10.1002/ejoc.201800260
European Journal of Organic Chemistry
FULL PAPER
1,2,3,4,6-Penta-O-(2-nitrophenyl)acetyl-D-glucopyranoside (3)
1C), 46.99 (d, 1C), 38.28 (t, 1C), 16.45 (t, 3C), 16.24 (t, 1C); ESI-MS calcd
for C38H32BrN4O17+ [M+H]+ 895.1, found 895.1.
To a solution of glucose (1.0 g, 5.6 mmol, 1 eq.) and 2-nitrophenylacetic
acid (6.1 g, 33.6 mmol, 6 eq.) in dry dichloromethane (50 mL) (4-
dimethylamino)pyridine (1.1 g, 5.6 mmol, 1 eq.) and EDC (6.4 g, 5.6 mmol,
6 eq.) were added. The reaction mixture was stirred at room temperature
for 16 hours, washed with 1N HCl (2x50 mL) and saturated NaHCO3-
solution (2x50 mL), dried over Na2SO4, filtered and concentrated. The
crude product was purified by flash chromatography (CH2Cl2/EtOAc,
gradient elution 100:1 to 20:1) to obtain the title compound as a white foam
(3.0 g, 53 %). According to NMR analysis, a 4:1 (α:β) mixture of anomers
was obtained; 1H NMR (400 MHz, CDCl3): α-(4): δ 8.20-8.11 (m, 4H), 8.09
(dd, J = 8.2, 1.2 Hz, 1H), 7.70-7.57 (m, 5H), 7.56-7.46 (m, 8H), 7.43 (td, J
= 7.8, 1.3, 1H), 7.34 (dd, J = 7.6, 1.3 Hz, 1H), 6.37 (d, J = 3.5 Hz, 1H), 5.59
(t, J = 9.9 Hz, 1H), 5.14 (t, J = 9.9 Hz, 1H), 5.08 (dd, J = 10.1, 3.9 Hz, 1H),
4.39 (dd, J = 12.3, 1.4 Hz, 1H), 4.32-4.09 (m, 9H), 4.08-3.93 (m, 3H); β-
(4): δ 8.20-8.11 (m, 4H), 8.09 (dd, J = 8.2, 1.2 Hz, 1H), 7.70-7.57 (m, 5H),
7.56-7.46 (m, 8H), 7.43 (td, J = 7.8, 1.3, 1H), 7.34 (dd, J = 7.6, 1.3 Hz, 1H),
5.79 (d, J = 8.2 Hz, 1H), 5.43 (t, J = 9.7 Hz, 1H), 5.22 (dd, J = 9.7, 8.2 Hz,
1H), 5.14 (t, J = 9.7 Hz, 1H), 4.36 (dd, J = 12.5, 4.6 Hz, 1H), 4.32-4.09 (m,
9H), 4.08-3.93 (m, 3H); 13C NMR (100 MHz, CDCl3): α-(4): δ 169.81 (s,
2C), 169.62 (s, 1C), 169.29 (s, 1C), 168.50 (s, 1C), 148.75 (s, 1C), 148.57
(s, 1C), 148.56 (s, 1C), 148.52 (s, 1C), 148.49 (s, 1C), 134.42 (d, 1C),
134.32 (d, 1C), 134.25 (d, 1C), 134.15 (d, 1C), 134.12 (d, 3C), 133.91 (d,
1C), 133.76 (d, 1C), 133.73 (d, 1C), 130.11 (s, 1C), 129.88 (s, 1C), 129.80
(s, 1C), 129.59 (s, 1C), 129.52 (s, 1C), 129.07 (d, 1C), 128.89 (d, 1C),
128.87 (d, 1C), 128.77 (d, 1C), 128.65 (d, 1C), 125.54 (d, 1C), 125.35 (d,
2C), 125.31 (d, 1C), 125.25 (d, 1C), 89.29 (d, 1C), 70.18 (d, 1C), 70.10 (d,
1C), 69.84 (d, 1C), 68.11 (d, 1C), 62.48 (t, 1C), 39.84 (t, 1C), 39.74 (t, 1C),
39.69 (t, 1C), 39.55 (t, 1C), 39.50 (t, 1C); β-(4): δ 169.69 (s, 1C), 169.66
(s, 1C), 169.24 (s, 1C), 169.18 (s, 1C), 168.86 (s, 1C), 148.56 (s, 1C),
148.52 (s, 1C), 148.49 (s, 1C), 148.46 (s, 1C), 148.42 (s, 1C), 134.56 (d,
1C), 134.45 (d, 1C), 134.25 (d, 1C), 134.15 (d, 1C), 134.12 (d, 3C), 133.82
(d, 1C), 133.76 (d, 1C), 133.73 (d, 1C), 130.06 (s, 1C), 129.88 (s, 1C),
129.83 (s, 1C), 129.55 (s, 1C), 129.46 (s, 1C), 129.00 (d, 1C), 128.89 (d,
1C), 128.87 (d, 1C), 128.80 (d, 1C), 128.61 (d, 1C), 125.42 (d, 1C), 125.35
(d, 2C), 125.31 (d, 1C), 125.25 (d, 1C), 91.97 (d, 1C), 72.86 (d, 1C), 72.37
(d, 1C), 70.51 (d, 1C), 68.32 (d, 1C), 62.15 (t, 1C), 39.62 (t, 1C), 39.55 (t,
1C), 33.91 (t, 1C), 25.67 (t, 1C), 24.99 (t, 1C); HRMS calcd for
C46H37N5NaO21+ [M+Na]+ 1018.1873, found 1018.1875.
2,3,4,6-Tetra-O-(2-nitrophenyl)acetyl-D-glucopyranose (5)
To a solution of compound 4 (1.45 g, 1.67 mmol, 1 eq.) in acetone (9 mL)
water (30 µl) and Ag2CO3 (0.52 g, 1.84 mmol, 1.1 eq.) were added. After
stirring at room temperature for 20 h in the dark, the reaction mixture was
filtered over celite and the filtrate was concentrated under reduced
pressure. The residue was dissolved in DCM and filtered over a short pad
of silica gel (elution with EtOAc/hexanes, 1:1) to obtain a 4:1 (α:β) mixture
1
of anomers of 5 (1.1 g, 79 %); H NMR (400 MHz, CDCl3): α-(6): δ 8.21-
8.08 (m, 4H), 7.68-7.54 (m, 5H), 7.53-7.41 (m, 6H), 7.36-7.30 (m, 1H), 5.65
(t, J = 9.9 Hz, 1H), 5.43 (d, J = 3.5 Hz, 1H), 5.03 (t, J = 9.8 Hz, 1H), 4.94
(dd, J = 10.1, 3.5 Hz, 1H), 4.35-4.26 (m, 2H), 4.25-4.18 (m, 2H), 4.18-4.11
(m, 3H), 4.10-4.00 (m, 3H), 3.95 (d, J = 17.6 Hz, 1H), 3.37 (bs, 1H); β-(6):
δ 8.21-8.08 (m, 4H), 7.68-7.54 (m, 5H), 7.53-7.41 (m, 6H), 7.36-7.30 (m,
1H), 5.39 (t, J = 9.9 Hz, 1H), 5.08 (t, J = 9.9 Hz, 1H), 4.97 (dd, J = 9.8, 8.2
Hz, 1H), 4.77 (d, J = 7.8 Hz, 1H), 4.35-4.26 (m, 2H), 4.25-4.18 (m, 2H),
4.18-4.11 (m, 3H), 4.10-4.00 (m, 3H), 3.95 (d, J = 17.6 Hz, 1H), 3.37 (bs,
1H); 13C NMR (100 MHz, CDCl3): α-(6): δ 169.88 (s, 1C), 169.67 (s, 1C),
169.57 (s, 1C), 169.43 (s, 1C), 148.52 (s, 4C), 134.37 (d, 1C), 134.18 (d,
1C), 134.10 (d, 4C), 133.95 (d, 1C), 133.78 (d, 1C), 130.23 (s, 1C), 129.98
(s, 2C), 129.67 (s, 1C), 128.89 (d, 1C), 128.86 (d, 1C), 128.75 (d, 2C),
125.46 (d, 1C), 125.44 (d, 1C), 125.35 (d, 1C), 125.28 (d, 1C), 90.14 (d,
1C), 71.78 (d, 1C), 70.07 (d, 1C), 69.05 (d, 1C), 67.24 (d, 1C), 62.91 (t,
1C), 39.95 (t, 1C), 39.82 (t, 2C), 39.77 (t, 1C); β-(6): 170.09 (s, 1C), 169.80
(s, 1C), 169.57 (s, 1C), 169.35 (s, 1C), 148.61 (s, 1C), 148.52 (s, 2C),
148.49 (s, 1C), 134.47 (d, 1C), 134.23 (d, 1C), 134.10 (d, 4C), 133.95 (d,
1C), 133.78 (d, 1C), 130.12 (s, 1C), 129.92 (s, 1C), 129.72 (s, 1C), 129.63
(s, 1C), 128.94 (d, 1C), 128.86 (d, 1C), 128.79 (d, 1C), 128.75 (d, 1C),
125.46 (d, 1C), 125.44 (d, 1C), 125.31 (d, 1C), 125.28 (d, 1C), 95.49 (d,
1C), 73.77 (d, 1C), 72.21 (d, 1C), 72.19 (d, 1C), 68.87 (d, 1C), 62.59 (t,
1C), 39.90 (t, 1C), 39.82 (t, 1C), 39.71 (t, 1C), 39.64 (t, 1C); HRMS calcd
for C38H32N4NaO18+ [M+Na]+ 855.1603, found 855.1604.
2,3,4,6-Tetra-O-(2-nitrophenyl)acetyl-α,D-glucopyranosyl
trichloroacetimidate (6)
To a solution of compound 5 (1.2 g, 1.4 mmol, 1 eq.) in dry CH2Cl2,
trichloroacetonitrile (43 µl, 4.3 mmol, 3 eq.) was slowly added at 0 °C,
followed by DBU (21 µl, 0.14 mmol, 0.1 eq.). The reaction mixture was
slowly warmed to room temperature and stirring was continued for 16 h.
The solution was concentrated under vacuum and the crude product was
purified by flash chromatography (EtOAc in hexanes, gradient elution) to
obtain the title compound as a lightly yellow foam (1.07 g, 76 %); 1H NMR
(600 MHz, CDCl3) δ 8.70 (s, 1H), 8.17 (dd, J = 8.3, 1.1 Hz, 1H), 8.15 (dd,
J = 8.0, 1.2 Hz, 1H), 8.12 (dd, J = 8.2, 1.2 Hz, 1H), 8.01 (dd, J = 8.2, 1.3
Hz, 1H), 7.69-7.56 (m, 4H), 7.54-7.41 (m, 7H), 7.31 (dd, J = 7.6, 1.2, 1H),
6.52 (d, J = 3.8 Hz, 1H), 5.71 (t, J = 9.8 Hz, 1H), 5.25 (t, J = 9.9 Hz, 1H),
5.22 (dd, J = 10.1, 3.7 Hz, 1H), 4.35 (dd, J = 12.6, 3.8 Hz, 1H), 4.31 (dd, J
= 12.6, 1.7 Hz, 1H), 4.24 (ddd; J = 10.5, 3.9, 2.1, 1H), 4.22 (d, J = 6.5 Hz,
1H), 4.20-4.14 (m, 3H), 4.09 (d, J = 16.9 Hz, 1H), 3.99 (d, J = 14.9 Hz, 1H),
3.96 (d, J = 14.1 Hz, 1H), 3.91 (d, J = 17.3 Hz, 1H); 13C NMR (150 MHz,
CDCl3) δ 169.76 (s, 1C), 169.69 (s, 1C), 169.50 (s, 1C), 168.24 (s, 1C),
160.61 (s, 1C), 148.76 (s, 1C), 148.56 (s, 1C), 148.48 (s, 1C), 148.44 (s,
1C), 143.43 (d, 1C), 134.21 (d, 2C), 134.10 (d, 1C), 134.08 (d, 1C), 133.69
(d, 2C), 133.65 (d, 1C), 130.14 (s, 1C), 129.64 (s, 1C), 129.57 (s, 1C),
129.47 (s, 1C), 128.97 (d, 1C), 128.90 (d, 1C), 128.83 (d, 1C), 128.66 (d,
1C), 125.44 (d, 1C), 125.35 (d, 1C), 125.31 (d, 2C), 92.96 (d, 1C), 90.80
(s, 1C), 70.33 (d, 1C), 70.27 (d, 1C), 69.93 (d, 1C), 67.80 (d, 1C), 62.10 (t,
1C), 39.76 (t, 1C), 39.69 (t, 1C), 39.52 (t, 1C), 39.49 (t, 1C); HRMS calcd
for C40H32Cl3N5NaO18+ [M+Na]+ 998.0700, found 998.0702.
1-Bromo-1-deoxy-2,3,4,6-tetra-O-(2-nitrophenyl)acetyl-α,D-
glucopyranose (4)
To
a solution of compound 3 (4.0 g, 4.02 mmol, 1 eq.) in dry
dichloromethane (3 mL) hydrogen bromide in acetic acid (30 % (wt), 5 mL)
was slowly added at 0 °C. The reaction was warmed to room temperature
and stirred for 4 h and then quenched by the addition of ice water (30 mL).
The mixture was diluted with CH2Cl2 and washed with saturated aqueous
NaHCO3 solution. The organic layer was dried over Na2SO4 and the
solvents were removed under reduced pressure to give the desired
product 4 as a yellow foam (2.9 g, 81%); 1H NMR (600 MHz, CDCl3) δ
8.19-8.14 (m, 3H), 8.09 (dd, J = 8.2, 1.2 Hz, 1H), 7.67-7.57 (m, 4H), 7.53-
7.47 (m, 5H), 7.46-7.42 (m, 2H), 7.31 (dd, J = 7.7, 0.9 Hz, 1H), 6.51 (d, J
= 4.1 Hz, 1H), 5.66 (t, J = 9.7 Hz, 1H), 5.21 (t, J = 9.8 Hz, 1H), 4.96 (dd, J
= 9.8, 3.9 Hz, 1H), 4.38 dd (J = 13.1, 4.2 Hz, 1H), 4.33-4.29 (m, 2H), 4.27
(d, J = 17.0 Hz, 1H), 4.22-4.14 (m, 3H), 4.08 (d, J = 17.0 Hz, 1H), 4.03 (d,
J = 17.0 Hz, 1H), 3.97 (d, J = 5.3 Hz, 1H), 3.95 (d, J = 5.6 Hz, 1H); 13C
NMR (150 MHz, CDCl3) δ 146.35 (s, 1C), 146.20 (s, 1C), 146.08 (s, 1C),
146.82 (s, 1C), 125.40 (s, 1C), 125.15 (s, 3C), 111.07 (d, 1C), 110.88 (d,
2C), 110.84 (d, 2C), 110.80 (d, 1C), 110.39 (d, 1C), 110.38 (d, 1C), 106.73
(s, 1C), 106.28 (s, 1C), 106.17 (s, 1C), 106.13 (s, 1C), 105.72 (d, 1C),
105.64 (d, 1C), 105.54 (d, 1C), 105.40 (d, 1C), 102.16 (d, 1C), 102.07 (d,
1C), 102.03 (d, 1C), 102.02 (d, 1C), 63.26 (d, 1C), 49.02 (d, 2C), 47.56 (d,
