Synthesis and Evaluation of Doxorubicin-Loaded Gold
Nanoparticles for Tumor-Targeted Drug Delivery
Yongle Du,† Long Xia,† Ami Jo,‡ Richey M. Davis,‡ Philippe Bissel,§ Marion F. Ehrich,§ and
6
7
8
9
David G. I. Kingston*,†
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
†Department of Chemistry and the Virginia Tech Center for Drug Discovery, Virginia Tech, Blacksburg,
Virginia 24061, United States
‡Department of Chemical Engineering and the Virginia Tech Center for Drug Discovery, Virginia Tech,
Blacksburg, Virginia 24061, United States
§Virginia-Maryland College of Veterinary Medicine and the Virginia Tech Center for Drug Discovery,
Virginia Tech, Blacksburg, Virginia 24061, United States
Supporting Information
ABSTRACT:
Doxorubicin is an effective and widely used cancer chemotherapeutic agent,
but its application is greatly compromised by its cumulative dose-dependent side effect of
cardiotoxicity. A gold nanoparticle-based drug delivery system has been designed to overcome
this limitation. Five novel thiolated doxorubicin analogs were synthesized and their biological
activities evaluated. Two of these analogs and PEG stabilizing ligands were then conjugated to
gold nanoparticles, and the resulting Au-Dox constructs were evaluated. The results show that
release of native drug can be achieved by the action of reducing agents such as glutathione or
under acidic conditions, but that reductive drug release gave the cleanest drug release. Gold
1
ACS Paragon Plus Environment

Bioconjugate Chemistry
Page 2 of 31
1
2
3
4
5
6
7
8
9
nanoparticles (Au-Dox) were prepared with different loadings of PEG and doxorubicin, and one
formulation was evaluated for mammalian stability and toxicity. Plasma levels of doxorubicin in
mice treated with Au-Dox were significantly lower than in mice treated with the same amount of
doxorubicin, indicating that the construct is stable under physiological conditions. Treatment of
mice with Au-Dox gave no histopathologically observable differences from mice treated with
saline, while mice treated with an equivalent dose of doxorubicin showed significant
histopathologically observable lesions.
