368
J.C. Rodr´ıguez et al. / Il Farmaco 58 (2003) 363Á369
/
(1H, d, H-6); 5.85 (1H, dd, H-7); 7.48 (1H, s, thiazol);
9.74 (1H, d, NHCO); 12.95 (1H, s, NHCOchloroacetyl);
13C NMR (DMSO-d6) d (ppm): C-1, 25.73; C-2, 123.51;
C-3, 62.66; C-4, 126.33; C-5, 162.78; C-6, 57.41; C-7,
58.57; C-8, 163.71; C-9, 162.52; C-10, 148.49; C-11,
62.14; C-12, 141.62; C-13, 114.57; C-14, 157.89; C-15,
170.18; C-16, 20.53; C-17, 165.34; C-18, 42.16.
and the mixture was stirred for 30 min at the same
temperature. The reaction mixture was washed succes-
sively with water (170 ml), brine (170 ml) and 5%
potassium hydrogen sulfate aqueous solution (170 ml),
and the organic layer dried over anhydrous sodium
sulfate. The solvent was removed and the resulting
liquid distilled under reduced pressure at 55 mmHg to
give V (fraction boiling between 92 and 94 8C) (113.2 g,
46.2%). 1H NMR (CDCl3) d (ppm): 1.34 (6H, m,
(CH3)2); 1.84 (3H, d, CH3); 4.95 (1H, sept, CHO);
6.44 (1H, q, OCHCl); 13C NMR (DMSO-d6) d (ppm):
C-19, 21.60 and 21.55; C-20, 84.30; C-21, 152.22; C-22,
73.26; C-23 and C-24, 25.16.
3.3. 7b-[2-(2-Chloroacetamidothiazol-4-yl)-(Z)-2-
methoxyiminoacetamido]-3-methoxymethyl-3-cephem-4-
carboxylic acid (III)
To a solution of II (26.0 g, 49 mmol) and sodium
hydrogen carbonate (4.1 g, 49 mmol) in water (80 ml),
methanol (170 ml, 4.2 mol) and calcium chloride
dihydrate (375 g, 2.55 mol) were added. The mixture
was stirred for 75 min. at 70 8C and then poured into
500 ml of ice water. The mixture was acidified with 37%
hydrochloric acid (10 ml) and extracted with ethyl
3.5. 1-Iodoethyl isopropyl carbonate (VI)
To a solution of V (5.1 g, 30.6 mmol) in benzene (50
ml) were added, at room temperature, sodium iodide (10
g, 66.7 mmol) and 18-crown-6 ether (0.25 g, 0.95 mmol),
and the mixture was refluxed with stirring during 12 h.
acetate (2ꢂ500 ml). The extracts were combined and
/
the organic layer was extracted with 10% potassium
hydrogen phosphate aqueous solution (350, 150 and 100
ml). The aqueous layers were combined and extracted
The mixture was washed with water (3ꢂ15 ml) followed
/
by 5% sodium thiosulfate aqueous solution (10 ml). The
organic layer was dried over anhydrous sodium sulfate
and after filtration, the filtrate was concentrated in
with ethyl acetate (2ꢂ500 ml) after acidification with
/
1
concentrated hydrochloric acid. The organic extracts
were combined, washed with brine (100 ml) and dried
over anhydrous sodium sulfate. The mixture was filtered
and the filtrate was concentrated under reduced pressure
to about 1/5 of the initial volume to yield a precipitate.
The mixture was allowed to stand at room temperature
for 3 h. The resulting precipitate was separated by
filtration, washed with ethyl acetate (30 ml) and dried to
vacuo to give VI (6.7 g, 85%). H NMR (CDCl3) d
(ppm): 1.32 (6H, m, (CH3)2); 2.15 (3H, d, CH3); 4.85
(1H, sept, CHO); 6.70 (1H, q, OCHCl).
3.6. 1-(Isopropoxycarbonyloxy)ethyl-7b-[2-(2-
aminothiazol-4-yl)-(Z)-2-methoxyiminoacetamido]-3-
methoxymethyl-3-cephem-4-carboxylate (VII)
(cefpodoxime proxetil)
give III (16 g, 65% yield). TLC (FM A) 0.69; m.p. 208Á
/
210 8C; 1H NMR (DMSO-d6) d (ppm): 3.25 (3H, s,
CH3O); 3.51 and 3.62 (2H, Abq, H-1); 3.92 (3H, s,
NOCH3); 4.20 (2H, s, CH2Cl); 4.40 (2H, s, CH2O); 5.20
(1H, d, H-6); 5.84 (1H, dd, H-7); 7.48 (1H, s, thiazol);
9.75 (1H, d, NHCO); 12.95 (1H, s, NHCOchloroacetyl);
13C NMR (DMSO-d6) d (ppm): C-1, 25.53; C-2, 125.39;
C-3, 69.95; C-4, 126.14; C-5, 163.00; C-6, 57.59; C-7,
58.51; C-8, 163.62; C-9, 162.52; C-10, 148.48; C-11,
62.13; C-12, 141.64; C-13, 114.57; C-14, 157.85; C-16,
57.40; C-17, 165.32; C-18, 42.15.
To a solution of III (2.0 g, 3.97 mmol) in N,N-
dimethylacetamide (10 ml), dicyclohexylamine (0.9 ml,
4.52 mmol) was added, followed by VI (1.3 g, 5.04
mmol) under cooling (0Á5 8C). The mixture was stirred
/
for 45 min at the same temperature and ethyl acetate (50
ml) was added. The mixture was washed successively
with water (15 ml), 1 M hydrochloric acid aqueous
solution (15 ml) and brine (15 ml). The organic layer was
dried over anhydrous sodium sulfate and the solvent
was removed by vacuum distillation to give an oil (2.4
g).
3.4. 1-Chloroethyl isopropyl carbonate (V)
The oil was dissolved in N,N-dimethylacetamide (20
ml), thiourea (0.61 g, 1.97 mmol) was added and the
resulting solution was stirred for 3 h at room tempera-
ture. The mixture was poured into 5% sodium hydrogen
carbonate aqueous solution (50 ml) and extracted with
ethyl acetate (75 ml). The organic layer was washed
successively with 10% potassium bisulfate aqueous
solution (25 ml) and brine (25 ml), and dried over
anhydrous sodium sulfate. After filtration, the solvent
was removed under reduced pressure and the residue
was stirred with isopropyl ether (25 ml). The resulting
precipitate was separated by filtration, washed with
To a solution of ethyl chloroformate (140 ml, 1.47
mol) and sulfuryl chloride (130 ml, 1.61 mol) was added
benzoyl peroxide (0.5 g, 2 mmol). The mixture was
refluxed for 7.5 h and it was distilled at atmospheric
pressure to give 1-chloroethyl chloroformate (boiling
range 119Á140 8C). To a solution of the resulting 1-
/
chloroethyl chloroformate in dichloromethane (675 ml)
isopropyl alcohol (134 ml, 1.74 mol) was added, under
cooling (0Á
/
5 8C) and with stirring. Pyridine (78 ml, 0.96
mol) was added dropwise to the solution over 20 min
