S. Sengupta, S. Mondal / Tetrahedron 58 (2002) 7983–7986
7985
NMR spectra were recorded in CDCl3 on a BRUCKER
AVANCE 300 (75 MHz) instrument. Optical rotations were
measured on a JASCO DIP-360 polarimeter. Elemental
analyses were performed at the Indian Association for the
Cultivation of Science. All reactions were carried out under
a nitrogen atmosphere. Reactions were monitored by thin
layer chromatography (TLC) on glass plates precoated with
silica gel G (Tara Chemicals). Compounds were visualized
by staining with iodine or warming on a hot plate after
spraying with aqueous H2SO4. Column chromatography
was performed on silica gel (60–120 mesh, Tara Chemi-
cals). Light petroleum refers to the fraction boiling at 60–
808C range. The a-amino diazoketone 5 was prepared from
L-alanine (4) according to the method of Ye and
McKervey.11
petroleum) to give 7b (0.23 g, 86%) as a colorless oil;
[Found: C, 60.12; H, 8.32; N, 4.75%; C15H25NO5 requires:
C, 60.18; H, 8.42 and N, 4.68%]; [a]2D0¼22.0 (c 1.0,
CHCl3); nmax (neat) 3350, 2920, 1710, 1650, 1500, 1440,
1360, 1250, 1145 cm21; dH (300 MHz, CDCl3) 1.28 (t, 3H,
J¼7.5 Hz, CH3CH2O–), 1.32 (d, 3H, J¼7.3 Hz, Me ), 1.44
(s, 9H, C(CH3)3), 2.40–2.80 (m, 4H, CO–CH2CH2–
CHv), 4.18 (q, 2H, J¼7.1 Hz, CH3CH2O–), 4.21–4.33
(m, 1H, NCHMe), 5.10 (br s, 1H, NH), 5.84 (d, 1H,
J¼15.6 Hz, CHvCH–CO2Et), 6.91 (dt, 1H, J¼6.6,
15.6 Hz, CH2–CHvCH); dC (75 MHz, CDCl3) 14.2, 17.6,
25.7, 28.3, 37.1, 55.0, 60.2, 79.8, 122.3, 146.6, 155.4, 166.3,
208.0.
1.1.3. (6R,7S )-Ethyl 6-acetoxy-7-(t-butyloxycarbonyl-
amino)oct-2-enoate (8). NaBH4 (0.02 g, 0.6 mmol) was
added to a solution of 7b (0.15 g, 0.5 mmol) in MeOH
(5 ml) at 2508C. After 15 min, the reaction was quenched
with brine and the whole extracted with CH2Cl2. The
organic layer was dried (Na2SO4) and the solvent removed
under reduced pressure to give the hydroxy ester. The latter
was dissolved in CH2Cl2 (3 ml) and was treated with Ac2O
(0.06 g, 0.06 ml, 0.06 mmol), Et3N (0.06 g, 0.6 mmol) and a
catalytic amount of DMAP at room temperature. After
completion of the reaction (ca. 3 h), more CH2Cl2 (10 ml)
was added and the whole washed with water. The organic
layer was dried (Na2SO4) and the solvent removed under
reduced pressure. The residue was purified by column
chromatography over silica gel (30% EtOAc in light
petroleum) to give 8 (0.15 g, 83%) as a colorless oil;
[Found: C, 59.42; H, 8.55; N, 4.14%; C17H29NO6 requires:
C, 59.46; H, 8.51 and N, 4.08%]; [a]2D0¼24.2 (c 1.0,
CHCl3); nmax (neat) 3340, 2970, 1700 (br), 1500, 1450,
1360, 1240 cm21; dH (300 MHz, CDCl3) 1.10 (d, 3H,
J¼6.9 Hz, Me ), 1.28 (t, 3H, J¼7.2 Hz, CH3CH2O–), 1.44
(s, 9H, C(CH3)3), 1.65–1.77 (m, 2H, CH2–CH2–CHv),
2.07 (s, 3H, COCH3), 2.17–2.31 (m, 2H, CH2–CH2–
CHv), 3.86 (m, 1H, NCHMe), 4.18 (q, 2H, J¼7.2 Hz,
CH3CH2O–), 4.58 (br s, 1H, NH), 4.84–4.89 (m, 1H, CH–
OCO), 5.82 (d, 1H, J¼15.6 Hz, CHvCH–CO2Et), 6.92 (dt,
1H, J¼6.9, 15.6 Hz, CH2–CHvCH); dC (75 MHz, CDCl3)
14.2, 15.6, 18.5, 21.0, 28.3, 48.3, 60.2, 75.7, 80.2, 121.9,
147.5, 155.1, 166.4, 170.3.
1.1.1. (S )-3-(t-Butyloxycarbonylamino)-1-( p-toluenesul-
fonyl)butan-2-one (6). 47% HBr (0.3 ml, 6.0 mmol) was
added dropwise to a solution of the a-amino diazoketone 511
(0.60 g, 2.8 mmol) in ether (15 ml) at 08C. After 30 min, the
reaction was neutralized with satd NaHCO3 solution and the
ether layer was separated. It was washed with water, dried
(Na2SO4) and the solvent removed in vacuo to give the
corresponding a-bromo ketone. The latter was dissolved in
DMF (5 ml) and NaSO2Tol (0.55 g, 3.1 mmol) was added to
it at room temperature. After 30 min, the reaction was
diluted with CH2Cl2 (10 ml) and washed with water. The
organic layer was dried (Na2SO4) and evaporated in vacuo.
The residue was purified by column chromatography over
silica gel (30% EtOAc in light petroleum) to give 6 (0.67 g,
70%) as a white crystalline solid; mp 121–1228C (ether–
light petroleum); [Found: C, 56.24; H, 6.80; N, 4.05%;
C16H23NO5S requires: C, 56.28; H, 6.80 and N, 4.10%];
[a]2D0¼21.8 (c 1.8, CHCl3); nmax (CHCl3) 3420, 2980,
1700, 1590, 1490, 1445, 1360, 1320, 1220, 1150 cm21; dH
(300 MHz, CDCl3) 1.24 (d, 3H, J¼8.0 Hz, Me ), 1.44 (s, 9H,
C(CH3)3), 2.45 (s, 3H, Ph-Me ), 4.21 (d, 1H, J¼13.8 Hz,
NCH–CH–SO2), 4.29–4.36 (m, 1H, NCHMe–), 4.42 (d,
1H, J¼13.8 Hz, NCH–CH–SO2), 5.18 (br s, 1H, NH ), 7.36
(d, 2H, J¼8.0 Hz, Ph), 7.77 (d, 2H, J¼8.1 Hz, Ph); dC
(75 MHz, CDCl3) 16.3, 21.6, 28.2, 56.0, 63.3, 80.4, 128.4,
129.9, 135.9, 145.4, 155.2, 198.4.
1.1.2. (S )-Ethyl 7-(t-butyloxycarbonylamino)-6-oxooct-
2-enoate (7b). Ethyl g-bromocrotonate (0.17 g, 0.87 mmol)
was added to a mixture of the g-amino-b-keto sulfone 6
(0.30 g, 0.87 mmol) and K2CO3 (0.13 g, 0.96 mmol) in
DMF (3 ml) at room temperature and the mixture stirred for
5 h. It was then acidified with dil. HCl and diluted with
CH2Cl2 (15 ml). The aqueous layer was separated and the
organic layer was washed with water and dried (Na2SO4).
Removal of solvent under reduced pressure followed by
column chromatography over silica gel (20% EtOAc in light
petrioleum) gave the a-alkylated g-amino-b-keto sulfone
(7a) as a 50:50 diastereomeric mixture (by NMR). Freshly
prepared Al(Hg) (from aluminum foil (0.3 g) and 2%
aqueous HgCl2 solution] was added to a solution of 7a in
THF–H2O (9:1, 7 ml) and the mixture heated under reflux
for 6 h. The reaction mixture was filtered, washed with THF
and the filtrate diluted with CH2Cl2 (10 ml). It was washed
with water, dried (Na2SO4) and the solvent removed under
reduced pressure. The residue was purified by column
chromatography over silica gel (20% EtOAc in light
1.1.4. 3-Acetoxy-6-ethoxycarbonylmethyl-2-methyl-
piperidine (10a,b). Trifluoroacetic acid (0.40 g, 0.25 ml,
3.48 mmol) was added to a solution of 8 (0.10 g,
0.29 mmol) in CH2Cl2 (2 ml) at 08C and the solution stirred
at room temperature for 1 h. All volatiles were then
removed under reduced pressure and the residue was
redissolved in CH2Cl2 (3 ml). Excess Et3N (0.15 g, 0.2 ml,
1.45 mmol) was added to it and the mixture stirred
overnight at room temperature. The reaction was then
diluted with CH2Cl2 (10 ml) and washed with water. The
organic layer was dried (Na2SO4) and the solvent removed
under reduced pressure. The residue was purified by column
chromatography over silica gel (30–50% EtOAc in light
petroleum) to give the cyclized products 10a and b.
10a (0.024 g, 34%); mp 52–538C (EtOAc–light
petroleum); [Found: C, 59.40, H, 8.59, N, 5.82%;
C12H21NO4 requires: C, 59.24, H, 8.70 and N, 5.76%];
[a ]2D0¼26.9 (c 0.5, CHCl3); nmax (CHCl3) 3320, 2940,
