Journal of the American Chemical Society
Communication
tolerated. The reaction is compatible with a wide range of
functional groups and can be accomplished in the presence of
nitriles (19), esters (20), aryl ethers (15), silyl ethers (13, 17,
21, and 27), alkenes (15), alkyl chlorides (26), sulfonamides
(31), dialkyl anilines (25), and aryl bromides (18). The
synthesis of compound 16 on a 5 mmol scale demonstrates
that the reaction can be used as a preparative method.30
One of the limitations of our original hydroalkylation
method was that nitrogen-based heteroarenes were not
compatible with the reaction. The new reaction tolerates a
wide range of heteroarenes including furans (23), 2-
chloropyridines (24), pyridazines (30), thiazoles (28),
pyrimidines (29), tetrazoles (33), and benzoxazoles (34). In
general, heteroarenes less basic than pyridine are tolerated,
while pyridine and more basic heterocycles are not.
We also explored the reaction with a range of secondary
alkyl iodides. Cyclic substrates, such as 5- through 7-membered
cyclic alkyl iodides, generally perform well (36, 40, 41).
Acyclic alkyl iodides are also viable substrates, although yields
tend to be lower.
Our initial attempts at using primary alkyl iodides as
coupling partners were unsuccessful. Under the reaction
conditions used for coupling secondary alkyl iodides, product
8 was formed in only 32% yield. The major side reactions in
this case were the reduction of the alkyl iodide31 and the semi-
reduction of the alkyne to an alkene. Eventually, we found that
with subtle changes to the reaction conditions we can obtain
alkene 8 in 90% yield (eq 1).
Table 1. Reaction Development
a
entry
change from standard conditions
yield (%)
1
2
none
CyBr instead of Cyl
88
2
3
4
SIPrCuCl instead of IPrCuCl
IMesCuCl instead of IPrCuCl
87
5
5
6
7
8
9
tpy′ + Nil2 instead of (tpy′)Nil
(tpy′)NiCl2 instead of (tpy′)Nil
(tpy)Nil instead of (tpy′)Nil
(dtbpy)NiCl2 instead of (tpy′)Nil
NiCl2(DME) + i-PrPybox instead of (tpy′)Nil
82
71
48
8
0
10
11
LiOt-Bu instead of LiOi-Pr
NaOi-Pr instead of LiOi-Pr
3
34
12
THF instead of DME
78
13
14
15
Ph2MeSiH instead of Ph3SiH
PMHS instead of Ph3SiH
Ph2SiH2 instead of Ph3SiH
51
8
12
a
Determined by GC using internal standard.
To achieve these results, we changed the catalyst from
IPrCuCl to SIPrCuCl, changed the solvent from DME to
DME/isooctane (1:1), adjusted the stoichiometry of the
turnover reagent (from 1.5 to 2.0 equiv), and lowered the
loading of the nickel catalyst (from 5 to 3 mol%).32
The conditions developed for the synthesis of 8 proved
general for a range of primary alkyl halides (Table 2). In
departure from the original hydroalkylation with alkyl triflates,
we could achieve hydroalkylation using α-branched (46, 49,
50, and 51) and even neopentyl-like alkyl iodide (45) in
relatively high yield. Similarly, electrophiles with heteroatoms
in the α position (46), which are incompatible with the
previous hydroalkylation, are also tolerated.
We also noted a few limitations of the hydroalkylation
reaction. Protic functional groups, such as hydroxyl and amino,
are not tolerated. Reducible functional groups, such as
aldehydes and activated alkene are also not compatible with
reactions conditions. Finally, tertiary alkyl iodides, aryl-
substituted alkynes, and disubstituted alkynes did not
participate in the hydroalkylation reaction.
gave a lower yield (entries 5 and 6). Nickel complexes
supported by other closely related ligands were inferior (entries
7−9). With LiOt-Bu in place for LiOi-Pr we observed a small
amount of Sonogashira product and complete recovery of the
starting silane (entry 10). These results suggest that IPrCuOt-
Bu does not readily react with Ph3SiH to form IPrCuH and
instead leads to the formation of copper-acetylide and
Sonogashira product. Similarly, changing the alkoxide counter-
ion from lithium to sodium led to lower yield of the product
(entry 11).
Among common ethereal solvents, THF was the only
solvent other than DME that afforded the desired product in a
significant yield (entry 12). Finally, PMHS and silanes closely
related to Ph3SiH were all significantly inferior to Ph3SiH
(entries 13−15).
Using the standard conditions shown in Table 1 (entry 1),
we explored the scope of the reaction and found that a wide
range of E-alkenes can be prepared (Table 2). It is important
to note that all products shown in Table 2 are obtained as a
single regioisomer and a single diastereoisomer. Even severe
steric hindrance in the propargylic position does not impede
the formation of the product (17) and substitution at the
propargylic (13) and homopropargylic position (27) is
Considering the generally established mechanisms of
copper-catalyzed hydrofunctionalization of alkynes8 and
nickel-catalyzed cross coupling reactions,33 we propose that
the hydroalkylation reaction proceeds according to the
mechanism shown in Scheme 4. Initial hydrocupration of the
alkyne (V → VI) is followed by transmetalation to nickel (VI
→ VIII). The alkyl iodide is activated by the newly formed
alkenyl nickel complex (VIII). Reductive elimination results in
C
J. Am. Chem. Soc. XXXX, XXX, XXX−XXX
