ACS Catalysis
Research Article
product (Scheme 2B). To further elaborate on the synthetic
utility of this protocol, consecutive alkynylations of ketone
substrates allowed for the connection (via a carbon−carbon
triple bond) of two different biologically important fragments
derived from a pharmaceutical compound and a natural
product, forming 5a and 5b in 63 and 48% yields, respectively
(Scheme 2C). Differing from aryl halides in conventional
Sonogashira reactions, by employing a ketone group as both
the directing group and leaving group, the natural product
deoxyestrone could be 1,2-bifunctionalized via ketone-directed
ortho-C−H alkylation and subsequent ligand-promoted ipso-
Ar−C(O) alkynylation (Scheme 2D).
Experimental procedures, characterization of com-
pounds, NMR spectral data, and DFT calculations
AUTHOR INFORMATION
Corresponding Authors
■
Mingyue Zheng − Drug Discovery and Design Center, State
Key Laboratory of Drug Research, Shanghai Institute of
Materia Medica, Chinese Academy of Sciences, Shanghai
Hui-Xiong Dai − Chinese Academy of Sciences Key Laboratory
of Receptor Researc, Shanghai Institute of Materia Medicah,
University of Chinese Academy of Sciences, Shanghai 201203,
In order to gain a better insight into the reaction
mechanism, we carried out a number of control experiments
(Scheme 3A). Considering that oxime ether N−O bonds are
very weak (33−37 kcal/mol), they can easily generate N- and
O-centered radicals at moderate temperatures via homolytic
scission.14,15 However, the addition of the radical scavengers
TEMPO (2,2,6,6-tetramethylpiperidine-N-oxyl) and BHT
(butylated hydroxytoluene) had a negligible impact on the
product yield, indicating that the reaction may not involve a
radical pathway (Scheme 3A-(1)). When pharmaceutical
fenbufen derivative 9 was subjected to the standard conditions,
the alkynylation product 3u and corresponding nitrile
compound 10 were obtained in 64 and 58% yields, respectively
(Scheme 3A-(2)). No desired product was detected when
amide 11 was employed under the standard conditions,
indicating that the 1,2-shift of the aryl group may not be
involved (Scheme 3A-(3)). Based on the above experiments
and a previous report,16 a plausible mechanism has been
proposed as shown in Scheme 3B. First, oxidative addition of
Pd(0) into the N−O bond of the oxime ether 1a’ gives the
palladium(II) intermediate I’, which can isomerize to
intermediate I. Computational studies showed that ligand-
promoted β-aryl elimination of I’ via transition state TS1 is
more favorable with a lower activation barrier (ΔG = 23.5
kcal/mol) than β-alkyl elimination via transition state TS1’
(ΔG = 35.9 kcal/mol) (Scheme 3C). Subsequent trans-
metallation of the aryl palladium species II with alkyne 2c gives
intermediate III. K2CO3 is assumed to promote the trans-
metallation process.4 Finally, palladium species III undergoes
reductive elimination to form the alkyne product 3c and
regenerate the Pd(0) species.
Authors
Hui Xu − Chinese Academy of Sciences Key Laboratory of
Receptor Researc, Shanghai Institute of Materia Medicah,
University of Chinese Academy of Sciences, Shanghai 201203,
China
Biao Ma − Chinese Academy of Sciences Key Laboratory of
Receptor Researc, Shanghai Institute of Materia Medicah,
University of Chinese Academy of Sciences, Shanghai 201203,
China
Zunyun Fu − School of Chinese Materia Medica, Nanjing
University Of Chinese Medicine, Nanjing, Jiangsu 210023,
China
Han-Yuan Li − Chinese Academy of Sciences Key Laboratory
of Receptor Researc, Shanghai Institute of Materia Medicah,
University of Chinese Academy of Sciences, Shanghai 201203,
China
Xing Wang − Chinese Academy of Sciences Key Laboratory of
Receptor Researc, Shanghai Institute of Materia Medicah,
University of Chinese Academy of Sciences, Shanghai 201203,
China
Zhen-Yu Wang − School of Chinese Materia Medica, Nanjing
University Of Chinese Medicine, Nanjing, Jiangsu 210023,
China
Ling-Jun Li − Chinese Academy of Sciences Key Laboratory of
Receptor Researc, Shanghai Institute of Materia Medicah,
University of Chinese Academy of Sciences, Shanghai 201203,
China
In summary, we have developed a palladium-catalyzed
pyridine-oxazoline-promoted alkynylation of unstrained aryl
ketones via Ar−C(O)bond cleavage. A variety of alkyne
products were synthesized with excellent functional-group
tolerance and heterocyclic compatibility. Late-stage diversifi-
cation of a number of pharmaceuticals and natural products
demonstrates the synthetic practicality of this methodology
and its potential application in drug discovery. 1,2-Bifunction-
alization of the natural product deoxyestrone was accom-
plished via ketone-directed ortho-C−H alkylation and ligand-
promoted ipso-Ar−C(O) alkynylation. Further applications of
this protocol to unstrained alkenyl and alkyl ketones are
currently ongoing in our laboratory.
Tai-Jin Cheng − Chinese Academy of Sciences Key Laboratory
of Receptor Researc, Shanghai Institute of Materia Medicah,
University of Chinese Academy of Sciences, Shanghai 201203,
China
Complete contact information is available at:
Author Contributions
§H.X., B.M., and Z.F. contributed equally to this paper.
Notes
The authors declare no competing financial interest.
ACKNOWLEDGMENTS
■
We gratefully acknowledge the Shanghai Institute of Materia
Medica, the Chinese Academy of Sciences, the NSFC
(21772211, 21920102003), the Youth Innovation Promotion
Association CAS (Nos. 2014229 and 2018293), the Science
and Technology Commission of Shanghai Municipality
ASSOCIATED CONTENT
■
sı
* Supporting Information
The Supporting Information is available free of charge at
1763
ACS Catal. 2021, 11, 1758−1764
