PAPER
Synthesis of C1-C6 Segment of Carbonolide B
397
benzoate was prepared as reported.12 Toluene, CH2Cl2, MeOH,
THF and Et2O were dried according to standard procedures. The re-
quired a-D-xylo-furanuronic acids 6a-c and a-D-lyxo-furonuronic
acid 6d were prepared according to our previous report.10
dropwise. The mixture was stirred for 1.5 h during which the tem-
perature slowly rose to r.t. The solvent was removed under reduced
pressure and the residue was purified by column chromatography
(petroleum ether/EtOAc, 15:1) to give 5d as a white solid. Yield:
0.90 g, 83%; mp 126−128 °C; [α]D25 -59.46 (c 1, CHCl3).
1,2-O-Isopropylidene-3-O-methyl-6-deoxy-6-diazo-a-D-xylo-
hexo-furan-5-ulose (5a); Typical Procedure
IR (nujol): ν = 2116 (CHN2), 1621 (C=O) cm−1.
To a stirred and cooled (0 °C) solution of a-D-xylo-furanuronic acid
6a (1 g, 4.5 mmol) in anhyd CH2Cl2 (15 mL) was added oxalyl chlo-
ride (0.48 mL, 5.5 mmol) and DMF (0.02 mL) under N2 atm. The
mixture was allowed to attain r.t. (25 °C) and stirred for 3 h. The
solvent was removed under reduced pressure and the acyl chloride
thus obtained was used in the next step. A solution of acyl chloride
in anhyd Et2O (10 mL) was cooled to 0 °C. To this an ice-cooled
solution of diazomethane (18 mmol) in Et2O (25 mL) was added
dropwise. The mixture was stirred for 2 h during which the temper-
ature slowly attained r.t. (30 °C). The solvent was removed under
reduced pressure and the residue was purified by column chromato-
graphy on silica gel (petroleum ether/EtOAc, 20:1) to give 5a as a
solid. Yield: 0.84 g, 76%; mp 141−142 °C; [α]D −173.63 (c 1,
CHCl3).
IR (nujol): ν = 2126 (CHN2), 1620 (C=O) cm-1.
1H NMR (300 MHz, CHCl3): δ = 1.33 (s, 3H, CH3), 1.48 (s, 3H,
CH3), 3.40 (s, 3H, OCH3), 4.08 (d, 1H, J = 3.6 Hz, C3-H), 4.58 (d,
1H, J = 3.7 Hz, C2-H), 4.68 (br d, 1H, J = 3.6 Hz, C4-H), 5.81 (br
s, 1H, CHN2), 5.99 (d, 1H, J = 3.7 Hz, C1-H).
1H NMR (200 MHz, CDCl3): δ = 1.29 (s, 3H, CH3), 1.45 (s, 3H,
CH3), 4.50 (d, 1H, J = 12 Hz, OCH2Ph), 4.55 (d, 1H, J = 4.0 Hz, C2-
H), 4.66 (d, 1H, J = 6.0 Hz, C4-H), 4.70 (d, 1H, J = 12.0 Hz,
OCH2Ph), 5.02 (dd, 1H, J = 6.0, 4.0 Hz, C3-H), 5.19 (s, 1H, C1-H),
5.78 (br s, 1H, CHN2), 7.27−7.50 (s, 5H, Ar-H).
Anal: C16H18N2O5 (318.32): Calc C, 60.37; H 5.70. Found C, 60.17;
H, 5.85.
5-Deoxy-3-O-methyl-1,2-O-(1-methylethylidene)-α-D-xylo hex-
ofuranuronic Acid Methyl Ester (4a); Typical Procedure
To a solution of α-diazo ketone 5a(0.75 g, 3.1 mmol) in anhyd
MeOH (12 mL) was added dropwise a solution of silver benzoate
(150 mg, 0.62 mmol) in Et3N (1.5 mL) at r.t. (25 °C) under N2 atm.
The mixture was stirred at the same temperature for 2.5 h. The sol-
vent was then removed under reduced pressure and the residue was
purified by column chromatography (petroleum ether/EtOAc, 15:1)
to give 4a as a colorless liquid. Yield: 0.59 g, 78%; [α]D25 −70.29 (c
1, CHCl3), [α]D25 −46.23 (c 1, MeOH), [Lit3a -45.89 (c 1, MeOH)].
25
IR (nujol): ν = 1738 (C=O) cm−1.
1H NMR (300 MHz, CDCl3): δ = 1.32 (s, 3H, CH3), 1.51 (s, 3H,
CH3), 2.75 (d, 2H, J = 7.0 Hz, CH2), 3.39 (s, 3H, OCH3), 3.70 (s,
3H, OCH3), 3.79 (d, 1H, J = 3.3 Hz, C3-H), 4.56 (dt, 1H, J = 7.0,
3.3 Hz C4-H), 4.59 (d, 1H, J = 4.0 Hz, C2-H), 5.87 (d, 1H, J = 4.0
Hz, C1-H).
Anal: C10H14N2O5 (242.23): Calc C, 49.58; H, 5.83. Found C,
49.70; H, 5.85.
1,2-O-Isopropylidene-3-O-benzyl-6-deoxy-6-diazo-a-D-xylo-
hexo-furan-5-ulose (5b)
White solid; yield: 0.91 g, 84%; mp 84−86 °C; [α]D25 −153.0 (c 1,
CHCl3).
Anal: C11H18O6 (246.25): Calc C, 53.65; H, 7.37. Found C, 53.52;
H, 7.60.
IR (nujol): ν = 2117 (CHN2), 1616 (C=O) cm−1.
5-Deoxy-3-O-benzyl-1,2-O-(1-methylethylidene)-α-D-xylo-
hexo-furanuronic Acid Methyl Ester (4b)
1H NMR (300 MHz, CHCl3): δ = 1.31 (s, 3H, CH3), 1.47 (s, 3H,
CH3), 4.33 (d, 1H, J = 3.3 Hz, C3-H), 4.57 (d, 1H, J = 3.3 Hz, C2-
H), 4.58 (s, 2H, OCH2Ph), 4.72 (br d, 1H, J = 3.3 Hz, C4-H), 5.84
(br s, 1H, CHN2), 6.01 (d, 1H, J = 3.3 Hz, C1-H), 7.25−7.37 (m, 5H,
Ar-H).
Colorless liquid; yield: 0.5 g, 66%; [α]D25 −64.59 (c 1, CHCl3).
IR (nujol): ν = 1740 (C=O) cm−1.
1H NMR (500 MHz, CDCl3): δ = 1.32 (s, 3H, CH3), 1.50 (s, 3H,
CH3), 2.80 (d, 2H, J = 7.0 Hz, CH2), 3.64 (s, 3H, OCH3), 4.01 (d,
1H, J = 3.0 Hz, C3-H), 4.46 (d, 1H, J = 12.0 Hz, OCH2Ph), 4.59 (dt,
1H, J = 7.0, 3.0 Hz C4-H), 4.62 (d, 1H, J = 3.5 Hz, C2-H), 4.65 (d,
1H, J = 12.0 Hz, OCH2Ph), 5.90 (d, 1H, J = 3.5 Hz, C1-H) 7.25−
7.37 (m, 5H, Ar-H).
Anal: C16H18N2O5 (318.32): Calc C, 60.37; H, 5.70. Found C,
60.34; H, 5.62.
1,2-O-Isopropylidene-3-O-benzyl-6-deoxy-6-diazo-a-D-ribo-
hexo-furan-5-ulose (5c)
White solid; yield: 0.86 g, 79%; mp 120−122 °C; [α]D25 +78 (c 1,
CHCl3).
Anal: C17H22O6 (322.35): Calc C, 63.34; H, 6.88. Found C, 63.17;
H, 6.85.
IR (nujol): ν = 2117 (CHN2), 1626 (C=O) cm−1.
5-Deoxy-3-O-benzyl-1,2-O-(1-methylethylidene)-α-D-ribo-
hexo-furanuronic Acid Methyl Ester (4c)
1H NMR (300 MHz, CHCl3): δ = 1.37 (s, 3H, CH3), 1.60 (s, 3H,
CH3), 3.84 (dd, 1H, J = 8.7, 3.9 Hz, C3-H), 4.50 (br d, 1H, J = 8.7,
C4-H), 4.56 (dd, 1H, J = 3.4, 3.9, C2-H), 4.70 (d, 1H, J = 12.3 Hz,
OCH2Ph), 4.80 (d, 1H, J = 12.3 Hz, OCH2Ph), 5.63 (br s, 1H,
CHN2), 5.79 (d, 1H, J = 3.4 Hz, C1-H), 7.25−7.45 (5H, m, Ar-H).
Colorless liquid; yield: 0.531 g, 70%; [α]D25 +92.44 (c 1, CHCl3).
IR (nujol): ν = 1741 (C=O) cm−1.
1H NMR (200 MHz, CDCl3): δ = 1.26 (s, 3H, CH3), 1.36 (s, 3H,
CH3), 2.46 (dd, 1H, J = 7.8, 15.1 Hz, CH2), 2.68 (dd, 1H, J = 3.9,
15.1 Hz, CH2), 3.66 (s, 3H, OCH3), 4.40 (ddd, 1H, J = 3.9, 7.8, 4.4
Hz, C4-H), 4.48−4.60 (m, 3H, C2-H, C3-H, OCH2Ph), 4.79 (d, 1H,
J = 11.7 Hz, OCH2Ph), 5.72 (d, 1H, J = 3.9 Hz, C1-H) 7.29−7.47
(m, 5H, Ar-H).
Anal: C16H18N2O5 (318.32): Calc C, 60.37; H, 5.70. Found C,
60.64; H, 5.88.
2,3-O-Isopropylidene-1-O-benzyl-6-deoxy-6-diazo-a-D-lyxo-
hexo-furano-5-ulose (5d)
To a soln of a-D-lyxo-furanuronic acid 6d (1 g, 3.4 mmol) in anhyd
THF (20 mL) at 0 °C was added Et3N (0.52 mL, 3.75 mmol) and
ethyl chloroformate (0.35 mL, 3.75 mmol) under N2 atm. The mix-
ture was stirred for 30 min and the solvent was removed under re-
duced pressure. The mixed anhydride thus obtained was directly
used in the next step. A solution of mixed anhydride in anhyd Et2O
was cooled to 0 °C under N2 atm and to this an ice-cooled solution
of diazomethane (0.57 g, 13.6 mmol) in Et2O (20 mL) was added
Anal: C17H22O6 (322.35): Calc C, 63.34; H, 6.88. Found C, 63.27;
H, 6.70.
5-Deoxy-1-O-benzyl-2,3-O-(1-methylethylidene)-α-D-lyxo-
hexo-furanosiduronic Acid Methyl Ester (4d)
Colorless liquid; yield: 0.516 g, 68%; [α]D25 +51.00 (c 1, MeOH).
IR (nujol): ν = 1741.1 (C=O) cm−1.
Synthesis 2000, No. 3, 395–398 ISSN 0039-7881 © Thieme Stuttgart · New York
