Competitive behavior of nitrogen based axial ligands in the oxovanadium(IV)-salen catalyzed sulfoxidation of phenylmercaptoacetic acid

Article abstract of DOI:10.1016/j.poly.2020.114712

The sulfoxidation of twelve phenylmercaptoacetic acids (PMAA) by H₂O₂ catalyzed by three oxovanadium(IV)-salen complexes, having varied substituents on PMAA and salen with regard to their position, size and inductive effect, has been performed spectrophotometrically in 100percent acetonitrile medium. Three nitrogen bases (NB), pyridine (Py), imidazole (ImH) and 1-methylimidazole (MeIm), were used as axial ligands. It has been found that the rate of sulfoxidation is not only tuned by the substituents on PMAA and salen, but it is also varied by the addition of nitrogen bases. The observed order of retardation found among the different nitrogen bases is ImH > MeIm > Py. The rate of reaction decreases with the increase in concentration of the NB axial ligands. The strongly binding ImH shows the least reactivity. Hydroperoxovanadium(V)-salen has been proposed as the sole active oxidizing species. A detailed mechanistic study reveals that the low rate constant values in the presence of the nitrogen base is due to the existence of competition of NB with H₂O₂ and PMAA during the formation of active species and the coordination of PMAA with active species, respectively. Both electron donating and electron withdrawing substituents on PMAA retard the sulfoxidation rate significantly. The Hammett correlation between the rate constants and substituent constants shows a non-linear concave downward curve which is explained by the existence of two different rate determining steps within the same mechanism; coordination of PMAA with the active species for electron withdrawing substituents and transfer of oxygen to PMAA for electron donating substituents. All the experimental observations are explained by proposing a suitable mechanism.

Full text of DOI:10.1016/j.poly.2020.114712

Journal Pre-proofs
Competitive behavior of nitrogen based axial ligands in the oxovanadi‐
um(IV)-salen catalyzed sulfoxidation of phenylmercaptoacetic acid
C. Kavitha, P. Subramaniam
PII:
S0277-5387(20)30369-7
DOI:
Reference:
https://doi.org/10.1016/j.poly.2020.114712
POLY 114712
To appear in:
Polyhedron
Received Date:
Revised Date:
Accepted Date:
20 April 2020
13 July 2020
20 July 2020
Please cite this article as: C. Kavitha, P. Subramaniam, Competitive behavior of nitrogen based axial ligands in
the oxovanadium(IV)-salen catalyzed sulfoxidation of phenylmercaptoacetic acid, Polyhedron (2020), doi:
https://doi.org/10.1016/j.poly.2020.114712
This is a PDF file of an article that has undergone enhancements after acceptance, such as the addition of a cover
page and metadata, and formatting for readability, but it is not yet the definitive version of record. This version
will undergo additional copyediting, typesetting and review before it is published in its final form, but we are
providing this version to give early visibility of the article. Please note that, during the production process, errors
may be discovered which could affect the content, and all legal disclaimers that apply to the journal pertain.
© 2020 Elsevier Ltd. All rights reserved.

Competitive behavior of nitrogen based axial ligands in the oxovanadium(IV)-
salen catalyzed sulfoxidation of phenylmercaptoacetic acid
C. Kavithaa,b,* , P. Subramaniamb
a Research Department of Chemistry, Aditanar College of Arts and Science, Tiruchendur
628 216, Tamil Nadu, India
b Manonmaniam Sundaranar University, Abishekapatti, Tirunelveli 627 012, Tamil Nadu, India
ABSTRACT
The sulfoxidation of twelve phenylmercaptoacetic acids (PMAA) by H2O2 catalyzed by three
oxovanadium(IV)-salen complexes, having varied substituents on PMAA and salen with regard
to their position, size and inductive effect, has been performed spectrophotometrically in 100%
acetonitrile medium. Three nitrogen bases (NB), pyridine (Py), imidazole (ImH) and 1-
methylimidazole (MeIm), were used as axial ligands. It has been found that the rate of
sulfoxidation is not only tuned by the substituents on PMAA and salen, but it is also varied by
the addition of nitrogen bases. The observed order of retardation found among the different
nitrogen bases is ImH > MeIm > Py. The rate of reaction decreases with the increase in
concentration of the NB axial ligands. The strongly binding ImH shows the least reactivity.
Hydroperoxovanadium(V)-salen has been proposed as the sole active oxidizing species. A
detailed mechanistic study reveals that the low rate constant values in the presence of the
nitrogen base is due to the existence of competition of NB with H2O2 and PMAA during the
formation of active species and the coordination of PMAA with active species, respectively.
Both electron donating and electron withdrawing substituents on PMAA retard the sulfoxidation
rate significantly. The Hammett correlation between the rate constants and substituent constants
shows a non-linear concave downward curve which is explained by the existence of two different
rate determining steps within the same mechanism; coordination of PMAA with the active
species for electron withdrawing substituents and transfer of oxygen to PMAA for electron
donating substituents. All the experimental observations are explained by proposing a suitable
mechanism.
________________________________
1

*Corresponding author. Tel.: +91 9952322550.
E-mail address: sivakavetha@gmail.com (C. Kavitha).
Keywords: Sulfoxidation, oxovanadium(IV)-salen, phenylmercaptoacetic acid, downward
Hammett plot, axial ligand, nitrogen base
Abbreviations: PMAA, phenylmercaptoacetic acid; PSAA, phenylsulfinylacetic acid; EWG,
electron withdrawing group; EDG, electron donating group; r, correlation coefficient; ImH,
imidazole; MeIm, 1-methylimidazole; Py, pyridine; NB, nitrogen bases; AN, acetonitrile; RDS,
rate determining step.
1. Introduction
Oxovanadium catalyzed organic reactions constitute a vital and powerful role, not only in
chemistry but also in biochemistry and biomedical sciences [1,2]. Reactions catalyzed by
oxovanadium species attract a lot of attention in biological systems because of their participation
in enzyme catalyzed processes such as halo peroxidases [3] and nitrogenases [4,5]. These
reactions are characterized by very high selectivity, high yield and proceed under mild
conditions. As the oxovanadium complexes generally exist in the IV and V oxidation states and
possess excellent biological activity, they are being utilized as antituberculosis, antibacterial and
antifungal agents [6,7] and to suppress tumor growth [8,9]. Further, oxovanadium complexes
with an N2O2 donor environment possessing chemo preventive properties have been employed to
reduce blood glucose levels by enhancing insulin secretion [10,11], for the treatment of obesity
and hypertension [12] and as anticancer [13,14] and anti-HIV [15] drugs.
The structural similarities of the ligating groups of the salen complexes with
metalloproteins and enzymes are responsible for their broad range of applications. Considering
their applications in areas such as catalysis across a wide range of transformations [16-18],
pronounced biological applicability along with biocompatibility varying from bio-related
nanotechnology to biosensors [19,20], biomedical sciences ranging from enzyme models to
therapeutics and drug development [1,9] and materials science [21-23], many research articles
and reviews have been published. Vanadium salen complexes are widely explored as
electrochemical sensors for sensing metal ions, biomolecules, cell organelles and
pharmaceuticals. The appearance of several recent reviews [16,23-27] addressing exclusively the
2

potential use of vanadium salen complexes substantiate the importance of vanadium salen
complexes.
Different mechanisms, namely electrophilic attack of a sulfur atom on the nucleophilic
2
peroxo oxygen atom [28], SN type oxygen transfer [29-32], direct oxygen transfer [33-35] and
single electron transfer [36-41], have been proposed by our laboratory recently for sulfoxidation
reactions on the basis of spectral and kinetic evidence. In continuation, this paper is dedicated to
the study of mechanistic aspects covering the effect of added nitrogen bases and electronic
modification of the substituents on the sulfoxidation of PMAA by H2O2 catalyzed by
oxovanadium(IV)-salen complexes. The overall reaction scheme is represented in Scheme 1.
Scheme 1. Overall reaction scheme.
This study has gained more importance due to high synthetic utility of such a type of
vanadium Schiff base complex in the synthesis of chiral sulfoxides in good yield with high
enantioselectivity. Coletti et al. [42] reported > 90 % sulfoxide yield during the oxidation of
sulfides catalyzed by di and tetra substituted salophen and salen oxo vanadium complexes. 60-94
% yield of sulfoxide has been reported in the sulfoxidation of thioanisoles catalyzed by
vanadium salen complexes [43] and vanadium Schiff base complexes derived from
salicylaldehyde analogues and amino alcohols [44-47]. More than 90 % sulfoxide yield has been
reported for the oxidation of sulfides catalyzed by a vanadium Schiff base derived from
salicylaldehyde and tert-leucinol [48-50]. Besides the advantage of the high yield of sulfoxide in
3

these vanadium Schiff base catalyzed sulfoxidation, the over oxidation of sulfoxide to sulfone
were also not observed.
2. Experimental section
2.1. Materials
Salicylaldehyde, 5-methyl and 5-chloro salicylaldehydes and vanadyl sulfate were
purchased from Alfa Aesar and used as supplied. Thiophenols were purchased from Sigma
Aldrich. HPLC-grade acetonitrile (Merck) and 30 % H2O2 were used as received without further
purification. H2O2 was standardized by iodometric titration. All other chemicals used were of
analytical reagent grade. The nitrogenous bases (NB), imidazole (ImH), 1-methyl imidazole
(MeIm) and pyridine (Py), were obtained from Merck and used without further purification,
except Py which was distilled over KOH before use.
2.2. Preparation of the phenylmercaptoacetic acids
Twelve phenylmercaptoacetic acids (Scheme 1) with different substituents, viz. H, p-Cl,
p-Br, p-F, m-F, p-OMe, m-OMe, p-OEt, p-Me, p-Et, p-i-Pr and p-t-Bu, were used in this work.
They were prepared using a standard procedure by the condensation of the corresponding
thiophenols with chloroacetic acid in alkaline medium [35,51]. The purity of the PMAAs was
checked using their melting points and LCMS spectra, which were found to agree with the
literature values. The LCMS analysis of each PMAA on a HPLC coupled Agilent ion trap mass
spectrometer using an inestsil-ODS-3V column of the size 4.6 × 250 mm confirmed the presence
of a single species.
2.3. Synthesis of the oxovanadium(IV)-salen complexes
The oxovanadium(IV)-salen complexes (I-III) were prepared following the literature
procedure [52,53], starting from the appropriately substituted salen ligands and VOSO4.5H2O.
The salen ligands were prepared by condensing the substituted salicylaldehydes with ethylene
diamine [54].
2.4. General kinetic studies
The kinetic runs were carried out under atmospheric conditions in a double beam BL 222
Elico UV-vis Biospectrophotometer. An inbuilt program was used to gather the absorbance
4

values at the desired wavelength periodically. The reactions were carried out in 100 %
acetonitrile medium under pseudo-first order conditions with an excess of the PMAA
concentration over the oxidant, NB and catalyst concentrations. In all the kinetic runs, the
concentration of NB was kept over the concentration of the catalyst and below that of H2O2. The
progress of the reaction was followed through the changes in the UV-visible spectra, by
monitoring the decrease in absorbance of the salen complex at an appropriate wavelength: 363
nm for complex I, 376 nm for complex II and 373 nm for complex III. In a typical run, the
reactions were started quickly by injecting freshly prepared standard H2O2 into the reaction
mixture containing PMAA, the oxovanadium(IV)-salen complex and the nitrogen base in a
quartz cuvette at zero time. A representative case of absorption change with time is presented in
Fig. 1. As most of the pseudo first order plots have an initial induction period, the pseudo-first
order rate constants (k1) were calculated from the slope of the linear potion of the plots, where
the OD decreases steadily after the induction period, using the equation, k1 = 2.303 × slope. The
precision of the rate constant is given in terms of 95 % confidence limit of the student’s t-test.
Fig. 1. Absorption spectral changes between 350 and 700 nm with time
[PMAA] = 5.0 × 10-2 M; [H2O2] = 5.0 × 10-3 M; [I] = 5.0 × 10-5 M; [MeIm] = 2.0 × 10-4 M;
Solvent = 100 % AN; Temp. = 30 °C.
Formation of PSAA was identified as the only product of the reaction by GC-MS and FT-
IR spectral methods. It is important to note that under the experimental conditions no over
oxidation of the product PSAA was achieved. The experimental procedure for the analysis and
characterization of the product (Supporting information) was in accordance with our latest
5

publication on the sulfoxidation of PMAA in the absence of nitrogen bases [33]. It was also
confirmed by GC-MS that sulfoxide is the sole product in all the substituted PMAAs, containing
both electron donating and electron withdrawing substituents, thus eliminating deeper oxidation
in all cases.
3. Results
3.1. Spectral observation
The electronic spectra of oxovanadium(IV)-salens I, II and III have an absorption
maxima at 363, 376 and 373 nm respectively, which arise as a result of ligand to metal charge
transfer [42]. Addition of PMAA or H2O2 to the salen complex during the reaction does not alter
the absorption of these peaks. Similarly, addition of the NB axial ligand to the reaction mixture
does not modify either the max value or the intensity of the peak. In the majority of cases, the
addition of axial donor ligands, a nitrogen base or oxide ligand, to salen/porphyrin complexes
causes a significant red shift in the max value [34-36,53,55-58] or a change in the intensity of the
peak [59]. In these reactions, formation of a 1:1 adduct between the complex and the axial ligand
has been identified as the active oxidizing species. From the above observations, it is obvious to
conclude that in the present oxidation, adduct formation between the oxovanadium-salen
complex and the nitrogen base is unambiguously not the active species.
Another spectral observation noted in the kinetic runs is that the absorbance of the
complex remains the same during the initial period of a reaction for certain time. This is also
reflected in the pseudo first order plots where an initial well defined induction period exists for a
definite period of time before a gradual decrease in the absorbance of the complex begins. The
existence of an induction period unambiguously indicates that the active catalytic species is
slowly generated in the reaction mixture after mixing all the reagents. The length of the induction
period is found to decrease with an increase in temperature and concentrations of PMAA, salen
complex and H2O2. On the addition of the axial ligands ImH, MeIm and Py, the induction period
begins to increase with concentration (Fig. 2).
One more salient feature observed during the course of the reaction is the delayed
appearance of a new broad peak with an increase in intensity at around 570 nm (Fig. 1), followed
by a decrease in its intensity. Actually this peak corresponds to the d-d transition of a
vanadium(IV) complex, which is invisible in the absence of H2O2 due to its low intensity. When
6

H2O2 is added, an increase in intensity appears in a sluggish manner and its rate of increase
depends on time and the increase in concentrations of both H2O2 and salen complex. This
strongly advocates the conversion of the oxovanadium(IV)-salen complex to a new species.
Fig. 2. Pseudo first order plots for NB variation with complex II
[PMAA] = 5.0 × 10-2 M; [H2O2] = 5.0 × 10-3 M; [II] = 5.0 × 10-5 M; Solvent = 100 % AN;

max = 376 nm; Temp. = 30 °C.
3.2. Kinetic results
The reaction was carried out at different PMAA concentrations in the range 2  10-2 M to
15  10-2 M, keeping all other conditions unchanged. It is noted that the pseudo first order rate
constant increases with the increase in concentration of PMAA. The non-integral slope value
observed in the plot of log k1 vs log [PMAA] supports the fractional order dependence of PMAA.
This is also verified by the inconstancy of the second order rate constants (k2), calculated using
k2 = k1/[PMAA]. The plot of 1/k1 against 1/[PMAA] was found to be linear (Fig. 3), having an
intercept value at the y-axis which confirms not only the fractional order dependence of PMAA
but also indicates that PMAA coordinates with any one of the reagents in a reversible step during
the reaction. The values of the pseudo first order and overall rate constants as a function of
PMAA are collected in Table 1. The overall rate constants (kov) were calculated using the
expression kov = k1/[PMAA]n, where n is the order of the reaction with respect to PMAA.
The relative high values of the Michaelis-Menten constant (KM) derived from 1/k1 against
1/[PMAA] plots (Table 2) indicate that the coordination of PMAA with the other reagent is weak
7

in nature. The Michaelis-Menten constants obtained with different complexes are found to be
independent of the nature of the nitrogen base. This signals a clear indication that the
coordination of PMAA with the oxovanadium complex is not influenced by the nature of the NB.
Table 1
Effect of [PMAA] on the rate constants in the presence of nitrogen bases.
102
[PMAA] Py
MeIm
ImH
(M)
104 k1
(s-1)
103 kov
104 k1
(s-1)
103 kov
104 k1
(s-1)
103 kov
[(M-1)n s-1)]
[(M-1)n s-1)]
[(M-1)n s-1)]
I
2.0
5.0
0.97  0.01 1.83  0.02
0.66  0.01 1.24  0.02
0.43  0.01 0.82  0.02
0.81  0.03 0.78  0.03
1.89  0.02
2.57  0.03
3.14  0.04
4.45  0.06
1.17  0.02
1.67  0.02
2.16  0.05
1.79  0.02
1.80  0.02
1.77  0.02
1.85  0.03
1.12  0.02
1.17  0.01
1.22  0.03
1.26  0.01
7.5
10
15
0.99  0.02 0.70  0.01
1.38  0.02 0.78  0.01
2.02  0.03 0.85  0.01
3.02  0.03
II
2.0
5.0
7.5
10
2.26  0.01 3.84  0.02
4.61  0.02 4.03  0.02
6.49  0.02 4.23  0.01
7.58  0.03 4.01  0.02
9.44  0.05 3.73  0.02
1.78  0.02 3.07  0.03
3.42  0.02 3.03  0.02
4.58  0.03 3.02  0.02
5.85  0.03 3.13  0.02
7.54  0.04 3.00  0.02
III
1.32  0.01 2.26  0.02
2.57  0.02 2.26  0.02
3.62  0.03 2.37  0.02
4.23  0.03 2.25  0.02
5.68  0.07 2.25  0.03
15
2.0
5.0
7.5
10
0.43  0.01 0.82  0.02
0.81  0.01 0.78  0.01
0.94  0.02 0.70  0.02
1.38  0.03 0.79  0.02
2.02  0.06 0.85  0.03
0.24  0.01 5.57  0.02
0.52 0.02 5.93  0.02
0.72  0.03 5.96 0.03
0.87  0.02 5.68  0.01
1.18  0.03 5.54  0.01
0.17  0.01 0.41  0.02
0.36  0.03 0.41  0.04
0.51  0.02 0.42  0.02
0.63  0.03 0.41  0.02
0.84  0.05 0.40  0.02
15
8

[H2O2] = 2.0 × 10-3 M; [I] = [II] = [III] = 2.0 × 10-5 M;
[Py] = [MeIm] = [ImH] = 2.0 × 10-4 M; Solvent = 100 % AN; Temp. = 30 °C.
Fig. 3. Plot of 1/k1 vs 1/[PMAA] for the reactions with the NBs
(General conditions as in Table 1)
Table 2
Michaelis-Menten constants for the reactions of PMAA with different complexes and NBs.
Complex
KM value
Py
MeIm
0.117
ImH
0.133
0.115
I
0.141
0.212
0.121
0.260
0.121
0.221
II
III
9

Fig. 4. Pseudo first order plot for H2O2 variation with Py and complex I.
[PMAA] = 10 × 10-2 M; [I] = 2.0 × 10-5 M; [Py] = 2.0 × 10-4 M; Solvent = 100% AN;

max = 363 nm; Temp. = 30 °C.
The dependence of the reaction rate on H2O2 in the presence of ImH, MeIm and Py was
studied by measuring the rate constants at different [H2O2]. As the concentration of H2O2
increases, the induction period gradually decreases (Fig. 4) and the rate of the reaction increases
(Table S1). Even though the pseudo first order rate constant increases with the increase in
[H2O2], the observed excellent pseudo first order plots (r > 0.995) clearly show that the order
with respect to H2O2 is one. The observed increase in reaction rate and decrease in induction
period with [H2O2] is visualized by the easy formation of active species with increasing
concentrations of H2O2.
3.3. Relative reactivity of the catalysts
Table 3
Effect of [catalyst] on the reaction rate.
105 [complex]
103 k1 (s-1)
(M)
Py
MeIm
ImH
I
1.0
2.0
5.0
7.0
10
1.52 ± 0.02
2.87 ± 0.02
4.26 ± 0.04
6.15 ± 0.05
8.76 ± 0.07
1.06 ± 0.01
2.11 ± 0.02
3.48 ± 0.03
5.72 ± 0.04
7.04 ± 0.06
0.89 ± 0.01
1.74 ± 0.02
2.60 ± 0.03
4.32 ± 0.03
6.29 ± 0.05
10

II
1.0
2.0
5.0
7.0
10
1.63 ± 0.02
3.27 ± 0.02
7.19 ± 0.05
11.8 ± 0.08
15.2 ± 0.11
1.22 ± 0.03
2.69 ± 0.02
6.48 ± 0.03
9.36 ± 0.06
13.8 ± 0.09
1.03 ± 0.01
2.48 ± 0.01
4.22 ± 0.02
7.64 ± 0.04
11.0 ± 0.08
III
1.0
2.0
5.0
7.0
10
0.17 ± 0.01
0.43 ± 0.01
0.56 ± 0.02
0.71 ± 0.01
0.86 ± 0.03
0.12 ± 0.01
0.38 ± 0.02
0.45 ± 0.01
0.62 ± 0.02
0.74 ± 0.02
0.07 ± 0.01
0.24 ± 0.01
0.38 ± 0.01
0.51 ± 0.02
0.60 ± 0.01
[PMAA] = 10 × 10-2 M; [H2O2] = 1.0 × 10-2 M; [Py] = [MeIm] = [ImH] = 2.0 × 10-4 M;
Solvent = 100 % AN; Temp. = 30 °C.
Realizing the importance of the electronic effect of the substituents, the reactivity of three
salen complexes having different substituents was compared. The rate constants obtained with
three catalysts at different concentrations in the presence of ImH, MeIm and Py are presented in
Table 3. It is observed that the pseudo-first order rate constant increases with the increase in
concentration of the oxovanadium(IV)-salen complex in all cases, irrespective of the nature of
the nitrogen base. The data show that the introduction of an electron donating group in the salen
moiety (II) enhances the catalytic activity, while an electron withdrawing group (III) retards the
reaction rate compared to the unsubstituted oxovanadium(IV)-salen complex (I).
3.4. Influence of axial ligands
In the literature it has been shown that additive axial ligands not only affect the catalytic
activity of the catalyst in oxygenation reactions but also influence the product selectivity
[54,60,61], stereoselectivity [62] and enantioselectivity [55,63]. To better understand the
influence of axial ligands on the catalytic activity of oxovanadium(IV)-salen, the reaction was
carried out with three nitrogen bases, Py, ImH and MeIm, having different -donating abilities.
The calculated pseudo first order rate constants in the presence of the nitrogen bases with
increasing amounts up to 5 × 10-4 M are presented in Table 4. The determination of the rate
constant is restricted to the nitrogen base concentrations mentioned in the Table 4 because
beyond 5 × 10-4 M no appreciable change in rate constant was observed. An examination of the
11

results reveal that the reaction rate is strongly retarded by all the three nitrogen bases in their
lower concentration range, whilst almost saturation is attained at higher concentrations [Fig. 5].
Table 4
Influence of nitrogen bases on the reaction rate
104
[NB]
Py
104 k1
(s-1)
MeIm
104 k1
(s-1)
ImH
104 k1
(s-1)
103 kov
[(M-1)n s-1]
103 kov
103 kov
[(M-1)n s-1]
[(M-1)n s-1]
(M)
I
0
41.0 ± 0.05 39.0 ± 0.05
41.0 ± 0.05 39.0 ± 0.05
29.0 ± 0.04 27.6 ± 0.04
25.3 ± 0.05 24.1 ± 0.05
13.6 ± 0.03 13.0 ± 0.03
7.94 ± 0.04 7.56 ± 0.04
6.17 ± 0.01 5.88 ± 0.01
4.47 ± 0.02 4.26 ± 0.02
3.89 ± 0.01 3.70 ± 0.01
2.76 ± 0.02 2.63 ± 0.02
II
41.0 ± 0.05 39.0 ± 0.05
23.1 ± 0.04 22.2 ± 0.03
18.9 ± 0.03 18.2 ± 0.03
10.4 ± 0.02 10.0 ± 0.02
5.32 ± 0.01 5.12 ± 0.01
3.78 ± 0.03 3.63 ± 0.03
2.97 ± 0.02 2.86 ± 0.02
2.56 ± 0.01 2.46 ± 0.01
2.01 ± 0.01 1.93 ± 0.01
0.05 36.9 ± 0.06 35.1 ± 0.06
0.1
0.3
0.5
1.0
2.0
3.0
5.0
26.2 ± 0.03 25.0 ± 0.03
20.3 ± 0.04 19.3 ± 0.04
18.6 ± 0.03 17.7 ± 0.03
14.2 ± 0.04 13.5 ± 0.04
9.79 ± 0.03 9.32 ± 0.03
7.14 ± 0.02 6.80 ± 0.02
6.32 ± 0.01 6.02 ± 0.01
0
93.7 ± 0.06 82.2 ± 0.05
93.7 ± 0.06 82.2 ± 0.05
72.3 ± 0.06 64.0 ± 0.05
59.6 ± 0.05 52.7 ± 0.04
45.2 ± 0.04 40.0 ± 0.04
37.7 ± 0.05 33.4 ± 0.04
22.9 ± 0.04 20.3 ± 0.04
14.3 ± 0.03 12.7 ± 0.03
11.8 ± 0.04 10.4 ± 0.04
10.2 ± 0.02 9.03 ± 0.02
III
93.7 ± 0.06 82.2 ± 0.05
63.3 ± 0.05 55.5 ± 0.04
40.8 ± 0.04 35.8 ± 0.04
34.3 ± 0.05 30.1 ± 0.04
26.8 ± 0.04 23.5 ± 0.04
18.6 ± 0.03 16.3 ± 0.03
9.92 ± 0.03 8.70 ± 0.03
8.40 ± 0.02 7.37 ± 0.02
7.20 ± 0.02 6.32 ± 0.02
0.05 81.7 ± 0.08 71.7 ± 0.07
0.1
0.3
0.5
1.0
2.0
3.0
5.0
72.3 ± 0.06 63.4 ± 0.05
53.5 ± 0.07 46.9 ± 0.06
41.9 ± 0.03 36.8 ± 0.03
33.6 ± 0.05 29.5 ± 0.04
25.1 ± 0.04 22.0 ± 0.04
17.8 ± 0.02 15.6 ± 0.02
14.0 ± 0.01 12.3 ± 0.01
0
9.68 ± 0.03 11.1 ± 0.03
9.68 ± 0.03 11.1 ± 0.03
7.11 ± 0.04 8.17 ± 0.05
9.68 ± 0.03 1.11 ± 0.03
6.36 ± 0.02 7.31 ± 0.02
0.05 7.82 ± 0.03 8.99 ± 0.03
12

0.1
0.3
0.5
1.0
2.0
3.0
5.0
6.83 ± 0.02 7.85 ± 0.02
5.49 ± 0.03 6.31 ± 0.03
4.68 ± 0.02 5.38 ± 0.02
3.69 ± 0.01 4.24 ± 0.01
2.87 ± 0.02 3.30 ± 0.02
2.27 ± 0.01 2.61 ± 0.01
1.98 ± 0.01 2.28 ± 0.01
6.23 ± 0.03 7.16 ± 0.03
4.99 ± 0.01 5.74 ± 0.01
4.09 ± 0.02 4.70 ± 0.02
3.28 ± 0.02 3.77 ± 0.02
2.10 ± 0.01 2.41 ± 0.01
1.91 ± 0.01 2.20 ± 0.01
1.59 ± 0.01 1.83 ± 0.01
5.54 ± 0.03 6.37 ± 0.03
4.01 ± 0.02 4.61 ± 0.02
3.24 ± 0.01 3.72 ± 0.01
2.34 ± 0.03 2.69 ± 0.03
1.85 ± 0.01 2.13 ± 0.01
1.31 ± 0.01 1.51 ± 0.01
1.10 ± 0.01 1.26 ± 0.01
[PMAA] = 5.0 × 10-2 M; [H2O2] = 5.0 × 10-3 M; [I] = [II] = [III] = 5.0 ×10-5 M;
Solvent = 100 % AN; Temp. = 30 °C.
Fig. 5. Variation of the pseudo first-order rate constant with [NB]
(General conditions as in Table 4)
The observed decrease in rate constant with the increase in concentration of the axial
ligand is probably due to the partial formation of inactive species, [O=V(salen)NB] [59] or
[O=V(salen)(NB)2] [53,60,64]. The formation of these species decreases the concentration of
high valent active species in the reaction medium, which is a precursor required to transfer an
oxygen atom to PMAA. The decrease in the reaction rate by the addition of a nitrogen base in the
present case is in agreement with the results already reported for the oxidation of thiodiglycollic
acid by an iron(III)-salen complex [59], manganese(III)-salen catalyzed H2O2 oxidation of
sulfides [65,66], oxygenation of hydrocarbons catalyzed by metalloporphyrins [67],
13

molybdenum(IV)-Schiff base catalyzed epoxidation of olefins by t-butyl hydroperoxide [68],
epoxidation of olefins by iodosylarenes [69], sodium periodate [70] catalyzed by manganese(III)
porphyrin and the epoxidation of olefins by Mn(III) oxazoline complexes [64] in the presence of
nitrogenous bases. Binding of the nitrogen base with the metal center of the catalyst, which
restricts the attack of reactants on the free coordination site of the catalyst, was identified as the
major cause for the observed rate inhibition in the above cases. The coordination of NB with the
reactive site of the oxo(salen)iron complex in the oxidation of phenyl methyl sulfides [71] and
iron-porphyrin during epoxidation of olefin [72] completely prevent the reactivity.
Among the three nitrogen bases used, ImH exhibits the highest activity towards rate
retardation. The rate constants in Table 4 clearly indicate that the observed effect of rate
retardation shown among the different NBs is in the order: ImH > MeIm > Py. Hence, the order
of reactivity among the NBs is Py > MeIm > ImH. This order seems to be directly related to the
-donating ability of these nitrogen donors. The ligand with the stronger -donating capability
seems to play a greater retarding effect on the rate constant. In the majority of NB mediated
reactions, where the NB acts as a cocatalyst, the reverse order of reactivity has been observed,
i.e. ImH accelerates the reaction to a greater extent than MeIm and Py. The observed order of
reactivity, ImH > MeIm > Py, in the epoxidation of olefins [61,64,53,73,74], oxidation of alcohol
and oximes [75], and decarboxylation of carboxylic acids [76] has been explained by the
increase in electron density on the metal center of the catalyst to a greater extent by a proximal
and distal effect of ImH. In all these cases, NBs accelerate the reaction rate by coordination with
the catalyst. However, the reverse order of reactivity observed in the sulfoxidation reaction
[34,59], Py > MeIm > ImH, was explained by strong binding of ImH with the active site of the
reactive species that restricts the binding of substrate, which is an essential step for a reaction to
take place.
3.5. Substituent effects
To gain more information on the electronic sensitivity of the substituents towards the
reaction center, the reactions between oxovanadium(IV)-salen complex (I) and twelve PMAAs
having different electron releasing and electron withdrawing substituents were investigated in the
presence of Py, ImH and MeIm and the consolidated kinetic data are listed in Table 5. It is noted
that both electron donating and electron withdrawing substituents on PMAA decrease the rate of
14

the reaction considerably and the unsubstituted PMAA is the most reactive species in this series.
The Hammett correlation of the electronic effect of the substituents unveiled a deviation from
linearity. The non-linear concave downward type Hammett plot observed [Fig. 6] is a composite
of two straight lines, one with a positive slope for EDGs falling on the one side of the curve and
the other with a negative slope for EWGs on the other side. Such a type of non-linear downward
Hammett plot, observed earlier [33], has been explained by a change in the rate determining
step/transition state upon changing the substituents.
The observed high  values with NBs (Table 5) prove that the reaction center is more
susceptible to electronic variation. It is pertinent to note that with NB the  value is found to be
almost constant, irrespective of temperature and the nature of the nitrogen base. In the absence of
NBs, the  value for the same reaction was found to increase with temperature [33].
Table 5
Overall rate constants and thermodynamic parameters for the reactions of PMAAs with complex
I in the presence of nitrogen bases.
103 kov [(M-1)n s-1)]
‡H
-‡S
PMAA
(kJ mol-1)
(J K-1 mol-1)
20 °C
30 °C
40 °C
Py
m-F
0.543  0.01
0.862  0.01
1.12  0.01
2.74  0.02
4.64  0.02
6.78  0.02
1.95  0.02
1.78  0.02
1.59  0.01
1.35  0.01
0.720  0.01
0.578  0.005
0.740  0.01
1.26  0.01
1.57  0.02
3.94  0.02
7.06  0.02
9.32  0.03
2.81  0.03
2.30  0.03
2.03  0.02
1.96  0.02
1.06  0.01
0.863  0.005
0.964  0.01
1.66  0.01
2.24  0.02
5.47  0.02
9.61  0.02
13.4  0.05
3.93  0.02
3.12  0.03
3.01  0.03
2.67  0.03
1.55  0.01
1.26  0.005
19.3  1.1
22.0  0.7
23.7  0.8
23.7  0.4
25.4  0.2
23.7  0.3
24.6  0.7
19.3  0.8
21.9  0.7
23.7  0.7
27.2  0.7
27.2  0.5
88.3  3.7
75.1  2.6
67.4  2.9
59.9  1.4
49.8  0.8
52.5  0.9
59.5  2.6
78.7  2.9
70.8  2.6
65.7  2.6
58.9  2.6
60.9  1.8
p-Br
p-Cl
m-OMe
p-F
H
p-iPr
p-Et
p-Me
p-t-Bu
p-OEt
p-OMe
ρ
EWS
-3.43  0.23
-3.4  0.20
-3.57  0.23
15

r
0.991
0.993
0.992
ρ
EDS
3.96  0.20
0.994
3.80  0.22
0.992
3.80  0.21
0.992
r
MeIm
m-F
0.251  0.005
0.438  0.01
0.510  0.01
1.28  0.01
0.349 0.005
0.623 0.01
0.729 0.01
1.76  0.02
2.99  0.02
4.26  0.02
1.30  0.02
1.08  0.02
0.969  0.01
0.792  0.01
0.496  0.01
0.399  0.005
0.465 0.01
0.859 0.01
1.03  0.02
2.48  0.03
4.44  0.03
6.28  0.02
1.88  0.03
1.48  0.03
1.39  0.02
1.15  0.01
0.758  0.01
21.1  1.4
22.8  1.3
24.6  1.3
22.8  0.8
28.1  0.6
25.4  0.4
24.5  1.1
19.3  1.1
22.8  1.0
22.8  1.0
29.0  1.2
88.7  4.9
77.9  4.6
70.8  4.6
69.3  2.8
47.7  2.1
53.2  1.4
66.1  3.9
85.0  3.9
74.3  3.5
75.8  3.5
59.5  4.2
72.9  3.5
p-Br
p-Cl
m-OMe
p-F
2.00  0.02
H
3.02  0.02
p-iPr
0.917  0.01
0.822  0.01
0.717  0.01
0.597  0.01
0.330  0.005
0.289  0.005
p-Et
p-Me
p-t-Bu
p-OEt
p-OMe
0.603  0.005 25.4  1.0
ρ
EWS
-3.32  0.17
0.995
-3.38  0.18
0.995
-3.49  0.18
0.995
r
ρ
EDS
3.84  0.18
0.994
3.82  0.14
0.997
3.78  0.16
0.996
r
ImH
m-F
p-Br
p-Cl
m-OMe
p-F
0.158  0.003 0.222  0.005
0.299  0.005 22.0  1.4
89.6  4.9
93.6  5.6
88.5  5.2
78.1  3.5
83.3  3.1
53.8  2.1
0.296  0.005
0.382  0.01
0.886  0.01
1.37  0.02
1.95  0.02
0.384  0.01
0.502  0.01
1.24  0.02
1.92  0.02
2.86  0.02
0.518  0.01
0.685  0.01
1.63  0.02
2.39  0.03
4.15  0.03
19.3  1.6
20.2  1.5
21.1  1.0
18.5  0.9
26.3  0.6
H
p-iPr
p-Et
0.622  0.01
0.535  0.01
0.810  0.02
0.696  0.01
1.13  0.02
20.2  1.4
19.3  1.3
84.3  4.9
78.7  4.5
0.937  0.02
p-Me
0.483  0.01
0.653  0.01
0.886  0.01
20.2  1.2
86.4  4.2
16

p-t-Bu
p-OEt
p-OMe
0.403  0.005
0.224  0.005
0.180  0.002
0.575  0.01
0.335  0.005
0.261  0.002
0.826  0.01
0.482  0.01
24.6  1.1
27.2  1.4
72.8  3.8
68.7  4.9
70.7  2.8
0.398  0.005 27.2  0.8
ρ
EWS
-3.33  0.17
0.994
-3.41  0.21
0.992
-3.42  0.21
0.992
r
ρ
EDS
3.83  0.20
0.993
3.82  0.18
0.994
3.76  0.22
0.992
r
[PMAA] = 5.0  10-2 M; [H2O2] = 5.0  10-3 M; [I] = 5.0  10-5 M;
[Py] = [MeIm] = [ImH] = 2.0  10-4 M; Solvent = 100 % AN.
Fig. 6. Hammett plots for the reactions at 30 °C
(General conditions as in Table 5)
3.6. Thermodynamic parameters
The sulfoxidation reaction of PMAA with the three complexes in the presence of nitrogen
bases was studied at three different temperatures and the thermodynamic parameters, viz.
enthalpy (‡H) and entropy (‡S) of activation, were evaluated from the slope and intercept of
Eyring’s plot of log (k2/T) vs. 1/T (Fig. 7) and the values are presented in Tables 5 and 6.
Table 6
Overall rate constants and thermodynamic parameters with complexes II and III.
‡H
-‡S
NB
103 kov [(M-1)n s-1)]
17

(kJ mol-1)
(J K-1 mol-1)
20 °C
30 °C
40 °C
II
Py
13.9  0.03
8.27  0.02
5.68  0.02
22.0  0.04
12.7  0.03
8.70  0.03
34.3  0.05
19.8  0.04
13.5  0.03
32.5  0.1
30.7  0.2
30.7  0.2
38.7  0.4
46.1  0.7
49.2  0.7
MeIm
ImH
III
Py
2.52  0.01
1.92  0.01
1.63  0.01
3.30  0.02
2.41  0.01
2.13  0.01
4.29  0.02
3.20  0.02
2.83  0.01
17.6  0.4
16.7  0.5
18.4  0.5
100  1.4
105  1.8
101  1.8
MeIm
ImH
[PMAA] = 5.0  10-2 M; [H2O2] = 5.0  10-3 M; [II] = [III] = 5.0  10-5 M;
[Py] = [MeIm] = [ImH] = 2.0  10-4 M; Solvent = 100% AN.
An inspection of the data reported in Tables 5 and 6 seems to indicate that both the
enthalpy and entropy of activation are found to be almost constant, irrespective of the nature of
PMAA and NB, but they do depend on the substituent present on the vanadium complex.
Fig. 7. Eyring’s plots for the reactions
When the ‡H values of different PMAAs are plotted against the ‡S values, no linear
correlation (r = 0.81) is obtained. On the other hand, an excellent linear Exner’s plot (r = 0.997)
is obtained when logarithm of the overall rate constants at two extreme temperatures are plotted
(Fig. 8). The excellent correlation obtained in the Exner’s plot. along with almost constant ‡H
and ‡S obtained with all substituted PMAAs (Table 5), lead to the conclusion that there is no
change in the reaction mechanism or the transition state with respect to the substituents on
18

PMAA. Hence, the observed downward Hammett correlation could be explained by invoking a
mechanism having a shift in the RDS within a single reaction pathway.
Fig. 8. ‡S vs ‡H and Exner’s plots for the reactions of PMAAs with I in the presence of Py.
4. Discussion
4.1. Active species
Various reactions catalyzed by metallosalen and metalloporphyrin ligands have shown
that nitrogen bases behave differently with different catalysts and under different reaction
conditions. In the majority of cases, the NB coordinates with the catalyst/oxidant by a proximal
effect to form high valent metal oxo-NB species, which are considered as the active oxidizing
species that transfers oxygen to the substrate. Reactions which involve the formation of such
precursors normally show rate acceleration [64,77,78] or marked improvement in product yield
[61,73,79]. The enhancement in the catalytic power of the catalyst as a result of reinforcement of
proximal electron donation by axially coordinated NB was suggested during the oxidation
[67,80,81], epoxidation [82-84] and sulfoxidation [34,60,85] reactions. Formation of NB ligated
active species with the catalyst was confirmed by a shift in the absorption spectra, change in the
color of the solution along with EPR and ESI-MS spectral data. The coordination of Py with the
vanadium atom of the pyrazolyl-V(III) catalyst used for ethylene polymerization was confirmed
by crystal structure analysis [86]. Coordination of ImH/MeIm with an iron(III) salen complex
during aniline oxidation by H2O2 was concluded by ESI-MS spectra [58]. The nitrogen bases are
19

generally presumed to bind at a site trans to the oxo group [87,88] and weaken the M-O bond of
the oxo species by donating electron density to the metal atom [62,64].
In some cases, where the adduct formed between the NB and the catalyst is not the active
species, the NB blocks the vacant site of the catalyst by weak coordination prior to the
coordination of oxidant/substrate. In such cases, retardation in the rate constant or product yield
is observed [55,59,70]. It is interesting to note that even the reactions where rate acceleration was
observed at a low concentration of the NB, rate retardation was reported at higher concentrations
of NB [60,64]. This observation has been explained by the increase in concentration of the bis
NB ligated species that do not have any vacant sites for coordination of the oxidant/substrate.
Previously, in various oxygenation reactions catalyzed by oxovanadium(IV) complexes
in the absence of NB, a newly formed high valent oxoperoxovanadium moiety has been
proposed as the sole reactive species. The gradual appearance of new broad peak followed by a
decrease in intensity corresponds to a d-d transition; this peak was observed at around 560 nm in
the asymmetric oxidation of sulfides to sulfoxides [89], at 590 nm in the oxidation of phenols
[90], at 572 nm in the oxidation of tertiary amines [91], and at 610 and 560 nm in the oxidations
of PSAA [28] and PMAA [33] during the course of the reaction catalyzed by Schiff base
oxovanadium(IV) and (V) complexes, and was taken as evidence for the formation of
hydroperoxovanadium(V) as the new active species. The existence and involvement of
hydroperoxovanadium(V) as the reactive species in the reactions of oxovanadium(IV)-salophen
and salen complexes was confirmed by IR, 51V NMR and theoretical studies [42].
Based on the above facts and discussion, it is concluded that the active oxidizing species
in the present study may be either the adduct formed between NB and oxovandium(IV)-salen or
hydroperoxovanadium(V)-salen species. The absence of an observable change in the
characteristic peak of oxovanadium(IV)-salen with NB, either in max or intensity, observed
retardation effect with an increase in [NB] (Table 4), appearance of a new peak with an increase
in intensity followed by its decay at 570 nm with time during the reaction (Fig. 1), precisely at
the same position as that in the absence of NB [33], and the coincidence of the max value of the
newly formed peak exactly in the same range as that of other reported values for the reactions
where hydroperoxovanadium(V) is involved as the active species [28,89-91] not only confirm
hydroperoxovanadium(V) (Fig. 9) is the sole active species for the sulfoxidation but also
eliminate the involvement of a 1:1 salen-NB adduct (C3) as the active oxidizing species under
20

these reaction conditions. The non-existence of the reaction without the combination of
oxovanadium(IV)-salen and H2O2 also emphasizes the importance of both H2O2 and salen in the
generation of active species and the involvement of hydroperoxovanadium(V)-salen in the
reaction.
Fig. 9. Structure of hydroperoxovanadium(V)-salen.
4.2. Mechanism
Based on the spectral observations, kinetic results, analysis of facts concerning the nature
of active species, low reactivity of PMAAs having electron donating and withdrawing
substituents and the retarding effect exerted by axial nitrogenous ligands, the following
mechanism with two different rate determining steps (Scheme 2) representing a possible catalytic
cycle of the oxovanadium complex is proposed.
21

Scheme 2. Overall mechanism for the sulfoxidation.
It is proposed that the first step in the mechanism involves the activation of the O-O
group by transferring a proton from H2O2 to the oxo group of vanadium(IV)-salen complex (C1),
with simultaneous binding of the hydroperoxo moiety to the vanadium center to form a
vanadium(IV) species (C2). If the conversion of C1 to C2 takes place via an intermediate (C10), in
which H2O2 is bound apically in an end-on fashion, then the end-on vanadium(IV) species (C2) is
formed. On the other hand, if H2O2 is coordinated to vanadium in a side-on fashion, then the
side-on isomer (C11) is formed. Side-on peroxo formation is strongly accelerated by acid-base
catalysts. In the side-on isomer, both peroxo oxygen atoms are coordinated to the vanadium
22

center. It has been shown that both end-on (C2) and side-on (C11) isomers are isoenergetic. As
they are relatively unstable [92,93], they are readily converted into hydroperoxovanadium(V)-
salen (C4) and peroxovanadium(V)-salen (C12) by losing a proton and water molecule,
respectively.
Scheme 3. Scheme for O-O activation and active species formation.
Thus, the possible oxidizing species in the reaction is either the end-on species,
hydroperoxovanadium(V)-salen (C4), or the side-on species, peroxovanadium(V)-salen (C12).
Balcells et al. [94] have shown by theoretical calculation that these two forms are
interconvertible as they have an energy difference within a span of 5 kcal/mol. The existence of a
51
rapid equilibrium between these two species is evidenced from a V NMR spectral study [95].
Further, attempts to isolate these active species were unsuccessful. Thus it has been inferred that
both forms are feasible candidates for the active form of the catalyst. The choice amongst them,
hydroperoxo or peroxo, as the active species depends on the reaction conditions, catalyst and
substrate.
Although peroxovanadium(V)-salen (C12) has been proposed as the active species for the
epoxidation of cyclohexene catalyzed by vanadium porphyrin complexes [96] and halide
oxidation catalyzed by vanadium haloperoxidases [93], the involvement of the hydroperoxo form
in most sulfoxidation reactions [42,45,54,94,97,98] is in agreement with our proposal. The
involvement of hydroperoxovanadium(V)-salen (C4) as the active species is supported by the
substituent effect shown in salen complexes. It is pertinent to note that an EDG on
23

oxovanadium(IV)-salen increases the electron density on the vanadium center and thereby
increases the nucleophilicity of the oxovanadium active species. Even though this effect
disfavors the attack of PMAA with C4 to form C5, the increase in rate with an EDG on C1 clearly
indicates the importance of O-O activation and active species formation in this reaction over
attack of PMAA with the active species. An EDG on the salen complex favors the polarization of
the oxovanadium bond in C1 and thereby facilitates the formation of C4 by the attack of H2O2.
The easy formation of active species with EDGs on the salen complex has been verified by the
decrease in magnitude of the induction period. The reverse explanation can be applied to EWGs
on the salen complex for the observed rate retardation effect and increase in induction period.
The significant role of active species generation in this reaction is also evidenced from the
retardation effect shown by increase in concentration of NB (Table 4).
On the basis of the mechanism proposed for the sulfoxidation reactions catalyzed by
hypervalent oxosalen species [34-36,99,100], an electrophilic attack of the vanadium atom of the
active species, hydroperoxovanaium(V) species (C4) on the sulfur atom of PMAA, leading to the
formation of C5 in a reversible process, is proposed for this reaction. This results in the
development of a partial positive charge on the coordinated sulfur atom and a negative charge on
the hydroperoxyl oxygen atom. The reverse nature of the step is suggested on the basis of the
observed Michaelis-Menten kinetics with PMAA. A similar sulfoxidation intermediate (C5) has
been postulated in the sulfoxidation of disulfide [94], methyl phenyl sulfides [45] and PMAA
[33] catalyzed by oxovanadium(IV)-Schiff base complexes. The formation of intermediate C5 is
affected by structural changes in PMAA and presumably influences the rate determining step.
This view is apparently in agreement with our experimental results that both EDGs and EWGs
on PMAA decrease the sulfoxidation rate. The observed retardation effect with EDGs and EWGs
(Table 5) indicates that the formation of C5 from C4 is not a common rate determining step for
both types of substituents. The observed downward non-linear Hammett plot with an opposite
sign of the reaction constant () for EDGs and EWGs (Fig. 6) is in agreement with a change in
the rate determining step or a change in the transition state with the change in the nature of the
substituent. The observed constant thermodynamic parameters, ‡H and ‡S, in all the
substituted PMAAs (Table 5) are a clear indication that two different transition states are not
involved in the reaction and supports two different rate determining steps for the donor and
acceptor substituents.
24

It is seen that an EWG on PMAA pulls electron density from the sulfur atom and thus
reduces the nucleophilic character of PMAA. As a result, the reactive species (C4) finds it
difficult to electrophillically attack the sulfur atom of PMAA and disfavors the formation of the
intermediate C5. Not only that, EWGs also tend to increase the positive charge on the sulfur atom
of C5 which results in the destabilization of C5 and also facilitates the conversion of C5 into C6 in
a fast manner. The above discussion leads us to conclude that the formation of C5 from C4 in a
reversible step is the rate controlling step for PMAAs containing EWGs. The appearance of a
positive charge at the reaction center of PMAA in the rate controlling step is evidenced from the
observed negative  value in the portion of the Hammett plot containing EWGs (Table 5 and Fig.
6).
The nucleophilic character of PMAA is strongly reduced as a result of coordination of
PMAA with the vacant site of the vanadium center (C4 to C5). Subsequently, a four membered
cyclic intermediate (C6) is formed by the coordination of the peroxo oxygen atom with PMMA
through the coordinated sulfur atom. This coordination is favored by EWGs on PMAA, while
EDGs make the coordination more difficult. Further, EDGs on the PMAA preclude the transfer
of oxygen to the sulfur atom in the intermediate C6 by increasing the charge density on the sulfur
atom, i.e. disfavoring the disproportionation of C6 into the products PSAA and C7. The transfer
of oxygen to the sulfur atom in the slow rate determining step for EDGs is evidenced by the
decrease in the rate constant with the increase in electron donating ability of the substituents and
the observed positive  value with EDGs in the Hammett correlation. Thus, the break at the
unsubstituted PMAA in the Hammett plot (Fig. 6) is in strong favor for a change in the rate
determining step in a multi stage mechanism as a function of the substituents on PMAA. The
process of formation of PSAA in a multistage mechanism is confirmed by the absence of
isobestic points during the course of the reaction (Fig. 1). The existence of an excellent linear
Exner’s plot (Fig. 8) with EDGs and EWGs in the same line rules out the operation of two
different mechanisms in this reaction series.
The observed non-linearity in the plot of log kov against oxidation potential of PMAAs
(Fig. 10) firmly rules out the operation of a single electron mechanism as proposed in many salen
mediated reactions, viz. oxidation of organic sulfides [101] and anilines [102] by chromium(V)
complexes, H2O2 oxidation catalyzed by iron(III)-salen complexes [103] and phenols catalyzed
by oxovanadium(IV)-salen [90].
25

Fig. 10. Plot of log kov against Eox potential of PMAA for the reaction with I and ImH.
4.3. Role of the nitrogen base and reactivity
A comparison of the rate constants with and without nitrogen bases (Table 4) indicates
that NBs deteriorate the catalytic activity of oxovanadium(IV)-salen complexes. According to
Scheme 2, two vacant sites on the vanadium atom are essential for the formation of high valent
oxidizing species and the transfer of oxygen from the active species to PMAA. If any one of the
sites is occupied by any additives then the rate of the reaction might be decreased. The observed
decrease in reactivity in the presence of NB is better explained by the concomitant formation of
an adduct (C3) between the catalyst (C1) and NB by weak coordination as a competitive reaction,
simultaneous and parallel to the formation of active species (C4); not only that, it also
emphasizes the crucial importance of free coordination sites on the oxosalen complex for a
smooth reaction to take place. Weak coordination of NB with the salen complex is confirmed by
the absence of any shift in the absorption and intensity of the peak for C1. The coordination of
NB prevents the coordination of H2O2 with the catalyst by restricting the free coordination site.
As a result, the formation of active species (C4) and binding of PMAA with active species to
form C5 become difficult, which are essential steps for the sulfoxidation to take place.
The interesting aspect gathered from the kinetic profiles reported in Fig. 2 is that the
induction period increases with an increase in the concentration of the NBs. This unambiguously
proves the existence of competition between the NB and H2O2 in coordinating with
oxovanadium(IV)-salen to form inactive species (C3) and active species (C4), respectively. The
26

simultaneous existence of competition between two reactions is confirmed from the fact that
NBs are found only to slow down the reactivity but not completely inhibit the reaction. As the
concentration of the NB increases, the fraction of the salen complex (C1) utilized for the
formation of unreactive species increases. Even though there is a competition between H2O2 and
NBs to form a six coordinated vanadium complex, apparently due to less steric hindrance around
the terminal oxygen atom of H2O2, the attachment of H2O2 to the vanadium center through the
terminal peroxo oxygen atom is more facile and dominant compared to the attack of the NB.
The occurrence of competition between H2O2 and NBs is further substantiated from the
order of reactivity noted among different NBs. Imidazole, being a strong  donor, binds with the
vanadium atom of the complex more preferentially, which prevents the formation of the active
species (C4) more effectively and is followed by the highest retardation rate among all the NBs.
As Py has a weak  donating ability, its possibility to bind with the salen complex is faint. This
results in easy formation of the active species (C4) in the presence of Py, showing a low
retardation effect as compared to ImH and MeIm.
In addition to the competition between NBs and H2O2 towards C1, the probability of
competition amongst NBs and PMAA through C4 leading to the formation of C8 and C5
respectively cannot be ruled out and that may be one of the reasons for the observed retardation
effect with NBs. In some reactions, coordination of the NB with the active species that compete
and prevent the binding of substrate was given as explanation for the observed retardation effect
with the NB [59,70]. In fact, coordination with two sites of the metal center connected with
HOO- and the NB in salen complexes was considered as the dominant form in the presence of
H2O2 and the NB [77,79].
The least reactive rate observed with ImH also demonstrates the existence of distal
hydrogen bonding, -N-H-----B, that is possible only for ImH. This interaction naturally increases
the binding ability of ImH by shifting electron density from the free base (B) to the coordinated
base. The increasing binding ability of ImH towards different catalysts by such a type of
hydrogen bonding is already advocated in many cases [53,64,104]. Another reason for ImH’s
higher rate retardation effect may be due to the ability of ImH to convert the catalyst into a
catalytically inactive bisligated species, by consuming a portion of the catalyst [53,67,74,105].
Beside the above mentioned effects, the added nitrogen bases also prevent the formation of
hydroperoxovanadium(V) salen (C4) by the preferential removal of a hydrogen atom from
27

coordinated H2O2 in C2. As a consequence, instead of forming the active species (C4) from C2 , a
,
less active cyclic peroxo species (C9) is formed in the catalytic cycle. The existence of the cyclic
peroxo species in acetonitrile medium has been proved by Coletti et al. [42] using theoretical
studies. Proton abstraction from a peroxo group coordinated with a metal atom by imidazole has
been advocated during the oxidation of hydrocarbons by H2O2 catalyzed by Mn-porphyrins
[106], oxidation of sulfides to sulfoxides by UHP using Mn(III)-oxazoline complexes [107] and
in the oxidation of olefins and sulfides catalyzed by a manganese(III)-tridentate Schiff base
complex using UHP as the oxidant [74].
5. Conclusions
This study describes the influence of nitrogen bases, such as imidazole, 1-methyl
imidazole and pyridine, on the selective sulfoxidation of several phenylmercaptoacetic acids to
phenylsulfinylacetic acids, catalyzed by oxovanadium(IV)-salen complexes. The findings prove
that axial ligation of the nitrogen bases to the vanadium atom of salen to form 1:1 adducts
compete with the formation of active hydroperoxovanadium(V) species, which results in a
decrease in the rate of sulfoxidation. The observed order of retardation ImH > MeIm > Py has
been explained on the basis of proximal and distal interactions of the nitrogen bases with the
oxovanadium(IV)-salen complex. A weak  donor with the lowest binding ability with the salen
complex has the highest catalytic effect in this reaction. Vanadium salen complexes with electron
donating substituents on the phenyl group are found to be more effective catalysts than those
with electron withdrawing substituents. The reaction between PMAA, H2O2, the
oxovanadium(IV)-salen complex cocatalyzed by nitrogen bases has been retarded by both
electron donors and electron acceptors in the p- and m-positions of PMAA. The observed
downward Hammett plot has been rationalized by a change in the rate determining step from
addition of PMAA to the active species with electron withdrawing substituents to transfer of
oxygen to PMAA with electron donating substituents within the same mechanism. The
sulfoxidation of PMAA to yield PSAA, a challenging compound in pharmaceutical chemistry,
can lead to the future use of this compound in medicinal industry.
Acknowledgements
28

PS gratefully acknowledged the UGC, New Delhi, India for providing financial support
in the form of a major research project (F.No.39-817/2010)(SR). CK thanks the UGC, SERO,
Hyderabad (No.TNTK00003661) for granting monetary benefits under the Faculty Development
Program and Manonmaniam Sundaranar University for allowing access to the benefits of the
Faculty Development Program. The authors thank the Management of Aditanar College of Arts
and Science, Tiruchendur for providing facilities to carry out this research.
References
[1] J.C. Pessoa, I. Correia, Coord. Chem. Rev. 388 (2019) 227.
[2] J.M. Mir, R.C. Maurya, P.K. Vishwakarma, Karbala Int. J. Mod. Sci. 3 (2017) 212.
[3]
[4]
[5]
[6]
[7]
A. Butler, Coord. Chem. Rev. 187 (1999) 17.
R.D. Little, A. Butler, J. Am. Chem. Soc. 123 (2001) 3289.
D. Rehder, J. Inorg. Biochem. 80 (2000) 133.
G.M. Hashidhara, T.R. Goudar, Synth. React. Inorg. Met. Org. Chem. 30 (2000) 1581.
Z.T. Maqsood, K.M. Khan, U. Ashiq, R.A. Jamal, Z.H. Chouhan, M.M. Tahir, C.T. Supura,
J. Enzym. Inhib. Med. Chem. 21 (2006) 37.
[8]
U. Jungwirth, C.R. Kowol, B.K. Keppler, C.G. Hartinger, W. Berger, P. Heffeter, Antioxid.
Redox. Signal. 15 (2011) 1085.
[9]
D. Rehder, Future Med. Chem. 4 (2012) 1823.
[10]
S. Roy, A.K. Mondru, S.K. Dontamalla, R.P. Vaddepalli, S. Sannigrahi, P.R. Veerareddy,
Biol. Trace Elem. Res. 144 (2011) 1095.
[11] D.C. Cran, S. Schoeberl, E. Gaidamauskas, B. Baruah, D.A. Roess, J. Biol. Inorg. Chem. 16
(2011) 961.
[12] I. Correia, J. Costa Pessoa, M.T. Duarte, R.T. Henriques, M.F.M. Piedade, L.F. Veiros, T.
Jackush, A. Dornyei, T. Kiss, M.M.C.A. Castro, C.F.G.C. Geraldes, F. Avecilla, Chem. Eur.
J. 10 (2004) 2301.
[13] E. Kioseoglou, S. Petanidis, C. Gabriel, A. Salifoglou, Coord. Chem. Rev. 301-302 (2015)
87.
[14] I.E. Leon. J.F. Cadavid-Vargas, A. Resasco, F. Maschi, M.A. Ayala, C. Carbone, S.B.
Etcheverry, J. Biol. Inorg. Chem. 21 (2016) 1009.
[15] A. Ross, D.C. Soares, D. Covelli, C. Pannecouque, L. Budd, A. Collin, N. Robertson, S.
Parsons, E. De Clercq, P. Kennepohl, P.J. Sadler, Inorg. Chem. 49 (2010) 1122.
29
