Tetrahedron
Scheme 3. Synthesis of C1-phospholipid, photocaged 3-N spirocyclopropene via a C1-acid containing cyclopropene.
ESI). For example, we attempted to install an alcohol using
oxirane or paraformaldehyde after treatment of the cyclopropene
with n-BuLi, but this produced only unreacted starting material.
We then explored the reaction with a tosyl-activated alcohol linked
to a dihydrooxazole-protected carboxylic acid. This reagent should
participate in base-mediated substitution of the tosylate at the
cyclopropene C1/C2, and the dihydrooxazole could be
subsequently hydrolysed to the carboxylic acid. However, our
attempts at nucleophilic substitution using n-BuLi produced a
mixture of unreacted starting material and oxazole decomposition.
Ultimately, of all electrophiles tested, the iodo-orthoformates were
the only electrophile that efficiently modified C1/C2 on the
cyclopropene, producing the orthoformate-modified cyclopropene
in high yield that quantitatively hydrolysed to the corresponding
ester upon silica gel chromatography, and, after saponification,
produced the racemic spirocyclopropene acid 16 (Scheme 2).
Importantly, employing the racemic compound 16 will produce a
mixture of diastereomers upon conjugation with biologically
active chiral lipids. However, the biological activity of lipids such
as the ceramides and phospholipids described below tolerates the
addition of structurally diverse tags, including large racemic trans-
cycloctenes33 and fluorophores.34
chloride/ruthenium-periodate conditions, so we proceeded with
ethyl trifluoroacetate protected analogs instead. We performed the
11–12 reaction sequence in one pot because our attempts to purify
the intermediates resulted in substantially lower overall yields due
to their decomposition on silica gel. Essentially, we converted
cyclic sulfate 11 to the sulfate ester-iodide using Bu4NI,
dehydrohalogentated the intermediate using DBU to produce the
sulfate alkene, and hydrolysed the sulfate under acidic conditions
to obtain 12 in 49% yield over three steps. Then, this N,O-bis
protected sphingosine 12 was TBDPS-deprotected using the
fluoride source Bu4NF to obtain a 23% yield of 13, which was
converted to the D-erythro-sphingosine 14 by base-mediated
hydrolysis in 82% yield.
The free amine sphingosine 14 was coupled to the 3-N
spirocyclopropene acid 16 using HATU to obtain the C1-ceramide
Boc-cyclopropene 17 in 76% yield. Finally, the lipidated-
cyclopropene was Boc-deprotected to obtain free amine C1-
ceramidated 3-N spirocyclopropene 18 in 22% yield. Importantly,
the low yields of 18 are due to difficulties inherent to the
purification of this charged lipid, not decomposition, because
similar cyclopropene scaffolds, including the Boc- and Nvoc-
protected variants of 18, have survived acidic HPLC and
deprotection conditions unscathed.26 Separately, the Nvoc
photocaged version was prepared directly without purifying the
Boc-deprotected intermediate 18 to obtain 19 in 89% yield over
two steps.
Finally, we explored lipidation of the carboxylic-acid-modified
cyclopropene C1 with two different classes of bioactive lipids:
ceramide and
a phospholipid. Ceramides are important
components of a eukaryotic cell lipidome. They make up
sphingomyelin, a major bilayer lipid, and control a variety of
cellular signaling processes.35,36 Consequently, functionalized
ceramides, such as a fluorophore-modified BODIPY-ceramide,
are employed for tracking the biological functions of ceramides in
the cell. Bioorthogonal chemistry-based applications include a
recently described trans-cyclooctene-containing ceramide analog
that Schepartz and co-workers used for super-resolution imaging
of the Golgi in living cells.33 The availability of a cyclopropene
analog of ceramide will further increase the available options for
bioorthogonal reagents that can be used to study ceramide
dynamics.
Like ceramides, phospholipids represent another important
class of biologically relevant lipids. The amphiphilic character of
phospholipids makes them a major component of the lipid bilayer
in the cell plasma membrane. The availability of a photocaged,
cyclopropene-containing phospholipid will permit its applications
as a bioorthogonal probe to study membrane biology. We installed
a commercially available phospholipid, 1,2-dioleoyl-sn-glycero-
3-phosphoethanolamine (18:1 (Δ9-cis) PE), at the C1 position of
cyclopropene 16 to obtain C1 phospholipidated 3-N
spirocyclopropene 20 in 21% yield, which, upon Boc deprotection,
afforded 21 in 40% yield. Similar to the photocaged ceramide
cyclopropene lipid, the Nvoc photocaged version 22 was prepared
without purifying the Boc-deprotected intermediate 21 to obtain
22 in 38% yield over two steps (Scheme 3). However, the amounts
obtained complicated our efforts at full spectroscopic
characterization other than HRMS due to the complexity of the
molecule, modest reaction yields, and high cost of the
phospholipid starting material.
To obtain a C1-ceramide containing spirocyclopropene we
started from D-ribo-phytosphingosine, a commercially available
reagent (Scheme 2, and Scheme S4, ESI). Ceramides are
sphingosines where the amine on the sphingosine contains
hydrophobic residues via an amide linkage. We converted D-ribo-
phytosphingosine to D-erythro-sphingosine using slight
modifications to the synthetic strategy reported by Kim and co-
workers.37 Briefly, the dual protection of the amine group on D-
ribo-phytosphingosine using ethyl trifluoroacetate to obtain 8, and
the primary alcohol with TBDPSCl to obtain 9 proceeded in
quantitative yield. Next, we converted 9 to cyclic sulfite 10 with
thionyl chloride. We found this cyclic sulfite to be unstable to
silica gel and overnight storage. Therefore, we subjected it
immediately to ruthenium-periodate oxidation to obtain the cyclic
sulfate 11 in 68% yield over two steps. Additionally, in our hands,
the trityl protected analogues were unstable to the required thionyl
In summary, we describe a method for the C1-lipidation of
cyclopropenes. We have generated two biologically relevant, C1-
lipidated cyclopropenes using an acid functionalized 3-N
spirocyclopropene scaffold. Both the C1-ceramide- and
phospholipid-linked spirocyclopropene represent the first
examples of cyclopropene modifications with biomolecules on the
alkenic C1/C2 position.
