Synthesis and properties of novel hole-transporting materials with triphenylamine units

Article abstract of DOI:10.1016/j.cclet.2011.11.018

Two novel organic hole-transporting materials have been synthesized by combination of triphenylamines (TPA) via π-conjugated bonds using Wittig reaction. The structures were characterized by NMR, FT-IR and HRMS. The optical, electrochemical and thermal properties of the materials were studied in detail. The results show that these two compounds have blue emission, proper HOMO levels and high thermal stability. Furthermore, a quantum chemical calculation on electron distribution of the two compounds was performed, which suggests the current synthesized materials would be promising candidates for hole-transporting materials.

Full text of DOI:10.1016/j.cclet.2011.11.018

Available online at www.sciencedirect.com
Chinese Chemical Letters 23 (2012) 141–144
www.elsevier.com/locate/cclet
Synthesis and properties of novel hole-transporting materials with
triphenylamine units
a,b
Wen Zheng Gao a, Xiang Gao Li a, Shi Rong Wang a, , Hai Jun Lv
*
a School of Chemical Engineering and Technology, Tianjin University, Tianjin 300072, China
b College of Chemical and Pharmaceutical Engineering, Hebei University of Science and Technology Shijiazhuang 050018, China
Received 12 July 2011
Available online 22 December 2011
Abstract
Two novel organic hole-transporting materials have been synthesized by combination of triphenylamines (TPA) via p-conjugated
bonds using Wittig reaction. The structures were characterized by NMR, FT-IR and HRMS. The optical, electrochemical and thermal
properties of the materials were studied in detail. The results show that these two compounds have blue emission, proper HOMO levels
andhigh thermalstability. Furthermore, a quantumchemical calculationon electrondistributionofthetwo compoundswas performed,
which suggests the current synthesized materials would be promising candidates for hole-transporting materials.
# 2011 Shi Rong Wang. Published by Elsevier B.V. on behalf of Chinese Chemical Society. All rights reserved.
Keywords: Wittig reaction; Triphenylamine; Hole-transporting materials; Quantum chemical calculation
In general, the hole-transporting layer in multi-layered organic light emitting diodes (OLEDs) plays the roles of
facilitating hole injection from the anode into organic layers, accepting holes and transporting the injected holes to the
emitting layer [1]. They should have proper energy level of highest occupied molecular orbital (HOMO) for efficient
hole injection and high mobility. They also ought to be of excellent solubility and can form homogenous thin films
with both morphological and thermal stability [2]. While a large number of organic materials exhibit good mobility,
there are some drawbacks such as poor stability and high driving voltage associated with these materials. So it is highly
desirable to design and synthesize new materials.
At present, triphenylamine (TPA) derivatives have been the most widely used hole-transporting materials because
of their high hole mobility [3]. The nitrogen atom in the triphenylamine bestows an electron-donating ability.
Moreover, Tokito et al. have found that the linear linkage is much more effective than the branch linkage in increasing
the Tg [4]. Herein, we designed and synthesized two new compounds by the combination of TPA units connected by p-
conjugate bonds. It was expected to obtain new hole-transporting materials with excellent performance.
1. Experimental
The designed synthetic route for the novel hole-transporting materials TM1 is depicted in Scheme 1.
Compounds 1–8 were synthesized according to previous literatures [5]. A mixture of 2:1 equiv of 4-[N,N-di
* Corresponding author.
E-mail address: wangshirong@tju.edu.cn (S.R. Wang).
1001-8417/$ – see front matter # 2011 Shi Rong Wang. Published by Elsevier B.V. on behalf of Chinese Chemical Society. All rights reserved.
doi:10.1016/j.cclet.2011.11.018

142
W.Z. Gao et al. / Chinese Chemical Letters 23 (2012) 141–144
H C CH
H C
CH
3
H C
CH
3
3
3
3
3
N
N
b
N
a
CHO
CH OH
2
1
CH PPh Br
2
3
2
H C
CH
3
3
H C
CH
H C
CH
H C
CH
3
3
3
3
3
3
H C
CH
3
3
N
N
N
N
f,g
a
c,d,e
N
b
CHO
CH OH
CH PPh Br
CHO
2
2
3
3
5
4
6
CH
3
N
2
CH
H C
3
3
N
N
CH
N
CH
N
3
3
CH
3
h,i,j
f,g
d,e
+
NH
CH
CH
3
3
TM 1
CH
I
3
OHC
CHO
8
7
N
CH
H C
3
3
6
N
N
CH
CH
TM 2
3
3
Scheme 1. Synthesis routes of TM1 and TM2. (a) NaBH4; (b) PPh3+HBrꢀ; (c) PPh3+CH3Brꢀ; (d) THF; (e) t-BuOK; (f) DMF; (g) POCl3; (h) CuCl;
(i) 1, 10-phenanthroline; (j) dimethylbenzene.
(4-tolyl)amino]benzyl(triphenyl)phosphonium bromide (compound 2) and 4-N,N-di(4-formylphenyl)tolylbenze-
namine (compound 8) were dissolved in freshly dried tetrahydrofuran (THF). The reaction system was cooled to
0 8C and then 2 equiv of potassium tertbutoxide which dissolved in dried THF was added dropwise under stirring.
The reaction mixture was stirred at room temperature for 6 h until compound 8 was consumed completely
monitored by thin-layer chromatography. THF was removed at reduced pressure and poured into water and
neutralized with dilute HCl and then extracted with dichloromethane. Target compounds were obtained as pure E
stereoisomer, after treatment of the Z/E mixture resulting from the Wittig condensation with a catalytic amount of
iodine under refluxing for 6 h in THF, then remanent iodine were removed by pouring into sodium hydroxide
solution (wt = 10%) and stirred for 2 h. After extracted with dichloromethane, the solvent was removed at reduced
pressure and the residues were chromatographed on a silica gel column (cyclohexane: ethyl acetate = 20:1 as
1
eluent) to give bright yellow solid. Yield 69.3%; IR (n (KBr)/cmꢀ1): 3026, 1590, 1500, 1310, 816; H NMR
(CDCl3, 500 MHz): d 2.326 (s, 12H), 2.342 (s, 3H), 6.933 (s, 4H), 6.986–7.112 (m, 28H), 7.323–7.365 (m, 8H);
ESI-HRMS (m/z) calcd. for C63H55N3(M+): 853.4396, Found: 853.4395.
TM2 was synthesized by using 1-{4-[N,N-di(4-tolyl)amino]phenyl}allyl(triphenyl)phosphonium bromide
(compound 6) and 4-N,N-di(4-formylphenyl)tolylbenzenamine (compound 8) according to the general method
described above. Yield 57.4%; IR (n (KBr)/cmꢀ1): 2910, 1597, 1500, 1322, 967, 807; 1H NMR (CDCl3, 500 MHz): d
2.313 (s, 12H), 2.328 (s, 3H), 6.640 (d, 2H, J = 15.5 Hz), 6.805 (d, 2H, J = 17.5 Hz), 6.948–7.072 (m, 34H), 7.291 (d,
6H, J = 7.5 Hz); ESI-HRMS (m/z) calcd. for C67H59N3(M+): 905.4709, found: 905.4706.
2. Results and discussion
The thermal properties of the two compounds were investigated by differential scanning calorimetry (DSC). The
two compounds show distinct Tg of 102.58 8C (TM1) and 114.68 8C (TM2), higher than that of the widely used hole-
transporting material N,N0-di(1-naphthyl)-N,N0-diphenyl-[1,10-biphenyl]-4,40-diamine (NPB) (98 8C) [6], which
