TETRAHEDRON
LETTERS
Pergamon
Tetrahedron Letters 41 (2000) 8167–8171
Synthesis and structural studies of oligomers of
6-amino-2,5-anhydro-6-deoxy- -mannonic acid
D
T. K. Chakraborty,a,* S. Jayaprakash,a P. Srinivasu,a M. Govardhana Chary,a
P. V. Diwan,a R. Nagaraj,b A. Ravi Sankara and A. C. Kunwara
aIndian Institute of Chemical Technology, Hyderabad 500 007, India
bCentre for Cellular and Molecular Biology, Hyderabad 500 007, India
Received 28 June 2000; revised 18 August 2000; accepted 23 August 2000
Abstract
A novel cycloetherification process involving a facile 5-exo SN2-type ring closure by intramolecular
opening of a terminal aziridine ring by a g-hydroxyl group, led to the stereoselective synthesis of
6-amino-2,5-anhydro-6-deoxy- -mannonic acid (1). Oligomerization of 1 by solution phase peptide
D
coupling methods gave oligomers 2–5. While most of the oligomers, in either protected or deprotected
form, did not show any significant secondary structure, octamer 5 (P=H) exhibited a very strong positive
band at 216 nm in its CD spectrum in MeOH and TFE, indicating the possibility of the presence of an
1
ordered structure in solution. Its H NMR spectra in various polar solvents, however, failed to produce
any distinct dispersion of the amide proton chemical shifts. Compounds 1–5 were found to be inactive in
hypoglyceamic tests in rats. © 2000 Elsevier Science Ltd. All rights reserved.
During the past few years chemists have developed a large variety of oligomeric compounds
that mimic biopolymers.1–4 These synthetic oligomers are composed of unnatural and yet
nature-like monomeric building blocks assembled together by iterative synthetic processes that
are amenable to combinatorial strategies. The main objective in developing such oligomers is to
mimic the ordered secondary structures displayed by the biopolymers and their functions. They
are also expected to be more stable toward proteolytic cleavage in physiological systems than
their natural counterparts. Rationally chosen monomeric units from the large repertoire of
structurally diverse building blocks are woven together in specific sequences by iterative
synthetic methods leading to the development of novel homo- and heteropolymers with
architecturally beautiful 3-D structures and desirable properties.
* Corresponding author.
0040-4039/00/$ - see front matter © 2000 Elsevier Science Ltd. All rights reserved.
PII: S0040-4039(00)01425-8

8168
Sugar amino acids constitute an important class of synthetic monomers that have been used
recently by several groups to construct oligomeric libraries.5–19 The idea behind the development
of sugar amino acids as a class of unique building blocks was the facile incorporation of these
species, using their carboxyl and amino termini for attachments by well-developed solid- or
solution-phase peptide synthesis methods, to construct any designed molecular framework. As part
of our ongoing project on sugar amino acids and their uses in designing molecules, we report herein
the synthesis and structural studies of a furanoid sugar amino acid, 6-amino-2,5-anhydro-6-deoxy-
D
-mannonic acid (1) and its oligomers 2–5.
Work on furanoid sugar amino acid oligomers has been reported by Fleet’s group where even
short oligomers, for example, a tetramer of gluconic acid-based furanoid sugar amino acid, formed
remarkably stable hydrogen-bonded secondary structures in nonpolar organic solvents.9–13 All the
oligomers examined by them had their ring hydroxyls protected and carried an azido group at
the N-terminus. Their structural studies by NMR were carried out in CDCl3. We felt it necessary
to prepare completely deprotected oligomers so that their structures and properties could be
studied in water or other polar solvents in order to develop true mimics of natural biopolymers.
To begin with, we decided to prepare the oligomers of mannonic acid based sugar amino acid
1. Synthesis of 1 is depicted in Scheme 1. The salient feature of the synthesis is a facile
cycloetherification step to construct the 2,5-anhydro furanoid ring. Based on the known
susceptibility of linear molecules having SN2 active sites to undergo spontaneous ring-closure,
induced by a heteroatom at the g-position, to produce thermodynamically favourable 5-membered
cyclic products,20,21 we envisaged that a terminal aziridine ring could be opened regio- and
stereoselectively by a g-hydroxy group, to build the targeted tetrahydrofuran ring of 1.22,23
Monodeprotection of acetonide rings of 3,4-di-O-benzyl-1,2:5,6-diisopropylidene- -mannitol (6)
D
gave a diol intermediate 7 in 66% yield.24 The primary hydroxyl of 7 was converted to an azide
8 in two steps in 86% overall yield. Next, the azido alcohol 8 was treated with 2 equivalents of
Ph3P in refluxing toluene leading to the formation of the aziridinyl intermediate, which was
protected in situ with Boc2O to give the target intermediate 9 in 91% yield. The aziridine formation
followed an SN2 mechanism executing inversion at the C5 position. The stage was now set to try
out the crucial cyclisation step. When 9 was treated with a catalytic amount of camphor sulfonic
acid in MeOH–CH2Cl2 (1:4), it underwent facile acetonide deprotection with concomitant and
spontaneous intramolecular ring closure by 5-exo SN2-type opening of the aziridine ring by the
g-OH group giving the desired 2,5-anhydro- -mannitol framework 10, in 95% yield. Finally,
D
oxidation of the primary hydroxyl in 10 using PDC in DMF followed by esterification with CH2N2
gave the protected monomer 11 in 77% yield.24
Scheme 1. Stereoselective synthesis of methyl N-Boc-6-amino-2,5-anhydro-3,4-di-O-benzyl-6-deoxy-D-mannonate (11)

8169
Oligomerization of 1 was achieved by standard solution phase peptide coupling methods using
1-ethyl-3-(3-(dimethylamino)propyl)carbodiimide hydrochloride (EDCI) and 1-hydroxybenzotri-
azole (HOBt) as coupling agents and CH2Cl2 and/or amine-free dry DMF as solvents.
Saponification of 11 gave the free carboxyl group that was reacted with the Boc-deprotected unit
using the above-mentioned reagents to furnish the dimer. Two dimers were joined together to
build the tetramer, followed by the synthesis of other oligomers in similar fashion. Up to the
tetramer, Bn-deprotections were done by hydrogenation in MeOH using Pd on C (10%) as
catalyst giving 85% (dimer) and 70% (tetramer) yields. For the hexamer and octamer, the final
deprotections were carried out using 10% trifluoromethanesulfonic acid in TFA, in the presence
of 10% p-cresol. After completion of the reaction, the reaction mixture was poured into an
excess of dry ether and the precipitated solids were collected by centrifugation. The residual
solids were washed three times with dry ether and dried under vacuum to obtain ꢀ70% yields
in both cases. They were used directly for further studies.24
The conformational analyses of 2–5 were carried out by studying their circular dichroism
(CD) spectra in methanol, trifluoroethanol (TFE) and water. The CD spectra of the octamer 5
(P=H) in MeOH and TFE exhibited very strong positive bands at ꢀ216 nm, as shown in Fig.
1(A), indicating the possibility of the presence of a turn structure in solution.25,26 Dilution of the
MeOH solution almost up to 50% with H2O did not change the nature of the band much.
1
Unfortunately, the H NMR spectra of 5 in various polar solvents, like DMSO-d6, CD3OH,
CD3OH–H2O mixture and H2O, did not exhibit any significant dispersion of the amide proton
chemical shifts. Fleet’s group also had similar experiences with the O-acetylated tetramer of the
same sugar amino acid in CDCl3.11 Acylation of the N-terminus of the tetramer with fatty acid
(3, P=CH3(CH2)12CO), designed to model a membrane-bound oligomer, also failed to separate
the amide proton peaks in its NMR spectrum.
Figure 1. (A) CD spectrum of 5 (P=H) in MeOH. (B) Studies on NH/ND exchanges in 5 (P=H): amide proton
peaks in CD3OH–H2O (4:1) (a); in CD3OD–D2O (4:1) after 20 (b), 30 (c), 40 (d), 60 (e) and 120 (f) minutes
1
Next, attempts were made to study the NH/ND exchange rates in 5 (P=H) by running its H
NMR first in CD3OH–H2O (4:1). Subsequently, spectra in CD3OD–D2O (4:1) were recorded 20,
30, 40, 60 and 120 minutes after solution preparation. The results are summarised in Fig. 1(B).

8170
Most of the amide protons exchanged rapidly, while one proton showed much slower solvent
exchange. This peak gradually disappeared over a period of time and almost totally exchanged
in 120 minutes. The study indicates that at least one amide proton is probably buried inside and
less accessible to the solvents or involved in some kind of intramolecular H-bond. However,
further structural studies are required to identify the exact nature of the ordered structure
displayed in its CD spectrum.
Finally, compounds 1–5 were tested for their hypoglyceamic activities in normal Wistar rats
and were found not to reduce their blood sugar levels. Modifications of the sugar backbone and
further improvements in design are expected to lead to many such novel molecular frameworks
that may exhibit interesting structures and also have useful properties.
Acknowledgements
The authors wish to thank CSIR (S.J.) and UGC (P.S.), New Delhi, for research fellowships
and CSIR, New Delhi, for a Young Scientist Award Research Grant (T.K.C.).
References
1. Barron, A. E.; Zuckermann, R. N. Curr. Opin. Chem. Biol. 1999, 3, 681–687.
2. Kirshenbaum, K.; Zuckermann, R. N.; Dill, K. A. Curr. Opin. Struct. Biol. 1999, 9, 530–535.
3. Soth, M. J.; Nowick, J. S. Curr. Opin. Chem. Biol. 1997, 1, 120–129.
4. Gellman, S. H. Acc. Chem. Res. 1997, 31, 173–180.
5. Mu¨ller, C.; Kitas, E.; Wessel, H. P. J. Chem. Soc., Chem. Commun. 1995, 2425–2426.
6. Wessel, H. P.; Mitchell, C. M.; Lobato, C. M.; Schmid, G. Angew. Chem., Int. Ed. Engl. 1995, 34, 2712–2713.
7. Suhara, Y.; Ichikawa, M.; Hildreth, J. E. K.; Ichikawa, Y. Tetrahedron Lett. 1996, 37, 2549–2552.
8. McDevitt, J. P.; Lansbury Jr., P. T. J. Am. Chem. Soc. 1996, 118, 3818–3828.
9. Smith, M. D.; Long, D. D.; Marquess, D. G.; Claridge, T. D. W.; Fleet, G. W. J. Chem. Commun. 1998,
2039–2040.
10. Smith, M. D.; Claridge, T. D. W.; Tranter, G. E.; Sansom, M. S. P.; Fleet, G. W. J. Chem. Commun. 1998,
2041–2042.
11. Smith, M. D.; Long, D. D.; Mart´ın, A.; Marquess, D. G.; Claridge, T. D. W.; Fleet, G. W. J. Tetrahedron Lett.
1999, 40, 2191–2194.
12. Long, D. D.; Hungerford, N. L.; Smith, M. D.; Brittain, D. E. A.; Marquess, D. G.; Claridge, T. D. W.; Fleet,
G. W. J. Tetrahedron Lett. 1999, 40, 2195–2198.
13. Claridge, T. D. W.; Long, D. D.; Hungerford, N. L.; Aplin, R. T.; Smith, M. D.; Marquess, D. G.; Fleet, G. W.
J. Tetrahedron Lett. 1999, 40, 2199–2202.
14. Goodnow Jr., R. A.; Richou, A.-R.; Tam, S. Tetrahedron Lett. 1997, 38, 3195–3198.
15. Goodnow Jr., R. A.; Tam, S.; Pruess, D. L.; McComas, W. W. Tetrahedron Lett. 1997, 38, 3199–3202.
16. Sabesan, S. Tetrahedron Lett. 1997, 38, 3127–3130.
17. Gervay, J.; Flaherty, T. M.; Nguyen, C. Tetrahedron Lett. 1997, 38, 1493–1496.
18. Szabo, L.; Smith, B. L.; McReynolds, K. D.; Parrill, A. L.; Morris, E. R.; Gervay, J. J. Org. Chem. 1998, 63,
1074–1078.
19. Sofia, M. J.; Hunter, R.; Chan, T. Y.; Vaughan, A.; Dulina, R.; Wang, H.; Gange, D. J. Org. Chem. 1998, 63,
2802–2803.
20. Dehmlow, H.; Mulzer, J.; Seilz, C.; Strecker, A. R.; Kohlmann, A. Tetrahedron Lett. 1992, 33, 3607–3610.
21. Chakraborty, T. K.; Jayaprakash, S.; Diwan, P. V.; Nagaraj, R.; Jampani, S. R. B.; Kunwar, A. C. J. Am. Chem.
Soc. 1998, 120, 12962–12963.
22. For earlier synthesis of furanoid sugar amino acids see Refs. 8, 9, 11, 12, 21 and 23.

8171
23. For the first synthesis of furanoid sugar amino acids see: Poitout, L.; Le Merrer, Y.; Depezay, J.-C. Tetrahedron
Lett. 1995, 36, 6887–6890.
1
24. All new compounds were characterised by IR, H and 13C NMR and LSIMS spectroscopic studies.
25. Woody, R. W. In The Peptides: Analysis, Synthesis, Biology; Udenfriend, S. J.; Meienhofer, J.; Hruby, V. J., Eds.
Academic Press: New York, 1985; Vol. 7, pp. 15–114.
26. McReynolds, K. D.; Gervay-Hague, J. Tetrahedron: Asymmetry 2000, 11, 337–362.
.
