H. Lee et al.
CatalysisCommunications121(2019)15–18
2. Experimental section
After the reaction, volatile was removed by vacuum drying, and the
mixture was cooled to room temperature and diluted to n-hexane: ethyl
acetate (9:1 v/v) solution followed by silica column chromatography. A
pure oil product Ar2PC(R) = CPAr2 could be obtained and analyzed by
NMR and HR-MS. Yields and characterization data are summarized in
Supplementary Information.
2.1. General conditions
All reactions were performed under an inert atmosphere using
standard Schlenk techniques. All solvents and gases were dried and
degassed using standard procedures. Chemicals were purchased from
Sigma Aldrich or Alfa Aesar and used without further purification un-
less otherwise stated. mMAO-3A was obtained from Akzo Nobel
Corporation as a 7% w/w solution in heptane. 1H, 13C, 19F, and 31P
nuclear magnetic resonance (NMR) spectra were recorded on a Bruker
AVANCE III HD 500 MHz spectrometer in CDCl3. Chemical shifts are
reported in ppm with the internal tetramethylsilane signal at 0.0 ppm
and the internal chloroform signal at 77.0 ppm as a standard. Elemental
analyses were performed with a CE Instruments/ThermoQuest Italia
Flash EA 1112 Series. Bruker Daltonics (Billerica, MA, USA) APPI 7 T
FT-ICR MS was used for (+) mode atmospheric pressure photoioniza-
tion analysis. Quantitative chromatographic analysis of the oligomer-
ization products was performed using an Agilent 7890A GC-FID with an
HP-PONA column (50 m × 0.20 mm). The reaction solvent, methylcy-
clohexane, was used as an internal standard. GPC analyses were per-
formed on a 1260 Infinity II GPC/SEC system equipped with a dual flow
refractive index (DRI) detector and a UV detector. The samples were
analyzed in 1,2,4-trichlorobenzene at 145 °C using a flow rate of
1.0 mL/min. All polymers were injected at a concentration of 1 mg/mL
in 1,2,4-trichlorobenzene, after filtration through a 2.5 μm syringe
filter. The average molar masses (number average molar mass Mn and
weight average molar mass Mw) and the molecular weight distribution
(Mw/Mn) were derived from the RI signal by a calibration curve based
on polystyrene standards. DSC was performed using a TA DSC model
Q200. The samples were analyzed under a nitrogen atmosphere ac-
cording to the following cycles: in the first cycle, the sample was heated
from 30 to 200 °C, at a heating rate of 10 °C/min, leaving the material at
200 °C for 1 min; the second cycle was done using a cooling rate of
10 °C/min, until 20 °C; in the third cycle, the sample was heated from
30 to 200 °C, at a heating rate of 10 °C/min.
2.3. Preparation of chromium complexes
In a glovebox, each ligand (0.2 mmol) and CrCl3(THF)3 (0.2 mmol)
are charged in a flask followed by 2.0 mL of dichloromethane, and then
the solution was stirred for 1 h. The color of the reaction mixture
changed from purple to blue. After this, the solvent was removed under
reduced pressure, and the resultant solid was washed twice with 5 mL
of n-hexane. The product was dried under vacuum to yield chromium
complex. As followed in the previous literature, ligated chromium
complexes tend to form bimetallic structures maintaining the oxidation
state +3 [20]. The chromium complexes were characterized and
summarized in Supplementary Information.
2.4. Ethylene oligomerization
All runs for ethylene oligomerization were carried out in a 3 L of
Büchi stainless steel autoclave charged with methylcyclohexane (1 L)
and mMAO-3A (500 equivalent of Al/Cr molar ratio), then heated to
just below the desired reaction temperature. A synthesized chromium
complex (suspension of solution in 5 mL of methylcyclohexane) was
added to the autoclave, which was then pressurized with ethylene and
stirred at 600 rpm. Ethylene was fed on demand to keep the reactor
pressure constant, and the uptake was monitored using a mass flow
meter (MFC). After an hour, the autoclave was cooled to 0 °C and de-
pressurized slowly to atmospheric pressure. The product was quenched
by adding 2-ethyl hexanol (2.0 mL). The crude products were filtered
and analyzed using GC-FID (Typical GC-FID data in Fig. S1). The
polymeric products were recovered by filtration and dried overnight in
an oven at 100 °C.
2.2. General procedure for the synthesis of ligands
3. Results and discussion
A series of novel ligands were obtained by suitable modification of
literature methods (Scheme 1) [21,22]. n-Butyl lithium solution
(26.6 mL, 42.5 mmol, 1.6 M in hexane) was slowly added to a solution
of alkyne (50.0 mmol) in diethyl ether (42 mL) stirred at −78 °C under
nitrogen condition for 1 h. Chlorodiarylphosphine (38.3 mmol) was
slowly added and then stirred further 2 h. The mixture was naturally
raised to the room temperature and filtered through a silica pad and
dried in vacuo. Further purification was carried out by distillation or
column chromatography. A portion of synthesized alkynyl diaryl
phosphine compound A (0.5 mmol), copper(I) iodide (5 mol%) and
cesium carbonate (10 mol%) were dissolved in N,N-dimethylformamide
(1 mL) followed by dropwise of diarylphosphine (0.6 mmol, 1.2 eq),
then the mixture was stirred for 3 h after raised temperature to 90 °C.
3.1. Synthesis of catalysts and their catalytic activity screening result
In our previous work, it was found that catalytic activity was
maintained when the fluorine atom was introduced at the ortho-position
on aryl phosphine ligand even at the high temperature over 140 °C
without any thermally degradable signals such as excess polymer for-
mation or deactivation [22]. From the result, some changes of the de-
sign were carried out on the ligand structure manipulating a bulkiness
on the ligand backbone and introducing ortho‑fluorine atoms according
to a number or a position. Total 14 ligand structures and precatalysts
derived from CrCl3(THF)3 were synthesized. After formation of the
metal complex, ortho‑fluorine atoms would be expected to be able to
directly or indirectly affect the metal center during oligomerization
Scheme 1. Synthesis of asymmetric Ar2PC(R) = CPAr2 ligands.
