groups. We envisaged that the rotatable C-C bonds at the
periphery may endow AIE characterstics to the synthesized
derivative 6. The amino/thiophene groups were incorporated in
derivative 6 due to their known affinity for gold ions (Scheme 1).
Gratifyingly, the derivative 6 exhibited AIE characterstics and
formed fluorescent assemblies in the H2O: THF solvent mixture
which served as reactors to generate Au-Fe3O4 nanocomposites
having size in the range of (1.5-2.0 nm). To the best of our
knowledge, there is no report in literature regarding generation
of Au-Fe3O4 nanocomposites having such a small size (Table
S2). During the formation of Au-Fe3O4 NPs, assemblies of
derivative 6 were oxidized to AIE active polymeric species PTh-
co-PANI-6 which showed broad emission in the broad range of
365-640 nm. A significant overlap between absorption spectra of
Au-Fe3O4 NPs and emission spectra of the oxidized species was
observed which indicated the possibility of good energy transfer
between them. To check the validity of our hypothesis, we
examined the model reaction between aniline (10) and methyl
propiolate (11) in the presence of CO source in the presence of
PTh-co-PANI-6: Au-Fe3O4 NPs as catalyst. The reaction was
Afterwards, we analyzed the photophysical behavior of the
compound in H2O/THF solvent system. The UV-vis and
temperature dependent absorption studies of derivative 6 in
THF/H2O solvent mixture suggested the development of J-
aggregates (Figure S2-S3). In the emission studies, upon
increasing the water content in the THF solutions (0-60%), a
gradual increase in the intensity of the emission band was
observed and the emission band was red shifted from 417 to
427 nm (Figure S4). The AIE behaviour of derivative 6 was
further confirmed by viscosity dependent fluorescence studies
(Figure S5). The formation of spherical aggregates of compound
6 was confirmed by TEM studies (Figure S6).
To ascertain the applicability of aggregates of derivative 6 for
preparation of Au-Fe3O4 nanocomposites, we followed the
procedure as reported earlier.[8] In the absorption studies, the
simultaneous addition of Au3+ and Fe3+ ions (15 equiv.) to the
solution of derivative 6, SPR band of Au NPs appeared at 550
nm (after 25 mins) which was gradually shifted to 570 nm. The
intensity of the level-off tail was also increased, thus, signifying
the preparation of Au-Fe3O4 magnetic nanocomposites (Figure
S7).[11] The color of the solution was also changed from colorless
to yellow to purple and finally turned to reddish brown (Figure
S8). The entire process was complete within 45 mins.
The TEM and HRTEM image of derivative 6 in the presence of
Au3+ and Fe3+ ions (15 equiv.) revealed the existence of
spherical PTh-co-PANI-6: Au-Fe3O4 magnetic nanocomposites
encapsulated into the network of polymeric species (Figure 1,
S9). The DLS studies demonstrated the size of formed Au-Fe3O4
nanodots in the range of 1.5-2.0 nm (Figure S10). The powder
XRD analysis of Au-Fe3O4 nanodots displayed diffraction peaks
for fcc lattice of Fe3O4 NPs and Au NPs (Figure S11).[12] The
XPS analysis of the PTh-co-PANI-6: Au-Fe3O4 nanodots
confirmed the presence of Au (0) ( Au4f, 85.9 and 88.9 eV)and
Fe3+ and Fe2+ species (Fe2p, 710.8 and 724.5 eV) in the Au-
Fe3O4 lattice.[13] Additionally, peaks were detected for S2p, C1s,
O1s and N1s which were due to organic residue (Figure S12).
The appearance of band at 630 cm-1 in the Raman spectrum
relates to the A1g vibration mode of Fe3O4 NPs (Figure S13).[11]
The DT-TGA analysis of PTh-co-PANI-6: Au-Fe3O4
nanomaterials suggested a nonlinearly weight loss from 200 to
600 °C. From the measurements for weight loss, the amount of
PTh-co-PANI coating layer on Au-Fe3O4 nanodots was found to
be approximately 32% (Figure S14). From hysteresis
measurements, the magnetic nature of Au-Fe3O4 nanodots was
estimated (Figure S15, Table S3).
complete in 5 hrs to furnish the desired product in 87% yield. In
[6]
the presence of previously reported catalytic system,
the
reaction was complete in 6 hrs to give the final product in 80%
yield. This study validates our assumption that by making
assemblies more emissive, increasing the emission intensity and
wavelength of assemblies, extent of energy transfer and finally
catalytic efficiency of the system can be enhanced. Further,
PTh-co-PANI-6: Au-Fe3O4 nanodots were deposited on a filter
paper to prepare a “dip- catalyst”. The “dip- catalyst” serves as a
reusable strip for carrying out the C(sp)–H activation and it
showed recyclability up to 10 cycles. To the best of our
knowledge, this is the first report regarding study of influence of
structural features and photophysical properties of supporting
materials on the photocatalytic efficiency of the system. Further,
this is the first report of utilization of Au-Fe3O4 based „dip strip‟
photocatalyst for the preparation of quinoline derivatives via C-H
activation reaction.
Results and Discussion
Initially, precursor 4 was prepared via Diels-Alder reaction
between derivatives 2[10] and 3. Further, precursor 4 and boronic
ester 5 undergo Suzuki- Miyaura cross coupling reaction to
deliver the target derivative 6 in 76% yield (Scheme 1). The
structure of this derivative 6 was elucidated by different
spectroscopic techniques (Figure S1).
During the formation of Au-Fe3O4 nanodots the aggregates of
derivative 6 were oxidized to PTh-co-PANI. To understand this
process, a reaction was performed between derivative
6
(B)
(A)
(H2O/THF) and Au3+ and Fe3+ ions at room temperature and
after one hour, reaction mixture was left for slow evaporation at
room temperature . The as formed magnetic Au-Fe3O4 nanodots
were filtered and then washed with organic solvents (CHCl3 and
THF). The residue filtrate was allowed to evaporate to obtain the
solid organic material and formed the oxidized species PTh-co-
PANI-6 (Figure 1).
3
5
Ph2O,
240oC
2
4
6
1
Scheme 1. (A) Structure of derivative 1 and (B) Synthesis of derivative 6.
1
As per H NMR studies of the oxidized material (PTh-co-PANI-
6), the signals in the aromatic region were shifted and
