Syntheses and Crystal Structures of Diorganotin Derivatives of
2,5-Dimercapto-1,3,4-thiadiazole
Chunlin Ma,*[a,b] Junhong Zhang,[a] Feng Li,[a] and Rufen Zhang[a]
Keywords: Macrocyclic ligands / N ligands / Oxo ligands / S ligands / Tin
Two novel trinuclear tin oxo clusters [(C2S3N2)R6Sn3O-
(OH)Y]·L [R = CH3, Y = OH, L = 1·5H2O (1); R = PhCH2, Y =
OEt, L = 0 (2)], a pentanuclear tin macrocycle [(CH3)2Sn
(C2N2S3)]5·CH2Cl2·3H2O (3) and [(PhCH2)4Cl2Sn(C2S3N2)]
(4) have been synthesized by the reaction of 2,5-dimercapto-
1,3,4-thiadiazole with dialkyltin dichloride in ethanol (95%)
or dichloromethane. Complexes 1−4 have been characterized
by elemental analysis and IR, 1H, 13C and 119Sn NMR spec-
troscopy. The structures of 1−3 have been determined by X-
ray crystallography. Complexes 1 and 2 display a unique
tricyclic structure consisting of fused five-membered Sn2ON2
and four-membered Sn2O2 rings that form a planar N2Sn3O2
skeleton, with a distorted trigonal bipyramidal coordination
at tin. Complex 3 is a pentanuclear 35-membered tin macro-
cycle containing the crown thioether-type ligand in which all
five tin atoms bond to the sulfur and nitrogen atoms with
distorted octahedral geometries. The structures of complexes
1 and 3 are stabilized by hydrogen bonds or intermolecular
non-bonding S···S interactions.
( Wiley-VCH Verlag GmbH & Co. KGaA, 69451 Weinheim,
Germany, 2004)
Introduction
of H2dmt, with four available donors all of which can be
utilized in bonding in varying combinations, as shown in
Scheme 1),[12] may act as a fulcrum about which lattice con-
struction is orchestrated in two or more dimensions.
Recent developments in coordination chemistry have pro-
duced numerous supermolecular and macrocyclic com-
plexes through the appropriate combination of organomet-
allic complexes and various organic ligands.[1Ϫ6] Organotin
macrocycles are attracting more and more attention for
their potential industrial applications and biological activi-
ties.[7,8] In these metallomacrocyclic systems, ligands with
multiply coordinating donor atoms and particular stereo-
chemistry may lead to different specific architectures. Het-
erocyclic thionate ligands,[5] which contain at least one de-
protonated heterocyclic thioamide group (NϪCϪS)Ϫ and
can act as monodentate, chelating or bridging ligands are
particularly important.[9] In our previous work, we studied
the ligand 2-mercaptonicotinic acid (Hmnc), which pos-
sesses one deprotonated heterocyclic thioamide group
(NϪCϪS)Ϫ, and found that the primary bond of the ligand
to the tin atoms occurs through sulfur rather than through
nitrogen. Moreover, different coordination patterns of the
ligand in the thiolic form have been found.[10,11]
Scheme 1. Tautomeric forms of H2dmt
In our previous work we reported a pentanuclear tin
macrocycle[13] in which the coordination of H2dmt is
through two sulfur atoms of the thiol (a) rather than the
thione (c) tautomer. While continuing our research on other
diorganotin complexes of H2dmt, we surprisingly obtained
four novel complexes [(C2S3N2)(CH3)6Sn3O(OH)2]·1.5H2O
(1), [(C2S3N2){(PhCH2)6Sn3O(OH)(OEt)}] (2) [(CH3)2Sn-
To continue our study in this field, we chose another li-
gand: 2,5-dimercapto-1,3,4-thiadiazole (H2dmt), which pos-
sesses a more complex deprotonated heterocyclic thioamide
group (SϪCϪNϪNϪCϪS)2Ϫ than Hmnc. The heterocycle
(C2N2S3)]5·CH2Cl2·3H2O
(3)
and
[(PhCH2)2ClSn-
(SϪC2SN2ϪS)SnCl(PhCH2)2] (4). It is worthwhile to note
that complexes 1 and 3 were obtained by the same reactants
in different solvents, and the complexes 2 and 4 were ob-
tained by the same reactants in different solvents, too, and
that H2dmt shows different coordination to the tin()
atom. All four complexes 1Ϫ4 were characterized by
[a]
Department of Chemistry, Liaocheng University,
Liaocheng 252059, P. R. China
Fax: ϩ86-538-671-5521
E-mail: macl@lctu.edu.cn
[b]
Department of Chemistry, Taishan University,
1
Taian 271021, P. R. China
elemental analysis and IR, H, 13C and 119Sn NMR spec-
Eur. J. Inorg. Chem. 2004, 2775Ϫ2783
DOI: 10.1002/ejic.200300860
 2004 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
2775

C. Ma, J. Zhang, F. Li, R. Zhang
FULL PAPER
troscopy and the structures of 1, 2 and 3 were determined of the R groups, the more difficult the substitution of the
by X-ray crystallography.
chlorine atoms.[16]
Description of the Structures
[(C2S3N2)(CH3)6Sn3O(OH)2]·1.5H2O (1) and
[(C2S3N2)(PhCH2)6Sn3O(OH)(OEt)] (2)
Results and Discussion
The molecular structures and unit cells of complexes 1
(Figure 1 and 2) and 2 (Figure 3 and 4) are shown below;
selected bond lengths and angles are collected in Table 1
and 2, respectively. Like other trinuclear organotin oxo clus-
ters,[17] complex 1 contains a tricyclic system formed by an
N2Sn2O ring and two Sn2O2 rings, in which the
N2Sn3O(OH)2 structural motif is almost planar with a
Complexes 1Ϫ4 were prepared by the reaction of dimeth-
yltin dichloride or dibenzyltin dichloride with 2,5-dimer-
capto-1,3,4-thiadiazole in either EtOH (95%) or CH2Cl2.
The reaction procedures are shown in Scheme 2.
˚
mean deviation of Ϯ0.0452 A. All three tin atoms show
severely distorted trigonal bipyramidal configurations.
Scheme 2
When the reaction solvent is EtOH (95%), the complexes
1 and 2 were obtained. In view of the results of our present
studies[10,14] and those of earlier work,[15] the possible
mechanism of formation of complexes 1 and 2 is as follows.
Firstly, a hydrolysis reaction of R2SnCl2 occurs to form
R2(Cl)Sn(OH), which is then further hydrolyzed to produce
[R2(OH)SnY] (Y ϭ OH or OEt). Two R2(Cl)Sn(OH) mol-
ecules then condense to form [R2(Cl)Sn]2O, which then re-
acts with [R2(OH)SnY] to produce [R6Sn3O(Cl)2(OH)Y].[14]
Finally, the two chlorine atoms of [R6Sn3O(Cl)2(OH)Y] are
substituted by two nitrogen atoms of the sodium salt of
H2dmt [Na2(C2N2S3)] to produce the title complexes 1 and
2. As shown in Scheme 2, the H2dmt acts as tautomer c,
bonding to tin() through two nitrogen atoms in both com-
plexes 1 and 2.
Figure 1. Molecular structure of complex 1; ellipsoids at 30% prob-
ability
When the reaction solvent was replaced by CH2Cl2 we
obtained complexes 3 and 4. In this case the hydrolysis of
R2SnCl2 does not occur and the ligand coordinates to the
tin() center, through two sulfur atoms, as the thiol tau-
tomer (a).
Moreover, in complex 4, the spatial resistances of two
benzyl groups are strong enough to prevent another H2dmt
ligand chelating to the central tin atom, which is well con-
sistent with the sequence of steric constraints phenyl ഠ
benzyl Ͼ n-butyl Ͼ methyl: the larger the steric constraint Figure 2. Unit cell of complex 1
2776  2004 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim www.eurjic.org
Eur. J. Inorg. Chem. 2004, 2775Ϫ2783

Diorganotin Derivatives of 2,5-Dimercapto-1,3,4-thiadiazole
FULL PAPER
Figure 3. Molecular structure of complex 2; ellipsoids at 30% probability
Sn(1) and Sn(3) have the same environment, where one µ3-
O atom and two C atoms of the methyl groups occupy the
equatorial positions [C(3), C(4) and O(2) for Sn(1); C(7),
C(8) and O(2) for Sn(3)], and the axial positions are occu-
pied by one N atom of the H2dmt and one O atom of the
hydroxyl group [N(1) and O(1) for Sn(1); N(2) and O(3) for
Sn(3)]. The geometry of Sn(2) is cis-R2SnO3, in which the
axial positions are occupied by the O(3) and O(1) atoms of
hydroxyl groups, and two C(5) and C(6) atoms of methyl
groups and one µ3-O(2) atom occupy the equatorial plane.
The distortion of the axial angles is very large at the three
tin atoms [O(1)ϪSn(1)ϪN(1) 150.4(2)°, O(3)ϪSn(3)ϪN(2)
150.0(2)° and O(3)ϪSn(2)ϪO(1) 144.1(2)° respectively]
compared to the ideal angle of 180°.
With regard to the hydrolysis, three [(CH3)2Sn] units are
bridged by one µ3-O atom and two O atoms of hydroxyl
groups, and thus form a trinuclear complex containing two
Sn2O2 rings. Three Sn atoms and three O atoms [Sn(1),
Sn(3), O(2), Sn(2), O(1), O(3)] comprise a fused ring system
and are nearly coplanar, with a mean deviation of Ϯ0.0326
˚
Figure 4. Unit cell of complex 2
A, which is similar to traditional hydrolytic products with a
ladder-type arrangement,[18] but different from the staircase
structure of [Me4Sn2(OSiMe3)2O]2.[19] The SnϪO distances
between µ3-O atom and the tin atoms are similar
˚
˚
[Sn(3)ϪO(2) 2.037(5) A, Sn(2)ϪO(2) 2.051(5) A and the two rings is 1.2°, which indicates that all the atoms of
˚
Sn(1)ϪO(2) 2.032 (5) A], but other SnϪO lengths between the two rings are almost planar. The SnϪN bond lengths
˚
˚
the O atoms of the hydroxyl and the tin atoms [Sn(1)ϪO(1) [Sn(1)ϪN(1) 2.274(6) A and Sn(3)ϪN(2) 2.246(7) A] are
˚
˚
˚
2.150(5) A, Sn(2)ϪO(1) 2.106(5) A, Sn(2)ϪO(3) 2.094(6) A, similar to the sum of the covalent radii of Sn and N (2.15
˚
˚
Sn(3)ϪO(3) 2.129(6) A] are slightly longer, and similar to A) and much shorter than the sum of the van der Waals
[21]
˚
the SnϪO bonds in the ladder structure [Me2Cl- radii of tin and nitrogen atoms (3.74 A),
which proves
[20]
˚
SnOSnMe2Cl]2 [2.115(9) A].
All of the above indicates that the nitrogen atoms coordinate to tin by strong chemical
that a strong oxo bridge exists in complex 1.
The two nitrogen atoms of the H2dmt ligand, which is a A, S(3)ϪC(2) 1.668(10) A] are similar to those in thiourea
five-membered ring, bond to tin atoms to form another (1.681 A),
bonds. Furthermore, the CϪS bonds [S(2)ϪC(1) 1.701(10)
˚
˚
[22]
˚
suggesting that they are CϭS double bonds
five-membered N2Sn2O ring. The dihedral angle between and therefore retain the thione form. All of above proves
