Inorg. Chem. 2002, 41, 2041−2053
Direct Addition of Alcohols to Organonitriles Activated by Ligation to a
Platinum(IV) Center
,†
Nadezhda A. Bokach,†,‡ Vadim Yu. Kukushkin,* Maxim L. Kuznetsov,‡ Dmitrii A. Garnovskii,‡
Giovanni Natile,§ and Armando J. L. Pombeiro*
,‡
Department of Chemistry, St. Petersburg State UniVersity, 198904 Stary Petergof,
Russian Federation, Centro de Qu´ımica Estrutural, Complexo I, Instituto Superior Te´cnico, AV.
RoVisco Pais, 1049-001 Lisbon, Portugal, and Dipartimento Farmaco-Chimico, UniVersity of Bari,
Via E. Orabona 4, I-70125 Bari, Italy
Received October 2, 2001
Treatment of trans-[PtCl4(RCN)2] (R ) Me, Et) with R′OH (R′ ) Me, Et, n-Pr, i-Pr, n-Bu) at 45 °C in all cases
allowed the isolation of the trans-[PtCl4{(E)-NHdC(R)OR′}2] imino ester complexes, while the reaction between
cis-[PtCl4(RCN)2] and the least sterically hindered alcohols (methanol and ethanol) results in the formation of cis-
[PtCl4{(E)-NHdC(R)OR′}2] (R/R′ ) Me/Me) or trans-[PtCl4{(E)-NHdC(Et)OR′}2] (R′ ) Me, Et), the latter being
formed via thermal isomerization (ROH, reflux, 3 h) of the initially formed corresponding cis isomers. The reaction
between alcohols R′OH and cis-[PtCl4(RCN)2] (R ) Me, R′ ) Et, n-Pr, i-Pr, n-Bu; R ) Et; R′ ) n-Pr, i-Pr, n-Bu),
exhibiting greater R/R′ steric congestion, allowed the isolation of cis-[PtCl4{(E)-NHdC(R)OR′}{(Z)-NHdC(R)-
OR′}] as the major products. The alcoholysis reactions of poorly soluble [PtCl4(RCN)2] (R) CH Ph, Ph) performed
2
under heterogeneous conditions, directly in the appropriate alcohol and for a prolonged time and, for R ) Ph, with
heating led to trans-[PtCl4{(E)-NHdC(R)OR′}2] (R) CH Ph, R′ ) Me, Et, n-Pr, i-Pr; R ) Ph, R′ ) Me) isolated
2
in moderate yields. In all of the cases, in contrast to platinum(II) systems, addition of R′OH to the organonitrile
platinum(IV) complexes occurs under mild conditions and does not require a base as a catalyst. The formed
isomerically pure (imino ester)Pt(IV) complexes can be reduced selectively, by Ph3PdCHCO Me, to the corresponding
2
isomers of (imino ester)Pt(II) species, exhibiting antitumor activity, without change in configuration of the imino
ester ligands. Furthemore, the imino esters NHdC(R)OR′ can be liberated from both platinum(IV) and platinum(II)
complexes [PtCln{NHdC(R)OR′}2] (n ) 2, 4) by reaction with 1,2-bis(diphenylphosphino)ethane and pyridine,
respectively. All of the prepared compounds were characterized by elemental analyses (C, H, N), FAB mass
spectrometry, IR, and 1H, 13C{1H}, and 195Pt (metal complexes) NMR spectroscopies; the E and Z configurations
of the imino ester ligands in solution were determined by observation of the nuclear Overhauser effect. X-ray
structure determinations were performed for trans-[PtCl4{(E)-NHdC(Me)OEt}2] (2), trans-[PtCl4{(E)-NHdC(Et)-
OEt}2] (10), trans-[PtCl4{(E)-NHdC(Et)OPr-i}2] (11), trans-[PtCl4{(E)-NHdC(Et)OPr-n}2] (12), and cis-[PtCl4{(E)-
NHdC(Et)OMe}2] (14). Ab initio calculations have shown that the EE isomers are the most stable ones for both
platinum(II) and platinum(IV) complexes, whereas the most stable configurations for the ZZ isomers are less stable
than the respective EZ isomers, indicating an increase of the stability on moving from the ZZ to the EE configurations
which is more pronounced for the Pt(IV) complexes than for the Pt(II) species.
Introduction
and C-N bonds due to the addition of nucleophiles to the
nitrile carbon, e.g., in the course of the Pinner1,2 and thio-
Pinner3 reactions. Often such processes require actiVation
of RCN toward the addition, either by an electron-acceptor
It is commonly recognized in organic chemistry that
organonitriles are intrinsic synthons for making C-O, C-S,
* Authors to whom correspondence should be addressed. E-mail:
kukushkin@VK2100.spb.edu (V.Yu.K.); pombeiro@ist.utl.pt (A.J.L.P.).
† St. Petersburg State University.
(1) (a) Dunn, P. J. In ComprehensiVe Organic Functional Group
Transformations; Katrizky, A. R., Meth-Cohn, O., Rees, C. W., Eds.;
Elsevier: Oxford, 1995; Vol. 5, p 741. (b) Granik, V. G. Russ. Chem.
ReV. (Engl. Transl.) 1983, 52, 377.
‡ Instituto Superior Te´cnico.
§ University of Bari. E-mail: natile@farmchim.uniba.it.
10.1021/ic011025h CCC: $22.00 © 2002 American Chemical Society
Published on Web 03/28/2002
Inorganic Chemistry, Vol. 41, No. 8, 2002 2041

Bokach et al.
group R or by use of acids, for instance HX (X ) Cl, Br),1
which, by protonating the N atom, increase the electrophi-
licity of the adjacent carbon atom thus facilitating the reaction
with nucleophiles. Instead of H+, metal ions can be used in
the addition reactions to enhance the reactivity of organo-
nitriles, thus accomplishing the dream of organic chemists
for smooth additions of nucleophiles to RCN molecules
(especially those inactiVated by electron-releasing R radicals).
Many of these metal-mediated processes have been sum-
marized in review articles on the subject.4-6
Our own investigation on the reactivity of coordinated
organonitriles toward nucleophiles has so far been focused
on couplings between platinum(IV) complexes of the type
[PtCl4(RCN)2] and oximes (R1R2CdNOH7), Vic-dioximes
[HONd(spacer)dNOH8], or dialkylhydroxylamines (R1R2-
NOH9) which led to the formation of [PtCl4{NHdC(R)ONd
CR1R2}2], [PtCl4{NHdC(R)ONd(spacer)dNOH})2], and
[PtCl4{NHdC(R)ONR1R2}2], respectively. The latter reac-
tions have also been extended to Re(IV)10 and Rh(III)11
organonitrile complexes. We also found that Ag+ or Cu2+
ions catalyze the coupling of dialkylcyanamides with oximes
at a platinum(II) center12 and that nitrones of the type
O-N+(R3)dC(R1)(R2) can give [2 + 3] cycloaddition to the
acetonitrile ligands in the complex [PtCl4(MeCN)2] furnish-
ing ∆4-1,2,4-oxadiazoline complexes of the type [PtCl4-
{NdC(Me)O-N(R3)-C(R1)(R2)}2] from which the hetero-
cycles can be quantitatively liberated.13 Finally, platinum-
mediated coupling of ligated organonitriles and benzophen-
one imine can lead to coordinated 1,3-diaza-1,3-dienes.14
We have now focused our attention on the addition of
alcohols to (organonitrile)Pt(IV) species leading to formation
of imino ester complexes. Our aim was to clarify the effects
of the oxidation state of the platinum center upon the
coupling reaction by comparing our results with those already
reported for appropriate platinum(II) systems.15,16 Interest in
the chemistry of platinum complexes with imino esters stems
also from the discovery, by one of us, that some of these
complexes break the rule of higher antitumor activity
expected for cis than for trans isomers.17 Moreover, we have
recently found an efficient method18 for the reduction of
platinum(IV) complexes to the corresponding platinum(II)
species, in nonaqueous media, and our idea was to extend
the reduction to imino ester complexes and to verify if there
could be any advantage in the preparation of biologically
relevant (imino ester)Pt(II) compounds starting from the
platinum(IV) rather than from the platinum(II) nitrile com-
plexes.
We have found that, in contrast to platinum(II) systems,
addition of R′OH to organonitrile platinum(IV) complexes
occurs under mild conditions and does not require a base as
a catalyst. The formed isomerically pure (imino ester)Pt-
(IV) complexes can be reduced selectively, by Ph3PdCHCO2-
Me, to the corresponding isomers of (imino ester)Pt(II)
species without change in configuration of the imino ester
ligands. Furthemore, the imino esters can be liberated from
both platinum(IV) and platinum(II) complexes. All of these
results, along with theoretical studies on relative stabilities
