Synthesis and thermal reactions of N-(2,3-epoxypropyl)diphenylamine

Article abstract of DOI:10.1007/s10593-007-0117-7

The synthesis of N-(2,3-epoxypropyl)diphenylamine is reported. It was found that thermal opening of the oxirane ring of N-(2,3-epoxypropyl)diphenylamine occurred both at the secondary and the tertiary carbon atoms but the basic reaction product is 3-hydro

Full text of DOI:10.1007/s10593-007-0117-7

Chemistry of Heterocyclic Compounds, Vol. 43, No. 6, 2007
SYNTHESIS AND THERMAL REACTIONS
OF N-(2,3-EPOXYPROPYL)DIPHENYLAMINE
B. Barvainiene1,2, A. Stanisauskaite1, and V. Getautis1
The synthesis of N-(2,3-epoxypropyl)diphenylamine is reported. It was found that thermal opening of the
oxirane ring of N-(2,3-epoxypropyl)diphenylamine occurred both at the secondary and the tertiary
carbon atoms but the basic reaction product is 3-hydroxy-1-phenyl-1,2,3,4-tetrahydroquinoline.
Keywords:
3-hydroxymethyl-1-phenylindoline,
3-hydroxy-1-phenyl-1,2,3,4-tetrahydroquinoline,
N-(2,3-epoxypropyl)diphenylamine, cyclization.
Heating diphenylamine 1 with epichlorohydrin (EPCH) under pressure [1] or with the addition of
sodium iodide at high temperatures [2] gives 3-hydroxy-1-phenyl-1,2,3,4-tetrahydroquinoline (2). In study [3]
compound 2 was obtained by heating diphenylamine 1 with excess EPCH at atmospheric pressure without a
catalyst. The same authors showed that formation of compound 2 occurs via N-(2-hydroxy-3-chloro-
propyl)diphenylamine [4]. We have found [5] that the tetrahydroquinoline 2 can also be prepared from the
epoxypropyl derivative of diphenylamine, i.e. N-(2,3-epoxypropyl)diphenylamine (3) which cyclizes upon
heating with opening of the oxirane ring at the secondary carbon atom in compound 2. The aim of this work is
the synthesis of compound 3 and a study of it cyclization processes.
Compound 3 is prepared by heating diphenylamine 1 with EPCH at 60-63ºC for 50 h in the presence of
glacial acetic acid with subsequent work up of the intermediate N-(2-hydroxy-3-chloropropyl)diphenylamine
with sodium hydroxide [4]. The drawback of this method is the long reaction time. The method we propose for
preparing compound 3 from diphenylamine 1 with EPCH in the presence of alkali differs in that the reaction is
carried out at room temperature in the presence of a 13 fold excess of KOH (with respect to the starting amine)
in order to shorten this time. Hence the synthesis of compound 3 can be carried out in a single step and the
reaction time is shortened to 7 h.
Many experiments have shown that the optimum temperature for the cyclization of compound 3 to
heterocycle 2 is 220-225ºC. Under these conditions the yield of compound 2 reaches 53%. At lower
temperatures the formation of compound 2 is very slow.
A study of the thermal reactions of compound 3 has shown that the 1,3-di(diphenylamino)-2-propanol
(4) and 3-hydroxymethyl-1-phenylindoline (5) are formed in addition to compound 2. With increase in the
cyclization temperature to 245-250ºC the amount of compound 5 increases but in this case the basic cyclization
reaction product is compound 2. Column chromatography of the reaction mass gave compounds 4 and 5 and also
the 1-phenyl-1,2,3,4-tetrahydroquinoline (6) and N-(2,3-dihydroxypropyl)diphenylamine (7). Formation of
__________________________________________________________________________________________
1Department of Organic Chemistry, Kaunas University of Technology, Kaunas LT-50270, Lithuania;
e-mail: brone.barvainiene@ktu.lt, albina.stanisauskaite@ktu.lt, and vytautas.getautis@ktu.lt. 2Faculty of
Technology, Kaunas College, Kaunas LT-50468. Translated from Khimiya Geterotsiklicheskikh Soedinenii, No.
6, pp. 852-855, June, 2007. Original article submitted March 22, 2006.
718
0009-3122/07/4306-718©2007 Springer Science+Business Media, Inc.

compound 5 (an indoline derivative) upon heating compound 3 is evidently because the oxirane ring opens at the
1
bond between tertiary carbon atom and oxygen atom. We have recorded the mass, IR, and H NMR spectra of
compound 5 in order to confirm its structure.
+
N
_
N
N
N
6
OH
+
+
8
_
H2O
OH
O
OH
H2O
∆
N
N
N
OH
7
3
2
_
Cl
OH
NH
OH
O
N
N
N
3
,
∆
OH
4
5
1
Comparing the IR spectra of compound 2 and 5 shows that both spectra show a broad, strong absorption
band at 3280 and 3300 cm-1 respectively, typical of hydroxyl group stretching vibrations. The vibration
associated with the C–OH group appears at 1065 and 1040 cm-1 respectively. In the first case the band is more
characteristic of a secondary and in the second a primary alcohol [6]. The mass spectrum of compound 5 shows a
rather low intensity (36%) molecular ion peak [M+ 225] together with a more stable fragment of even mass
[M-31]+ which can be formed by simple fission of a single bond from the molecular ion with odd mass [7]. In
addition disruption of the aromaticity of the pyrrole part of the indole molecule infers that the initial loss of the
substituent as a whole occurs from position 3 [8]. According to this the substance separated is compound 5 and
this structure is also confirmed by 1H NMR spectroscopy.
The formation of compound 4 by heating 3 can evidently be represented as the result of desalkylation of
the latter, forming diphenylamine 1 which reacts with the starting compound 3. The production of compounds 6
and 7 can be rationalized as a dehydration of the cyclization product 2 to give 1-phenyl-1,2- (or 1,4-)
dihydroxyquinoline which then disproportionates to 6 and the 1-phenylquinolinium base 8 as shown in [9].
However, we were unable to separate and identify compound 8. The water formed in the process of dehydration
of compound 2 takes part in a reaction with the epoxypropyl derivative 3 to form 7 which proved identical to
that obtained by treating compound 3 with diluted trifluoroacetic acid in dioxane.
719

EXPERIMENTAL
1H NMR spectra were recorded on a Tesla BS-487C spectrometer (80 MHz) with HMDS (δ 0.05 ppm)
as internal standard. IR spectra were taken on an IR-20 spectrometer for KBr tablets. Mass spectra were recorded
on a Hitachi M-80A instrument with direct sample introduction into the ion chamber and a voltage of 80 eV.
Monitoring of the course of the reactions was carried out by TLC on Silufol UV-254 plates which were revealed
with a UV lamp with 254 filter or by iodine vapor. Chemapol L40/100 was used for the column
chromatography.
N-(2,3-Epoxypropyl)diphenylamine (3). A mixture of diphenylamine (50.7 g, 0.3 mol), EPCH (277.5,
3.0 mol), and powdered anhydrous potassium carbonate (58.5 g, 0.45 mol) was stirred for 20-30 min and
powdered potassium hydroxide (198 g, 3.0 mol) was added at such a rate that the reaction temperature did not
exceed 30ºC. The reaction was carried out for 7 h (TLC, ether–petroleum ether, 1:1) and then treated with cold
water and extracted with ether. After removal of ether and excess EPCH the residue was distilled in vacuo in a
nitrogen stream. The fraction with bp 158-159ºC was collected at 1-2 mm Hg (bp 161-163ºC at 2.5 mm Hg [4])
to give compound 3 (61.8 g, 91.5%).
1,3-Di(diphenylamino)-2-propanol (4). A mixture of compound 1 (12.7 g, 0.075 mol) and compound 3
(11.3 g, 0.05 mol) was heated at 150-155ºC to the disappearance of the starting materials (4 days, TLC, acetone-
hexane, 1:4) to give compound 4 (9.9 g, 50%); mp 92-93ºC (hexane). IR spectrum, ν, cm-1: 3540 (OH); 3065,
3090 (arom. CH); 2925 with sh. at 2935, 2875 (aliph. CH); 1595 (C=C); 1500 with sh. at 1460 (C=C, aliph.
CH); 750 with sh at 745, 700 (CH, monosubstitued benzene). 1H NMR spectrum (CDCl3), δ, ppm: 7.5-6.5 (20H,
m, Ar); 4.40-4.35 (5H, m, NCH2CHCH2N); 1.12 (1H, m, OH). Found, %: C 82.02; H 6.52; H 7.23. C27H26N2O.
Calculated, %: C 82.20; H 6.64; N 7.10.
N-(2,3-Dihydroxypropyl)diphenylamine (7). Compound 3 (5.6 g, 0.025 mol) was dissolved in dioxane
(25 ml) and 0.12 ml of a solution of trifluroacetic acid in water (0.8 g CF3COOH in 100 ml water) was added at
105ºC over 5 min. The mixture was refluxed to the absence of starting material (TLC, acetone-hexane, 1:4). The
mixture was then cooled and diluted with water (200 ml). The water was decanted and compound 7 (4.9 g) was
obtained as an oily substance crystallizing on standing. Yield 80.7%; mp 95.5-96.5ºC (from a mixture of toluene
and hexane, 1:1). IR spectrum, ν, cm-1: 3500-3100 (br, OH); 3070, 3045 (arom. CH); 2960, 2940, 2900, 2880
(aliph. CH); 1595 (C=C); 1500 with sh. at 1455, 1470 (C=C, aliph. CH); 1065 with sh. at 1040 (primary and
secondary OH); 750 with sh. at 780, 735, 700 (CH, monosubstituted benzene). 1H NMR spectrum (acetone-d6),
δ, ppm: 7.62-6.75 (10H, m, Ar); 4.15-3.00 (7H, CH2CH(OH)CH2OH). Found, %: C 73.99; H 6.87; N 5.64.
C15H17NO2. Calculated, %: C 74.05; H 7.04; N 5.76.
Cyclization of N-(2,3-epoxypropyl)diphenylamine (3). A. Compound 3 (11.3 g, 0.05 mol) was heated
at 220-225ºC in a nitrogen atmosphere for 30 h. The reaction product was chromatographed eluting with
acetone-hexane (1:4) to give compound 2 (6.0 g, 53.1%); mp 77-78ºC and compound 4 (1.5 g, 7.6%);
mp 92-93ºC. Compound 5 was also observed by chromatography in addition to 2 and 4. The spectroscopic data
for compound 2 has been published in [5].
B. Compound 3 (45 g, 0.2 mol) was heated at 245-250ºC for 8 h. The reaction product was separated
analogously to method A to give compound 4 (2.4 g) with mp 92.2-93ºC (mixed sample with compound 4
prepared as above did not give a melting point depression) as well as compound 6 [2.1 g, yield 5%, bp
142-145ºC, 2-3 mm Hg; bp 142.5-145, 2-3 mm Hg, [3]), compound 7 [1.7 g, yield 3.5%, mp 95.5-96.5ºC], and a
mixture of compounds 2 and 5 (20 g) which was dissolved in ethanol. Cooling to 0-2ºC gave crystals which were
filtered off and crystallized three times from ethanol to give compound 2 (16.2 g, 36.6%) with mp 79-80.5ºC.
After evaporation of the mother liquor the residue was purified by column chromatography eluting with
acetone–ether–hexane (1:1:3) to give compound 2 (5.5%) and compound 5 plus an admixture of compound 2
(0.8 g) which was separated by repeated column chromatography. Yield of compound 5 was 0.5 g;
720

mp 81-83ºC (from ethanol). IR spectrum, ν, cm-1: 3300 (br, OH); 3050 with sh. at 3025 (arom. CH); 2920-2880
(aliph. CH); 1590 (C=C); 1040 (C–OH); 748 with sh. at 765, 752, 700 (CH mono and o-disubstituted benzene).
1H NMR spectrum (CDCl3), δ, ppm: 7.38-6.71 (9H, m, Ar); 4.15-3.76 (4H, m, CH2OH, N–CH2); 3.56 (1H, m,
CH); 1.6 (1H, m, OH). Mass spectrum, m/z (Irel, %): 225 [M]+ (24), 194 [M-CH2OH]+ (100). Found, %: C 79.81;
H 6.62; N 5.98. C15H15NO. Calculated, %: C 79.97; H 6.71; N 6.22.
C. Compound 3 (22.5 g, 0.1 mol) was heated at 260-265ºC in a nitrogen atmosphere for 2.5 h. The
reaction product was separated as indicated above to give compound 2 (6.2 g, 27.5%), compound 6 (2 g, 8.9%),
compound 7 (2.5 g, 12%), compound 5 (1.1 g, 0.5%), and compound 4 (2 g, 5%).
This work was carried out with the financial support of the Lithuanian fund for science and education
(project B-18/2006).
REFERENCES
1.
2.
3.
Farbwerke vorm. Meister Lucius & Bruning, Ger. Pat. 284291; Chem. Zentralblatt, 2, 110 (1915).
W. Davies and W. Savige, J. Chem. Soc., 890 (1950).
H. H. Vorozhtsov, Jr. and S. I. Kutkevichus., Khim. Geterotsikl. Soedin., 374 (1965). [Chem. Heterocycl.
Comp., 1, 248 (1965)].
4.
5.
6.
7.
8.
9.
S. I. Kutkevichus and N. N. Vorozhtsov, Jr., Khim. Geterotsikl. Soedin., 549 (1965). [Chem. Heterocycl.
Comp., 1, 368 (1965)].
B. Barvainiene, A. Stanisauskaite, and V. Getautis, Khim. Geterotsikl. Soedin., 138 (2006). [Chem.
Heterocycl. Comp., 42, 123 (2006)].
E. Pretsch, P. Bühlmann, and C. Affolter, Structure Determination of Organic Compounds, Springer
Verlag (2000).
R. M. Silverstein, G. C. Bassler, and T. C. Morrill, Spectrometric Identification of Organic Compounds,
J. Wiley and Sons, Chichester (1991).
P. B. Terentiev and A. P. Stankevicius, Mass Spectrometric Analysis of Biologically Active Azo Bases [in
Russian], Mokslas, Vilnius (1987).
N. N. Vorozhtsov, Jr. and S. I. Kutkevichus, Zh. Obshch. Khim., 28, 2682 (1958).
721
