Solution-Processible Conjugated Electrophosphorescent
Polymers
Albertus J. Sandee,† Charlotte K. Williams,† Nicholas R. Evans,† John E. Davies,†
Clare E. Boothby,‡ Anna Ko¨hler,‡ Richard H. Friend,‡ and Andrew B. Holmes*,†
Contribution from the MelVille Laboratory for Polymer Synthesis, Department of Chemistry,
UniVersity of Cambridge, Lensfield Road, Cambridge CB2 1EW, United Kingdom, and
CaVendish Laboratory, Department of Physics,
UniVersity of Cambridge, Madingley Road, Cambridge CB3 0HE, United Kingdom
Received November 5, 2003; E-mail: abh1@cam.ac.uk
Abstract: We report the synthesis and photophysical study of a series of solution-processible phospho-
rescent iridium complexes. These comprise bis-cyclometalated iridium units [Ir(ppy)2(acac)] or [Ir(btp)2-
(acac)] where ppy is 2-phenylpyridinato, btp is 2-(2′-benzo[b]thienyl)pyridinato, and acac is acetylacetonate.
The iridium units are covalently attached to and in conjugation with oligo(9,9-dioctylfluorenyl-2,7-diyl) [(FO)n]
to form complexes [Ir(ppy-(FO)n)2(acac)] or [Ir(btp-(FO)n)2(acac)], where the number of fluorene units, n, is
1, 2, 3, ∼10, ∼20, ∼30, or ∼40. All the complexes exhibit emission from a mixed triplet state in both
photoluminescence and electroluminescence, with efficient quenching of the fluorene singlet emission.
Short-chain complexes, 11-13, [Ir(ppy-(FO)n-FH)2(acac)] where n ) 0, 1, or 2, show green light emission,
red-shifted through the FO attachment by about 70 meV, but for longer chains there is quenching because
of the lower energy triplet state associated with polyfluorene. In contrast, polymer complexes 18-21 [Ir-
(btp-(FO)n)2(acac)] where n is 5-40 have better triplet energy level matching and can be used to provide
efficient red phosphorescent polymer light-emitting diodes, with a red shift due to the fluorene attachment
of about 50 meV. We contrast this small (50-70 meV) and short-range modification of the triplet energies
through extended conjugation, with the much more substantial evolution of the π-π* singlet transitions,
which saturate at about n ) 10. These covalently bound materials show improvements in efficiency over
simple blends and will form the basis of future investigations into energy-transfer processes occurring in
light-emitting diodes.
Introduction
In light-emitting diodes (LEDs), electrons and holes are
injected from opposite electrodes and combine to form spin-
singlet or spin-triplet excitons. Radiative decay from the singlets
is fast (fluorescence) whereas that from the triplets (phospho-
rescence) is formally forbidden by the requirement of spin
conservation. The inclusion of heavy metal atoms in the
molecular structure can give strong spin-orbit coupling which
renders phosphorescence partially allowed. Models of spin
statistics predict that the electron-hole recombination event
should produce three times as many triplets as singlets,5 and
this has been confirmed experimentally for electroluminescent
devices (OLEDs) fabricated from small molecules.6 For poly-
mers, there is growing evidence that the triplet-singlet ratio
can be as low as 1:17,8 and recent work on polyacetylides
containing heavy metal atoms incorporated into the backbone
has enabled a detailed study of singlet and triplet excited
states.9-12
The discovery of electroluminescence from conjugated poly-
mers has led to the development of and intense interest in the
field of polymer optoelectronics.1-3 The chemical synthesis,
photophysics, and material properties are of interest not only
as an academic curiosity but also as a commercial reality.
Luminescent conjugated polymers show real promise as the
active material in light-emitting display devices for the next
generation of information technology based consumer products.
The principle interest in the use of these polymers lies in the
scope for low-cost, large surface area manufacturing, facilitated
by solution-processing of film-forming materials.4 The wide-
spread commercialization of light-emitting polymers is depend-
ent on improving device efficiencies; this can be achieved both
by improvements in device engineering and by insights into
their fundamental chemistry and physics enabling design of
intrinsically more efficient materials.
† Melville Laboratory for Polymer Synthesis.
(5) Ko¨hler, A.; Wilson, J. S.; Friend, R. H. AdV. Mater. 2002, 14, 701-
707.
‡ Cavendish Laboratory.
(1) Burroughes, J. H.; Bradley, D. D. C.; Brown, A. R.; Marks, R. N.; Mackay,
K.; Friend, R. H.; Burn, P. L.; Holmes, A. B. Nature 1990, 347, 539-541.
(2) Kraft, A.; Grimsdale, A. C.; Holmes, A. B. Angew. Chem., Int. Ed. 1998,
37, 402-428.
(3) Braun, D.; Heeger, A. J. Appl. Phys. Lett. 1991, 58, 1982-1984.
(4) Friend, R. H.; Gymer, R. W.; Holmes, A. B.; Burroughes, J. H.; Marks, R.
N.; Taliani, C.; Bradley, D. D. C.; Dos Santos, D. A.; Bre´das, J. L.;
Lo¨gdlund, M.; Salaneck, W. R. Nature 1999, 397, 121-128.
(6) Baldo, M. A.; O’Brien, D. F.; Thompson, M. E.; Forrest, S. R. Phys. ReV.
B 1999, 60, 14422-14428.
(7) Wilson, J. S.; Dhoot, A. S.; Seeley, A. J. A. B.; Khan, M. S.; Ko¨hler, A.;
Friend, R. H. Nature 2001, 413, 828-831.
(8) Cao, Y.; Parker, I. D.; Yu, G.; Zhang, C.; Heeger, A. J. Nature 1999, 397,
414-417.
(9) Wittmann, H. F.; Friend, R. H.; Khan, M. S.; Lewis, J. J. Chem. Phys.
1994, 101, 2693-2698.
9
10.1021/ja039445o CCC: $27.50 © 2004 American Chemical Society
J. AM. CHEM. SOC. 2004, 126, 7041-7048
7041

A R T I C L E S
Sandee et al.
The energy of the non emissive triplet state in organic
compounds can be harvested by energy transfer to a phospho-
rescent dopant such as a lanthanide or heavy metal organome-
tallic complex. As early as 1990, Kido and colleagues described
an OLED employing [Tb(acac)3] as the phosphor and giving
green light emission,13 and Wittmann, et al.9 proposed the use
of platinum-containing poly-ynes both as semiconductor and
as triplet emitter. In 1998, Thompson and Forrest and their co-
workers published a seminal paper describing the use of
platinum(II) porphyrins (PtOEP) as the phosphor in an OLED
and were able to obtain higher efficiency red-light emission than
had proved possible with lanthanide dopants.14,15 Energy-transfer
processes and the sites of electron-hole recombination in blends
of PtOEP in conjugated polymer hosts have been studied in
some detail by the Cambridge16-18 and Sheffield19,20 groups.
More recently, Thompson and Forrest and colleagues demon-
strated spectacular enhancements in OLED efficiencies, with
external quantum efficiencies as high as 19%, using Ir(III)
cyclometalated complexes as blends in host luminescent
materials.21-29 However, the processing of such materials can
be complex and costly, often requiring deposition under high
vacuum and controlled temperature, and the use of multiple
layers.
phors into conjugated polymer hosts and the fabrication of LEDs
using these composite materials; however, the improvements
in device efficiency have been modest.16-20,33-40 It has been
proposed that energy is lost by transfer to low-lying triplet states
in the polymer host41 or by triplet-triplet annihilation; under
such conditions, the efficiency is limited by phase separation
and aggregation of dopants even at low-blending concentrations.
It is recognized that this could be suppressed when the
phosphorescent dopant and polymer host have similar surface
functional groups42 or when they are implemented in one
composite material.34,43,44 In a recent paper, statistical copoly-
mers based on dioctylfluorene, with hole-transporting moieties
and phosphorescent Ir(III) complexes attached as pendant groups
to the main backbone, were synthesized and showed some
improvements in device efficiency.45
We aim to attach phosphors covalently to a conjugated
polymer backbone so as to allow efficient energy transfer
between polymer and phosphor and further to minimize ag-
gregation and quenching of phosphorescence. Herein, we
describe the controlled synthesis of such oligomers and polymers
based on 9,9-dialkylfluorene repeat units in conjugation with
bis-cyclometalated iridium(III) acac complexes. The photo-
physics of optical and electrical excitation are presented and
this has enabled insights to be drawn into design criteria for
phosphorescent polymer light-emitting devices.
Spin-coatable solutions of well-defined amorphous iridium
complexes blended in polycarbazole and poly(phenylenevi-
nylene) hosts were described by Bazan and Heeger,30 with the
ultimate production of efficient, but multilayer devices.31,32
Considerable attention has been focused on blending of phos-
Results and Discussion
