically interesting heterorotaxanes can be envisaged as arising from polyfunctional molecules that possess both host (crown ether) and guest (ammonium templates). In the present investigation, we have explored the construction of selected members of this new heterorotaxane family, which possess crown ether moieties that are wrapped around a dumbbell-shaped molecule. These structures are prepared by routes in which "stitching" processes, involving template-directed clipping reaction or olefin metathesis reactions, are used to install crown ether ring systems encircling ammonium cation centers. This is then followed by implementation of a threading-followed-by-stoppering sequence to install a second encircling crown ether ring. The results show that the polyfunctional building blocks assemble with high efficiencies. Finally, this investigation provides a foundation for future studies aimed at constructing more complicated heterorotaxane architectures, such as switchable systems, self-assembling polymers, and functional molecular machines.

Full text of DOI:10.1021/jo402166y

Subscriber access provided by DUKE UNIV
Article
Construction of Hetero[n]rotaxanes Using
Polyfunctional Rotaxane Frameworks
Ziyong Li, Guoxing Liu, Wen Xue, Di Wu, Ying-Wei Yang,
Jishan Wu, Sheng Hua Liu, Juyoung Yoon, and Jun Yin
J. Org. Chem., Just Accepted Manuscript • DOI: 10.1021/jo402166y • Publication Date (Web): 14 Oct 2013
Downloaded from http://pubs.acs.org on October 17, 2013
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a free service to the research community to expedite the
dissemination of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts
appear in full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been
fully peer reviewed, but should not be considered the official version of record. They are accessible to all
readers and citable by the Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered
to authors. Therefore, the “Just Accepted” Web site may not include all articles that will be published
in the journal. After a manuscript is technically edited and formatted, it will be removed from the “Just
Accepted” Web site and published as an ASAP article. Note that technical editing may introduce minor
changes to the manuscript text and/or graphics which could affect content, and all legal disclaimers
and ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors
or consequences arising from the use of information contained in these “Just Accepted” manuscripts.
The Journal of Organic Chemistry is published by the American Chemical Society.
1155 Sixteenth Street N.W., Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the
course of their duties.

Page 1 of 31
The Journal of Organic Chemistry
1
2
3
4
5
6
7
Construction of Hetero[n]rotaxanes Using Polyfunctional
Rotaxane Frameworks
8
9
Ziyong Li,† Guoxing Liu,† Wen Xue,† Di Wu,† Ying-Wei Yang,§ Jishan Wu,ǁ Sheng Hua
Liu,†* Juyoung Yoon,‡* Jun Yin†*
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
†Key Laboratory of Pesticide and Chemical Biology, Ministry of Education, College of Chemistry, Central
China Normal University, Wuhan 430079, P. R. China.
‡Department of Chemistry and Nano Science, Global Top 5 Program, Ewha Womans University, Seoul
120-750, Korea.
§State Key Laboratory of Supramolecular Structure and Materials, College of Chemistry, Jilin University,
Changchun, 130012, P. R. China.
ǁDepartment of Chemistry, National University of Singapore, 3 Science Drive 3, 117543, Singapore.
* E-mail: yinj@mail.ccnu.edu.cn; chshliu@mail.ccnu.edu.cn; jyoon@ewha.ac.kr
ABSTRACT: Heterorotaxanes, one class of topological organic structures, have attracted increasing
interesting during the past two decades. In general, two types of heterorotaxane structures exist, one in
which two or more different macrocycles are threaded onto one dumbbell-shaped molecule and the other
where one macrocycle is threaded onto two or more different dumbbell-shaped molecules. In comparison
1
ACS Paragon Plus Environment

The Journal of Organic Chemistry
Page 2 of 31
1
2
3
4
5
6
7
8
9
to these traditional types, another family of topologically interesting heterorotaxanes can be envisaged as
arising from polyfunctional molecules that possess both host (crown ether) and guest (ammonium
templates). In the current investigation, we have explored the construction of selected members of this
new heterorotaxane family, which possess crown ether moieties that are wrapped dumbbell-shaped
molecule. These structures are prepared by routes in which “stitching” processes, involving
template-directed clipping reaction or olefin metathesis reactions, are used to install crown ether ring
systems encircling ammonium cation centers. This is then followed by implementation of a
threading-followed-by-stoppering sequence to install a second encircling crown ether ring. The results
show that the polyfunctional building blocks assemble with high efficiencies. Finally, this investigation
provides a foundation of future studies aimed at constructing more complicated heterorotaxane
architectures, such as switchable systems, self-assembling polymers and functional molecular machines.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
n INTRODUCTION
Construction of the novel topological structures has been one of the major goals of research efforts in
the areas of supramolecular chemistry and self-assembly. Much attention has been given to the design and
synthesis of molecular representations of mathematical topologies, and to the structural analysis of these
1
topologically interesting chemical motifs. As one type of classic topological structures, mechanically
interlocked molecules (MIMs), such as rotaxanes, catenanes, knots, and links, have unique structural
2
features that enable their application in various fields, including molecular devices, molecular switches
and machines, 3 nanotechnology, 4 biological technology, 5 drug delivery 4a, 5b and polymer materials. 6 As a
consequence, the creation of MIMs that have novel configurations is an important aim of supramolecular
self-assembly and systems chemistry.
In recent years, the focus of studies of rotaxanes has shifted from single and simple structures to those
2
ACS Paragon Plus Environment

Page 3 of 31
The Journal of Organic Chemistry
1
2
3
4
5
7
that possess functionalized and complicated structures.
Recently, heterorotaxanes have attracted
6
7
increasing interest owing to the fact that interactions between the cyclic and linear components of these
8
9
8
systems can lead to different chemical structures with interesting functionalities.
Based on a
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
consideration of binding affinities between different host and guest components, a self-sorting strategy was
developed for the efficient construction of heterorotaxanes, which have topological configurations that are
similar to those of dumbbell-shaped molecules wrapped by different types of macrocyclic hosts. 9 For
example, in 1996 Stoddart and his coworkers took advantage of the different binding affinities of
dibenzo[24]crown-8 and bis(p-phenylene-34-crown-10) towards secondary dialkylammonium and
10
bipyridinium ions to synthesize a novel hetero[3]pseudorotaxane.
Schalley et al. used the different
binding behaviors of [24]crown-8 and [21]-crown-7 towards dialkylammonium ions to construct
hetero[3]rotaxanes. 11 12 Chiu et. al also described the use of another self-sorting method to construct a
13
hetero[3]rotaxane.
Recently, a new twin-axial hetero[7]rotaxane derived from benzo-21-crown-7 and
14
bis(p-phenylene-34-crown-10) was prepared by Liu and co-workers. In addition to crown ethers, other
macrocyclic hosts such as cucurbiturils, 15 cyclodextrins, 16 and others 17, 18 have been utilized to construct
heterorotaxanes. For example, in 2010 Wu and our group independently reported a hetero[4]rotaxane that
is generated from a crown ether and cucurbituril by employing a threading-followed-by-clipping approach.
19
Another family of heterorotaxanes contain members that are composed of macrocycles in which
different dumbbell-shaped molecules are threaded. In 2006, Anderson et al. described a hetero[3]rotaxane
containing one stilbene and one cyanine dye moiety threaded through the center of a γ–cyclodextrin
20
molecule. Schalley’s group also constructed a series of heterorotaxanes by employing self-assembly of
hosts containing 21-crown-7 and 24-crown-8 units onto different ammonium templates. 21
3
ACS Paragon Plus Environment

The Journal of Organic Chemistry
Page 4 of 31
1
2
3
4
5
6
7
8
9
In the effort described below, we have designed, synthesized and investigated several new
hetero[n]rotaxanes (n = 3, 4) and hetero[5]pseudorotaxane that have unique topological structures that are
different from those of the two traditional types described above. The new types of dual functional
molecules are comprised of crown ether and ammonium building blocks that play the roles of respective
hosts and guests. The crown ether groups in these dual functional molecules are designed to have the
ability to wrap dumbbell-shaped molecules while the ammonium components play the roles of guest
templates that thread the crown ethers. The dual-functional molecules highly efficiently assemble to form
novel topological hetero[n]rotaxanes.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
n RESULTS AND DISCUSSION
Design of new heterorotaxanes. The general strategy we have developed for the preparation of novel
hetero[n[rotaxane is depicted pictorially in Scheme 1. In general, the heterorotaxanes are comprised of two
simple rotaxanes A and B, which are formed from polyfunctional host-guest building blocks. It should be
noted that previous efforts have shown that dual functional molecules of this type undergo intermolecular
self-assembly to form daisy-shaped molecules and polymers. 22 Consequently, in our approach a stopper is
introduced in order to avoid daisy-shaped polymer formation. The building block C, contains a stopper
group along with both a crown ether and an ammonium cation group. In this approach, hetero[n]rotaxane
construction take place through a two-step self-assembly strategy in which the ammonium unit serves as a
template for incorporating an encircling macrocyclic ring by using either template-directed clipping
reaction or olefin metathesis reactions. 23 These processes afford intermediate D, which is then subjected to
a threading-followed-by-stoppering sequence to install a second encircling crown ether ring as part of the
new heterorotaxane.
4
ACS Paragon Plus Environment

Page 5 of 31
The Journal of Organic Chemistry
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 1. A schematic representation of the route for heterorotaxane formation.
Synthesis of building blocks. One group of substances needed to aid spectroscopic analysis of the
processes involved in heterorotaxane formation following the strategy described above, include the
azacrown and normal crown ethers 4 and 9 (Scheme 2). The synthesis 4 is accomplished using
dibenzylammonium ion 3 as a template and aldimine forming condensation reaction of the
4-alkoxyl-substituted 2,6-pyridinedicarboxaldehyde 1 with tetra(ethylene glycol) bis(2-aminophenyl)ether
2 followed by BH3·THF promoted reduction. The preparation of crown ether 9 is carried out using olefin
metathesis reaction (41%) of the bis-olefin containing pseudo-crown ether 8, which is generated by
24
substitution reaction between naphthalene-diol 5 and mono-tosylate 6 followed by O-allylation reaction
of the resulting diol 7.
Scheme 2. Synthesis of macrocycles 4 and 9.
The substance selected to aid spectroscopic analysis of the stopper region in the heterorotaxane forming
5
ACS Paragon Plus Environment

The Journal of Organic Chemistry
Page 6 of 31
1
2
3
4
5
6
7
8
9
process is the dumbbell-shaped ammonium ester 16 (Scheme 3). The route employed to prepare 16 begins
with. Reductive amination reaction between 3,5-dihydroxybenzaldehyde (12) and 5-aminopentan-1-ol (13)
which generates amine 14 (83%). Protonation of the amine group in 14 using excess trifluoroacetic acid
followed by counterion exchange with saturated aqueous NH4PF6 affords the corresponding ammonium
salt 15. Finally, treatment of 15 with 3,5-dimethoxybenzoic anhydride (11), produce from the
corresponding acid 10, and catalytic tributylphosphane leads to formation of the dumbbell-shaped
ammonium salt 16 in a yield of 55%. The final products and intermediates in the synthetic pathways
shown in Schemes 2 and 3 as well in all of the Schemes that follow were fully characterized by using
standard spectroscopic techniques (see the Supporting Information).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 3. Synthesis of the dumbbell-shaped ammonium 16.
With models 4, 9 and 16 in hand, we set out to synthesize the dual functional structural components of
the heterorotaxanes. One key substance 24, containing a crown ether and an ammonium structural unit,
was synthesized utilizing the route shown in Scheme 4. Treatment of 3,5-dihydroxybenzaldehyde 20 with
25
the pseudo crown ether 19, formed by a route starting with bis-phenol 17 and mono-tosylate 6, in the
presence of Cs2CO3 produces the aldehyde-substituted crown ether 21 in 46% yield. Reductive amination
of 21 with 3,5-dimethoxybenzylamine (22) gives the precursor of the Boc-protected amino crown ether 23,
produced for the purpose of convenient purification. The Boc-deprotection with trifluoroacetic acid (TFA)
6
ACS Paragon Plus Environment

Page 7 of 31
The Journal of Organic Chemistry
1
2
3
4
5
in dry dichloromethane followed by counterion exchange with saturated aqueous NH4PF6 gives the target
6
7
ammonium tethered bis(m-phenylene)-26-crown-8 24.
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 4. Synthesis of the dual functional crown ether 24.
A similar synthetic strategy was employed to prepare the dual functional crown ether 30, which contains
two ammonium groups and one crown ether host unit (Scheme 5). The sequence was initiated by treatment
of 3,5-dihydroxybenzaldehyde (25) with the bis-tosylate 27, generated from 25. This process produces
crown ether 28 (54%), which then undergoes reductive amination with 3,5-dimethoxybenzylamine 22
followed by N-protection using Boc2O to form the bis-substituted crown ether 29 (69% three steps).
Subsequent deprotection and counterion exchange affords the bis-ammonium tethered crown ether 30. A
single crystal of 30 suitable for crystallographic analysis was obtained by diffusion of isopropyl ether into
an acetonitrile solution at room temperature (Figure S1). X-ray crystallographic analysis of 30 shows that
it exists in a highly ordered packed structure in the solid state (Table S1).
7
ACS Paragon Plus Environment

The Journal of Organic Chemistry
Page 8 of 31
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 5. Synthesis of the dual functional crown ether 30.
Scheme 6. Synthesis of dual functional crown ether 34.
The triangular shaped tris-ammonium tethered crown ether 34 was prepared employing the pathway
outlined in Scheme 6. The route begins with Cs+ template controlled reaction of
3,5-dihydroxybenzaldehyde 25 with bis-tosylate 31, which forms the key tris-aldehyde intermediate 32
(43%). Reductive amination of 32 with amine 22 followed by Boc-protection (for the purpose of
8
ACS Paragon Plus Environment

Page 9 of 31
The Journal of Organic Chemistry
1
2
3
4
5
purification), deprotection and ion exchange then gives 34.
6
7
8
9
Hetero[n]rotaxanes assembly. A reductive amination based stitching process was employed to affix a
macrocyclic ring on the side chain ammonium residue in the dual functional substrate 24. This process was
accomplished by mixing 24 with dialdehyde 1 and bis-aniline derivative 2 in CD3CN (pictorially
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
+
represented in Scheme 7). The observation of a broad singlet at 9.76 ppm for ammonium NH2 protons
1
as well as a singlet at 8.24 ppm for imine (CH=N) protons in H NMR spectra of the crude reactions
mixture shows that macrocyclic bis-imine formation has taken place in a reversible manner (Figure S2).
Reduction of the imine moieties in this substance with BH3·THF followed by chromatographic purification
then generates the kinetically stable [2]rotaxane-1 (78%).
1
The resonance for ammonium protons in the H NMR spectrum of [2]rotaxane-1 is upfield shifted
(singlet at 8.31 ppm) compared to those of its bis-imine containing precursor. In addition, resonance of
protons on the stopper units (H2 and H3, H6 and H7) of [2]rotaxane-1 (Figure 1C, see Scheme 4 for proton
numbering) also display upfield shifts in comparison to those in the dual functional molecule 24 (Figure
1B) as a result of shielding effects associated with the encircling crown ether macrocyclic ring. In contrast,
the resonances for the methylene protons (H4 and H5) adjacent to the ammonium nitrogen are downfield
shifted. In addition, a downfield shift of the proton (Hb) on the hetero-crown ether ring in [2]rotaxane-1 is
downfield shifted relative to the related proton in the model 4 (Figure 1A). The observed shifts in proton
resonances, which are in good agreement with those noted in previous studies, 19, 26 suggest that the newly
installed crown ether ring system in [2]rotaxane-1 encircles the ammonium moiety of the dual functional
molecule. Additional evidence supporting this conclusion comes from analysis of the electrospray
-
ionization mass spectum (ESI-MS), which contains a peak at m/z 1320.3 that corresponds to the -PF6 salt
of [2]rotaxane-1 (see the supporting information).
9
ACS Paragon Plus Environment

The Journal of Organic Chemistry
Page 10 of 31
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 7. Synthesis of hetero[3]rotaxanes-1 and hetero[3]rotaxanes-2.
In order to construct the topologically novel hetero[3]rotaxane-1, [2]rotaxane-1 was treated with the
ammonium salt 15 and the resulting threaded complex was subjected to a tributylphosphine catalyzed
endcapping reaction with 3,5-dimethylbenzoic anhydride (11). Evidence for the formation of
hetero[3]rotaxane-1 in this process comes from analysis of its 1H NMR spectrum. As shown in Figure 1D,
an obvious downfield shift of the resonance for the ammonium protons and upfield shifts for benzene ring
protons (HB and HC) in the comparative spectra of [2]rotaxane-1 and hetero[3]rotaxane-1 show that the
crown ether unit in the former substance is threaded by the ammonium template (modeled by 16) (Figure
1E). The results of two-dimensional ROESY experiment enabled the identification of the changes
occurring in resonances associated with dual functional and hetero crown ether and dumbbell-shaped
components upon formation of hetero[3]rotaxane-1. For example, the benzene ring prtotons of the dual
functional molecular component are strongly shielded by the hetero crown ether component in
hetero[3]rotaxane-1. In addition, obvious correlations exist between the benzene ring (H3 and H6) and
methylene (Hb) protons and between protons in the dumbbell-shaped and dual functional molecular
components of hetero[3]rotaxane-1 (Figure S3). Finally, inspection of the MALDI-MS spectrum (Figure
2A) shows the presence of a peak at m/z 1736.84 that is assigned to [M-PF6 -HPF6]+ of
-
hetero[3]rotaxane-1 (Figure 2A).
10
ACS Paragon Plus Environment

Page 11 of 31
The Journal of Organic Chemistry
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 1. Partial 1H NMR spectra (400 MHz, CD3CN, 298 K) of 4 (A); 24 (B); [2]rotaxane-1 (C); hetero[3]rotaxane-1 (D)
and 16 (E).
Figure 2. MALDI-TOF mass spectra of hetero[3]rotaxane-1 (A), hetero[3]rotaxane-2 (B), hetero[4]rotaxane-3 (C),
hetero[4]rotaxane-4 (D).
Another method used to generate a heterorotaxane from 24 involves the use of an olefin metathesis
process. In this approach, the complex formed by treatment of 24 with the bis-olefin containing crown
ether 8 was reacted using the Grubbs’ catalyst to form [2]rotaxane-2 (67%) (Scheme 7). Subsequent
threading of [2]rotaxane-2 by the ammonium ion 15 followed by endcapping reaction with
1
3,5-dimethylbenzoic anhydride (11) produced hetero[3]rotaxane-2 in a 51% yield. In the H NMR
spectrum, protons in the two side methylene groups (H4 and H5) adjacent to the ammonium residue in
11
ACS Paragon Plus Environment

The Journal of Organic Chemistry
Page 12 of 31
1
2
3
4
5
6
7
8
9
[2]rotaxane-2 display similar downfield shifts as seen in the spectrum of [2]rotaxane-1 while the
corresponding benzene ring protons (H2, H3 and H6, H7) display similar upfield shifts owing to the
shielding effect of the encircling naphthalene-based crown ether ring system (Figure 3B and 3C). In the 1H
NMR spectrum of hetero[3]rotaxane-2, the resonance associated with the ammonium protons on the
dumbbell component are shifted downfield relative to those in the model 16, suggesting that that this
moiety is encircled by a crown ether group of the dual functional component. In addition, resonances of
protons HB and HC also display upfield shifts in a manner that is similar to the corresponding protons in the
spectrum of hetero[3]rotaxane-1 (Figures 3D and 3E).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 3. Partial 1H NMR spectra (400 MHz, CD3CN, 298 K) of 9 (A); 24 (B); [2]rotaxane-2 (C); hetero[3]rotaxane-2 (D)
and 16 (E).
The results of ESI MALDI-TOF mass spectrometric analysis support the assigned structures of
[2]rotaxane-2 and hetero[3]rotaxane-1. Specifically, the peak at m/z 1105.1 in the spectrum of
- +
[2]rotaxane-2 is assigned to the [M-PF6 ] species while the spectrum of hetero[3]rotaxane-2 contains a
-
peak at m/z 1521.72 for the [M-PF6 -HPF6]+ species (Figure 2B and SI). Finally, the two-dimensional
12
ACS Paragon Plus Environment

Page 13 of 31
The Journal of Organic Chemistry
1
2
3
4
5
6
7
ROESY spectrum of hetero[3]rotaxane-2 contains significant cross peaks associated with the existence of
interactions between the host and guest components (Figure S4).
8
9
An investigation was conducted to determine if hetero[4]rotaxanes can be generated by using
appropriate polyfunctional substrates. The crown ether 30 was selected for this purpose because, in
addition to a host component, it contains two ammonium units that can serve as templates for stitching
processes that introduce crown ether rings. Template-directed clipping reaction of 30 and two equivalents
of dialdehyde 1 and diamine 2 in CH3CN was employed to generate a bis-imine, which upon treatment
with BH3·THF produced [3]rotaxane-3 in a high yield (Scheme 8). In addition, the analogous
[3]rotaxane-4 was prepared from 30 by using olefin metathesis reaction of diene 8. Both [3]rotaxanes
were then subjected to threading with 15 and endcapping reactions with anhydride 15. The overall
sequences afforded hetero[4]rotaxane-3 and hetero[4]rotaxane-4 in high yields.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 8. Synthesis of hetero[4]rotaxane-3 and hetero[4]rotaxane-4.
1
The steps in these assembly sequences were followed by using H NMR spectroscopy. As can be seen
by inspection of Figures 4 and S5, the resonance of protons (H2’, H3’ and H6’, H7’) on the benzene rings of
30 are downfield shifted in [3]rotaxane-3 and [3]rotaxane-4 while two side methylenes (H4’ and H5’)
adjacent to the ammonium nitrogens are also downfield shifted. The results clearly show that the
template-directed clipping reaction leads to incorporation of crown ether components wrapped around the
13
ACS Paragon Plus Environment

The Journal of Organic Chemistry
Page 14 of 31
1
2
3
4
5
6
7
8
9
ammonium ion centers. In contrast to those of the dumbbell-shaped molecule 16, the ammonium protons
of hetero[4]rotaxane-3 and hetero[4]rotaxane-4 are also downfield shifted while the resonance of
benzene ring protons are upfield shifted relative to those in 16. Morover, the 2D ROESY spectra of both
hetero[4]rotaxanes display some important correlations expected for their assigned structures (Figure S6
and S7). Finally, the mass spectra of both substances contain peaks at expected m/z ratios (as shown in SI
and Figures 2C and 2D).
