Pd-Catalyzed Isomerization of Aryl-Substituted Epoxides
J . Org. Chem., Vol. 62, No. 19, 1997 6559
24.9. IR: 3500-2600 (broad), 3028, 2927, 2854, 1962-1885
(w), 1704, 1603, 1494, 1451, 1411, 1288, 1241, 1187, 1094,
1048, 964, 744, 693. MS: 242 (M+ - H2O, 5.0), 159 (2.5), 145
(6.8), 131 (20.3), 117 (25.0), 104 (100.0), 91 (7.3), 78 (3.7). A
solution of this carboxylic acid (1.97 g, 7.58 mmol) in anhy-
drous ethanol (0.79 g, 1.0 mL, 0.017 mol) was treated with
p-toluenesulfonic acid hydrate (0.29 g, 1.52 mmol) and refluxed
for 1 h. After cooling, the mixture was diluted with ether and
water (10 mL each) and washed with NaHCO3 (10 mL) and
brine (10 mL). After drying and evaporation, the crude
product was chromatographed (Rf ) 0.77, 6:1 hexane-ethyl
acetate) to give 1.13 g (52%) of ethyl (E)-11-phenyl-10-
undecenoate. 1H NMR: δ 7.35-7.26 (m, 5H), 6.37 (d, J ) 15.9
Hz, 1H), 6.22 (dt, J ) 15.9, 6.6 Hz, 1H), 4.12 (q, J ) 7.1 Hz,
2H), 2.29 (t, J ) 7.1 Hz, 2H), 2.19 (m, 2H), 1.31-1.22 (m, 12
H), 1.25 (t, J ) 7.1 Hz, 3H). IR: 3061, 3028, 2928, 2854, 1946,
1874, 1738, 1689, 1598, 1494, 1453, 1371, 1249, 1180, 1099.
1029, 964, 910, 735, 701. MS: 242 (M+ - C2H5OH, 58.9), 224
(6.6), 214 (3.3), 200 (3.9), 173 (2.4), 155 (11.4), 145 (9.8), 131
(21.5), 117 (41.0), 104 (100.0), 91 (6.3). The ester (1.13 g, 3.92
mmol) was epoxidized with MCPBA (1.11 g, 4.71 mmol, 73%
pure) in CH2Cl2 (10 mL) according to the above procedure; the
usual workup and chromatography gave 950 mg (80%) of ethyl
10,11-epoxy-11-phenylundecanoate (21); Rf ) 0.81 (6:1, hex-
ane-ethyl acetate). 1H NMR: δ 7.37-7.23 (m, 5H), 4.11 (q,
J ) 7.1 Hz, 2H), 3.59 (d, J ) 1.9 Hz, 1H), 2.94 (td, J ) 5.5, 2.2
Hz, 1H), 2.28 (t, J ) 7.3 Hz, 2H), 1.71-1.19 (m, 16H), 1.24 (t,
J ) 7.3 Hz, 3H). 13C NMR: δ 173.8, 137.9, 128.2, 127.8, 125.3,
63.0, 62.9, 59.9, 58.4, 34.1, 32.1, 29.1, 28.9, 25.7, 24.7, 23.6,
14.0. IR: 3062, 3029, 2931, 2855, 1950, 1881, 1730, 1689,
1604, 1497, 1452, 1371, 1303, 1246, 1180, 1099, 1029, 880, 752,
700. MS: 241 (M+ - C2H5O - H2O, 2.5), 213 (100.0), 199
(10.8), 183 (5.8), 167 (22.6), 155 (17.2), 134 (17.5), 121 (22.9),
108 (20.2), 91 (46.5).
11,12-Ep oxy-12-p h en yl-2-d od eca n on e (22). To a sus-
pension of pyridinium chlorochromate (3.13 g, 0.145 mol) and
Celite (6.3 g) in CH2Cl2 (20 mL) was added (E)-11-phenyl-10-
undecen-1-ol (2.38 g, 9.67 mmol); the oxidation was complete
after 2 h at rt, by TLC. The reaction mixture was diluted with
100 mL of pentane-ether (1:1) and filtered. After evaporation,
chromatography gave 1.86 g (79%) of (E)-11-phenyl-10-un-
decenal;56 Rf ) 0.58 (6:1 hexane-ethyl acetate), mp 48-49 °C.
1H NMR: δ 9.74 (t, J ) 1.9 Hz, 1H), 7.36-7.17 (m, 5H), 6.37
(d, J ) 15.9, 1H), 6.22 (dt, J ) 15.9, 6.6 Hz, 1H), 2.19 (m, 2H),
1.42-1.30 (m, 14H), 1.17 (d, J ) 6.1 Hz, 3H). To a cooled
solution of methylmagnesium iodide (10 mL, 1.9 M in ether,
0.019 mol) was slowly added a solution of the above aldehyde
(1.86 g, 7.59 mmol) in ether (5 mL). The reaction mixture was
stirred at rt for 30 min at which point TLC indicated only the
product alcohol (Rf ) 0.28, 6:1 hexane-ethyl acetate). The
reaction mixture was quenched with 15 mL of ice water,
washed with saturated aqueous NaHSO4 (3 × 15 mL), NaH-
CO3 (3 × 15 mL), and brine (15 mL), and dried (MgSO4).
Evaporation of solvent gave 1.42 g (72%) of crude (E)-12-
phenyl-11-dodecen-2-ol, which was sufficiently pure to continue
with the next step. 1H NMR: δ 7.35-7.15 (m, 5H), 6.37 (d, J
) 15.9 Hz, 1H), 6.22 (dt, J ) 15.9, 6.6 Hz, 1H), 2.19 (m, 2H),
1.42-1.30 (m, 14H), 1.17 (d, J ) 6.1 Hz, 3H). 13C NMR: δ
137.9, 131.1, 129.7, 128.4, 126.7, 125.9, 68.1, 68.0, 39.3, 33.0,
29.5, 29.4, 29.3, 29.2, 25.7, 23.4. IR: 3378, 3025, 2927, 2854,
1941-1798 (w), 1651, 1598, 1494, 1449, 1373, 1308, 1119,
1071, 963, 743, 692. MS: 243 (M+ - H2O, 18.2), 199 (3.1),
185 (8.4), 171 (9.1), 158 (8.1), 143 (15.6), 138 (86.1), 129 (69.1),
117 (23.5), 104 (67.9), 96 (44.2), 82 (26.7). The above alcohol
(1.42 g, 5.44 mmol) was added to a mixture of PCC (1.76 g,
8.16 mmol) and Celite (3.52 g) in CH2Cl2 (10 mL). After 20 h
at rt, the reaction mixture was worked up as described above;
chromatography gave 867 mg (62%) of (E)-12-phenyl-11-
dodecen-2-one; Rf ) 0.59 (6:1 hexane-ethyl acetate). 1H
NMR: δ 7.36-7.15 (m, 5H), 6.37 (d, J ) 15.9 Hz, 1H), 6.22
(dt, J ) 15.9, 6.6 Hz, 1H), 2.41 (t, J ) 7.3 Hz, 2H), 2.19 (m,
2H), 2.12 (s, 3H), 1.59-1.24 (m, 12H). 13C NMR: δ 209.1,
137.8, 131.0, 129.6, 128.3, 126.5, 125.7, 43.7, 32.9, 29.7, 29.3,
29.2, 29.1, 29.0, 23.8, 23.7. IR: 3034, 2927, 2850, 1954, 1885,
1715, 1598, 1494, 1461, 1375, 1161, 1082, 965, 742, 694. MS:
242 (M+ - OH, 100.0), 227 (4.6), 202 (4.0), 186 (8.9), 171 (7.8),
157 (9.4), 143 (20.2), 138 (31.4), 129 (68.6), 117 (37.3), 104
(86.8), 95 (36.3), 82 (60.3). The ketone (867 mg, 3.35 mmol)
was dissolved in CH2Cl2 (10 mL), cooled to 0 °C, and epoxidized
with MCPBA (950 mg, 73% pure, 4.02 mmol). After stirring
at rt for 3 h, the mixture was worked up as described above;
chromatography gave 718 mg (78%) of pure 11,12-epoxy-12-
phenyl-2-dodecanone (22); Rf ) 0.39 (6:1 hexane-ethyl ace-
tate). 1H NMR: δ 7.34-7.23 (m, 5H), 3.59 (d, J ) 1.9 Hz, 1H),
2.93 (td, J ) 5.5, 1.9 Hz, 1H), 2.41 (t, J ) 7.6 Hz, 2H), 2.12 (s,
3H), 1.71-1.29 (m, 14H). 13C NMR: δ 209.0, 137.8, 128.3,
127.8, 125.5, 63.1, 62.9, 58.5, 43.6, 32.2, 29.7, 29.2, 29.1, 29.0,
25.8, 23.7. IR: 2922, 2849, 1940-1790 (w), 1715, 1653, 1499,
1461, 1373, 1207, 1161, 1128, 870, 782, 757, 741, 700. MS:
241 (M+ - C2H4 - H2O, 1.7), 228 (19.7), 217 (6.5), 183 (100.0),
165 (6.4), 147 (12.8), 133 (3.3), 121 (6.0), 107 (10.1), 95 (6.2),
81 (5.4). Anal. Calcd for C18H26O2: C, 78.79; H, 9.55.
Found: C, 79.20; H, 9.58.
11,12-Ep oxy-12-p h en yl-1-d od ecyn e (23). The general
procedure is taken from the literature.57 To a clear solution
of carbon tetrabromide (985 mg, 2.97 mmol) in CH2Cl2 (7 mL)
in a Schlenk flask under a positive flow of N2 was added
triphenylphosphine (1.56 g, 5.94 mmol) to give an orangish
red mixture. (E)-11-Phenyl-10-undecenal (364 mg, 1.49 mmol;
see first step in the preparation of 22) dissolved in CH2Cl2 (1
mL) was added, causing the color to change from orange to
yellow. After stirring at rt for 30 min, TLC showed no starting
material. The reaction mixture was diluted with pentane (30
mL) followed by filtration to remove triphenylphosphine oxide
and evaporation of solvent. This step was repeated twice. The
crude product was purified by chromatography to give (E)-1,1-
dibromo-12-phenyl-1,11-dodecadiene (327 mg, 55%); Rf ) 0.66
(6:1 hexane-ethyl acetate). 1H NMR: δ 7.36-7.17 (m, 5H),
6.38 (t, J ) 16.6 Hz, 1H), 6.22 (dt, J ) 15.9, 6.6 Hz, 1H), 2.21
(m, 2H), 2.08 (m, 2H), 1.53-1.25 (m, 12H). 13C NMR: δ 180.0,
138.7, 137.9, 130.9, 129.7, 128.3, 126.6, 125.8, 32.9, 32.8, 29.3,
29.2, 29.1, 29.0, 28.9, 27.7. IR: 3025, 2925, 2854, 1941-1796
(w), 1728, 1598, 1494, 1454, 1071, 1028, 963, 799, 743, 692.
MS: 239 (M+ - Br2, 4.5), 185 (3.1), 171 (12.2), 157 (16.5), 143
(10.7), 131 (24.7), 117 (60.4), 104 (100.0), 91 (13.1). A solution
of the dibromoalkene (296 mg, 0.74 mmol) in THF (4 mL) at
-78 °C under nitrogen was treated with n-butyllithium (1.2
mL, 1.3 M in hexane, 1.6 mmol). After being stirred for 1 h
at -78 °C, the reaction mixture was warmed to rt and
maintained at rt for a further hour, at which point TLC showed
only the product; Rf ) 0.90 (6:1 hexane-ethyl acetate). The
reaction mixture was diluted with hexane and water (10 mL
each). The organic layer was separated, washed with brine
(10 mL), and dried (MgSO4). After evaporation of solvent, 177
mg (99%) of crude (E)-12-phenyl-11-dodecen-1-yne was ob-
tained. 1H NMR: δ 7.36-7.15 (m, 5H), 6.38 (d, J ) 15.9 Hz,
1H), 6.22 (dt, J ) 15.9, 6.6 Hz, 1H), 2.24-2.15 (m, 4H), 1.93
(t, J ) 2.7 Hz, 1H), 1.52-1.26 (m, 12H). 13C NMR: δ 137.9,
131.0, 129.7, 128.3, 126.6, 125.8, 97.4, 84.6, 67.9, 32.8, 29.2,
28.9, 28.6, 28.5, 28.4, 18.2. IR: 3312, 3095, 3061, 3028, 2932,
2855, 2118, 1944-1801 (w), 1649, 1598, 1494, 1449, 1071,
1029, 964, 743, 692, 631. MS: 240 (M+, 35.2), 225 (2.0), 197
(7.7), 183 (23.9), 169 (33.2), 155 (33.7), 149 (68.3), 130 (86.1),
117 (89.6), 104 (100.0), 94 (41.6), 81 (35.2). The above enyne
(149 mg, 0.62 mmol) was epoxidized with MCPBA (176 mg,
73% pure, 0.75 mmol) in CH2Cl2 (5 mL) according to the above
procedure; chromatography gave 107 mg (67%) of pure 11,12-
epoxy-12-phenyl-1-dodecyne (23); Rf ) 0.76 (6:1 hexane-ethyl
acetate). 1H NMR: δ 7.38-7.24 (m, 5H), 3.60 (d, J ) 1.9 Hz,
1H), 2.95 (td, J ) 5.5, 2.2 Hz, 1H), 2.19 (td, J ) 6.8, 2.9 Hz,
2H), 1.94 (t, J ) 2.9 Hz, 1H), 1.69-1.25 (m, 14H). 13C NMR:
δ 137.9, 128.3, 127.8, 125.4, 97.4, 84.5, 67.9, 62.9, 58.4, 32.1,
29.2, 28.8, 28.5, 28.3, 25.7, 18.2. IR: 3310, 2931, 2856, 2117,
1962-1729 (w), 1605, 1497, 1462, 1071, 1027, 880, 750, 698,
627. MS: 199 (M+ - CH2CCH - H2O, 1.7), 173 (9.9), 157
(57) (a) Corey, E. J .; Fuchs, P. L. Tetrahedron Lett. 1972, 36, 3769-
3772. (b) Ramirez, F.; Desai, N. B.; McKelvie, N. J . Am. Chem. Soc.
1962, 84, 1745-1747.
(56) Han, N.; Lei, X.; Turro, N. J . J . Org. Chem. 1991, 56, 2927-
2930.
