Synthesis of rhodotorulic acid and its 1,4-dimethylated derivative

Article abstract of DOI:10.3987/COM-14-S(K)67

Facile syntheses of rhodotorulic acid, isolated from Rhodotorula pilimanae as a siderophore, and its 1,4-dimethylated derivative have been achieved by microwave-assisted cyclization of the corresponding dipeptide precursors.

Full text of DOI:10.3987/COM-14-S(K)67

HETEROCYCLES, Vol. 90, No. 2, 2015
1309
HETEROCYCLES, Vol. 90, No. 2, 2015, pp. 1309 - 1316. © 2015 The Japan Institute of Heterocyclic Chemistry
Received, 30th June, 2014, Accepted, 23rd July, 2014, Published online, 5th August, 2014
DOI: 10.3987/COM-14-S(K)67
SYNTHESIS OF RHODOTORULIC ACID AND ITS
1,4-DIMETHYLATED DERIVATIVE
Michiyasu Nakao, Shintaro Fukayama, Syuji Kitaike, and Shigeki Sano*
Graduate School of Pharmaceutical Sciences, The University of Tokushima,
Sho-machi, Tokushima 770-8505, Japan; E-mail: ssano@tokushima-u.ac.jp
Abstract – Facile syntheses of rhodotorulic acid, isolated from Rhodotorula
pilimanae as a siderophore, and its 1,4-dimethylated derivative have been
achieved by microwave-assisted cyclization of the corresponding dipeptide
precursors.
Siderophores are iron-chelating compounds utilized by bacteria and fungi under iron-limiting conditions.1
Rhodotorulic acid [(S,S)-1] is a dihydroxamate siderophore isolated from Rhodotorula pilimanae,2 and its
biological activities3 as well as its iron-chelating ability4 have been investigated. It can be assumed that
the diketopiperazine (DKP) ring of (S,S)-1 is biosynthesized starting with L-ornithine, and that two
N-hydroxyacetamide moieties serve as a tetradentate ligand for Fe(III) coordination. Therefore, (S,S)-1
has been considered to form a 3 : 2 complex with Fe(III) based on CD spectra and potentiometric
titrations, in contrast to hexadentate siderophores such as desferrioxamine B, which forms a 1 : 1 complex
with Fe(III).5 The coordination pattern of (S,S)-1 with Fe(III) has also been suggested by electrospray
ionization mass spectrometry.6 Despite its interesting structural features, there are only a few examples of
(S,S)-1 synthesis.7-10 Herein, we describe a convenient synthesis of (S,S)-1 and its 1,4-dimethylated
derivative [(S,S)-2] through microwave-assisted cyclization of the corresponding dipeptide precursors.
Figure 1. Rhodotorulic acid [(S,S)-1] and its 1,4-dimethylated derivative [(S,S)-2]
Amino acid building blocks, (S)-5-[N-(benzyloxy)acetamido]-2-[(tert-butoxycarbonyl)amino]pentanoic
acid [(S)-9] and methyl (S)-2-amino-5-[N-(benzyloxy)acetamido]pentanoate hydrochloride [(S)-10], for
dipeptide precursors were synthesized as shown in Scheme 1. Esterification of Boc-L-Glu(OBn)-OH

1310
HETEROCYCLES, Vol. 90, No. 2, 2015
[(S)-3] with methanol using 1-ethyl-3-(3-dimethylaminopropyl)carbodiimide hydrochloride (EDC•HCl)
as a coupling reagent in the presence of a catalytic amount of N,N-dimethyl-4-aminopyridine (DMAP)
followed by deprotection of the benzyl ester via catalytic hydrogenolysis under hydrogen with palladium
on carbon (10 wt. % loading) afforded the carboxylic acid (S)-5 in 90% yield (2 steps). Formation of a
mixed anhydride of (S)-5 with ethyl chloroformate in the presence of N-methylmorpholine (NMM)
followed by reduction with sodium borohydride gave the primary alcohol (S)-6 in 89% yield. One-step
transformation of the hydroxy group of (S)-6 into the protected hydroxylamino group was performed
under Mitsunobu conditions. The reaction of (S)-6 with N-[(2,2,2-trichloroethoxy)carbonyl]-
O-benzylhydroxylamine in the presence of diisopropyl azodicarboxylate (DIAD) and triphenylphosphine
in THF provided the Mitsunobu product (S)-7. Without further purification, reductive cleavage of the
2,2,2-trichloroethoxycarbonyl (Troc) group of (S)-7 with zinc powder followed by acetylation of the
resulting hydroxylamine with acetic anhydride furnished (S)-87,9 in 86% yield (2 steps). Finally,
hydrolysis of (S)-8 under aqueous alkaline conditions gave the corresponding N-protected amino acid
(S)-9.7,9 In contrast, amino acid ester hydrochloride (S)-109 was obtained by deprotection of the Boc group
of (S)-8 under acidic conditions.
Scheme 1. Synthesis of amino acid building blocks (S)-9 and (S)-10

HETEROCYCLES, Vol. 90, No. 2, 2015
1311
Scheme 2. Synthesis of rhodotorulic acid [(S,S)-1] and its 1,4-dimethylated derivative [(S,S)-2]
Benzotriazol-1-yloxytris(dimethylamino)phosphonium hexafluorophosphate (BOP reagent) was used in
the condensation of both building blocks (S)-9 and (S)-10 in the presence of N,N-diisopropylethylamine
to furnish the dipeptide (S,S)-11 in 95% yield. In previous reports of the synthesis of (S,S)-1, two steps
have been required to construct the DKP structure via N-terminal deprotection and intramolecular
cyclization of the dipeptide precursor.7-10 In addition, a long reaction time has been needed for
intramolecular cyclization. On the other hand, microwave irradiation has been reported to be efficient for
a one-pot conversion of N-Boc-dipeptide methyl esters into DKPs with a short reaction time.11 We
therefore attempted a one-pot conversion of (S,S)-11 into DKP (S,S)-12 using microwave irradiation. As a
result, removal of the Boc group followed by intramolecular cyclization of (S,S)-11 under microwave
irradiation with a single-mode microwave reactor (InitiatorTM 60; Biotage AB) at 170 °C in a mixed
solvent of water/methanol for 10 min furnished the DKP (S,S)-12 in 63% yield. Finally, catalytic
hydrogenolysis of (S,S)-12 under hydrogen with palladium on carbon (10 wt. % loading) provided
rhodotorulic acid [(S,S)-1] in 80% yield. Furthermore, N-methylation of the DKP ring of (S,S)-12
followed by catalytic hydrogenolysis of the resultant (S,S)-13 afforded 1,4-dimethylated rhodotorulic acid
[(S,S)-2]. The structures of (S,S)-1 and (S,S)-2 were confirmed by spectroscopic methods. In general, DKP
derivatives have poor solubility in various solvents due to their intermolecular hydrogen bonding through

1312
HETEROCYCLES, Vol. 90, No. 2, 2015
the amide moiety of the DKP ring.12 Therefore, only a few solvents, including water and
dimethylsulfoxide (DMSO), have been found to be capable of dissolving (S,S)-1. However, (S,S)-2 was
found to be soluble in water, DMSO, methanol, ethanol, chloroform, and ethyl acetate. This enhanced
solubility is likely due to the disappearance of intermolecular hydrogen bonding as a result of
N-methylation.
In conclusion, we have presented the synthesis of rhodotorulic acid [(S,S)-1] and its 1,4-dimethylated
derivative [(S,S)-2] using a microwave-assisted cyclization of the corresponding common dipeptide
precursor (S,S)-11 as a key step. Intriguingly, (S,S)-2 was found to be more soluble in various organic
solvents than (S,S)-1. Derivatization of (S,S)-1 and (S,S)-2 toward the synthesis of novel iron-chelating
compounds is currently underway and will be reported in due course.
EXPERIMENTAL
All melting points were determined on a Yanagimoto micro melting point apparatus and are uncorrected.
1
IR spectra were obtained using a JASCO FT/IR-6200 IR Fourier transform spectrometer. H NMR (500
MHz) and 13C NMR (125 MHz) spectra were recorded on a Bruker AV500 spectrometer. Chemical shifts
are given in ! values (parts per million) using tetramethylsilane (TMS) as an internal standard. Electron
spray ionization mass spectra (ESIMS) were recorded on a Waters LCT Premier spectrometer. Elemental
combustion analyses were performed using a J-SCIENCE LAB JM10. The microwave-assisted reaction
was performed utilizing an automated single-mode microwave synthesizer (InitiatorTM 60; Biotage AB).
All reactions were monitored by TLC employing 0.25-mm silica gel plates (Merck 5715; 60 F254).
Column chromatography was carried out on silica gel [Kanto Chemical 60N (spherical, neutral); 63-210
mm] or [Fuji Silysia Chemical PSQ 60B (spherical)]. Anhydrous THF, CH2Cl2, and DMF were used as
purchased from Kanto Chemical. N-Methylmorpholine (NMM) and N,N-diisopropylethylamine were
distilled prior to use. All other reagents were used as purchased.
Methyl
(S)-5-[N-(Benzyloxy)acetamido]-2-{(S)-5-[N-(benzyloxy)acetamido]-2-[(tert-butoxy-
carbonyl)amino]pentanamide}pentanoate [(S,S)-11]
To a solution of (S)-9 (618 mg, 1.62 mmol) and (S)-10 (537 mg, 1.62 mmol) in anhydrous CH2Cl2 (6 mL)
were added BOP reagent (1.1 g, 2.44 mmol) and N,N-diisopropylethylamine (552 µL, 3.25 mmol) at 0 °C
under argon. The reaction mixture was allowed to warm to rt and stirred for 24 h. The reaction mixture
was treated with 5% citric acid aq (2 mL) and then extracted with CHCl3 (50 mL x 3). The extract was
dried over anhydrous MgSO4, filtered, and concentrated in vacuo. The oily residue was purified by silica
gel column chromatography [Silica Gel PSQ 60B: CHCl3–MeOH (100:0 to 10:1)] to afford (S,S)-11 (1.0
g, 95%). Colorless oil; ["]D19 +5.6 (c 0.51, CHCl3); 1H NMR (500 MHz, CDCl3) ! 1.43 (s, 9H), 1.47–1.88

HETEROCYCLES, Vol. 90, No. 2, 2015
1313
(m, 8H), 2.09 (s, 3H), 2.11 (s, 3H), 3.41–3.53 (m, 1H), 3.60–3.73 (m, 2H), 3.66 (s, 3H), 4.12–4.27 (m,
1H), 4.32–4.42 (m, 1H), 4.48–4.56 (m, 1H), 4.76–4.88 (m, 4H), 5.22–5.28 (m, 1H), 7.08–7.17 (m, 1H),
13
7.33–7.42 (m, 10H); C NMR (125 MHz, CDCl3) ! 20.4, 20.5, 23.0, 23.2, 28.3, 29.1, 30.6, 43.6, 44.7,
51.9, 52.2, 52.3, 76.31, 76.34, 79.6, 128.72, 128.74, 128.96, 129.01, 129.19, 129.24, 134.3, 134.4, 155.8,
13
172.37, 172.45 (two overlapping singlets), 173.16; C NMR (125 MHz, C6D6) ! 20.5 (two overlapping
singlets), 23.4, 23.7, 28.4, 29.2, 31.1, 43.9, 45.2, 51.7, 52.2, 52.7, 76.1, 76.3, 79.1, 128.77, 128.79, 128.8,
128.9, 129.4, 129.5, 135.1, 135.4, 156.3, 172.1, 172.8, 172.9, 173.1; IR (neat) 3304, 2978, 2935, 1743,
1659, 1499 cm-1; ESI-MS m/z: calcd for C34H48N4NaO9 [M+Na]+, 679.3319; found, 679.3350.
N,N’-{[(2S,5S)-3,6-Dioxopiperazine-2,5-diyl]bis(propane-3,1-diyl)}bis[N-(benzyloxy)acetamide]
[(S,S)-12]
A suspension of (S,S)-11 (611 mg, 0.931 mmol) in a mixed solvent of H2O (15 mL) with MeOH (5 mL)
was irradiated at 170 °C for 10 min utilizing a Biotage Initiator® microwave synthesizer. The reaction
mixture was treated with H2O (20 mL) and then extracted with AcOEt (50 mL x 3). The extract was dried
over anhydrous MgSO4, filtered, and concentrated in vacuo. The oily residue was purified by silica gel
column chromatography [Silica Gel 60N: CHCl3–MeOH (98:2 to 85:15)] to afford (S,S)-12 (305 mg,
63%). Colorless powder (MeOH–Et2O); mp 149–150 °C (lit.7 127–129 °C, lit. 9 129–131 °C, and lit.10
27
25
13
97–99 °C); ["]D -20.5 (c 1.03, MeOH) {lit.7 ["]D -16.5 (c 0.67, MeOH), lit.9 ["]D -16.4 (c 1.01,
EtOH), and lit.10 ["]D20 -16.4 (c 1.01, EtOH)}; 1H NMR (500 MHz, CD3OD) ! 1.67–1.85 (m, 8H), 2.03 (s,
6H), 3.63–3.73 (m, 4H), 3.98 (t, J = 5.2 Hz, 2H), 4.87 (s, 4H), 7.34–7.43 (m, 10H); 13C NMR (125 MHz,
CD3OD) ! 20.5, 23.6, 32.4, 45.6, 55.7, 77.2, 129.8, 130.0, 130.7, 136.1, 170.2, 174.5; IR (KBr) 3193,
3043, 2953, 2886, 1665, 1455 cm-1; ESI-MS m/z: calcd for C28H36N4NaO6 [M+Na]+, 547.2533; found,
547.2525. Anal. Calcd for C28H36N4O6: C, 64.10; H, 6.92; N, 10.68. Found: C, 63.96; H, 6.91; N, 10.53%.
N,N’-{[(2S,5S)-3,6-Dioxopiperazine-2,5-diyl]bis(propane-3,1-diyl)}bis(N-hydroxyacetamide)
[Rhodotorulic Acid, (S,S)-1]
The mixture of (S,S)-12 (100 mg, 0.191 mmol) and 10% Pd–C (20 mg, 0.019 mmol) in MeOH (3 mL)
was stirred at rt for 1 h under hydrogen. The reaction mixture was filtered and concentrated in vacuo to
afford (S,S)-1 (53 mg, 80%). Colorless powder (H2O); mp >217 °C (dec) [lit.7 217–218 °C, lit.8
27
229–232 °C, lit.9 216–218 °C (dec), and lit.10 217–218.5 °C (dec)]; ["]D -30.2 (c 0.16, H2O) {lit.8 ["]D
-30.5 (c 0.67, AcOH), lit.9 ["]D17 -30.4 (c 0.5, H2O), lit.10 ["]D25 -28.8 (c 1.00, H2O)}; 1H NMR (500 MHz,
DMSO-d6) ! 1.50–1.72 (m, 8H), 1.97 (s, 6H), 3.43–3.52 (m, 4H), 3.79–3.86 (m, 2H), 8.16 (brs, 2H), 9.72
13
(brs, 2H); C NMR (125 MHz, DMSO-d6) ! 20.2, 22.0, 30.2, 46.7, 53.7, 167.7, 170.0; IR (KBr) 3187,
3086, 2867, 1686, 1594, 1517, 1473, 1448 cm-1; ESI-MS m/z: calcd for C14H24N4NaO6 [M+Na]+,

1314
HETEROCYCLES, Vol. 90, No. 2, 2015
367.1594; found, 367.1588. Anal. Calcd for C14H24N4O6: C, 48.83; H, 7.02; N, 16.27. Found: C, 48.53; H,
6.99; N, 16.14%.
N,N’-{[(2S,5S)-1,4-Dimethyl-3,6-dioxopiperazine-2,5-diyl]bis(propane-3,1-diyl)}bis[N-(benzyloxy)-
acetamide] [(S,S)-13]
NaH (50–72%, 13.6 mg, 0.284 mmol) was added to a solution of (S,S)-12 (49.7 mg, 0.0947 mmol) in
anhydrous DMF (2 mL) and stirred at 0 °C for 5 min under argon. After adding MeI (17.7 µL, 0.284
mmol), the mixture was stirred at 0 °C for 30 min under argon. The reaction mixture was treated with 1N
HCl aq (1 mL) and then extracted with AcOEt (20 mL x 3). The extract was washed with sat. Na2S2O3 aq
(5 mL) and H2O (5 mL x 3). The organic layer was dried over anhydrous MgSO4, filtered, and
concentrated in vacuo. The oily residue was purified by silica gel column chromatography [Silica Gel
PSQ 60B: CHCl3–MeOH (20:1 to 10:1)] to afford (S,S)-13 (43.2 mg, 83%). Colorless oil; ["]D20 +11.4 (c
0.90, CHCl3); 1H NMR (500 MHz, CDCl3) ! 1.60–1.92 (m, 8H), 2.09 (s, 6H), 2.89 (s, 6H), 3.58–3.68 (m,
13
2H), 3.74–3.87 (m, 4H), 4.81 (dd, J = 10.5, 13.7 Hz, 4H), 7.34–7.43 (m, 10H); C NMR (125 MHz,
CDCl3) ! 20.5, 23.5, 30.5, 32.6, 44.1, 61.7, 76.4, 128.8, 129.1, 129.2, 134.3, 165.7, 172.3; IR (neat) 2937,
2878, 1660, 1454, 1403 cm-1; ESI-MS m/z: calcd for C30H40N4NaO6 [M+Na]+, 575.2846; found, 575.2815.
N,N’-{[(2S,5S)-1,4-Dimethyl-3,6-dioxopiperazine-2,5-diyl]bis(propane-3,1-diyl)}bis(N-hydroxyacet-a
mide) [1,4-Dimethylated Rhodotorulic Acid, (S,S)-2]
The mixture of (S,S)-13 (24.2 mg, 0.0438 mmol) and 10% Pd–C (2.3 mg, 0.00219 mmol) in MeOH (1
mL) was stirred at rt for 2 h under hydrogen. The reaction mixture was filtered and concentrated in vacuo
28
to afford (S,S)-2 (12 mg, 80%). Colorless prism (CHCl3–Et2O); mp 134–135.5 °C; ["]D +31.0 (c 0.45,
CHCl3); 1H NMR (500 MHz, CDCl3) ! 1.67–1.89 (m, 6H), 2.05–2.18 (m, 2H), 2.16 (s, 6H), 2.98 (s, 6H),
13
3.57–3.67 (m, 2H), 3.77–3.92 (m, 4H), 9.35 (brs, 2H); C NMR (125 MHz, CDCl3) ! 20.6, 22.2, 30.9,
32.9, 47.3, 61.9, 166.7, 172.7; IR (KBr) 3351, 3115, 2939, 2868, 1663, 1636, 1600 cm-1; ESI-MS m/z:
calcd for C16H28N4NaO6 [M+Na]+, 395.1907; found, 395.1920. Anal. Calcd for C16H28N4O6: C, 51.60; H,
7.58; N, 15.04. Found: C, 51.30; H, 7.51; N, 14.91%.
ACKNOWLEDGEMENTS
This work was supported in part by a Grant for the Regional Innovation Cluster Program (Global Type)
promoted by MEXT.
REFERENCES
1. R. Saha, N. Saha, R. S. Donofrio, and L. L. Bestervelt, J. Basic Microbiol., 2013, 53, 303.

HETEROCYCLES, Vol. 90, No. 2, 2015
1315
2. C. L. Atkin and J. B. Neilands, Biochemistry, 1968, 7, 3734.
3. M. I. Sanz Ferramola, D. Benuzzi, V. Calvente, J. Calvo, G. Sansone, S. Cerutti, and J. Raba,
‘Microbial Pathogens and Strategies for Combating Them: Science, Technology and Education’, Vol.
2, ed. by A. Méndez-Vilas, Formatex Res. Center, 2013, pp. 1385-1394; T. Funahashi, T. Tanabe, K.
Mihara, K. Miyamoto, H. Tsujibo, and S. Yamamoto, Biol. Pharm. Bull., 2012, 35, 753; J. M.
Scervino, I. Sampedro, M. A. Ponce, M. A. Rodriguez, J. A. Ocampo, and A. Godeas, Soil Biol.
Biochem., 2008, 40, 2474; D. Andersen, J. C. Renshaw, and M. G. Wiebe, Mycol. Res., 2003, 107,
949.
4. G. Müller, S. J. Barclay, and K. N. Raymond, J. Biol. Chem., 1985, 260, 13916; G. Müller, B. F.
Matzanke, and K. N. Raymond, J. Bacteriol., 1984, 160, 313; R. W. Grady, C. M. Peterson, R. L.
Jones, J. H. Graziano, K. K. Bhargava, V. A. Berdoukas, G. Kokkini, D. Loukopoulos, and A.
Cerami, J. Pharmacol. Exp. Ther., 1979, 209, 342.
5. C. J. Carrano, S. R. Cooper, and K. N. Raymond, J. Am. Chem. Soc., 1979, 101, 599; C. J. Carrano
and K. N. Raymond, J. Am. Chem. Soc., 1978, 100, 5371.
6. M. K. Nguyen-van-Duong, V. Guillot, L. Nicolas, A. Gaudemer, L. Lowry, I. Spasojevi!, and A. L.
Crumbliss, Inorg. Chem., 2001, 40, 5948; I. Spasojevi!, H. Boukhalfa, R. D. Stevens, and A. L.
Crumbliss, Inorg. Chem., 2001, 40, 49.
7. B. H. Lee, G. J. Gerfen, and M. J. Miller, J. Org. Chem., 1984, 49, 2418.
8. J. Widmer and W. Keller-Schierlein, Helv. Chim. Acta, 1974, 57, 1904.
9. T. Fujii and Y. Hatanaka, Tetrahedron, 1973, 29, 3825.
10. Y. Isowa, T. Takashima, M. Ohmori, H. Kurita, M. Sato, and K. Mori, Bull. Chem. Soc. Jpn., 1972,
45, 1467.
11. M. Nakao, Y. Toriuchi, S. Fukayama, and S. Sano, Chem. Lett., 2014, 43, 340; L. Pérez-Picaso, H. F.
Olivo, R. Argotte-Ramos, M. Rodríguez-Gutiérrez, and M. Y. Rios, Bioorg. Med. Chem. Lett., 2012,
22, 7048; L. Pérez-Picaso, J. Escalante, H. F. Olivo, and M. Y. Rios, Molecules, 2009, 14, 2836; M.
Tullberg, M. Grøtli, and K. Luthman, J. Org. Chem., 2007, 72, 195; F. Jam, M. Tullberg, K. Luthman,
and M. Grøtli, Tetrahedron, 2007, 63, 9881; A.-C. Carlsson, F. Jam, M. Tullberg, Å. Pilotti, P.
Ioannidis, K. Luthman, and M. Grøtli, Tetrahedron Lett., 2006, 47, 5199; M. Tullberg, M. Grøtli, and
K. Luthman, Tetrahedron, 2006, 62, 7484; A. López-Cobeñas, P. Cledera, J. D. Sánchez, P.
López-Alvarado, M. T. Ramos, C. Avendaño, and J. C. Menéndez, Synthesis, 2005, 3412; A.
López-Cobeñas, P. Cledera, J. D. Sánchez, R. Pérez-Contreras, P. López-Alvarado, M. T. Ramos, C.
Avendaño, and J. C. Menéndez, Synlett, 2005, 1158.
12. G. T. R. Palmore, T.-J. M. Luo, M. T. McBride-Wieser, E. A. Picciotto, and C. M. Reynoso-Paz
Chem. Mater., 1999, 11, 3315; G. T. R. Palmore and M. T. McBride, Chem. Commun., 1998, 145; S.

1316
HETEROCYCLES, Vol. 90, No. 2, 2015
Palacin, D. N. Chin, E. E. Simanek, J. C. MacDonald, G. M. Whitesides, M. T. McBride, and G. T. R.
Palmore, J. Am. Chem. Soc., 1997, 119, 11807.
