H. Abe et al. / Tetrahedron: Asymmetry 13 (2002) 1519–1527
1525
3.13. Methyl (1S,5S,6S)-6-(tert-butyldiphenylsilyloxy-
0.638 mmol) in DMF (3 ml) at 0°C. The mixture was
stirred for 1 h at room temperature, poured into water,
extracted with hexane. The organic layer was washed
with brine, dried over magnesium sulfate and evapo-
rated to give a residue, which was subjected to silica gel
column chromatography with ethyl acetate–hexane
(1:40) to afford 24 (155 mg, 98%). For an analytical
sample, recrystallization from hexane was carried out to
afford colorless prisms, mp 74–75°C. IR (KBr) cm−1:
methyl)bicyclo[3.1.0]hex-2-ene-3-carboxylate, 22
A mixture of palladium(II) acetate (4.6 mg, 0.0203
mmol), triphenylphosphine (10.6 mg, 0.0404 mmol),
(−)-21 (335 mg, 0.675 mmol), triethylamine (188 ml, 1.35
mmol), methanol (1.09 ml, 27.0 mmol) and DMF (N,
N-dimethylformamide) (5 ml) was stirred for 24 h at
room temperature under a carbon monoxide atmo-
sphere. After addition of water, the mixture was
extracted with ether. The organic layer was washed
with water, dried over magnesium sulfate and evapo-
rated to give a residue. Silica gel column chromatogra-
phy with ethyl acetate–hexane (1:15) gave 22 as a
colorless oil (197 mg, 72%). IR (neat) cm−1: 1718
1
1111 (C-O). H NMR (200 MHz, CDCl3) l: 1.02 (18H,
s), 1.12–1.33 (1H, m), 1.59–1.71 (1H, m), 1.92 (1H, d,
J=17.6), 1.96–2.04 (1H, m), 2.48 (1H, dd, J=8.0,
17.6), 3.50 (2H, d, J=7.4), 3.95 (2H, s), 5.42 (1H, s),
7.28–7.42 (12H, m), 7.62–7.68 (8H, m). 13C NMR (50
MHz, CDCl3) l: 19.23, 19.35, 23.61, 26.80, 26.89,
27.92, 31.99, 58.60, 62.26, 123.10, 127.47, 127.61,
129.39, 129.56, 133.76, 134.21, 134.26, 135.51, 135.59,
144.29. [h]1D8 −60.5 (c 1.20, CHCl3) [82% ee]. Anal. calcd
for C40H48O2Si2: C, 77.87; H, 7.84. Found: C, 78.04; H,
7.84%. The ee was determined by HPLC analysis with
a chiral column (Daicel CHIRALCEL OD); eluent,
hexane; flow rate, 0.5 ml/min; tR=19.3 and 22.4 min.
1
(CꢁO), 1243 (C-O), 1104 (C-O). H NMR (200 MHz,
CDCl3) l: 1.03 (9H, s), 1.46 (1H, dddd, J=6.4, 7.8, 8.0,
8.2), 1.81 (1H, qd, J=8.0, 1.4), 2.08–2.18 (1H, m), 2.35
(1H, ddd, J=1.4, 2.0, 18.8), 2.67 (1H, ddd, J=2.0, 8.0,
18.8), 3.40 (1H, dd, J=8.2, 11.2), 3.56 (1H, dd, J=6.4,
11.2), 3.68 (3H, s), 6.62 (1H, q, J=2.0), 7.32–7.42 (6H,
m), 7.60–7.68 (4H, m). 13C NMR (50 MHz, CDCl3) l:
19.15, 21.40, 24.26, 26.79, 29.18, 31.04, 51.21, 57.83,
127.55, 129.48, 133.84, 133.88, 135.20, 135.54, 142.31,
164.82, 165.26. [h]2D2 −110.8 (c 1.27, CHCl3) [77% ee].
The ee was determined by HPLC analysis with a chiral
column (Daicel CHIRALCEL OD); eluent, isopropyl
alcohol–hexane (1:300); flow rate, 0.5 ml/min; tR=16.2
and 18.8 min.
3.16. (1R,2R,3S,5R,6S)-3,6-Bis(tert-butyldiphenylsilyl-
oxymethyl)bicyclo[3.1.0]hexan-2-ol, (+)-25
A solution of 24 (54.2 mg, 87.8 mmol) in THF (3 ml)
was added to a mixture of 9-BBN (0.5 M in THF, 526
ml, 0.263 mmol) and THF (2 ml). The mixture was
heated under reflux for 30 min, and cooled to 0°C.
Ethanol (0.3 ml), 3 M sodium hydroxide aqueous solu-
tion (0.2 ml) and 31% hydrogen peroxide aqueous
solution (0.2 ml) were successively added to the reac-
tion mixture. The mixture was heated under reflux for 1
h, poured into water, and extracted with ether. The
organic layer was dried over magnesium sulfate and
evaporated to give a residue. Silica gel column chro-
matography with ethyl acetate–hexane (1:8) gave (+)-25
as a colorless oil (31.0 mg, 56%). IR (neat) cm−1: 3391
3.14. (1S,5S,6S)-6-(tert-Butyldiphenylsilyloxymethyl)-3-
(hydroxymethyl)bicyclo[3.1.0]hex-2-ene, 23
DIBAL (1.0 M in toluene, 788 ml, 0.788 mmol) was
added dropwise to a solution of 22 (160 mg, 0.394
mmol) in toluene (5 ml) at −78°C, and the mixture was
allowed to warm to room temperature. After stirring
for 30 min, 10% sodium hydroxide aqueous solution
was added at 0°C, and the resulting mixture was stirred
for 5 min. The mixture was extracted with ether,
washed with brine, dried over magnesium sulfate and
evaporated. Purification by silica gel column chro-
matography with ethyl acetate–hexane (1:6) gave 23 as
a colorless oil (120 mg, 81%). IR (neat) cm−1: 3339
1
(-OH), 1112 (C-O). H NMR (500 MHz, CDCl3) l:
0.76 (1H, ddd, J=2.5, 11.0, 14.0), 1.02 (9H, s), 1.03
(9H, s), 1.20–1.27 (1H, m), 1.47 (1H, t, J=8.5), 1.55–
1.61 (1H, m), 1.85 (1H, ddd, J=7.5, 10.5, 14.0), 2.17
(1H, bs), 2.53–2.57 (1H, m), 3.26 (1H, t, J=9.5), 3.44–
3.48 (2H, m), 3.70–3.73 (2H, m), 7.27–7.42 (12H, m),
7.59–7.66 (8H, m). 13C NMR (125 MHz, CDCl3) l:
19.04, 19.19, 21.81, 24.49, 24.58, 26.85, 29.76, 59.78,
60.33, 65.02, 75.95, 127.53, 127.56, 127.73, 129.55,
129.75, 133.19, 133.21, 133.91, 133.94, 135.49, 135.60.
[h]2D2 +15.1 (c 1.44, CHCl3) [84% ee]. Anal. calcd for
C40H50O3Si2: C, 75.66; H, 7.94. Found: C, 75.65; H,
7.77%. The ee was determined by HPLC analysis with
a chiral column (Daicel CHIRALCEL OD); eluent,
isopropyl alcohol–hexane (1:200); flow rate, 0.5 ml/min;
tR=30.6 and 35.0 min.
1
(-OH), 1112 (C-O). H NMR (500 MHz, CDCl3) l:
1.04 (9H, s), 1.26–1.31 (1H, m), 1.65–1.70 (1H, m), 1.97
(1H, bd, J=17.5 Hz), 1.99–2.02 (1H, m), 2.43 (1H, dd,
J=8.0, 17.5), 3.40 (1H, dd, J=8.0, 11.0), 3.58 (1H, dd,
J=6.5, 11.0), 3.85 (2H, s), 5.35–5.36 (1H, m), 7.36–7.44
(6H, m), 7.66–7.68 (4H, m). 13C NMR (50 MHz,
CDCl3) l: 19.17, 19.38, 23.35, 26.83, 27.89, 31.89,
58.35, 61.07, 123.99, 127.45, 127.52, 129.50, 134.11,
135.61, 135.65, 144.59. [h]1D8 −109.3 (c 1.50, CHCl3)
[77% ee]. The ee was determined by HPLC analysis
with a chiral column (Daicel CHIRALCEL OD); elu-
ent, isopropyl alcohol–hexane (1:20); flow rate, 0.5 ml/
min; tR=12.9 and 14.0 min.
3.17. (1S,2S,3R,5S,6R)-2-Benzyloxy-3,6-bis(hydroxy-
methyl)bicyclo[3.1.0]hexane, 26
3.15. (1S,5S,6S)-3,6-Bis(tert-butyldiphenylsilyl-
oxymethyl)bicyclo[3.1.0]hex-2-ene, 24
DIBAL (1.0 M in toluene, 4.30 ml, 4.3 mmol) was
added dropwise to a solution of 6 (257 mg, 0.845 mmol)
in toluene (1 ml) at −78°C, and the mixture was allowed
to warm to room temperature. After stirring for 1 h,
TBDPSCl (80 ml, 0.308 mmol) was added to a solution
of 23 (96.4 mg, 0.255 mmol) and imidazole (43.4 mg,
