Hydroacylation of Olefins with Salicylaldehyde
TABLE 3. Rh-Catalyzed Hydroacylation between Salicylaldehyde
and Various Olefins 16-24 in the Presence of MeCN
between salicylaldehyde 1 and monoolefins such as 1-hexene
and 1-octene smoothly proceeded to give the normal- and iso-
hydroacylated products 29 and 30 in a ratio of >20 to 1, in
86% and 82% yields, respectively. The ratio of normal- and
iso-products (>20:1) was almost the same as that of alkenylni-
triles (entries 3-10 in Table 1) and that of 1,7-octadiene (entry
3 in Table 3). Therefore, these reactions might proceed via the
same reaction pathway. The hydroacylation of 3,3-dimethylbut-
1-ene 22, which is a tert-butyl ethylene, also proceeded at room
temperature, and the normal-hydroacylated product 31 was
exclusively obtained in 82% yield (entry 7). Unfortunately, the
hydroacylation of disubstituted olefins or internal olefins did
not proceed, or proceeded just in trace amount. It should be
noted that the reaction was tolerant of protected amine, and thus
the hydroacylation of allyl amine 23 proceeded to give normal-
hydroacylated product 32 in 53% yield (entry 8). Under the
same reaction conditions, the hydroacylation of 1-hexyne 24
was completed within 1 h at room temperature, while the
reported reaction conditions require 2 h and the rigorous
condition of refluxing in toluene.2
Mechanistic Consideration of the Nitrile-Promoted Rh-
Catalyzed Hydroacylation. The detailed reaction mechanism
for the influence of nitriles is not clear. It has already been
reported that nitrile could be exchanged for the phosphine ligand
in the Rh-complex, or additionally coordinate to the transition
metal-complex.8 We measured a liquid-phase IR spectrum of
RhCl(PPh3)3 (1.0 equiv), MeCN (1.0 equiv), and salicylaldehyde
(1.0 equiv) in CH2Cl2 solution. The IR spectrum indicated an
increase of the CN stretching frequency; that is, the absorption
observed at 2256 cm-1 (νCN) in the free MeCN was shifted to
absorption at 2356 cm-1 (νCN).10 These results suggested that
the use of MeCN as an outer ligand would change the property
of the Rh-complex by coordination and might promote the
hydroacylation reaction.
The regio-selectivity, that is, iso- and normal-selectivity of
the products, could be explained on the basis of Rh-aldehyde-
olefin intermediates, albeit the real intermediates might consist
of nitrile, and the existence of the dinuclear Rh-complex may
play some important roles.11 The coordination of monoolefin
and salicylaldehyde would afford two plausible intermediates
(a) and (b), as shown in Figure 1. Transfer of the hydrogen
from the Rh-complex to the coordinated olefin might produce
alkylated Rh-intermediates (c) and (d). These intermediates (a-
d) may be interchangeable. Reductive elimination from inter-
mediate (c) affords the normal-hydroacylated product, whereas
that from intermediate (d) gives the iso-hydroacylated product.
Taking the thermodynamic stability of the intermediates into
consideration, intermediates (a) and (c) seem to be more
favorable than intermediates (b) and (d) because steric repulsion
exists in intermediates (b) and (d). Thus, the Rh-catalyzed
hydroacylation of monoolefins would preferentially afford the
normal-hydroacylated products. On the other hand, the hydro-
acylation of 1,5-hexadiene afforded the iso-hydroacylated
product as a major product. This may be attributed to the fact
that the 1,5-hexadiene-chelated Rh-intermediates (e) and (f),
which have only a minimal steric repulsion, may become
thermodynamically
a The reaction was carried out at room temperature using RhCl(PPh3)3
(0.4 equiv), NaOAc (0.4 equiv), and MeCN (6 equiv) in CH2Cl2 solution.
b 0.2 equiv of RhCl(PPh3)3 was used. c Isomer, which was acylated at the
C5-position of diene, was also formed. d The ratio was >20 (n):1 (i). e The
iso-hydroacylated product was not detected.
Effect of Nitrile on the Rh-Catalyzed Hydroacylation of
Various Olefins. Next, we checked the hydroacylation of
various olefins 16-23 with 1 using RhCl(PPh3)3 (0.20 or 0.40
equiv) in the presence of NaOAc (0.40 equiv) and MeCN (6.0
equiv) in CH2Cl2 solution. Table 3 summarizes the results. The
hydroacylation of 1,5-hexadienes 16 and 17 having a substituent
proceeded in 3-7 h at room temperature to produce the
hydroacylated products 25 and 26 in good yields (entries 1 and
2). The hydroacylation of 16 preferentially afforded the iso-
hydroacylated product 25b similarly to that in the absence of
MeCN,3a,b but that of 17 dominantly gave the normal-hydro-
acylated product 26a. The hydroacylation of 18 without MeCN
gave the product in merely 10-15% yield. In contrast, that under
the conditions of RhCl(PPh3)3 (0.40 equiv), NaOAc (0.40 equiv),
and MeCN (6.0 equiv) in CH2Cl2 solution afforded the normal-
and iso-hydroacylated products in a ratio of >20 to 1 in 73%
yield (entry 3). The reaction was tolerant of an ester functional
group. The hydroacylation of 1,6-diene 19 bearing a diester
smoothly proceeded to give normal-products 28 in 80% yield.
The iso-product was not detected at all (entry 4). The hydroa-
cylation of 19 could not proceed by use of RhCl(PPh3)3 only;
therefore, the addition of MeCN and NaOAc would enhance
the reactivity. These results suggested that the hydroacylation
of some 1,5- and 1,6-dienes in the presence of NaOAc and
MeCN may proceed via the diene-mono-coordinated intermedi-
ate, but not via the diene-chelated intermediate.
(10) Uson, R.; Oro, L. A.; Artigas, J.; Sariego, R. J. Organomet. Chem.
1979, 179, 65-72.
(11) (a) Colebrooke, S. A.; Duckett, S. B.; Lohman, J. A. B. Chem.
Commun. 2000, 685-686. (b) Gridnev, I. D.; Higashi, N.; Asakura, K.;
Imamoto, T. J. Am. Chem. Soc. 2000, 122, 7183-7194. (c) Aubry, D. A.;
Bridges, N. N.; Ezell, K.; Stanley, G. G. J. Am. Chem. Soc. 2003, 125,
11180-11181.
Thus, we tested the hydroacylation of various monoolefins,
which were not appropriate as the Rh-catalyzed-hydroacylation
substrate before. As expected, the Rh-catalyzed hydroacylation
J. Org. Chem, Vol. 72, No. 7, 2007 2545
