Ring-Opening Metathesis Polymerization
FULL PAPER
Table 2. Data for polyCOE synthesis obtained with complexes 8a, 9a,
and 10a.
Complex 8b: Complex 8b was obtained as a brown powder (158 mg,
67% yield). H NMR (500 MHz, CDCl3): d=17.49 (s, 1H; Ru=CH), 8.12
1
(s, 1H; N=CH), 7.63 (t, J=7.7 Hz, 1H; aromatic p-HSIPr), 7.52 (d, J=
7.1 Hz, 1H; aromatic m-HSIPr), 7.43–7.37 (m, 2H; aromatic HSIPr), 7.16 (t,
J=7.8 Hz, 2H; aromatic HSIPr), 6.65 (s, 2H; aromatic HMes), 4.81–4.79 (m,
1H; HFc), 4.47 (t, J=2.6 Hz, 1H; HFc), 4.44–4.36 (m, 1H; NCHxHy),
4.34–4.32 (m, 1H; HFc), 4.23–4.10 (m, 8H; 5HFc, 2CH(Me)2, NCHxCHy),
4.09–3.97 (m, 2H; NCH2), 3.05 (sep, J=6.8 Hz, 1H; CH(Me)2), 3.00 (sep,
J=6.8 Hz, 1H; CH(Me)2), 2.22 (s, 3H; p-MeMes), 1.93 (s, 3H; o-MeMes),
1.75 (s, 3H; o-MeMes), 1.38 (d, J=7.0 Hz, 3H; MeiPr), 1.36 (d, J=6.6 Hz,
3H; MeiPr), 1.32 (d, J=6.5 Hz, 3H; MeiPr), 1.17 (d, J=6.9 Hz, 3H; MeiPr),
1.14 (d, J=6.8 Hz, 3H; MeiPr), 1.09 (d, J=6.8 Hz, 3H; MeiPr), 0.92 (d, J=
6.6 Hz, 3H; MeiPr), 0.58 ppm (d, J=6.5 Hz, 3H; MeiPr); 13C NMR
(126 MHz, CDCl3): d=309.77, 220.16, 169.42, 150.34, 149.55, 149.18,
148.62, 147.32, 138.69, 135.23, 134.90, 132.47, 130.42, 129.83, 129.18,
129.08, 128.47, 124.83, 124.41, 123.75, 97.38, 76.53, 75.47, 72.71, 70.27,
66.43, 55.09, 53.66, 29.54, 28.72, 28.41, 28.23, 28.02, 27.05, 26.38, 26.34,
24.59, 23.90, 22.72, 22.36, 21.16, 20.97, 20.72 ppm; HRMS (EI): m/z calcd
for C48H59N3Cl2FeRu: 905.2470 [M]+; found: 905.2472.
Catalyst Ratio
COE/Ru
Mn
[gmolÀ1
PDI trans/cis Time
Conversion
[%]
[c]
N
]
ratio[e]
8a+[a]
8a+[b]
8b+[a]
9a
1000
1000
500
1000
1000
–
–
–
–
–
–
3.2:1
3.1:1
5 h
5 h
24 h
96
95
96
[d]
[d]
[d]
2.8:1[f]
55760
66990
1.16 4.3:1
1.22 4.3:1
10 min 99
30 min 99
10a
[a] Chemical oxidation. [b] Electrochemical oxidation. [c] Solvent: THF.
[d] Insoluble in THF. [e] Determined by NMR spectroscopy in CDCl3.
[f] Same ratio observed for the soluble polyCOE obtained at COE/Ru=
100.
Conclusion
Synthesis of complexes 9a and 9b: A Schlenk flask containing [RuCl2-
AHCTUNGTER(GNNNU SIMes)ACHUTTNGREN(NGU Ind)(py)] (200 mg, 0.26 mmol) or [RuCl2ACHTUNGERTNGN(UN SIPr)ACHTUNGTRENNUNG(Ind)(py)]
Eight new Hoveyda-type complexes with ferrocenyl sub-
stituents were synthesized. Two of these complexes (8a and
8b) were found to be latent catalysts for ROMP reactions in
the reduced state, but are able to polymerize cis-cyclooctene
following chemical or electrochemical oxidation of the fer-
rocenyl group. The oxidative stimulus by using mild chemi-
cal oxidizers is orthogonal to most organic functional
groups. The electrochemical initiation of the polymerization
through electrodes adjusted to an oxidative potential is un-
precedented for ROMP reactions and could enable micro-
structure control of the polymerization process. Further-
more, control over the cross-linking process, might provide
access to thermally triggered shape-memory polymers.
(216 mg, 0.26 mmol) was evacuated and back-filled with nitrogen three
times. Toluene (3 mL) and 5 (75 mL, 0.29 mmol) were added under an at-
mosphere of nitrogen and the resulting mixture was heated for 1.5 h at
658C. After evaporation of the volatile compounds, methanol (5 mL) was
added to the remaining solid, and the mixture sonicated and kept in the
fridge at À358C for 2 h. The precipitate was collected by filtration,
washed with cold methanol, and dried in vacuo.
Complex 9a: Complex 9a was obtained as a pink powder (131 mg, 70%
yield). 1H NMR (500 MHz, C6D6): d=16.43 (d, J=0.8 Hz, 1H), 6.94 (s,
2H), 6.91 (s, 2H), 4.26 (s, 5H), 4.02–4.00 (m, 1H), 3.86 (t, J=2.6 Hz,
1H), 3.74 (dd, J=2.7, 1.1 Hz, 1H), 3.45 (s, 4H), 2.68 (s, 9H), 2.64 (s,
9H), 2.19 ppm (s, 6H); 13C NMR (126 MHz, C6D6): d=291.81, 212.61,
129.79, 129.67, 115.15, 101.18, 69.91, 68.87, 61.11, 57.58, 51.72, 21.15,
19.99 ppm (brs); HRMS (EI): m/z calcd for C34H41N3Cl2FeRu: 719.1061
[M]+; found: 719.1056.
Complex 9b: Complex 9b was obtained as a pink powder (182 mg, 87%
yield). 1H NMR (300 MHz, CDCl3): d=16.45 (d, J=0.8 Hz, 1H), 7.47 (t,
J=7.7 Hz, 2H), 7.39–7.27 (m, 4H), 4.50 (dt, J=2.5, 0.8 Hz, 1H), 4.23 (t,
J=2.7 Hz, 1H), 4.20 (s, 5H), 4.09 (s, 4H), 3.80 (dd, J=2.6, 1.1 Hz, 1H),
3.75 (sep, J=6.8 Hz, 4H), 2.80 (brs, 3H), 2.63 (brs, 3H), 1.40 (d, J=
6.6 Hz, 6H), 1.28 ppm (t, J=6.9 Hz, 18H); 13C NMR (75 MHz, CDCl3):
d=294.43, 214.13, 148.65, 137.78, 129.32, 124.43, 124.35, 114.01, 100.96,
69.82, 69.17, 62.09, 57.33, 54.72, 53.65 (brs), 28.70, 28.59, 26.65, 26.56,
24.38, 24.19 ppm; HRMS (EI): m/z calcd for C40H53N3Cl2FeRu: 803.2000
[M]+; found: 803.1999.
Experimental Section
Synthesis of complexes 8a and 8b: A Schlenk flask containing [RuCl2-
ACHTUNGTRENNUNG(SIMes)ACHTUNGTRENNUNG(Ind)(py)] (200 mg, 0.26 mmol) or [RuCl2ACHTUNGERTNGN(UN SIPr)CAHTNUGTRENN(UGN Ind)(py)]
(216 mg, 0.26 mmol) was evacuated and back-filled with nitrogen three
times. Next, a stock solution of 3 (0.1m, 3.1 mL) in dry and degassed tol-
uene was added under an atmosphere of nitrogen. The resulting solution
was heated for 1.5 h at 658C. The volatile compounds were removed in
vacuo and the residue purified by column chromatography (cyclohexane/
acetone/NEt3, 100:20:1 v/v/v). After evaporation of the volatile com-
pounds, n-pentane (5 mL) was added to the remaining solid, and the mix-
ture was sonicated and kept in a fridge at À358C for 2 h. The precipitate
was collected by filtration and dried in vacuo.
Synthesis of complexes 10a and 10b: A Schlenk flask containing [RuCl2-
AHCTUNGTER(GNNNU SIMes)ACHUTTNGREN(NGU Ind)(py)] (200 mg, 0.26 mmol) or [RuCl2ACHTUNGERTNGN(UN SIPr)ACHTUNGTRENNUNG(Ind)(py)]
(216 mg, 0.26 mmol) was evacuated and back-filled with nitrogen three
times. Next, a solution of 6 (92 mg, 0.31 mmol) in dry and degassed tol-
uene (3 mL) was added under an atmosphere of nitrogen. The resulting
mixture was heated for 1 h at 608C. After evaporation of the volatile
compounds, methanol (10 mL) was added to the remaining solid, and the
mixture was sonicated. The precipitate was collected by filtration,
washed with methanol, and dried in vacuo.
Complex 8a: Complex 8a was obtained as a brown-orange powder
(156 mg, 73% yield). 1H NMR (500 MHz, CDCl3): d=17.45 (s, 1H; Ru=
CH), 8.06 (s, 1H; N=CH), 7.12 (s, 1H; aromatic HSIMes), 7.01 (s, 1H; aro-
matic HSIMes), 6.84 (s, 1H; aromatic HSIMes), 6.75 (s, 1H; aromatic HSIMes),
6.56 (s, 2H; aromatic HMes), 4.80–4.77 (m, 1H; HFc), 4.47 (t, J=2.5 Hz,
1H; HFc), 4.40–4.37 (m, 1H; HFc), 4.16 (s, 5H; HFc), 4.09–4.02 (m, 2H;
NCH2), 3.91–3.84 (m, 2H; NCH2), 2.68 (s, 3H; o-MeSIMes), 2.50 (s, 3H; o-
MeSIMes), 2.45 (s, 3H; p-Me), 2.27 (s, 3H; p-Me), 2.18 (s, 3H; o-MeSIMes),
2.15 (s, 3H; p-Me), 1.99 (s, 3H; o-MeSIMes), 1.87 (s, 3H; o-MeMes),
1.81 ppm (s, 3H; o-MeMes); 13C NMR (126 MHz, CDCl3): d=314.13,
217.03, 169.40, 146.80, 139.30, 139.17, 138.75, 138.71, 138.62, 138.13,
137.92, 134.76, 134.46, 132.01, 129.51, 129.14, 128.62, 99.30, 76.65, 75.15,
72.77, 70.22, 65.00, 51.92, 50.98, 21.39, 21.23, 20.90, 20.76, 20.35, 20.03,
19.19, 18.33 ppm; HRMS (EI): m/z calcd for C42H47N3Cl2FeRu: 821.1531
[M]+; found: 821.1511. Single crystals of 8a were obtained by slow evap-
oration of CH2Cl2/cyclohexane at ambient temperature under air.
Complex 10a: Complex 10a was obtained as
a brownish powder
(156 mg, 79% yield). 1H NMR (500 MHz, CDCl3): d=18.72 (t, J=
5.2 Hz, 1H), 8.08 (s, 1H), 7.03 (s, 4H), 4.04 (s, 9H), 3.92 (t, J=1.9 Hz,
2H), 3.90 (t, J=1.9 Hz, 2H), 2.96 (d, J=5.2 Hz, 2H), 2.71–2.23 (m,
18H), 1.05 ppm (s, 6H); 13C NMR (126 MHz, CDCl3): d=343.65, 218.31,
173.29, 140.10, 138.39, 129.57, 103.11, 70.29, 66.40, 63.74, 51.59 (brs),
42.10, 26.85, 21.39, 20.28 (brs), 18.42 ppm (brs); HRMS (EI): m/z calcd
for C37H45N3Cl2FeRu: 759.1374 [M]+; found: 759.1414.
Complex 10b: Complex 10b was obtained as
a brownish powder
(202 mg, 92% yield). 1H NMR (500 MHz, CDCl3): d=18.80 (t, J=
4.8 Hz, 1H), 8.21 (s, 1H), 7.47 (t, J=7.7 Hz, 2H), 7.32 (d, J=7.7 Hz,
4H), 4.10 (s, 4H), 3.97 (d, J=2.9 Hz, 7H), 3.88 (t, J=1.9 Hz, 2H), 3.60
(d, J=12.6 Hz, 4H), 2.70 (d, J=4.8 Hz, 2H), 1.22 (d, J=6.8 Hz, 24H),
