DissociatiVe Electrom Transfer to Peresters
J. Am. Chem. Soc., Vol. 123, No. 39, 2001 9583
compound was isolated by flash chromatography (CH2Cl2-EtOH 96:
4). Yield, 90%: mp 191-192 °C (EtOAc-petroleum ether); Rf1 ) 0.80;
Rf2 ) 0.55; Rf4 ) 0.80; IR (KBr) 1773, 1704 cm-1; 1H NMR (DMSO-
d6) δ 7.83 (s, 4H, Pht CH), 3.90 (m, 1H, cyclohexane CH), 2.6 (m,
1H, cyclohexane CH), 2.20 (m, 4H, cyclohexane CH2), 1.55 (m, 4H,
cyclohexane CH2).
of these DET reactions are inherently very slow. Most probably,
the study of intramolecular DET rates in well-defined D-Sp-A
molecules will provide a particularly efficient tool to gain new
insights into the fine details of the dynamics of these dissociative
processes.
cis-4-Phthaloylaminocyclohexanecarboxylic Acid-OOtBu (1b).
This compound was prepared from cis-4-phthaloylaminocyclohexan-
ecarboxylic acid (0.15 g, 0.55 mmol) and a 5.5 M solution of tert-
butyl hydroperoxide in n-decane (0.10 mL, 0.55 mmol) as described
above for 1a and purified by flash chromatography (EtOAc-petroleum
ether 1:9). Yield, 79%: mp 105-106 °C (EtOAc-petroleum ether);
Rf1 ) 0.95; Rf2 ) 0.95; Rf3 ) 0.30; IR (KBr) 1769, 1723, 1703 cm-1;1H
NMR (CDCl3) δ 7.78 and 7.67 (2m, 4H, Pht CH), 4.15 (m, 1H,
cyclohexane CH), 2.85 (m, 1H, cyclohexane CH), 2.50 (m, 4H,
cyclohexane CH2), 1.70 (m, 4H, cyclohexane CH2), 1.38 (s, 9H, OOtBu
CH3); 13C NMR (CDCl3) δ 171.13 (perester CO), 168.06 (Pht CO),
133.76 (phenyl CH4 and CH5), 131.95 (phenyl CH1 and CH2), 123.02
(phenyl CH3 and CH6), 83.48 (OOtBu quaternary C), 50.10, 36.84,
26.95, 26.41, 26.24 (cyclohexane CH and CH2 and OOtBu CH3).
Pht-Aib-OMe (3a). To an ice-cold solution of Pht-Aib-OH (1 g,
4.2 mmol) in CH2Cl2 (10 mL), DMAP (0.5 g, 4.2 mmol) and EDC‚
HCl (0.79 g, 4.2 mmol) were added, followed by methanol (0.17 mL,
4.2 mmol). After stirring for 4 h at room temperature, the reaction
mixture was evaporated to dryness and the residue dissolved in EtOAc.
The organic solution was washed with 10% KHSO4, H2O, 5% NaHCO3,
and H2O, dried over Na2SO4, and concentrated under reduced pressure.
A flash chromatography step (CH2Cl2-EtOH 98:2) was required to
purify the title compound. Yield, 80%: mp 70 °C (EtOAc-petroleum
ether); Rf1 ) 0.90; Rf2 ) 0.90; Rf3 ) 0.30; IR (KBr) 1765, 1734, 1710
Experimental Section
Synthesis and Characterization. Melting points were determined
using a Leitz model Laborlux 12 apparatus and are not corrected. Thin-
layer chromatography (TLC) and column chromatography were per-
formed on Merck Kieselgel 60 F254 plates and on Merck Kieselgel 60
(0.040-0.063 mm), respectively. The following eluants were used for
TLC analysis: (1) chloroform-ethanol, 9:1; (2) toluene-ethanol, 7:1;
(3) ethyl acetate-petroleum ether, 1:8; (4) 1-butanol-acetic acid-
water, 3:1:1. The TLC chromatograms were visualized by UV
fluorescence (254 nm) or developed by chlorine-starch-potassium
iodide chromatic reaction, as appropriate. Selective visualization of the
-O-O- bond was achieved by developing the TLC plates with a
solution of NH4SCN (0.63 g) and FeSO4‚(NH4)2SO4‚6H2O (Mohr’s salt,
0.88 g) in 1% H2SO4 (12 mL). All compounds were obtained in a
chromatographically homogeneous state. The solid-state IR absorption
spectra (KBr disk technique) were recorded with a Perkin-Elmer model
1720X FT-IR spectrophotometer, nitrogen-flushed, equipped with a
sample shuttle device, at 2-cm-1 nominal resolution, averaging 50 scans.
1H NMR and 13C NMR spectra were obtained by using a Bruker model
AC 250 spectrometer. Deuteriochloroform (99.96%, d; Aldrich) and
deuterated dimethyl sulfoxide (99.96%, d6; Acros Organics), with
tetramethylsilane as the internal standard, were used as solvents.
The mixed alkyl-acyl peroxides (peresters) 2a21a and 2b44 were
prepared by using a literature procedure.45 The mediators used for the
homogeneous redox catalysis experiments were commercially available
or synthesized as described below.
1
cm-1; H NMR (CDCl3) δ 7.80 and 7.70 (2m, 4H, Pht CH), 3.75 (s,
3H, OMe CH3), 1.85 (s, 6H, Aib CH3).
3-FPht-Aib-OH (3-FPht, 3-fluorophthaloyl). This derivative was
prepared from H-Aib-OH (0.46 g, 4.5 mmol) and the symmetrical
anhydride (3-FPht)2O (1 g, 5.4 mmol) according to the procedure
described for Pht-Aib-OH.30 Yield, 79%: mp 145-146 °C (EtOAc-
petroleum ether); Rf1 ) 0.75; Rf2 ) 0.50; Rf4 ) 0.80; IR (KBr) 1785,
1717 cm-1; 1H NMR (CDCl3) δ 7.70 and 7.35 (2m, 3H, Pht CH), 1.87
(s, 6H, Aib CH3).
Pht-Aib-OOtBu (1a) (Pht, phthaloyl; Aib, R-aminoisobutyric acid).30
With respect to the previously described literature procedure,30 an
improved synthetic protocol was employed. To an ice-cold solution of
Pht-Aib-OH30 (0.40 g, 1.6 mmol) in CH2Cl2 (6 mL), 4-(dimethylamino)-
pyridine (DMAP; 0.20 g, 1.6 mmol) and N-ethyl-N′-dimethylamino-
propylcarbodiimide) hydrochloride (EDC; 0.31 g, 1.6 mmol) were
added, followed by a 5.5 M solution of tert-butyl hydroperoxide in
n-decane (0.29 mL, 1.6 mmol). After stirring for 4 h at room
temperature, the reaction mixture was evaporated to dryness and the
residue dissolved in ethyl acetate (EtOAc). The organic solution was
washed with 10% KHSO4, H2O, 5% NaHCO3 and H2O, dried over
Na2SO4, and evaporated to dryness. The title compound was purified
by silica gel column chromatography (EtOAc-petroleum ether 1:8).
It precipitated as a waxy solid from a EtOAc solution upon addition of
petroleum ether. Yield, 80%: Rf1 ) 0.95; Rf2 ) 0.95; Rf3 ) 0.35; IR
3-FPht-Aib-OMe. This derivative was prepared from 3-FPht-Aib-
OH (1 g, 4.0 mmol) as described above for Pht-Aib-OMe. Yield 76%:
mp 95-96 °C (EtOAc-petroleum ether); Rf1 ) 0.90; Rf2 ) 0.90; Rf3
1
) 0.35; IR (KBr) 1776, 1736, 1710 cm-1; H NMR (CDCl3) δ 7.80
and 7.36 (2m, 3H, Pht CH), 3.76 (s, 3H, OMe CH3), 1.83 (s, 6H, Aib
CH3).
cis-4-Phthaloylaminocyclohexanecarboxylic Acid-OMe (3b). This
compound was prepared from cis-4-phthaloylaminocyclohexanecar-
boxylic acid (0.10 g, 0.37 mmol) as described above for 3a and purified
by flash chromatography (CH2Cl2-EtOH 97:3). Yield, 88%: mp 128-
129 °C (EtOAc-petroleum ether); Rf1 ) 0.90; Rf2 ) 0.90; Rf3 ) 0.30;
IR (KBr) 1765, 1723, 1706 cm-1;1H NMR (CDCl3) δ 7.80 and 7.70
(2m, 4H, Pht CH), 4.15 (m, 1H, cyclohexane CH), 3.76 (s, 3H, OMe
CH3), 2.65 (m, 1H, cyclohexane CH), 2.3 (m, 4H, cyclohexane CH2),
1.65 (m, 4H, cyclohexane CH2).
1
(KBr) 1780, 1719 cm-1; H NMR (CDCl3) δ 7.83 and 7.73 (2m, 4H,
Pht CH), 1.91 (s, 6H, Aib CH3), 1.34 (s, 9H, OOtBu CH3);13C NMR
(CDCl3) δ 169.98 (perester CO), 167.96 (Pht CO), 134.14 (phenyl CH4
and CH5), 131.65 (phenyl CH1 and CH2), 123.18 (phenyl CH3 and CH6),
84.33 (OOtBu quaternary C), 60.25 (Aib quaternary C), 26.14 (OOtBu
CH3), 24.67 (Aib CH3).
cis-4-Phthaloylaminocyclohexanecarboxylic Acid. (Pht)2O (0.26
g, 2.5 mmol) and cis-4-aminocyclohexanecarboxylic acid (0.30 g, 2.1
mmol) were finely ground and then melted at 190 °C. After 15 min,
heating was stopped. The cold reaction mixture was dissolved in a
H2O-triethylamine (pH 8) solution and extracted with diethyl ether.
The aqueous layer was acidified to pH 2 with KHSO4 and extracted
twice with EtOAc. The organic phase was washed with H2O, dried
over Na2SO4, and evaporated to dryness. From this residue, the title
Electrochemical Apparatus and Procedures. N,N-Dimethylfor-
mamide (Carlo Erba, 99.8%) and tetrabutylammonium perchlorate
(Fluka, 99%) were treated as previously described.13 Electrochemical
measurements were conducted in an all-glass cell, thermostated at the
required temperature. An EG&G-PARC 173/179 potentiostat-digital
coulometer, EG&G-PARC 175 universal programmer, Nicolet 3091
12-bit resolution digital oscilloscope, and Amel 863 X/Y pen recorder
were used. The feedback correction was applied to minimize the ohmic
drop between the working and the reference electrodes. The glassy
carbon (Tokai GC-20) electrode was prepared and activated before each
measurement as previously described.13 The electrode area was
determined through the limiting convolution current of ferrocene, the
diffusion coefficient of ferrocene being 1.13 × 10-5 cm2 s-1 in DMF.11
Some experiments were carried out on 3a by using a mercury
microelectrode.13 The reference electrode was Ag/AgCl, calibrated after
each experiment against the ferrocene/ferricenium couple. In the
presence of 0.1 M TBAP, we measured E°Fc/Fc+ to be 0.464 V versus
(43) Other mechanisms have been proposed to be responsible for rate
enhancement at low driving forces. One of them considers the interference
of an inner-sphere component when the ET becomes more endergonic.42
Recently, Jensen and Daasbjerg published very interesting results suggesting
that for some halides the rate could be enhanced at low driving forces
because of a more pronounced SN1-like contribution to the transition-state
structure (Jensen, H. K.; Daasbjerg, K. J. Chem. Soc., Perkin Trans 2 2000,
1251.).
(44) Lorenz, P.; Ru¨chardt, C.; Schacht, E. Chem. Ber. 1971, 104, 3429.
(45) Blomquist, A. T.; Berstein, J. J. Am. Chem. Soc. 1951, 73, 5546.
