Solid phase synthesis of benzothiazolyl compounds

Article abstract of DOI:10.1016/S0040-4039(01)00109-5

2-Aminobenzenethiol, bound through its thiol function to the 2-chlorotrityl (Clt)-, trityl (Trt)-, 4-methyltrityl (Mtt)- and 4-methoxytrityl (Mmt)-resins, was acylated at the amino-function by aliphatic and aromatic acids. The obtained 2-N-acyl-aminobenzenethiols were cleaved from the resin by treatment with trifluoroacetic acid solutions in dichloromethane. The 2-N-acyl-aminobenzenethiols released from the resin were cyclised to the corresponding 2-substituted benzothiazoles, by standing in a solution of dithiothreitol in DMF or methanol for 1-3 h at room temperature.

Full text of DOI:10.1016/S0040-4039(01)00109-5

TETRAHEDRON
LETTERS
Pergamon
Tetrahedron Letters 42 (2001) 2201–2204
Solid phase synthesis of benzothiazolyl compounds
Spyros Mourtas, Dimitrios Gatos and Kleomenis Barlos*
Department of Chemistry, University of Patras, Patras, Greece
Received 25 April 2000; revised 4 January 2001; accepted 17 January 2001
Abstract—2-Aminobenzenethiol, bound through its thiol function to the 2-chlorotrityl (Clt)-, trityl (Trt)-, 4-methyltrityl (Mtt)-
and 4-methoxytrityl (Mmt)-resins, was acylated at the amino-function by aliphatic and aromatic acids. The obtained 2-N-acyl-
aminobenzenethiols were cleaved from the resin by treatment with trifluoroacetic acid solutions in dichloromethane. The
2-N-acyl-aminobenzenethiols released from the resin were cyclised to the corresponding 2-substituted benzothiazoles, by standing
in a solution of dithiothreitol in DMF or methanol for 1–3 h at room temperature. © 2001 Elsevier Science Ltd. All rights
reserved.
The benzothiazolyl-moiety is a structural element of
compounds with potent and selective antitumour activ-
ity,1–3 of wide spectrum Ca2+ channel antagonists4 and
of inhibitors of several enzymes such as monoamine
torial methods. We studied this possibility using
2-aminobenzenethiol 1 (Scheme 1) as the model starting
material.
oxidase
(MAO),5–8
lipoxygenase,9
acetylcholin-
For comparison to SPS, we reacted 1 with an equimo-
lar amount of benzoyl- and acetyl chloride and diiso-
propylethylamine (DIPEA) in dimethylformamide
(DMF). HPLC-analysis (Fig. 1a) of the reaction mix-
tures showed, besides the expected benzothiazole 2 and
minor byproducts, the formation of the azoxybenzene
derivative 3, as the main reaction product. Both were
identified by ES-MS (Fig. 1b: 2b, m/z=212.02 [M+H]+;
Fig. 1c: 3b, m/z=471.28 [M+H]+).
esterase,10 thrombin,11 of collagenase and neutral
proteases,12 of aldose reductase,13,14 of H+–K+
ATPase15 and of carbonic anhydrase.16
Benzothiazoles are synthesised in solution by the con-
densation of ortho-amino thiophenols with carboxylic
acid derivatives,17 the radical cyclisation of
thioacylbenzanilides18,19 or the base induced cyclisation
of the corresponding ortho-haloanilides.18–20 These
methods are performed under conditions not appropri-
ate for solid phase synthesis (SPS) and give in several
cases complex product mixtures. A SPS of benzothia-
zolyl compounds carried out under mild conditions
would therefore simplify the discovery of new pharma-
cologically interesting structures, by applying combina-
To suppress these side reactions, the thiol function of 1
should be protected. Groups of the trityl-type, which
are removed by mild acidolysis are suitable thiol pro-
tecting groups, as shown in the case of the protection of
cysteine during peptide synthesis.21 The corresponding,
commercially available, trityl-type resins 422–24 (Scheme
2) are, in addition, suitable solid supports for thiols.25
Scheme 1.
Keywords: benzothiazoles; benzothiazole equivalent; solid phase synthesis; trityl resin.
* Corresponding author.
0040-4039/01/$ - see front matter © 2001 Elsevier Science Ltd. All rights reserved.
PII: S0040-4039(01)00109-5

2202
S. Mourtas et al. / Tetrahedron Letters 42 (2001) 2201–2204
Figure 1. (a) Analytical HPLC of the crude mixture obtained after the reaction of benzoyl chloride with 1 in DMF; Column:
Lichrospher RP-8, 5 mm; 4×250 mm; gradient: from 20 to 100% acetonitrile in water within 30 min; flow rate 1 ml/min; detection
at 265 nm; (b) ES-MS of the component A; (c) ES-MS of the component B.
Scheme 2.
To achieve the SPS of 2-benzothiazolyl compounds and
to suppress simultaneously the above side reactions
taking place in solution, we tested the resins 4 for the
attachment of 1 on solid phase. In fact, treatment of the
resin-chlorides with an equimolar amount of the thiol 1
and 0.7 equivalents of diisopropylethylamine (DIPEA)
in dichloromethane (DCM) for 0.5–4 h at rt, led to the
corresponding resins 5. Under these conditions, attach-
ment of 1 through its amine function onto the resin is
not possible. The remaining unreacted trityl chloride
was converted to the corresponding trityl-methyl ether,
by washing the resin with a mixture of DCM/methanol/
DIPEA (85:10:5). The loading of the resins obtained
was determined by sulfur analysis. We observed highest
attachment rates in the case of 4d. That affords the
resin 5d, within 30 min with a loading of 0.7–0.8 mmol
1/g. In contrast, 4a gave at the same time resins with a
loading of 0.3–0.4 mmol/g.
The acid stability of the thioether bond in 1 to the
various resins was tested by treating 5 with trifluo-
roacetic acid (TFA) solutions in DCM. The cleavage is
reversible and triethylsilane (TES) was added for scav-
enging the trityl-cations formed on the resin during
cleavage. As expected, the acid sensitivity increases
considerably from 5a to 5d. Thus, a 3×5 min treatment
of the resins with 65, 50, 15 and 1.1% TFA, respectively
in DCM/TES (95:5), led to 88, 90, 95 and 100% cleav-
age of 1 from the corresponding resin, while in the
absence of TES the cleavage yield dropped to 27, 48, 64
and 100%.
Resins 5 were then acylated with a threefold molar
excess of acyl- or aroyl chloride and DIPEA in DMF
for 3–4 h at rt. The acylation of 5 was also performed
using the acid anhydrides. Complete acylation (Scheme
2) in addition was achieved using several aliphatic and

S. Mourtas et al. / Tetrahedron Letters 42 (2001) 2201–2204
2203
Figure 2. (a) Analytical HPLC of the solution obtained during the cleavage of 7b from the 4-methoxy-trityl resin, by treatment
with 1.1% TFA (conditions as in Fig. 1); (b) ES-MS of component C; (c) HPLC-analysis of crude 7b after treatment with DTT.
Figure 3.
aromatic acids activated in situ with diisopropylcar-
bodiimide (DIC). 1-Hydroxybenzotriazole, frequently
used as an additive in peptide synthesis, led to slower
and in most cases incomplete acylations in this case.
The products 6 obtained were then treated with the
appropriate TFA solutions (see above) in order to
cleave the benzenethiols 7a–j from the various resins.
A sample of the mixtures obtained was concentrated
under a stream of nitrogen, and analysed by HPLC
(Fig. 2a shows the HPLC analysis of the mixture
obtained during the cleavage of 7b from the 4-methoxy-
Figure 4. (a) Analytical HPLC (conditions as in Fig. 1); (b)
ES-MS of crude 12.
trityl resin by treatment with 1.1% TFA). The individ-
ual components A–C were collected and subjected to
ES-MS analysis, after standing for 3 h at rt. Surpris-
ingly both components A and B showed identical
molecular masses, which corresponds to the benzothia-
zolyl compound 2b and C corresponds (Fig. 2b: 8b,
m/z=457.3 [M+H]+) to the oxidised dimer 8b. Azoxy-
benzene derivatives as 3b were not detected. We con-
so much favoured, that even the haloalkyl- and car-
boxy-derivatives 9–11 (Fig. 3), which can be considered
as precursors of various benzothiazolyl compounds,
gave the corresponding benzothiazoles in 90–95%
purity (Fig. 4a shows the HPLC-analysis of the reaction
mixture and Fig. 4b the ES-MS-analysis of the main
product obtained after the conversion of 11 to the
methylester of 2-benzothiazolylcarboxylic acid 12).
cluded that component
A
corresponds to the
acyl-derivative 7b. This cyclises spontaneously to the
corresponding benzothiazole by standing in the acetoni-
trile/water mixture used for their HPLC-elution. To
reduce the disulfide 8b, dithiothreitol (DTT) was added
to the solution. Indeed, we observed that 8b was con-
verted to 7b and 2b and the latter was the only product
(Fig. 2c: 2b) of the reaction after standing for 2–3 h at
rt. In all cases tested, the acylation of 5 with various
acids proceeded very similarly to that of the benzoyla-
tion reaction. These observations led to the develop-
ment of an improved protocol26 for the SPS, in 80–90%
yield, of several 2-alkyl- and aryl-benzothiazoles 2 in
90–97% purity. The ring closure reaction from 7 to 2 is
References
1. Bradshaw, T. D.; Wrigley, S.; Shi, D.-F.; Schulz, R. J.;
Paull, K. D.; Stevens, M. F. G. Brit. J. Cancer. 1998, 77,
745–752.
2. Kashiyama, E.; Hutchinson, I.; Chua, M. S.; Stinson, S.
F.; Phillips, L. R.; Kaur, G.; Sausville, E. A.; Bradshaw,
T. D.; Westwell, A. D.; Stevens, M. F. G. J. Med. Chem.
1999, 42, 4172–4184.

2204
S. Mourtas et al. / Tetrahedron Letters 42 (2001) 2201–2204
3. Hall, I. H.; Peaty, N. J.; Henry, J. R.; Easmon, J.;
18. Hutchinson, I.; Stevens, M. F. G.; Westwell, A. D.
Tetrahedron Lett. 2000, 41, 425–428.
19. Spitulnik, M. J. Synthesis 1976, 730–731.
Heinisch, G.; Purstinger, G. Arch. Pharm. 1999, 332,
115–123.
4. Lara, B.; Gandia, L.; Torres, A.; Martinez-Sierra, R.;
Garcia, A. G.; Lopez, M. G. Eur. J. Pharmacol. 1997,
325, 109–119.
5. Sato, G.; Chimoto, T.; Aoki, T.; Hosokawa, S.;
Sumigama, S.; Tsukidate, K.; Sagami, F. J. Toxicol. Sci.
1999, 24, 165–175.
6. Naitoh, T.; Kawaguchi, S.; Kakiki, M.; Ohe, H.; Kaji-
wara, A.; Horie, T. Xenobiotica 1998, 28, 269–280.
7. Naitoh, T.; Mishima, M.; Kawaguchi, S.; Matsui, K.;
Andoh, T.; Kagei, K.; Kakiki, M.; Yuzuriha, T.; Horie,
T. Xenobiotica 1997, 27, 1053–1070.
8. Kagaya, T.; Kajiwara, A.; Nagato, S.; Akasaka, K.;
Kubota, A. J. Pharmacol. Exp. Ther. 1996, 278, 243–251.
9. Hadjipavlou-Litina, D. J.; Geronikaki, A. A. Drug Des.
Discov. 1997, 15, 199–206.
20. Roe, A.; Tucker, W. P. J. Heterocycl. Chem. 1965, 2,
148–151.
21. Fre´chet, J. M. J.; Maque, K. E. Tetrahedron Lett. 1975,
3055–3058.
22. Barlos, K.; Gatos, D.; Hatzi, O.; Koch, N.; Koutso-
gianni, S. Int. J. Pept. Protein Res. 1996, 47, 148–153.
23. Barlos, K.; Gatos, D.; Kallitsis, J.; Papaphotiou, G.;
Sotiriou, P.; Wenqing, Y.; Scha¨fer, W. Tetrahedron Lett.
1989, 30, 3943–3946.
24. Barlos, K.; Gatos, D.; Chatzi, O. In Peptides 1992;
Proceedings of the Twenty-Second European Peptide
Symposium; Schneider, C. H.; Eberle, A. N., Eds.;
ESCOM: Leiden, 1993; pp. 281–282.
25. Publication in preparation.
26. General procedure for the solid phase synthesis of 2-sub-
stituted benzothiazoles: 1 g resin-bound benzenethiol 5
with a loading of 0.74 mmol 1/g was suspended in 5–6 ml
DMF. Then, 2.1 mmol of the carboxylic acid and 2.2
mmol DIC were added and the mixture was shaken for 3
h at rt. The completion of the acylation reaction was
checked by cleaving the product from a sample of resin
and analysing by HPLC. In cases of uncompleted acyla-
tion, a second acylation was performed with the same
quantities. Then, the resin was filtered and washed with
5×10 ml DMF and 5×10 ml DCM. The resin still remain-
ing on the filter was then treated (2 min each) with 7×6
ml of 1.1% TFA in DCM/TES (95:5). The filtrates of the
seven treatments were concentrated in vacuum to an oily
residue and dissolved in 6–10 ml of DMF/methanol (9:1)
which contained 0.1–0.2 mmol DTT. After 3 h of stand-
ing at rt, the mixture was extracted with diethylether or
ethyl acetate, washed with water, dried and concentrated
in vacuum. Ether or n-hexane were then added and the
solid product 2 was filtered, washed with a mixture of
ether/hexane and dried. Yield: 80–90% 2b with purity,
determined by HPLC at 220–300 nm, varying from 90–
97%.
10. Nagel, A. A.; Liston, D. R.; Jung, S.; Mahar, M.; Vin-
cent, L. A.; Chapin, D.; Chen, Y. L.; Hubbard, S.; Ives,
J. L.; Jones, S. B. J. Med. Chem. 1995, 38, 1084–1089.
11. Matthews, J. H.; Krishnan, R.; Costanzo, M. J.;
Maryanoff, B. E.; Tulinsky, A. Biophys. J. 1996, 2830–
2839.
12. Caccese, R. G.; DiJoseph, J. F.; Scotnicki, J. S.; Borella,
L. E.; Adams, L. M. Agents Actions 1991, 34, 223–225.
13. Mylari, B. L.; Larson, E. R.; Beyer, T. A.; Zembrowski,
W. J.; Aldinger, C. E.; Dee, M. F.; Siegel, T. W.;
Singleton, D. H. J. Med. Chem. 1991, 34, 108–122.
14. Kotani, T.; Nagaki, Y.; Ishi, A.; Konishi, Y.; Yago, H.;
Suehiro, S.; Okukado, N.; Okamoto, K. J. Med. Chem.
1997, 40, 684–694.
15. Sohn, S. K.; Chang, M. S.; Choi, W. S.; Kim, K. B.;
Woo, T. W.; Lee, S. B.; Chung, Y. K. Can. J. Physiol.
Pharmacol. 1999, 77, 330–338.
16. Sugrue, M. F.; Gautheron, P.; Schmitt, C.; Viader, M. P.;
Conquet, P.; Smith, R. L.; Share, N. N.; Stone, C. A. J.
Pharmacol. Exp. Ther. 1985, 232, 534–540.
17. Ben-Alloum, A.; Bakkas, S.; Soufiaoui, M. Tetrahedron
Lett. 1997, 38, 6395–6396.
.
.
