R
SYNTHETIC COMMUNICATIONSV
3
thiourea under acidic conditions gave rise to various quantity of aminothiazoles as side
products. The same method was embraced for the synthesis of the N-alkylated imino-
thiazolines that could be obtained by replacing thioureas with mono and N, N-disubsti-
tuted thioureas under different reaction conditions.[21] Various other strategies include
potassium thiocyanate treatment of a-bromoketimines,[22] reaction of N-monoalkylated
thioureas with 3-bromomethyl-2-cyanocinnamonitrile,[23] cycloadditions followed by
elimination of 5-imino-1,2,4-thiazolidin-3-ones with enamines and ester enolate,[24] ring
transformation of 1-arylmethyl-2-(thiocyanomethyl)aziridines in the presence of TiCl4
and acylchloride,[25] reaction of N-propargylaniline with acylisothiocyanates,[26] and phe-
nylamino acetonitrile with alkyl isothiocyanates.[27] In addition to this, the synthesis
of thiazol-2-imines was also carried out by the reaction of substituted amines with iso-
thiocyanates.[28] Lately, the three component reaction of phenacyl bromide or 2-chloro-
1,3-dicarbonyl compound, amine and phenyl isothiocyanate has been developed to give
subsequent thiazol-2-imines.[29] The one-pot reaction of 1,1-(ethane-1,2-diyl) dipyridi-
nium bistribromide (EDPBT), as a brominating agent, enolizable ketones and disubsti-
tuted thioureas was reported by Murru et al.[30]
Although there are reports of the one-pot three-component[31] reaction of thiazol-2-
imines in basic alumina under MW irradiation[32] or the trypsin-catalyzed reactions[33]
which are effective, but the drawbacks associated with many reported methods are
unavoidable and hazardous with malicious workups. Therefore, there is an urgent need
to develop efficient, easily available and green approach which can be easily pursued for
the synthesis of thiazol-2-imines. Our attempt to synthesize thiazol-2-imines without the
use of catalyst or reagent of that sort, towards directing a greener approach instigated us
to explore the microwave irradiation method. We could overcome many drawbacks with
respect to the existing methodologies such as easy workup, higher yields, atom economy,
short reaction time, and low wastage during the course of the reaction.
Experimental
General procedure for the synthesis of (5Z)-N-(3-(aryl)-4-phenylthiazol-2(3H)-
ylidene)benzenamine 4(a–l) and 5-methyl-2-aryl-4-((2Z)-4-phenyl-2-
(arylimino)thiazol-3(2H)-yl)-2H-1,2,4-triazol-3(4H)-one 4(o–t)
The reaction was performed in a single mode Discover SP (CEM Corporation,
Matthews, North Carolina, United States) microwave synthesizer with controlled irradi-
ation up to 300 W having a magnetic stirrer. An equimolar ratio of compounds 1, 2a,
and 3(a–l) were taken in a sealed glass tube vial (30.0 mL) in ethanol (10.0 mL). The
sealed vessel with reaction mixture was pre-stirred for 60 s at room temperatuꢀre.
Further, the reaction mixture was irradiated by 100 W microwave radiation at 120 C
for 10–15 min at medium stirring. The reaction temperatures were monitored with an
IR sensor equipped outside of the reactor. After completion of the reaction (TLC), the
reaction mixture was cooled and quenched in ice. The resulting precipitate was filtered
and recyrstallized from ethanol (Scheme 1). Similarly, compounds 4(o–t) were prepared
by employing equimolar ratio of compounds 1, 2(a–-c), and 3(m–n) in a sealed glass
tube vial (30.0 mL) in ethanol (10.0 mL), which was further irradiated by 100 W micro-
wave radiation at 120 ꢀC for 10–15 min, followed by similar workup (Scheme 2).
