10544
P. Bisel et al. / Tetrahedron 60 (2004) 10541–10545
4. Experimental
residue. 3 g of the above residue were separated by means of
silica gel column chromatography eluting with cyclo-
hexane/EtOAc 3:2 yielding four fractions A, B, C, and D.
Fraction D consisted of pure 4a (1.04 g, 31%). Fraction A
consisted of pure 5a (292 mg, 10%). Fraction B was
rechromatographed on silica gel eluting with cyclohexane/
EtOAc 2:1 yielding 5b (170 mg, 6%) and 4c (328 mg, 10%).
Fraction C was rechromatographed on silica gel eluting with
cyclohexane/EtOAc 2:1 yielding 4b (295 mg, 9%).
4.1. General methods
Melting points were determined with a Mel-Temp II
apparatus (Devices Laboratory USA) and are uncorrected.
1H and 13C NMR spectra were recorded at 300 and
75.4 MHz, respectively, on a Varian Unity 300 spectrometer
with chloroform-d and methanol-d4, respectively, as
internal standards. The chemical shifts are reported as d
values using the solvent peaks as reference. Optical
rotations were measured on a Perkin–Elmer 241 polari-
meter. Column chromatography was carried out with Merck
silica gel Si60 (0.2–0.063 mm). TLC was performed on
Si60 F254 TLC plates from Merck. Drying of organic
extracts during the workup of reactions was performed over
anhydrous Na2SO4 with subsequent filtration. Evaporation
of the solvents was accomplished under reduced pressure
with a rotatory evaporator. HRMS (EI, 70 eV) was
performed on a Finnigan MAT 8200 spectrometer at the
Department of Biochemistry and Organic Chemistry,
University of Freiburg.
The amine bases 4a–c were each taken up in ether and
treated with ether–HCl to yield the corresponding hydro-
chlorides in quantitative yields (4a$HCl can be precipitated
directly from the crude oily residue upon treatment with
acetone and ether–HCl).
4.2.1. trans-Ethyl-2-[2(S)-carbamoyl-(2(S)-(1(R)-phenyl-
ethyl)amino)cyclohex-1(R)-yl]ethanoate hydrochloride
(4a$HCl). White solid, mp 200 8C; [a]2D5ZC1.85 (EtOH,
c 1.03); 1H NMR (CD3OD) d 1.22 (t, JZ7.0 Hz, 3H), 1.1–
1.3 (m, 3H), 1.3–1.6 (m, 3H), 1.74 (d, JZ6.7 Hz, 3H), 1.7–
1.8 (m, 1H), 1.9–2.1 (m, 1H), 2.4–2.6 (m, 2H), 2.7–2.80 (m,
1H), 4.13 (q, JZ7.0 Hz, 2H), 4.51 (q, JZ6.7 Hz, 1H), 7.4–
7.5 (m, 3H), 7.6–7.7 (m, 2H); 13C NMR (CD3OD) d 14.5,
20.8, 21.5, 22.4, 25.8, 26.0, 35.7, 38.9, 60.1, 62.1, 71.7,
129.0, 130.4, 130.9, 138.8, 172.4, 173.4; MS (CI, NH3,
45 eV): m/z (%) 333 (100) [MCHC]; HRMS (EI, 70 eV)
calcd for C18H26NO2 [MKCONH2] 288.1963. Found
288.1968.
4.1.1. (RS)-Ethyl 2-(2-oxocyclohex-1-yl)ethanoate (1).
Prepared from cyclohexanone by classical ‘Stork-enamine’
synthesis in a 0.1 M batch (30% yield). For NMR data see
Ref. 10.
4.1.2. E-Ethyl-2-[(2-(1(R)-phenylethyl)imino)cyclohex-
1(RS)-yl]ethanoate (2). A solution of 1 (5.5 g, 30 mmol),
p-toluenesulfonic acid (15 mg) and (R)-1-phenylethylamine
(4.5 g, 37 mmol) in dry benzene was refluxed using a Dean–
Stark apparatus for 16 h. The solvent was removed under
reduced pressure and the residue was dried under high
vacuum to yield the crude ketimine mixture which was used
without further purification in the cyanide addition step. 13C
NMR (CDCl3) d 14.0/14.1, 25.4/25.5, 25.5/25.7, 26.9/27.6,
28.7/28.9, 33.9/34.1, 36.6/36.8, 43.8/44.0, 57.4/57.5, 59.6/
59.7, 125.9/126.0, 126.3/126.3, 127.8/128.0, 146.5/147.0,
169.2/169.9, 173.2/173.4.
4.2.2. trans-Ethyl-2-[2(R)-carbamoyl-(2(R)-(1(R)-phenyl-
ethyl)amino)cyclohex-1(S)-yl] ethanoate hydrochloride
(4b$HCl). White solid, mp 195 8C; [a]2D5ZK22.04 (EtOH,
c 1.00); 1H NMR (CD3OD) d 1.1 (t, JZ7.1 Hz, 3H), 1.4–1.6
(m, 3H), 1.6–1.8 (m, 2H), 1.78 (d, JZ6.8 Hz, 3H), 1.9–2.2 (m,
2H), 2.2–2.4 (m, 1H), 2.45(dd, JZ16.9, 10.7 Hz, 1H), 2.5–2.7
(m, 2H),4.12(q, JZ7.1 Hz, 2H),4.50(q, JZ6.8 Hz, 1H),7.3–
7.4 (m, 3H), 7.4–7.6 (m, 2H);13C NMR(CD3OD) d 14.5, 22.0,
22.5,22.6,27.3,27.5,36.1,39.4,58.8, 62.0, 70.7, 129.6,129.9,
130.5, 138.2, 171.6, 173.7; MS (CI, NH3, 45 eV): m/z (%) 333
(100) [MCHC]; HRMS (EI, 70 eV) calcd for C18H26NO2
[MKCONH2] 288.1963. Found 288.1972.
4.1.3. Ethyl-2-[2(RS)-cyano-(2(RS)-(1(R)-phenylethyl)-
amino)cyclohex-1(RS)-yl]ethanoate (3). To a solution of
the ketimine mixture 2 (8.5 g, 29.6 mmol) and anhydrous
ZnCl2 (200 mg) in MeOH (100 mL), TMSCN (4.4 mL,
35 mmol) was added at 0 8C over a period of 30 min. The
reaction mixture was allowed to warm up to room
temperature and stirred over night. The solids were filtered
off, the solvent was evaporated and the residue was dried to
yield a mixture of the a-amino nitrile mixture 3 (8.9 g, 96%)
which was further reacted without purification.
4.2.3. cis-Ethyl-2-[2(R)-carbamoyl-(2(R)-(1(R)-phenyl-
ethyl)amino)cyclohex-1(R)-yl]ethanoate hydrochloride
(4c$HCl). White solid, mp 210 8C; [a]2D5ZC10.8 (EtOH,
c 1.12); 1H NMR (CD3OD) d 1.12 (t, JZ7.0 Hz, 3H), 1.4–
1.9 (m, 11H with 1.77 (d, JZ6.7 Hz, 3H)), 2.2–2.4 (m, 3H),
4.12 (q, JZ7.0 Hz, 2H), 4.47 (q, JZ6.7 Hz, 1H), 7.3–7.4
(m, 3H), 7.5–7.6 (m, 2H); 13C NMR (CD3OD) d 13.3, 20.8,
21.4, 23.0, 26.2, 28.4, 34.3, 39.0, 58.6, 61.0, 70.9, 128.1,
128.8, 129.2, 138.4, 171.0, 172.6; MS (CI, NH3, 45 eV): m/z
(%) 333 (100) [MCHC]; HRMS (EI, 70 eV) calcd for
C18H26NO2 [MKCONH2] 288.1963. Found 288.1967.
4.2. Hydrolysis of the nitrile mixture 3
A solution of the nitrile mixture 3 (5 g, 16 mmol) in CH2Cl2
(3 mL) was added dropwise to concd H2SO4 (50 mL) at
K20 8C. Stirring was maintained for a period of 3 days. The
reaction mixture was poured onto ice (600 mL) and the
solids filtered off. The filtrate was adjusted to pH 8 with
concd ammonia and extracted with EtOAc (3!150 mL).
The combined organic extracts were washed with water,
brine, dried with MgSO4, filtered, concentrated and finally
dried in high vacuum to yield 4.77 g (89%) of an oily
4.2.4. (1R,2S)-1-((1(R)-Phenylethyl)amino)-cis-3-azabi-
cyclo[4.4.0]decan-2,4-dione (5a). White solid, mp
170 8C; [a]2D5ZC12.5 (EtOH, c 1.00); H NMR (CDCl3)
1
d 1.0–1.4 (m, 7H with 1.28 (d, JZ6.7 Hz, 3H)), 1.4–1.5 (m,
1H), 1.6–1.8 (m, 2H), 1.8–2.0 (m, 1H), 2.18 (dd, JZ18.0,
2.8 Hz, 1H), 2.3–2.4 (m, 1H), 2.97 (dd, JZ17.9, 5.5 Hz,
1H), 4.0 (q, JZ6.7 Hz, 2H) 7.2–7.4 (m, 5H), 7.6 (s br, 1H);
13C NMR (CD3OD) d 23.0, 24.5, 26.6, 30.0, 32.1, 35.2,
