1830
K. Akiyama et al. / Tetrahedron 61 (2005) 1827–1833
stirred at 0 8C for 30 min. After addition of water and
neutralization with 2 M HCl, the mixture was extracted with
ethyl acetate (30 mL!5), dried over MgSO4, and purified
with silica gel column chromatography (EtOAc/hexane,
1:9) to afford the alcohol (7, 5.17 g, 83%): [a]2D6C2.5 (c
2.00, CHCl3); IR (neat) n 3414, 2954, 2928, 2884, 2856,
(3.63 g, 91%). A part of this alcohol (1.50 g) was dissolved
in benzene (40 mL), and treated with imidazole (809 mg),
triphenylphosphine (3.13 g), and iodine (2.38 g) at room
temperature for 2 h. After addition of sodium sulfite
aqueous solution, extraction with EtOAc (3 mL!4) fol-
lowed by purification with silica gel column chroma-
tography (EtOAc/hexane, 1:9) afforded an iodide (9, 1.92 g,
95%): [a]2D7C32.8 (c 2.00, CHCl3); IR n (neat) 2956, 2928,
1459, 1406, 1387, 1219, 1093, 1067 cmK1 1H NMR
;
(400 MHz, CDCl3) dH 0.03 (6H, s, SiCH3), 0.89 (9H, s,
SiCCH3), 0.92 (3H, d, JZ6.6 Hz, H-9), 1.06 (3H, d, JZ
6.8 Hz, H-8), 1.07 (1H, m, H-5), 1.51 (1H, m, H-5), 1.76
(1H, m, H-6), 1.87 (1H, m, H-4), 3.37 (1H, dd, JZ6.1,
9.8 Hz, H-7), 3.48 (1H, dd, JZ4.9, 9.8 Hz, H-7), 3.76 (2H, t,
JZ4.8 Hz, H-1), 3.81 (1H, dd, JZ5.1, 6.8 Hz, H-3), 4.09
(1H, dt, JZ6.8, 4.8 Hz, H-2), 5.97 (1H, s, OCHPh), 7.38–
7.49 (5H, m, Ph); 13C NMR (100 MHz, CDCl3) dC
K5.4(2C), 15.4, 18.2, 25.9(3C), 32.8, 33.1, 37.2, 63.4,
65.4, 67.4, 79.8, 82.2, 103.1, 127.0, 128.4(2C), 129.5(2C),
137.3; FABMS m/z 395 [MCH]C; HRFABMS found m/z
395.2618 (calcd for 395.2618, C22H39O4Si).
1
2857, 1462, 1421, 1388, 1265, 1091, and 1027 cmK1; H
NMR (400 MHz, CDCl3) dH 0.91 (3H, d, JZ6.6 Hz, H-9),
0.93 (3H, d, JZ6.9 Hz, H-8), 1.09 (1H, m, H-5), 1.30 (1H,
m, H-5), 1.42 (3H, s, OCCH3), 1.43 (2H, m, H-4,6), 1.46
(3H, s, OCCH3), 3.00 (1H, dd, JZ5.9, 9.6 Hz, H-7), 3.08
(1H, dd, JZ4.1, 9.6 Hz, H-7), 3.29 (1H, dd, JZ1.0, 7.8 Hz,
H-3), 3.52 (1H, dt, JZ1.0, 7.8 Hz, H-1), 4.00 (1H, dt, JZ
1.0, 7.8, H-1), 4.33 (1H, q, JZ7.8 Hz, H-2), 4.64 (1H, d, JZ
11.2 Hz, OCH2Ph), 4.86 (1H, s, OCH2Ph), and 7.33–7.39
(5H, m, Ph); 13C NMR (100 MHz, CDCl3) dC 14.4, 17.9,
20.8, 25.8, 26.8, 31.3, 32.6, 40.9, 66.5, 73.7, 79.1, 81.8,
109.3, 127.5(2C), 128.0, 128.2(2C), and 139.1; FABMS m/z
433 [MCH]C; HRFABMS found m/z 433.1224 (calcd for
433.1240, C19H30IO3).
3.1.4. (2R,3R,4S,6R)-3-Benzyloxy-7-(t-butyldimethysilyl-
oxy)-4,6-dimethyl-1,2-heptanediol (8). To a solution of the
alcohol (7, 6.68 g) in dichloromethane (80 mL), dimethyl-
sulfide borane (1.8 mL) was slowly added at 0 8C under
argon atmosphere, and the mixture was stirred and gradually
warmed to room temperature over 1 h. This reaction mixture
was cooled again to 0 8C and boron trifluoride ethyl ether
complex (2.15 mL) was added. The mixture was further
stirred for 10 min. After addition of water, extraction with
EtOAc (50 mL!5) followed by purification with silica gel
column chromatography (EtOAc/hexane, 1:1) afforded a
1,2-diol (8, 4.68 g, 70%): [a]2D7K22.9 (c 2.00, CHCl3); IR n
(neat) 3448, 2956, 2928, 2857, 1462, 1421, 1388, 1265,
1091, and 1027 cmK1; 1H NMR (400 MHz, CDCl3) dH 0.03
(6H, s, SiCH3), 0.89 (9H, s, SiCCH3), 0.90 (3H, d, JZ
6.6 Hz, H-9), 0.98 (3H, d, JZ6.9 Hz, H-8), 1.04 (1H, m,
H-5), 1.65 (1H, m, H-5), 1.75 (1H, m, H-6), 1.86 (1H, m,
H-4), 3.35 (1H, dd, JZ4.8, 5.7 Hz, H-3), 3.41 (2H, dd, JZ
5.3, 7.8 Hz, H-7), 3.54 (1H, m, H-1), 3.63 (1H, m, H-1),
3.74 (1H, m, H-2), 4.55 (1H, d, JZ11.2 Hz, OCH2Ph), 4.74
(1H, s, OCH2Ph), and 7.30–7.37 (5H, m, Ph); 13C NMR
(100 MHz, CDCl3) dC K5.4(2C), 15.5, 17.8, 18.3,
25.9(3C), 32.7, 33.2, 37.7, 64.5, 68.0, 72.0, 74.6, 82.2,
127.8(2C), 127.9, 128.5(2C), and 138.2; FABMS m/z 397
[MCH]C; HRFABMS found m/z 397.2747 (calcd for
397.2774, C22H41O4Si).
3.1.6. (2R,3R,4S,6R,8E)-3-Benzyloxy-1,2-isopropyliden-
dioxy-4,6,8-trimethyl-8-heptene (10). To the mixture of
lithium metal (87.1 mg) and anhydrous ether (4 mL) under
argon atmosphere, 2-bromo-cis-2-butene (851 mg) was
added over 30 min, and the mixture was stirred for 2 h at
room temperature. Then, the mixture was cooled to 0 8C and
a solution of the iodide (9, 901 mg) in THF (6 mL) was
added to this mixture, which was gradually warmed to room
temperature and stirred for 2 h. After addition of ammonium
chloride aqueous solution, the mixture was extracted with
ethyl acetate (30 mL!4), dried over MgSO4, and purified
with silica gel column chromatography (EtOAc/hexane,
1:19) to give the alkene (10, 461 mg, 62%): [a]2D7C20.8 (c
2.00, CHCl3); IR n (neat) 2958, 2930, 1654, 1455, 1378,
1
1250, 1214, 1159, and 1068 cmK1; H NMR (400 MHz,
CDCl3) dH 0.77 (3H, d, JZ6.3 Hz, H-12), 0.93 (3H, d, JZ
6.6 Hz, H-11), 0.95 (1H, m, H-5), 1.38 (3H, s, OCCH3), 1.39
(1H, m, H-5), 1.45 (2H, m, H-4,6), 1.54 (3H, d, JZ6.4 Hz,
H-10), 1.55 (3H, s, H-13), 1.57 (1H, m, H-7), 1.61 (1H, m,
H-6), 1.70 (1H, m, H-4), 1.90 (1H, brdd, JZ5.5, 13.0 Hz,
H-7), 3.32 (1H, dd, JZ1.8, 8.1 Hz, H-3), 3.50 (1H, t, JZ
8.1 Hz, H-1), 4.00 (1H, dd, JZ6.2, 8.1 Hz, H-1), 4.29 (1H,
m, H-2), 4.55 (1H, d, JZ11.7 Hz, OCH2Ph), 5.15 (1H, d,
JZ11.7 Hz, OCH2Ph), 5.14 (1H, q, JZ6.4 Hz, H-9), and
7.30–7.38 (5H, m, Ph); 13C NMR (100 MHz, CDCl3) dC
13.3, 14.9, 15.7, 25.8, 26.9, 27.9, 32.7, 41.8, 47.9, 66.5,
73.9, 77.2, 79.4, 120.1, 127.2, 127.6(2C), 128.1(2C), 134.4,
and 139.4; FABMS m/z 361 [MCH]C; HRFABMS found
m/z 361.2736 (calcd for 361.2743, C23H37O3).
3.1.5. (2R,3R,4S,6R)-3-Benzyloxy-7-iodo-1,2-isopropyl-
idendioxy-4,6-dimethylheptane (9). A solution of the
diol (8, 5.35 g) in dichloromethane (40 mL) was treated
with 2,2-dimethoxypropane in the presence of p-toluene-
sulfonic acid monohydrate (120 mg) at room temperature
for 1 h. After addition of sodium hydrogen carbonate
aqueous solution, the mixture was extracted with ethyl
acetate (50 mL!5), dried over MgSO4, and purified with
silica gel column chromatography (EtOAc/hexane, 3:97) to
afford an acetonide (5.38 g, 91%), which was dissolved
in THF (30 mL) and treated with tetrabutylammonium
fluoride, 1.0 M solution in THF (16 mL) at room tempera-
ture for 1 h. After addition of water, the mixture was
extracted with ethyl acetate (50 mL!4), washed with brine,
dried over MgSO4, and purified with silica gel column
chromatography (EtOAc/hexane, 1:4) to give an alcohol
3.1.7. (2R,3R,4S,6R,8E)-3-Benzyloxy-2-hydroxy-4,6,8-
trimethyl-8-decenyl pivaloate (11). A solution of the
alkene (10, 891 mg) in methanol (20 mL) was treated with
p-toluenesulfonic acid monohydrate (86 mg) at room
temperature for 2 h. After addition of water, the mixture
was extracted with ethyl acetate (30 mL!4), dried over
MgSO4, and purified with silica gel column chromatog-
raphy (EtOAc/hexane, 1:4) to give a diol (662 mg, 84%), a
part of which (507 mg) was dissolved in pyridine (1 mL) at
0 8C and treated with pivaloyl chloride (0.32 mL) at room
