Rh2(S-1,2-NTTL)4: A Novel Rh2(S-PTTL)4 Analog With Lower Ligand
Symmetry for Asymmetric Synthesis of Chiral
Cyclopropylphosphonates
*
FRADY G. ADLY, JOHNCARLO MADDALENA, AND ASHRAF GHANEM
Chirality Program, University of Canberra, ACT, Australia
ABSTRACT
A new series of dirhodium(II) tetracarboxylate was derived from N-1,2-
naphthaloyl-(S)-amino acid ligands. In terms of enantioselectivity, Rh2(S-1,2-NTTL)4 (3a)
derived from N-1,2-naphthaloyl-(S)-tert-leucine, was the best-performing catalyst among the
new series in the enantioselective synthesis of cyclopropylphosphonate derivatives (up to
>99% enantiomeric excess). A predictive model was proposed to justify the observed high enan-
tiomeric induction exhibited by Rh2(S-1,2-NTTL)4 with donor-acceptor phosphonate carbenoids.
Chirality 00:000–000, 2014. © 2014 Wiley Periodicals, Inc.
KEY WORDS: dirhodium; cyclopropanation; cyclopropylphosphonate; Rh2(S-PTAD)4; Rh2
(S-NTTL)4; Rh2(S-PTTL)4; metal carbenoids; paddlewheel complexes
INTRODUCTION
and development of new methods utilizing stereoselective
cyclopropanation reactions is highly desirable. Accordingly,
a great deal of effort has been devoted to render the
stereoselective synthesis of substituted cyclopropanes more
appealing to organic chemists.27,28
Remarkable progress in dirhodium(II) complex catalyzed
asymmetric transformations has been achieved in a number
of processes including cyclopropanation and C-H insertion30
and was recently supported by the generation and exploration
of physical and chemical properties of a metastable Rh2-
The chiral cyclopropyl moiety has played an important role
in organic chemistry for decades.1–6 Of particular interest,
cyclopropylphosphonate derivatives have been extensively
studied during the last decade as they display several interesting
biological activities.7 For instance, they have been used as moie-
ties of nucleotides,8 as herbicides or plant growth regulators,9
and as insecticides.10 They were also used as analogs of the an-
tidepressant Milnacipran,11 as mimics of 1-aminocyclopropane
carboxylic acid (ACC) with a high inhibitory activity for ACC-
deaminase and alanine racemase,12,13 as analogs of the
unusual amino acids (–)-allonorcoronamic acid14 and (Z)-2,3-
methanohomoserine15 and as an analog of the GABAB receptor
antagonist phaclophen.16 Furthermore, cyclopropylphoshonates
can act as N-methyl-D-aspartate (NMDA) receptor antagonists.17
They also possess antiproliferation properties,18 and are
virostatics,19 antidiabetics,20 antitumor agents,21 selective anti-
HBV agents,22 cytostatic agents,23 and display antiviral activity.24
Typically, enantiomerically enriched compounds are pro-
duced either by chemical transformation of an enantiomerically
enriched precursor—derived from natural chiral pools or by
the separation of racemic mixtures. However, these approaches
have drawbacks: while the former requires stoichiometric
quantities of a suitable precursor, the latter yields only up to
50% of the desired enantiomer. On the other hand, asymmetric
catalysis, which consists of metal complexes with chiral
ligands, have demonstrated vital possible merits over these
conventional procedures whereby a single molecule of the
chiral catalyst can return many equivalents of molecules of
the chiral product for ending catalyst molecule.25,26
carbenoid intermediate supported by
a donor-acceptor
carbene fragment.31 Efforts in this area have led to the devel-
opment of a family of dirhodium(II) carboxylate complexes
that are derived from N-protected amino acids (Fig. 1). The
development in this family of dirhodium paddlewheel
catalysts mainly focused on modifications of the electronic
and/or the steric properties of the ligands, as different
bridging ligands coordinated to the dirhodium axes can
offer distinct degrees of charges to the metal.25 Conse-
quently, it is possible to control the electronic profile of the
whole catalyst by changing these ligands. For instance, the
Hashimoto and Ikegami group developed a series of N-
phthaloyl protected amino acids as ligands for dirhodium
complexes (Fig. 1),25,32,33 with the tert-leucine derived
catalyst Rh2(S-PTTL)4 giving the highest asymmetric induc-
tion.34–40 This has been further developed by the same group
and others to include many other analogs.25,41–44 Müller et al.
used the same scaffold and emerged with Rh2(S-NTTL)4 as a
catalyst derived from N-1,8-naphthaloyl-(S)-tert-leucine.29,45,46
Rh2(S-PTTL)4 and Rh2(S-NTTL)4 proved to be superior cata-
lysts for the preparation of chiral cyclopropanes; however,
none can be considered as a universal catalyst affording high
enantiomeric induction with different classes of substrates
and under different reaction conditions. This limitation has
During the last decade, new methods for the
stereoselective synthesis of highly functionalized cyclopro-
panes have been extensively developed.27,28 Among these
methods, transition-metal-catalyzed cyclopropanation of
olefins with diazoesters occupies a prominent position in the
field of asymmetric catalysis (Scheme 1). Once this principle
was demonstrated, highly selective catalysts were developed,
mainly based on CuI and RhII associated with appropriate
chiral nonracemic ligands.29 However, to enhance the syn-
thetic potential of cyclopropanes further, the understanding
© 2014 Wiley Periodicals, Inc.
*Correspondence to: A. Ghanem, Building 3, Room D41, University of
Canberra, ACT, 2601, Australia. E-mail: ashraf.ghanem@canberra.edu.au
Received for publication 4 January 2014; Accepted 1 May 2014
DOI: 10.1002/chir.22349
Published online in Wiley Online Library
(wileyonlinelibrary.com).

ADLY ET AL.
Scheme 1. Metal catalyzed decompositions of donor-acceptor diazo
compounds.
Fig. 2. Ligands backbone structure comparison.
Hashimoto catalytic series along with the horizontal naphtha-
lene rings of Müller catalytic series (Fig. 2).
MATERIALS AND METHODS
Chemicals
All starting materials and reagents were purchased from Sigma-Aldrich
(St. Louis,, MO) and Acros Organics (Morris Plains, NJ) and used with-
out any further purification. 1,2-Napthalic anhydride was purchased from
Tokyo Chemical Industry (TCI). All solvents were of high-performance
liquid chromatography (HPLC) grade and dried and distilled immediately
prior to use: dichloromethane over calcium hydride, 2,2-DMB, n-pentane
and toluene over activated 4Å-MS, and chlorobenzene from potassium
hydroxide. All moisture-sensitive reactions were performed using oven-
dried glassware and flame dried under vacuum prior to use. Thin-layer
chromatography (TLC) was performed using Sigma-Aldrich precoated
silica gel 60 F254 aluminum support (20 x 20 cm, layer thickness 0.2 mm)
and spots were visualized using UV light (254 nm). Preparative TLC separa-
tions were performed using Sigma-Aldrich precoated silica gel 60 F254
glass support (20 x 20 cm, layer thickness 0.25 mm). Column chromatogra-
phy was carried out on silica gel 60 (130-270 mesh ASTM, Sigma-Aldrich)
52
53
using the specified eluents. Rh2(S-PTTL)4 and Rh2(S-NTTL)4 were
prepared according the previously published procedures.
Instruments
Melting points were measured on a Stuart-SMP10 melting point appara-
tus and are uncorrected. IR was measured on a Perkin-Elmer (Boston,
MA) TravelIR FT-IR spectrometer. Nuclear magnetic resonance (NMR)
spectra were recorded on Varian (Palo Alto, CA) 400-MR spectrometer
at room temperature in the solvents given. Chemical shifts were
expressed in parts per million (ppm) and reported either relative to an
internal tetramethylsilane standard (TMS δ = 0.0 or relative to solvent
peaks (CDCl3 δ = 7.2, HOD δ = 4.8, DMSO-d6 δ = 2.5) for 1H and (CDCl3
δ = 77.0, DMSO-d6 δ; = 39.5) for 13C. Multiplicities are denoted as follows:
s = singlet, d = doublet, t = triplet, q = quartet, dd = double doublet, ddd =
double double doublet, m = multiplet, br = broad, apt = apparently.
Coupling constants (J) are reported in Hz. Mass spectra were obtained
on Finnigen mat LCQ MS/MS ESI spectrometer and AB MDS Sciex
4800 MALDI-TOF-TOF Mass Analyzer.
Fig. 1. Chiral dirhodium tetracarboxylates derived from N-protected
amino acids.25
led to the development of other promising catalysts belonging
to the same family, Rh2(S-PTAD)4 and Rh2(S-TCPTAD)4,
derived from N-protected adamantylglycine47–49 to access
enantiomerically pure/enriched cyclopropane derivatives.
But, unfortunately, the relatively long synthetic routes of
these catalysts may ruin their overall appeal.50 Therefore,
the development of both synthetically accessible and highly
stereoselective chiral dirhodium catalysis is still highly
desirable.
As a part of our group’s ongoing research and guided by
our previous findings on the nature of the chiral crown cavity
complexes,29,51 we are continuing to pursue variations to the
heterocyclic tether protecting the amine functionality. All
previous reports used to use symmetrical N-protecting
groups in the preparation of the chiral ligands. Herein, the
effect of lowering the symmetry of the N-protecting group
on the enantiomeric induction of the catalyst is the foundation
of this article. A new catalytic series was built derived from
chiral N-protected 1,2-naphthaloyl amino acid ligands at
which the ligands can retain the N-phthaloyl rings of the
Chirality DOI 10.1002/chir
HPLC Analysis
The HPLC analysis was carried out at 25oC using a Prominence
Shimadzu System that consists of LC-20AD solvent delivery unit, SPD-
M20A photodiode-array detector, SIL-20AHT autosampler, and CTO-20A
column oven. For data processing, LabSolutions data managing software,
v. 5.54 SP2 was utilized. Chiralpak AD (0.46mm x 250mm), Chiralcel OJ
(0.46mm x 250mm) and Chiralpak IB (0.46mm x 250mm) were obtained
from Daicel Chemical Company (Tokyo, Japan). HPLC-grade n-hexane,
ethyl acetate and 2-propanol were obtained from Scharlau Chemie
(Barcelona, Spain). Chiral HPLC separation conditions were determined
by obtaining a separation of a racemic sample and by applying previously
reported parameters if any. Refer to supporting information for more details.
Synthesis of Dirhodium Complexes
General procedure for carboxylate ligands preparation. To
a
mixture of 1,2-naphthalic anhydride (1.1 equiv.) and the L-amino acid
(1 equiv.) in anhydrous toluene, triethylamine (0.1 equiv.) was added

ASYMMETRIC SYNTHESIS OF CHIRAL CYCLOPROPYLPHOSPHONATES
and the mixture was heated to reflux for 12 h under nitrogen atmosphere.
J = 8.4 Hz, Ar-H), 8.38 (d, 1H, J = 8.2 Hz, Ar-H), 8.14 (d, 1H, J = 8.2 Hz,
Ar-H), 7.88-7.69 (m, 3H, Ar-H), 6.94 (apt d, 2H, J = 8.5 Hz, Ar-H), 6.51
(apt d, 2H, J = 8.5 Hz, Ar-H), 5.01 (dd, 1H, J = 11.6, 4.8 Hz, NCH), 3.40-
3.25 (m, 3H, CH2, OH); 13C NMR (100 MHz, DMSO-d6): δ 170.3 (COOH),
168.4, 167.5 (2 x CON), 155.8, 136.4, 135.9, 130.3, 130.1, 129.6, 129.2,
129.1, 127.3, 127.0, 125.9, 123.7, 118.4, 115.1 (16 x Ar-C), 53.3 (NCH),
33.2 (CH2); IR (film) ν 3437, 3243, 2943, 1734, 1686, 1387, 1225, 772,
675 cm-1; MS (ESI) m/z: 359.9 (C21H14NO–5; calc. 360.1), 210.2
(C21H14NO–5 - CO2 - C7H6O; calc. 210.1). Re-crystallized from hot MeOH.
The mixture was diluted with ethyl acetate, washed with 0.1M hydrochlo-
ric acid solution, dried over anhydrous Na2SO4, filtered, and concentrated
in vacuo. The residue was then purified on silica gel column chromatog-
raphy using ethyl acetate: n-hexane as an eluent. The amounts of 1,2-
naphthalic anhydride and L-amino acids are presented in that order.
N-(1,2-Naphthaloyl)-(S)-tert-Leucine (S-1,2-NTTL, 1a). 1,2-Naphthalic
anhydride (0.650 g, 3.28 mmol), L-tert-Leucine (0.391 g, 2.98 mmol); Yellow
oil (0.825 g, 89%); Rf =0.38 (1:3 ethyl acetate: n-hexane); 1H NMR (400
MHz, CDCl3): δ 9.47 (br s, 1H, COOH), 8.79 (d, 1H, J=8.1 Hz, Ar-H), 8.03
(d, 1H, J=8.3 Hz, Ar-H), 7.81 (d, 1H, J=8.1 Hz, Ar-H), 7.74 (d, 1H, J=8.2
Hz, Ar-H), 7.58-7.52 (m, 2H, Ar-H), 4.68 (s, 1H, NCH), 1.12 (s, 9H, C(CH3)
3); 13C NMR (100 MHz, CDCl3): δ 172.8 (COOH), 168.0, 167.5 (2 x CON),
135.6, 134.2, 129.8, 128.5, 127.8, 127.6, 126.9, 125.9, 123.9, 117.5 (10 x Ar-C),
58.7 (NCH), 34.6 (C(CH3)3), 26.9 (C(CH3)3); IR (film) ν 3231, 2922, 1751,
1698, 1374, 1104, 1014, 796, 766, 725, 662 cm-1; MS (ESI) m/z: 309.9
(C18H16NO–4; calc. 310.1), 266.0 (C18H16NO–4 - CO2; calc. 266.1), 209.2
(C18H16NO–4 - CO2 - C4H9; calc. 209.1).
General Procedure for Ligand Exchange
A mixture of the carboxylate ligand (6 equiv.) and dirhodium acetate
(1 equiv.) in dry chlorobenzene was refluxed for 24 h under nitrogen
atmosphere using a soxhelt extractor fitted with a thimble containing a
dry mixture of Na2CO3 and sand (1:1) for the removal of acetic acid. After
this, the solvent was evaporated in vacuo and the residue was dissolved in
CH2Cl2, washed with saturated NaHCO3, dried over anhydrous Na2SO4,
filtered, and concentrated in vacuo. The green residue was then purified
on silica gel column chromatography using ethyl acetate: n-hexane as an
eluent. Products were dried overnight under vacuum at 50oC. The
amounts of carboxylate ligand and dirhodium acetate are presented in
that order.
N-(1,2-Naphthaloyl)-(S)-Phenylalanine (S-1,2-NTPA, 1b). 1,2-
Naphthalic anhydride (0.5 g, 2.52 mmol), L-Phenylalanine (0.35 g, 2.10
mmol); Pale yellow solid (0.65 g, 89%); mp 182oC; Rf = 0.20 (1:2 ethyl
1
acetate: n-hexane); H NMR (400 MHz, CDCl3): δ 8.85 (d, 1H, J= 8.3 Hz,
Ar-H), 8.12 (d, 1H, J = 8.2 Hz, Ar-H), 7.92 (d, 1H, J = 8.1 Hz, Ar-H), 7.78 (d,
1H, J = 8.3 Hz, Ar-H), 7.66 (dt, 2H, J= 14.9, 6.9 Hz, Ar-H), 7.38-7.00 (m, 5H,
Ar-H), 5.27 (dd, 1H, J = 9.3, 6.9 Hz, NCH), 3.74-3.52 (m, 2H, CH2); 13C
NMR (100 MHz, CDCl3): δ 174.3 (COOH), 168.6, 167.9 (2 x CON), 136.6,
136.5, 135.1, 130.8, 129.5, 128.8, 128.7, 128.6, 127.9, 126.9, 124.9, 118.5 (16
x Ar-C), 52.9 (NCH), 34.5 (CH2); IR (film) ν 3327, 2943, 1701, 1375, 1287,
769, 700 cm-1; MS (ESI) m/z: 343.9 (C21H14NO–4; calc. 344.0), 299.9
(C21H14NO–4 - CO2; calc. 300.1), 209.1 (C21H14NO–4 - CO2 - C7H7; calc.
209.0). Re-crystallized from hot MeOH.
Dirhodium(II,II) tetrakis[N-(1,2-naphthaloyl)-(S)-tert-Leucinate]
(Rh2(S-1,2-NTTL)4, 3a). Ligand (0.69 g, 2.23 mmol), Rh2(OAc)4
(0.17 g, 0.38 mmol); green solid (0.36 g, 65%); Rf = 0.54 (1:2 ethyl acetate:
n-hexane); 1H NMR (400 MHz, CDCl3): δ 8.84 (br s, 4H, Ar-H), 7.92 (br s,
4H, Ar-H), 7.74 (br s, 8H, Ar-H), 7.52 (br s, 8H, Ar-H), 4.92 (s, 4H, 4 x
NCH), 1.1 (s, 36H, 4 x C(CH3)3); 13C NMR (100 MHz, CDCl3): δ 186.2
(COO), 167.3 (CON), 135.3, 133.5, 130.1, 128.2, 127.3, 126.9, 126.1,
124.3, 117.6 (Ar-C), 60.3 (NCH), 34.8 (C(CH3)3), 27.0 (C(CH3)3); IR (film)
ν 2958, 1707, 1610, 1396, 1366, 1341, 1105, 783, 765 cm-1; HRMS (MALDI-
TOF) m/z: 1661.2025 (C72H61N4O16Rh2 + K+ + 2EtOAc, calc. 1661.4481),
1645.2306 (C72H61N4O16Rh2 + Na+ + 2EtOAc, calc. 1645.3395), 1485.1979
(C72H61N4O16Rh2 + K+, calc. 1485.3433), 1469.2275 (C72H61N4O16Rh2 +
Na+, calc. 1469.2347).
N-(1,2-Naphthaloyl)-(S)-Leucine (S-1,2-NTLU, 1c). 1,2-Naphthalic
anhydride (0.5 g, 2.52 mmol), L-Leucine (0.3 g, 2.29 mmol); Pale yellow
solid (0.64 g, 90%); mp 138-139oC; Rf = 0.22 (1:3 ethyl acetate: n-hexane);
1H NMR (400 MHz, CDCl3): δ 10.94 (br s, 1H, COOH), 8.78 (d, 1H,
J = 8.3 Hz, Ar-H), 8.03 (d, 1H, J = 8.2 Hz, Ar-H), 7.81 (d, 1H, J = 8.1 Hz,
Ar-H), 7.73 (d, 1H, J = 8.2 Hz, Ar-H), 7.56 (dt, 2H, J = 24.8, 7.0 Hz, Ar-H),
4.94 (dd, 1H, J = 11.5, 4.3 Hz, NCH), 2.32 (ddd, 1H, J = 14.8, 11.0, 4.1 Hz,
CH2), 1.89 (ddd, 1H, J = 14.4, 10.2, 4.4 Hz, CH2), 1.52-1.41 (m, 1H, CH
(CH3)2), 0.86 (dd, 6H, J = 13.3, 6.6 Hz, CH(CH3)2); 13C NMR (100 MHz,
CDCl3): δ 175.2 (COOH), 167.8, 167.3 (2 x CON), 135.6, 134.1, 129.9,
128.5, 127.8, 127.6, 126.9, 126.0, 123.9, 117.5 (10 x Ar-C), 49.3 (NCH),
36.1 (CH2), 24.0 (CH(CH3)2), 22.0, 19.9 (2 x CH(CH3)2); IR (film) ν
2968, 1705, 1373, 1276, 764, 655 cm-1; MS (ESI) m/z: 309.9 (C18H16NO4–;
Dirhodium(II,II) tetrakis[N-(1,2-naphthaloyl)-(S)-Phenylalaninate]
(Rh2(S-1,2-NTPA)4, 3b). Ligand (0.5 g, 1.45 mmol), Rh2(OAc)4
(0.11 g, 0.24 mmol); green solid (0.25 g, 63%); Rf = 0.28 (1:1 ethyl ace-
tate: n-hexane); 1H NMR (400 MHz, CDCl3): δ 7.98 (d, 4H, J = 8.1 Hz,
Ar-H), 7.82 (d, 4H, J = 7.4 Hz, Ar-H), 7.71 (d, 4H, J = 8.3 Hz, Ar-H),
7.57 (m, 8H, Ar-H), 7.35-6.99 (m, 24H, Ar-H), 5.37 (dd, 4H, J = 11.4,
4.7 Hz, 4 x NCH), 3.73-3.50 (m, 8H, 4 x CH2); 13C NMR (100 MHz,
CDCl3):
δ 188.5 (COO), 168.4, 167.9 (CON), 137.9, 136.5, 135.0,
131.1, 129.4, 128.6, 128.5, 128.0, 127.2, 126.6, 125.3, 118.8 (Ar-C), 54.6
(NCH), 35.7 (CH2); IR (film) ν 2944, 1734, 1716, 1373, 1229, 770, 697
cm-1; HRMS (ESI-TOF) m/z: 1721.2692 (C84H60N4O16Rh2 + 2Acetone +
Na+, calc. 1721.2536), 1663.2191 (C84H60N4O16Rh2 + Acetone + Na+, calc.
1663.2118), 1646.2117 (C84H60N4O16Rh2 + H2O + 2Na+, calc. 1646.1702),
1606.1798 (C84H60N4O16Rh2 + Na+ + H+, calc. 1606.1777).
calc. 310.1), 266.0 (C18H16NO–4 - CO2; calc. 266.1), 209.2 (C18H16NO–4
CO2 - C4H9; calc. 209.1). Re-crystallized from hot MeOH.
-
N-(1,2-Naphthaloyl)-(S)-Tryptophan (S-1,2-NTTR, 1d). 1,2-Naphthalic
anhydride (0.5 g, 2.52 mmol), L-Tryptophan (0.47 g, 2.29 mmol); Yellow solid
(0.83 g, 85%); mp 238-239oC; Rf =0.51 (1:1 ethyl acetate: n-hexane); 1H NMR
(400 MHz, DMSO-d6): δ 13.3 (br s, 1H, COOH), 10.71 (s, 1H, NH), 8.68 (d,
1H, J=8.3 Hz, Ar-H), 8.34 (d, 1H, J=8.3 Hz, Ar-H), 8.11 (d, 1H, J=8.2 Hz,
Ar-H), 7.81-7.69 (m, 3H, Ar-H), 7.51 (d, 1H, J=7.9 Hz, Ar-H), 7.22 (d, 1H,
J=8.1 Hz, Ar-H), 7.06 (d, 1H, J=2.3 Hz, Ar-H), 6.96 (t, 1H, J=7.5 Hz, Ar-H),
6.87 (t, 1H, J=7.4 Hz, Ar-H), 5.14 (dd, 1H, J= 10.3, 5.6 Hz, NCH), 3.71-3.51
(m, 2H, CH2); 13C NMR (100 MHz, DMSO-d6): δ 170.9 (COOH), 168.9,
168.1 (2 x CON), 136.6, 136.4, 136.2, 130.9, 130.5, 129.6, 129.4, 127.4, 127.4,
126.4, 124.1, 123.8, 121.3, 118.8, 118.3, 111.8, 110.3 (18 x Ar-C), 53.1 (NCH),
24.6 (CH2); IR (film) ν 3458, 3317, 2917, 1700, 1380, 1282, 769, 740 cm-1;
MS (ESI) m/z: 382.9 (C23H15N2O–4; calc. 383.1), 339.2 (C23H15N2O4– - CO2;
calc. 339.1), 210.2 (C23H15N2O4– - CO2 - C9H7N; calc. 210.1). Re-crystallized
from hot MeOH.
Dirhodium(II,II) tetrakis[N-(1,2-naphthaloyl)-(S)-Leucinate] (Rh2
(S-1,2-NTLU)4, 3c). Ligand (0.5 g, 1.60 mmol), Rh2(OAc)4 (0.12 g,
0.27 mmol); green solid (0.166 g, 61 %); Rf = 0.69 (1:2 ethyl acetate: n-
hexane); 1H NMR (400 MHz, CDCl3): δ 8.90 (d, 4H, J = 7.8 Hz, Ar-H),
8.22-7.95 (m, 4H, Ar-H), 7.95-7.73 (m, 8H, Ar-H), 7.73-7.43 (m, 8H, Ar-H),
5.02 (br s, 1H, 4 x NCH), 2.23 (br s, 4H, 2 x CH2), 2.03 (br s, 4H, 2 x
CH2), 1.50 (br s, 4H, 4 x CH(CH3)2), 1.01 (br s, 12H, 2 x CH(CH3)2),
0.93 (br s, 12H, 2 x CH(CH3)2); 13C NMR (100 MHz, CDCl3): δ
188.9 (COO), 168.5, 168.0 (CON), 136.3, 134.5, 131.2, 129.1, 128.5,
128.4, 128.0, 127.9, 127.2, 125.2, 118.7, 118.6 (Ar-C), 51.8 (NCH),
38.2, 38.0 (CH2), 25.1 (CH(CH3)2), 23.4, 21.4, 21.3 (CH(CH3)2); IR
(film) ν 2954, 1734, 1716, 1374, 1229, 770, 675 cm-1; HRMS (MALDI-
TOF) m/z: 1661.2783 (C72H61N4O16Rh2 + K+ + 2EtOAc, calc. 1661.4481),
1645.3109 (C72H61N4O16Rh2 + Na+ + 2EtOAc, calc. 1645.3395), 1485.2178
(C72H61N4O16Rh2 + K+, calc. 1485.3433), 1469.2975 (C72H61N4O16Rh2 +
Na+, calc. 1469.2347).
N-(1,2-Naphthaloyl)-(S)-Tyrosine (S-1,2-NTTY, 1e). 1,2-Naphthalic
anhydride (0.5 g, 2.52 mmol), L-Tyrosine (0.42 g, 2.29 mmol); Yellow
solid (0.74 g, 90%); mp 248-249oC; Rf = 0.25 (1:1 ethyl acetate: n-hexane);
1H NMR (400 MHz, DMSO-d6): δ 9.11 (br s, 1H, COOH), 8.70 (d, 1H,
Chirality DOI 10.1002/chir

ADLY ET AL.
Dirhodium(II,II) tetrakis[N-(1,2-naphthaloyl)-(S)-Tryptophanate]
0.46 cm, 1% 2-propanol in n-hexane (v/v%); 2 mL/min, 220 nm, τ1 = 36
min, τ2 = 42 min).
(Rh2(S-1,2-NTTR)4, 3d). Ligand (0.73 g, 1.90 mmol), Rh2(OAc)4
(0.14 g, 0.32 mmol); green solid (0.30 g, 55 %); Rf = 0.20 (2:1 ethyl acetate:
n-hexane); H NMR (400 MHz, DMSO-d6): δ 10.75 (s, 4H, 4 x NH), 8.50
1
(1S,2R)-Diethyl 1,2-diphenylcyclopropylphosphonate (10)55
. Color-
less oil; Rf = 0.26 (1:1 ethyl acetate: n-hexane); Enantiomer separation by
HPLC (Chiralpak AD column, 25 x 0.46 cm, 0.6% 2-propanol in n-hexane
(v/v%); 0.8 mL/min, 220 nm, τ1 =69 min, τ2 = 76 min). The spectroscopic data
are consistent with previously reported data.55
(m, 4H, Ar-H), 8.31 (br s, 4H, Ar-H), 8.07 (br s, 4H, Ar-H), 7.80-7.41 (m,
12H, Ar-H), 7.25 (d, 4H, J = 7.8 Hz, Ar-H), 7.17-6.69 (m, 16H, Ar-H), 5.27
(br s, 4H, 4 x NCH), 3.57 (br s, 8H, 4 x CH2); IR (film) ν 2970, 1734,
1699, 1374, 1228, 768, 740 cm-1; MS (ESI) m/z: 1760.6 (C92H60N8O16Rh2 +
Na+ - H+, calc. 1760.2), 1376.7 (C92H60N8O16Rh2 + Na+ - C23H16N2O4, calc.
1377.1), 992.7 (C92H60N8O16Rh2 + Na+ - C46H32N4O8, calc. 992.9).
(1S,2R)-Diisopropyl 1,2-diphenylcyclopropylphosphonate (11)55
. Co-
lorless oil; Rf = 0.40 (1:1 ethyl acetate: n-hexane); Enantiomer separation
by HPLC (Chiralpak AD column, 25 x 0.46 cm, 0.6% 2-propanol in n-hexane
(v/v%); 0.8 mL/min, 220 nm, τ1 = 49 min, τ2 = 54 min). The spectroscopic
data are consistent with previously reported data.55
Dirhodium(II,II) tetrakis[N-(1,2-naphthaloyl)-(S)-Tyrosinate] (Rh2
(S-1,2-NTTY)4, 3e). Ligand (0.63g, 1.76 mmol), Rh2(OAc)4 (0.13 g,
0.30 mmol); green solid (0.27 g, 56 %); Rf = 0.23 (2:1 ethyl acetate: n-
hexane); 1H NMR (400 MHz, DMSO-d6): δ 8.43-8.25 (m, 4H, Ar-H),
8.21-8.04 (m, 4H, Ar-H), 7.92-7.25 (m, 16H, Ar-H), 7.04-6.82 (m, 8H,
Ar-H), 6.65-6.34 (m, 8H, Ar-H), 5.18-4.90 (m, 4H, 4 x NCH), 3.50-3.05
(m, 12H, 4 x CH2, 4 x OH); IR (film) ν 3294, 2970, 1734, 1699, 1375,
1217, 770, 742, 685 cm-1.
General Procedure for the Preparation of
Cyclopropylcarboxylates
To a solution of the alkene (5.0 equiv.) and dirhodium catalyst (0.01
equiv.) in dry and degassed solvent under inert atmosphere, the diazo
compound (1.0 equiv.) dissolved in the same dry and degassed solvent,
was added dropwise over 1 h using a syringe pump. After that, the
reaction was stirred for at least 1 h. When the diazo compound was fully
consumed as indicated by TLC, the reaction solvent was removed in
vacuo. The diastereomeric ratio (dr) of the product was determined by
1H NMR of the crude mixture. The product was purified by means of
preparative TLC (ethyl acetate/n-hexane). The enantiomeric excess (ee %)
of the product was determined by chiral HPLC analysis.
General Procedure for the Preparation of
Cyclopropylphosphonate Derivatives
To a stirred solution of alkene (5 equiv.) and Rh(II) catalyst (0.01
equiv.) in 2,2-DMB (5 mL) heated under reflux (59oC) under nitrogen at-
mosphere, a solution of α-diazobenzylphosphonate (1 equiv.) in 2,2-DMB
(10 mL) was added dropwise via syringe pump over 1 h. After the
addition, the reaction was refluxed until the TLC indicates a complete
consumption of the diazo starting material. The diastereomeric ratio
(dr) of the product was determined by 1H NMR of the crude mixture.
The product was purified by means of preparative TLC (ethyl acetate/
n-hexane) and the enantiomeric excess (ee %) of the product was
determined by chiral HPLC analysis.
Methyl 1,2-diphenylcyclopropanecarboxylate (13)56,57
. White solid;
mp 60-62oC; Rf = 0.30 (1:10 ethyl acetate: n-hexane); Enantiomer separation
by HPLC (Chiralcel OJ column, 25 x 0.46 cm, 0.5% 2-propanol in n-hexane;
1 mL/min. 220 nm, τ1 = 14 min, τ2 = 20 min). The spectroscopic data are
consistent with previously reported data.56,57
(1S,2R)-Dimethyl 1,2-diphenylcyclopropylphosphonate (5)54,55
. Co-
Methyl 2β-phenyl-1β-(2-(Z)-styryl)cyclopropane-1α-carboxylate
lorless oil; Rf = 0.15 (1:1 ethyl acetate: n-hexane); Enantiomer separa-
tion by HPLC (Chiralcel OJ column, 25 x 0.46 cm, 2% 2-propanol in
n-hexane (v/v%); 1 mL/min, 220 nm, τ1 = 18 min, τ2 = 21 min). The
spectroscopic data are consistent with previously reported data.54,55
(15)58
.
White solid; mp 58-61oC; Rf = 0.63 (1:3 ethyl acetate: n-hexane);
Enantiomer separation by HPLC (Chiralcel OJ column, 25 x 0.46 cm, 1.5%
2-propanol in n-hexane; 1 mL/min. 254 nm, τ1 = 15 min, τ2 = 21 min). The
spectroscopic data are consistent with previously reported data.58
(1S,2R)-Dimethyl1-pheny-2-(p-chlorophenyl)-cyclopropylphosphonate
(6)55
. Colorless oil; Rf = 0.11 (1:1 ethyl acetate: n-hexane); Enantiomer
General Procedure for One-Pot Intermolecular
Cyclopropanation of Olefins Using Meldrum’s Acid
separation by HPLC (Chiralcel OJ column, 25 x 0.46 cm, 8% 2-propanol
in n-hexane (v/v%); 1 mL/min, 220 nm, τ1 = 10 min, τ2 = 12 min). The
spectroscopic data are consistent with previously reported data.55
To a stirred mixture of Meldrum’s acid (1 equiv.), PhI(OAc)2 (1.4
equiv.), dirhodium catalyst (0.01 equiv.), Al2O3 (2.3 equiv.) and 4Å
molecular sieves in dry dichloromethane under N2 atmosphere, olefin
(10 equiv.) was added. After allowing the reaction mixture to stir at room
temperature for 4 h, the reaction was terminated by filtration through
celite and concentrated under reduced pressure. The residue was puri-
fied by means of preparative TLC chromatography using ethyl acetate:
n-hexane (1:4) as an eluent to get the desired products. The enantiomeric
ratio of the product was determined by HPLC analysis.
(1S,2R)-Dimethyl 1-pheny-2-(p-methoxyphenyl)-cyclopropylphos-
phonate (7)55
. Colorless oil; Rf = 0.11 (1:1 ethyl acetate: n-hexane);
Enantiomer separation by HPLC (Chiralcel OJ column, 25 x 0.46 cm, 3%
2-propanol in n-hexane (v/v%); 1 mL/min, 220 nm, τ1 =37 min, τ2 =42 min).
The spectroscopic data are consistent with previously reported data.55
(1S,2R)-Dimethyl 1-pheny-2-(p-methylphenyl)-cyclopropylphospho-
nate (8). White solid; Rf = 0.17 (1:1 ethyl acetate: n-hexane); 1H NMR
(400 MHz, CDCl3): δ 7.13-7.10 (m, 3H, Ar-H), 7.07-7.04 (m, 2H, Ar-H), 6.85
(d, 2H, J = 7.8 Hz, Ar-H), 6.61 (d, 2H, J = 8.2 Hz, Ar-H), 3.72 (d, 3H, JHP = 10.6
Hz, OCH3), 3.66 (d, 3H, JHP = 10.6 Hz, OCH3), 2.97 (ddd, 1H, JHP = 16.1,
J = 9.1, 6.6 Hz, CH), 2.19 (s, 3H, CH3), 2.03 (ddd, 1H, JHP = 17.5, J= 9.0, 5.1
Hz, CH2), 1.67 (ddd, 1H, JHP = 12.5, J = 6.6, 5.1 Hz, CH2); Enantiomer
separation by HPLC (Chiralcel OJ column, 25 x 0.46 cm, 3% 2-propanol in
n-hexane (v/v%); 1 mL/min, 220 nm, τ1 = 12 min, τ2 = 15 min).
6,6-dimethyl-1-phenyl-5,7-dioxaspiro[2.5]octane-4,8-dione59
. White
solid; mp 132oC; Rf =0.55 (1:3 ethyl acetate: n-hexane); Enantiomer separation
by HPLC (Chiralpak IB column, 25 x 0.46 cm, 10% ethyl acetate in n-hex-
ane; 1 mL/min. 254 nm, τ1 =10 min, τ2 = 12.9 min). The spectroscopic data
are consistent with previously reported data.59
6,6-dimethyl-1-(4-chlorophenyl)-5,7-dioxaspiro[2.5]octane-4,8-
dione59
.
White solid; mp 157oC; Rf = 0.71 (1:3 ethyl acetate: n-hexane);
Enantiomer separation by HPLC (Chiralpak IB column, 25 x 0.46 cm, 10%
ethyl acetate in n-hexane; 0.5 mL/min. 254 nm, τ1 = 26 min, τ2 = 32 min).
The spectroscopic data are consistent with previously reported data.59
(1S,2R)-Dimethyl 1-pheny-2-(1-naphthyl)-cyclopropylphosphonate
(9). Colorless oil; Rf = 0.14 (1:1 ethyl acetate: n-hexane); 1H NMR (400
MHz, CDCl3): δ 7.72-7.53 (m, 2H, Ar-H), 7.50 (d, 1H, J = 7.50 Hz, Ar-H),
7.35 (m, 2H, Ar-H), 7.29 (s, 1H, Ar-H), 7.07 (m, 4H, Ar-H), 6.76 (dd, 1H,
6,6-dimethyl-1-(4-bromophenyl)-5,7-dioxaspiro[2.5]octane-4,8-
dione. White solid; mp 144oC; Rf = 0.40 (1:3 ethyl acetate: n-hexane);
1H NMR (400 MHz, CDCl3): δ 7.34 (dd, 4H, J = 8.5 Hz, Ar-H), 3.39
(apt t, 1H, J = 9.4 Hz, CH), 2.63 (dd, 1H, J = 9.3, 4.8 Hz, CH2), 2.54 (dd, 1H,
J = 9.5, 4.8 Hz, CH2), 1.74 (s, 3H, CH3), 1.71 (s, 3H, CH3); Enantiomer
J = 8.5, 1.8 Hz, Ar-H), 3.75 (d, 3H, JHP = 10.6 Hz, OCH3), 3.70 (d, 3H, JHP
=
10.6 Hz, OCH3), 3.16 (ddd, 1H, JHP = 16.1, J = 9.1, 6.6 Hz, CH), 2.14 (ddd,
1H, JHP = 17.5, J = 9.0, 5.3 Hz, CH2), 1.85 (ddd, 1H, JHP = 12.5, J = 6.6, 5.1
Hz, CH2); Enantiomer separation by HPLC (Chiralpak AD column, 25 x
Chirality DOI 10.1002/chir

ASYMMETRIC SYNTHESIS OF CHIRAL CYCLOPROPYLPHOSPHONATES
separation by HPLC (Chiralpak IB column, 25 x 0.46 cm, 10% ethyl acetate
in n-hexane; 0.5 mL/min. 254 nm, τ1 = 31 min, τ2 = 39 min).
6,6-dimethyl-1-(4-methylphenyl)-5,7-dioxaspiro[2.5]octane-4,8-
dione59
.
White Solid; mp 137oC; Rf = 0.33 (1:3 ethyl acetate: n-hexane);
Enantiomer separation by HPLC (Chiralpak IB column, 25 x 0.46 cm, 10%
ethyl acetate in n-hexane; 0.5 mL/min. 254 nm, τ1 = 26 min, τ2 = 31 min).
The spectroscopic data are consistent with previously reported data.59
6,6-dimethyl-1-naphthyl-5,7-dioxaspiro[2.5]octane-4,8-dione59
. Yellow-
ish solid; mp 120oC; Rf = 0.68 (1:3 ethyl acetate: n-hexane); Enantiomer
separation by HPLC (Chiralpak IB column, 25 x 0.46 cm, 10% ethyl
acetate in n-hexane; 0.5 mL/min. 254 nm, τ1 = 46 min, τ2 = 56 min).
The spectroscopic data are consistent with previously reported data.59
RESULTS AND DISCUSSION
Synthesis of Dirhodium (II) Tetracarboxylate
Catalytic Series
Unlike the previously reported trends used in the develop-
ment of chiral dirhodium(II) catalysts where the modifica-
tions in the dirhodium paddlewheel catalysts mostly focused
on the use of symmetrical N-protecting group (Fig. 1), we
are introducing ligands with a lower symmetry N-protecting
group. As a starting point, we thought about a protecting
group that can retain the N-phthaloyl rings of Hashimoto’s
catalytic series along with the horizontal naphthalene rings
of Müller’s catalytic series (Fig. 2) for intermolecular
cyclopropanation reactions. Thus, chiral carboxylate ligands
derived from N-1,2-naphthaloyl-(S)-amino acids were synthe-
sized. The ligands 1a–e were prepared via the condensation
of 1,2-naphthalic anhydride and (S)-amino acids in toluene/
TEA solvent mixture (Scheme 2). The structures elucidation
of the prepared ligands was confirmed on the basis of their
1D-, 2D-NMR, and MS spectral data. The HMBC spectra for
1a, 1b, 1c, and 1d revealed a long-range chemical shift corre-
lation between the chiral hydrogen and both carbonyl carbons
Scheme 2. Preparation of chiral ligands.
1
of the imide. This long-range H-13C correlation provided evi-
dence for the formation of the cyclic imide structures (1a–e)
and not the open chain amides 2a–b (Scheme 2).
High-temperature ligand exchange was then carried out
using the prepared chiral carboxylic acid ligands and rho-
dium acetate (Rh2(OAc)4).60 Ligand exchange proceeded
successfully, affording the corresponding dirhodium(II,II)
tetrakis[N-(1,2-naphthoyl)-(S)-amino acid] complexes (3a–e)
(Scheme 3). Their structures were confirmed on the basis
1
of their H and 13C NMR spectra.
Screening for Asymmetric Cyclopropanation With
Donor-Acceptor Diazophoshonate Substrates
With the new catalytic series in hand (3a–e), their efficiencies
were evaluated in standard donor-acceptor cyclopropanation
reactions using dimethyl α-diazobenzylphosphonate 4 (as
carbene precursor) and styrene (as olefin substrate) in 2,2-
dimethylbutane (2,2-DMB) as reaction solvent. The previously
reported Rh2(S-PTTL)4 and Rh2(S-NTTL)4 catalysts (Fig. 1)
were included in the screening as well-established cata-
lysts in the enantioselective cyclopropanation reactions
(Table 1). All catalysts revealed high levels of diastereo-
selectivities where the diastereomeric ratios (dr) >20:1
for the resulted cyclopropane products.
Scheme 3. Preparation and structure of new catalysts.
catalyst bearing the bulky tert-butyl group (3a) was the best
catalyst among the series. This was followed by those bearing
the iso-butyl (3c) and benzyl (3b) groups and finally those
carrying the (3-indolyl)methyl (3d) and the 4-hydroxyl-
benzyl (3e) groups. The cyclopropanation reaction catalyzed
by Rh2(S-1,2-NTTL)4 (3a) generated the cyclopropane
product in 92% ee (Fig. 3), which is similar to the same reac-
tion catalyzed by Rh2(S-PTTL)4 and slightly better than the
one catalyzed by Rh2(S-NTTL)4 (90% ee).
The results in Table 1 were in agreement with the previ-
ously reported trend by Hashimoto in regard to the steric
bulk at the α-position and the selectivity of the catalyst.41,61
From the illustrated results, it can be concluded that the
Chirality DOI 10.1002/chir

ADLY ET AL.
TABLE 1. Asymmetric cyclopropanation with dimethyl
α-diazobenzylphosphonate (donor-acceptor substrate)
TABLE 2. Scope of Rh2(S-1,2-NTTL)4 (3a) with respect to the
alkene
Entry
1
R group
Product
Yield (%)
92
ee (%)
Entry
Catalyst
Code
Reaction
Time (h)
Yield
(%)
ee
(%)
6
7
8
9
94
47
1
2
3
4
5
6
7
8
Rh2(S-PTAD)4
Rh2(S-PTTL)4
Rh2(S-NTTL)4
Rh2(S-1,2-NTTL)4
Rh2(S-1,2-NTPA)4
Rh2(S-1,2-NTLU)4
Rh2(S-1,2-NTTR)4
Rh2(S-1,2-NTTY)4
-
-
-
8
10
5
5
5
5
20
20
86
83
91
93
91
94
76
80
99
92
90
92
34
64
22
26
3a
3b
3c
3d
3e
2
3
4
93
90
86
>99
95
Diastereomeric ratios (dr) were determined by 1H NMR of the crude mixture.
Enantiomeric excess (ee %) were determined by chiral HPLC using Chiralcel
OJ column, 2% 2-propanol in n-hexane (v/v%), 1 mL/min., 220 nm, τ1 = 18 min.,
τ2 = 21 min. See Materials and Methods section for more details.
>98
Diastereomeric ratios (dr) were determined by 1H NMR of the crude mixture.
Enantiomeric excess (ee %) were determined by chiral HPLC. See Materials
and Methods section for more details.
The scope of the Rh2(S-1,2-NTTL)4 catalyst was further
investigated with respect to the alkene (Table 2). The
reactions proceeded smoothly, resulting in the formation
of cyclopropylphosphonate products with very high yields
(86–93%), diasteroselectivity (>20:1 dr), and enantioselectivity
(94-> 99% ee).
The effect of diazophosphonate ester size on the
enantioselectivity of the Rh2(S-1,2-NTTL)4 - catalyzed reaction
was next examined (Table 3). The diastereoselectivity is
independent on the size of the phosphonate group and not
greatly influenced by the ester size. However, both yield
and enantioselectivity were decreasing with increasing the
ester group size and the highest levels of enantioselectivity
were observed with dimethyl phenyldiazophosphonate
(Entry 1, Table 3).
Fig. 3. Chiral HPLC trace of (1S,2R)-Dimethyl 1,2-diphenylcyclopro-
pylphosphonate (5) (a) prepared using Rh2(OAc)4 (Racemic sample) (b)
prepared using Rh2(S-1,2-NTTL)4. Chromatographic conditions: Chiralcel OJ
column, 2% 2-propanol in n-hexane (v/v%), 1 mL/min., 220 nm.
Screening for Asymmetric Cyclopropanations With Other
Donor-Acceptor Substrates
Encouraged by the cyclopropanation results illustrated in
Tables 1–3, the scope of the new catalysts was further investi-
gated by looking into more donor-acceptor carbenoid
cyclopropanations. To study the influence of replacing the
phosphonate ester group of the carbenoid with a carboxylate
ester group on the catalyst enantioselectivity, the next series
of experiments were carried out using methyl α-
phenyldiazoacetate 12 (Table 4).
As illustrated in Table 4, all catalysts afforded the cyclopro-
pane product 13 in excellent to good yields (89–65%) with
high diastereoselectivity (>18:1 dr). However, the asymmet-
ric induction deteriorated dramatically with the replacement
The yields of the cyclopropane product 5 were generally
high for all catalysts, ranging from 76% to 93%. The observed
yield of the product resulting from the reaction catalyzed by
Rh2(S-1,2-NTTL)4 was slightly higher than those resulting
from reactions catalyzed by Rh2(S-PTTL)4 and Rh2(S-NTTL)4
(Table 1). This can be rationalized to the ligand’s larger
aromatic moiety, which offers a relatively higher solubility of
Rh2(S-1,2-NTTL)4 in nonpolar solvents. Its better solubility also
offered a quicker conversion into products resulting in a
shorter reaction time when compared to Rh2(S-PTTL)4.
Chirality DOI 10.1002/chir

ASYMMETRIC SYNTHESIS OF CHIRAL CYCLOPROPYLPHOSPHONATES
TABLE 3. Effect of the ester group size on the enantiomeric
induction of Rh2(S-1,2-NTTL)4
TABLE 5. Effect of solvent and temperature on the
stereoselectivity of Rh2(S-1,2-NTTL)4 with methyl
α-diazophenylacetate substrate
Entry
R group
Product
Yield (%)
ee (%)
1
2
3
Me
Et
i-Pr
5
10
11
93
69
43
92
60
Entry
Solvent
Temperature (oC)
Yield (%)
ee (%)
68a
1
2
3
4
5
2,2-DMB
2,2-DMB
Toluene
CH2CL2
Pentane
23
-20
23
23
23
89
82
88
90
87
30
28
-2
26
18
aAfter reflux for 3 days. Diastereomeric ratios (dr) were determined by 1H
NMR of the crude mixture. Enantiomeric excess percents (ee %) were deter-
mined by chiral HPLC. See Materials and Methods section for more details.
Diastereomeric ratios (dr) were determined by 1H NMR of the crude mixture.
Enantiomeric excess (ee %) were determined by chiral HPLC using Chiralcel®
OJ column, 0.5% 2-propanol in n-hexane (v/v%), 1 mL/min., 220 nm, τ1 = 14
min., τ2 = 20 min. See Materials and Methods section for more details.
TABLE 4. Asymmetric cyclopropanation with methyl
α-diazophenylacetate (donor-acceptor substrate)
TABLE 6. Asymmetric cyclopropanation with methyl α-
diazostyrylacetate (donor-acceptor substrate)
Entry
Catalyst
Code
Yield (%)
ee (%)
87a
87
88
89
86
86
63
65
21a
20
8
30
18
14
20
16
57
1
2
3
4
5
6
7
8
Rh2(S-PTAD)4
Rh2(S-PTTL)4
Rh2(S-NTTL)4
-
-
-
Rh2(S-1,2-NTTL)4
Rh2(S-1,2-NTPA)4
Rh2(S-1,2-NTLU)4
Rh2(S-1,2-NTTR)4
Rh2(S-1,2-NTTY)4
3a
3b
3c
3d
3e
Entry
Catalyst
Code
Solvent
Yield (%) ee (%)
1
2
3
4
5
6
7
8
Rh2(S-PTTL)4
Rh2(S-NTTL)4
-
-
CH2Cl2
CH2Cl2
CH2Cl2
Pentane
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
83
82
88
87
82
89
65
67
40
16
10
10
18
23
20
20
Rh2(S-1,2-NTTL)4
Rh2(S-1,2-NTTL)4
Rh2(S-1,2-NTPA)4
Rh2(S-1,2-NTLU)4
Rh2(S-1,2-NTTR)4
Rh2(S-1,2-NTTY)4
3a
3a
3b
3c
3d
3e
aIn toluene. Diastereomeric ratios (dr) were determined by 1H NMR of the
crude mixture. Enantiomeric excess (ee %) were determined by chiral HPLC
using Chiralcel® OJ column, 0.5% 2-propanol in n-hexane (v/v%), 1 mL/min.,
220 nm, τ1 = 14 min., τ2 = 20 min. See Materials and Methods section for
more details.
of the phosphonate ester group with a carboxylate ester
group. The enantiomeric induction of the catalysts did not
exceed 30% ee, which was exhibited by Rh2(S-1,2-NTTL)4
(3a) (Entry 4, Table 4). Although the enantiomeric induction
of Rh2(S-1,2-NTTL)4 was not significantly high, it was still
considerably higher than those exhibited by Rh2(S-PTAD)4,
Rh2(S-NTTL)4, and Rh2(S-PTTL)4 for the same reaction
(Entries 1, 2, and 3, Table 4).
As an attempt to enhance the enantioselectivity of Rh2(S-
1,2-NTTL)4 catalyst, the effects of changing the reaction
conditions (e.g., solvent and temperature) were investigated
(Table 5). Using methylene chloride as a reaction solvent
rather than 2,2-DMB resulted in slight decrease in
enantioselectivity of Rh2(S-1,2-NTTL)4 (Entry 4, Table 5).
The enantioselectivity decreased dramatically when toluene
or pentane was used (Entries 3 and 5, Table 5). Furthermore,
the variation of temperature had a little influence on the
Diastereomeric ratios (dr) were determined by 1H NMR of the crude mixture.
Enantiomeric excess percents (ee %) were determined by chiral HPLC using
Chiralcel OJ column, 1.5% 2-propanol in n-hexane (v/v%), 1 mL/min., 254 nm,
τ1 = 15 min., τ2 = 21 min. See Materials and Methods section for more details.
enantioselectivity of Rh2(S-1,2-NTTL)4 over a reaction tem-
perature range from 23oC to –20oC (Entries 1 and 2, Table 5).
The final series of experiments were carried out using
methyl α-styryldiazoacetate 14 with the phenylvinyl function-
ality as an attempt to enhance the enantioinduction of the
catalysts with diazocarboxylates. The reactions were carried
out at room temperature using methylene chloride as
reaction solvent (Table 6). The desired cyclopropane product
15 was obtained in yield range from 65% to 89% with high
levels of diastereoselectivity (>20:1 dr). However, the
enantiomeric induction did not exceed 23% ee when using
Rh2(S-1,2-NTLU)4 (Entry 6, Table 6). Although the
Chirality DOI 10.1002/chir

ADLY ET AL.
enantioselectivity of Rh2(S-PTTL)4 was the highest (40% ee),
of the resulting cyclopropane derivatives, Rh2(S-1,2-NTTL)4 (3a)
was the best among the series (30-20% ee) and it revealed similar
enantiomeric induction to Rh2(S-NTTL)4 (32-17% ee) but both
were lower than Rh2(S-PTTL)4 (37-27% ee).
the enantioselectivity exhibited by Rh2(S-1,2-NTLU)4 (3c),
Rh2(S-1,2-NTTR)4 (3d), Rh2(S-1,2-NTTY)4 (3e), and Rh2(S-
1,2-NTPA)4 (3b) were higher than that observed when using
Rh2(S-NTTL)4. Altering the reaction solvent from methylene
chloride to pentane did not affect the degree of
enantioselectivity (Entries 3 and 4, Table 6).
Predictive Model for Asymmetric Induction
There are some uncertainties about the arrangement of
ligands in solution for this family of catalysts which led to
some uncertainties about their mode of asymmetric induction
during carbenoid transformations. As a consequence, a
number of predictive models have appeared to justify the
stereoselection in dirhodium(II)-catalyzed reactions.
The first predictive model was proposed by Hashimoto and
it was based on the x-ray crystal structure of Rh2(S-PTPA)4. In
this model, it was proposed that dirhodium(II) carboxylates
derived from N-phthalimido amino acid ligands preferentially
exist in C2-symmetric conformation, at which two adjacent N-
phthalimido groups are positioned on the top face of the
complex and the other two are positioned on the bottom
face.36,61,64 Hashimoto’s model was used to successfully
predict the stereochemical outcome of asymmetric C-H
insertion reactions catalyzed by Rh2(S-PTAD)4.65
Screening for Asymmetric Cyclopropanation With
Diacceptor Substrates
In order to probe the enantiomeric induction of the pre-
pared catalytic series with diacceptor carbenoid intermedi-
ates, the enantioselective cyclopropanation of Meldrum’s
acid with a variety of alkenes was examined. To facilitate
the screening, a previously developed user-friendly one-pot
cyclopropanation procedure was used, wherein the
phenylidonium ylides are generated and decomposed in
situ.53,60,62,63. All the reactions were carried out at room
temperature in methylene chloride as reaction solvent and
the data are summarized in Table 7.
All catalysts revealed moderate isolated yields, except for
Rh2(S-1,2-NTTR)4 (3d) and Rh2(S-1,2-NTTY)4 (3e). The
asymmetric induction exhibited by the prepared catalysts ranged
from moderate to low (30–7% ee) for all substrates. In terms of ee
Later on, Fox and colleagues reported that the Rh2(S-
PTTL)4 had C4-symmetry “all-up” in solid state through its
TABLE 7. Asymmetric cyclopropanation with Meldrum’s acid (diacceptor substrate)
Rh2(S-1,2-
NTTL)4 (3a)
Rh2(S-1,2-
NTPA)4 (3b)
Rh2(S-1,2-
NTLU)4 (3c)
Rh2(S-1,2-
NTTR)4 (3d)
Rh2(S-1,2-
NTTY)4 (3e)
Rh2(S-PTTL)4
Rh2(S-NTTL)4
Yield
(%)
ee
Yield
(%)
ee
Yield
(%)
ee
Yield
(%)
ee
Yield
(%)
ee
Yield
(%)
ee
Yield
(%)
ee
R-group
(%)a
(%)a
(%)a
(%)a
(%)a
(%)a
(%)a
45%
52%
37%
36%
38%
40%
32%
60%
57%
30%
47%
51%
12%b
9%b
54%
59%
16%
18%
20%
18%
18%
14%
16%
13%
31%b
28%b
15%b
14%b
42%
33%
53%
35%
29%
27%
63%
36%
28%
20%
23%
46%
32%
44%
27%
22%
20%
41%
30%
38%
11%
8%
55%
47%
46%
12%
8%
11%
13%
12%
17%
17%
13%
14%
13%
15%
9%
12%
7%
17%b
8%b
9%b
aThe R-enantiomer is the major product. bAnalyzed as crude mixture. Enantiomeric excesses (ee %) were determined by chiral HPLC. See Materials and Methods
section for more details.
Chirality DOI 10.1002/chir

ASYMMETRIC SYNTHESIS OF CHIRAL CYCLOPROPYLPHOSPHONATES
derived from N-protected amino acid ligands. The efficiency
and selectivity of this catalyst has been demonstrated in a
variety of diastereo- and enantioselective reactions of donor-
acceptor and diacceptor carbenoids.
It was demonstrated that Rh2(S-1,2-NTTL)4 (3a) is a
promising backup catalyst for the cyclopropanation reaction
involving donor-acceptor phosphonate carbenoids. However,
the results did not provide a clear advantage for the “lower
symmetry” approach. Further investigations related to this
point are in progress and the results will be reported in due
course.
The results also revealed that the nature of the acceptor
group in the donor-acceptor carbenoid strongly affects
the asymmetric induction imparted by Rh2(S-1,2-NTTL)4.
This can provide a guideline for choosing the optimal
dirhodium(II) catalyst before attempting an asymmetric
cyclopropanation and broadens the range of available cata-
lysts for the synthesis of chiral cyclopropylphosphonate deriv-
atives. Hashimoto’s stereochemical model proved to be an
excellent model to justify the observed selectivity of the new
Rh2(S-1,2-NTTL)4 catalyst. This predictive model raised the
importance of considering the conformational mobility of
the ligands in solution once the carbene binds to the catalyst.
Fig. 4. Model for asymmetric cyclopropanation catalyzed by Rh2(S-1,2-
NTTL)4.
ACKNOWLEDGMENTS
The authors gratefully acknowledge the W.J. Weeden
scholarship program at the University of Canberra, Australia,
for the PhD scholarship offered to Mr. Frady Gamal Adly
Gouany. Dedicated to Professor Paul Müller on the occasion
of his 75th birthday.
x-ray crystal structure, with the four N-phthalimido groups on
one face of the complex creating a chiral crown cavity.66,67
Also, other research groups have reported x-ray structures
of other catalysts that belong to the same family and all these
catalysts were adopting an “all-up” C4 conformation.29,51,68–70
According to the Fox model, the bulky tert-butyl groups
are necessary to limit reactivity to only one of the catalyst
faces, whereas the distorted C4-symmetric chiral crown-like
ligand arrangement guides the facial selectivity at the open
Rh-face.50
SUPPORTING INFORMATION
Additional supporting information may be found in the
online version of this article at the publisher’s web-site.
LITERATURE CITED
Based on the x-ray structure of Rh2(S-1,2-NTPA)4 (3b), that
revealed an “up, up, down, down” arrangement of the ligands
across the rhodium core,71 Hashimoto’s model was adopted
for Rh2(S-1,2-NTTL)4. It was hypothesized that the N-1,2-
naphthaloyl groups are oriented in an “up-up-down-down”
arrangement in solution. In the case of dimethyl
benzylphosphonate carbenoid, the much bulkier dimethyl
phosphonate group (tetrahedral geometry) orients itself away
to avoid the steric interaction with the N-1,2-napthaloyl walls
(Fig. 4a). The alkene is predicted to approach from the front
and lead to the observed product. This may justify the high
enantiomeric excess of the cyclopropyl derivatives when
using carbenoid with bulky phosphonate group (Tables 1
and 2). On the other hand, both the methyl carboxylate and
the phenyl groups of methyl benzylcarboxylate carbenoid
are almost of the same size (having planner geometry) and
can occupy both positions shown in Figure 4b,c. The alkene
attacks from the front and may lead to the observed low
enantiomeric excess of the corresponding cyclopropyl
derivatives (Tables 4–6).
1. Wong HNC, Hon M-Y, Tse C-W, Yip Y-C, Tanko J, Hudlicky T. Use of
cyclopropanes and their derivatives in organic synthesis. Chem Rev
1989;89:165–198.
2. Donaldson WA. Synthesis of cyclopropane containing natural products.
Tetrahedron 2001;57:8589–8627.
3. de Meijere A, Kozhushkov SI, Fokin AA, Emme I, Redlich S, Schreiner
PR. New structurally interesting cyclopropane derivatives. A world of
wonders and surprises. Pure Appl Chem 2003;75:549–562.
4. Rubin M, Rubina M, Gevorgyan V. Transition metal chemistry of
cyclopropenes and cyclopropanes. Chem Rev 2007;107:3117–3179.
5. Pellissier
H Recent developments in asymmetric cyclopropanation.
Tetrahedron 2008;64:7041–7095.
6. Chen DY-K, Pouwer RH, Richard J-A. Recent advances in the total
synthesis of cyclopropane-containing natural products. Chem Soc Rev
2012;41:4631–4642.
7. Quntar AAAA, Dembitsky VM, Srebnik M. α-, β-, γ- and ω-
Cyclopropylphosphonates: Preparation and biological activity. Org Prep
Proced Int 2008;40:505–542.
8. Hah JH, Gil JM, Oh DY. The stereoselective synthesis of
cyclopropylphosphonate analogs of nucleotides. Tetrahedron Lett
1999;40:8235–8238.
9. Diel PJ, Maier L. Organische Phosphorverbindungen 78 Herstellung Und
Eigenschaften Von N-Phosphonomethylglycin Derivaten. Phosphorus,
Sulfur Silicon Relat Elem 1984;20:313–321.
10. Reid JR, Marmor RS. Synthesis of methyl arylmethyl 2,2-dimethyl-3-(2-
methyl-1-propenyl)cyclopropylphosphonates as potential insecticides. J
Org Chem 1978;43:999–1001.
CONCLUSION
In conclusion, we have developed dirhodium(II,II) tetrakis
[N-(1,2-naphthoyl)-(S)-tert-leucine] (Rh2(S-1,2-NTTL)4, 3a)
as a new member of the chiral dirhodium catalysts family
11. Duquenne C, Goumain S, Jubault P, Feasson C, Quirion J-C.
Electrosynthesis of α-arylated β-substituted cyclopropylphosphonates.
Chirality DOI 10.1002/chir

ADLY ET AL.
Synthesis of a phosphonic anaogue of minalcipran. Org Lett 2000;2:
34. Takahashi T, Tsutsui H, Tamura M, Kitagaki S, Nakajima M, Hashimoto S.
Catalytic asymmetric synthesis of 1,1-spirobi[indan-3,3-dione] via a double
intramolecular C–H insertion process. Chem Commun 2001;1604–1605.
453–455.
12. Erion MD, Walsh CT. 1-Aminocyclopropanephosphonate: time-dependent
inactivation of 1-aminocyclopropanecarboxylate deaminase and Bacillus
stearothermophilus alanine racemase by slow dissociation behavior.
Biochemistry 1987;26:3417–3425.
13. Groth U, Lehmann L, Richter L, Schollkopf U. Syntheses of α-
aminophosphonic acids. VI. Synthesis of diastereomerically pure 1-
aminocyclopropylphosphonic acids. Liebigs Ann Chem 1993:427–431.
35. Kitagaki S, Anada M, Kataoka O, Matsuno K, Umeda C, Watanabe N,
Hashimoto S. Enantiocontrol in tandem carbonyl ylide formation and
intermolecular 1,3-dipolar cycloaddition of α-diazo ketones mediated by chiral
dirhodium(II) carboxylate catalyst. J Am Chem Soc 1999;121:1417–1418.
36. Tsutsui H, Matsuura M, Makino K, Nakamura S, Nakajima M, Kitagaki S,
Hashimoto S. Enantioselective tandem formation and [2,3]-sigmatropic re-
arrangement of cyclic propargylic oxonium ylides catalyzed by dirhodium
(II) Tetrakis[Naphthaloyl-(S)-tert-leucinate]. Isr J Chem 2001;41:283–295.
37. Yamawaki M, Tsutsui H, Kitagaki S, Anada M, Hashimoto S. Dirhodium
(II) tetrakis[N-tetrachlorophthaloyl-(S)-tert-leucinate]: a new chiral Rh(II)
catalyst for enantioselective amidation of C-H bonds. Tetrahedron Lett
2002;43:9561–9564.
14. Hercouet A, Le Corre M, Carboni B. Asymmetric synthesis of a phosphonic
analogue of (À)-allo-norcoronamic acid. Tetrahedron Lett 2000;41:197–199.
15. Yamazaki S, Takada T, Imanishi T, Moriguchi Y, Yamabe S. Lewis acid-
promoted [2 + 1] cycloaddition reactions of a 1-seleno-2-silylethene to 2-
phosphonoacrylates: Stereoselective synthesis of a novel functionalized
α-aminocyclopropanephosphonic acid. J Org Chem 1998;63:5919–5928.
38. Tsutsui H, Yamaguchi Y, Hashimoto S. Dirhodium(II) tetrakis[N-
tetrafluorophthaloyl-(S)-tert-leucinate]: an exceptionally effective Rh(II)
catalyst for enantiotopically selective aromatic C-H insertions of diazo
ketoesters. Tetrahedron: Asymmetry 2003;14:817–821.
16. Hanessian S, Cantin L-D, Roy S, Andretti D, Gomtsyan A. The synthesis of
enantiomerically pure, symmetrically substituted cyclopropane phos-
phonic acids — A constrained analog of the GABA antagonist phaclophen.
Tetrahedron Lett 1997;38:1103–1106.
39. Minami K, Saito H, Tsutsui H, Nambu H, Anada M, Hashimoto S. Highly
enantio- and diastereoselective construction of 1,2-disubstituted
cyclopentane compounds by dirhodium(II) Tetrakis[N-phthaloyl-(S)-tert-
leucinate]-catalyzed C-H insertion reactions of a-diazo esters. Adv Synth
Catal 2005;347:1483–1487.
17. Dappen MS, Pellicciari JR, Natalini B, Monahan JB, Chiorri C, Cordis AA.
Synthesis and biological evaluation of cyclopropyl analogs of 2-amino-5-
phosphonopentanoic acid. J Med Chem 1991;34:161–168.
18. Hatse S, Naesens L, Clercq ED, Balzarini J. N6-cyclopropyl-PMEDAP: A
novel derivative of 9-(2-phosphonylmethoxyethyl)-2,6-diaminopurine
(PMEDAP) with distinct metabolic, antiproliferative, and differentiation-
inducing properties Biochem Pharmacol 1999;58:311–323.
40. Hashimoto S, Watanabe N, Anada M, Ikegami S. Site-and Enantiocontrol
in intramolecular C-H insertion reactions of α-diazo carbonyl compounds
catalyzed by dirhodium(II) carboxylates.
1996;54:988–999.
J Synth Org Chem Jpn
19. Zidek Z, Potmesil P, Kmoniekova E, Holy A. Immunobiological activity of
N-[2-(phosphonomethoxy)alkyl] derivatives of N6-substituted adenines,
and 2,6-diaminopurines. Eur J Pharmacol 2003;475:149–159.
20. Van Poelje PD, Erion MD, Fujiwara T. CA. A combination of FBPase in-
hibitors and antidiabetic agwnts useful for the treatment of diabetes.
PCT int. Appl 2002:123595.
21. Naesens L, Hatse S, Segers C, Verbeken E, De Clereq E, Waer M,
Balzarini J. 9-(2-phosphonylmethoxyethyl)-N6-cyclopropyl-2,6-diaminopurine:
A novel prodrug of 9-(2-phosphonylmethoxyethyl)guanine with improved
antitumor efficacy and selectivity in choriocarcinoma-bearing rats. Oncol
Res 1999;11:195–203.
41. H S-i, Watanabe N, Ikegami S. Enantioselective intramolecular C-H
insertion of a-diazo b-keto esters catalyzed by homochiral rhodium(II)
carboxylates. Tetrahedron Lett 1990;31:5173–5174.
42. Watanabe N, Ohtake Y, Hashimoto S, Shiro M, Ikegami S. Asymmetric
creation of quaternary carbon centers by enantiotopically selective
aromatic C-H insertion catalyzed by chiral dirhodium(II) carboxylates.
Tetrahedron Lett 1995;36:1491–1494.
43. Hashimoto S, Watanabe N, Ikegami S. Enantioselective intramolecular C-
H insertion reactions of α-diazo β-keto esters catalyzed by dirhodium(II)
Tetrakis[N-phthaloyl-(S)-phenylalaninate]: The effect of the substituent
at the insertion site on enantioselectivity. Synlett 1994:353–355.
22. Choi JR, Cho DG, Roh KY, Hwang JT, Anh S, Jang HS, Cho WY, Kim KW,
Cho YG, Kim J.
A novel class of phosphonate nucleosides. 9-[(1-
Phosphonomethoxycyclopropyl)methyl]guanine as a potent and selective
anti-HBV Agent. J Med Chem 2004;47:2864–2869.
44. Watanabe N, Ogawa T, Ohtake Y, Ikegami S, Hashimoto S. Dirhodium(II)
Tetrakis[N-phthaloyl-(S)-tert-leucinate]:
A
notable
catalyst
for
enantiotopically selective aromatic substitution reactions of α-
diazocarbonyl compounds. Synlett 1996:85–86.
45. Muller P, Allenbach Y, Robert E. Rhodium(II)-catalyzed olefin
cyclopropanation with the phenyliodonium ylide derived from Meldrum’s
acid. Tetrahedron: Asymmetry 2003;14:779–785.
46. Marcoux D, Charette AB. trans-Directing ability of amide groups in
cyclopropanations: application to the asymmetric cyclopropanation of
alkenes with diazo reagents bearing two carboxylate groups. Angew
Chem 2008;47:10155–10158.
23. Zidek Z, Potmesil P, Holy A. Cytostatic activity of antiviral acyclic nucleo-
side phosphonates in rodent lymphocytes. Toxicol Appl Pharmacol
2003;192:246–253.
24. Hockova D, Holy A, Masojidkova M, Andrei G, Snoeck RT, De Clereq E.
5-Substituted-2,4-diamino-6-[2-(phosphonomethoxy)ethoxy]
pyrimidinesacyclic nucleoside phosphonate analogues with antiviral
activity. J Med Chem 2003;46:5064–5073.
25. El-Deftar M, Adly FG, Gardiner MG, Ghanem A. Chiral dirhodium catalysts:
a new era for asymmetric catalysis. Curr Org Chem 2012;16:1808–1836.
47. Reddy RP, Lee GH, Davies HML. Dirhodium tetracarboxylate derived
from admantylglycine as chiral catalyst for carbenoid reactions. Org Lett
2006;8:3437–3440.
26. Halpern J, Trost BM. Asymmetric catalysis. Proc Natl Acad Sci U S A
2004;101:5347–5347.
27. Lebel H, Marcoux J-F, Molinaro C, Charette AB. Stereoselective
48. Briones JF, Davies HML. Rh2(S-PTAD)4 catalyzed asymmetric
cyclopropanation of aryl alkynes. Tetrahedron 2011;67:4313–4317.
cyclopropanation reactions. Chem Rev 2003;103:977–1050.
28. Carreira EM, Kvaerno L. Classics in stereoselective synthesis. Weinheim:
49. Denton JR, Sukumaran D, Davies HML. Enantioselective synthesis of
trifluoromethyl-substituted cyclopropanes. Org Lett 2007;9:2625–2628.
50. Qin C, Boyarskikh V, Hansen JH, Hardcastle KI, Musaev DG, Davies
Wiley-VCH; 2008. p 483–513.
29. Ghanem A, Gardiner MG, Williamson RM, Muller P. First X-ray structure
of a N-naphthaloyl-tethered chiral dirhodium(II) complex: structural basis
for tether substitution improving asymmetric control in olefin
cyclopropanation. Chem-Eur J 2010;16:3291–3295.
HML. D2-symmetric dirhodium catalyst derived from
a
1,2,2-
triarylcyclopropanecarboxylate ligand: design, synthesis and application.
J Am Chem Soc 2011;133:19198–19204.
30. Davies HML, Walji AM. Rhodium(II)-stabilized carbenoids containing
both donor and acceptor substituents. In: Evans PA, editor. Rhodium cat-
alyzed organic reactions. Weinheim: Wiley-VCH; 2005. p 301–340.
31. Kornecki KP, Briones JF, Boyarskikh V, Fullilove F, Autschbach J,
Schrote KE, Lancaster KM, Davies HML, Berry JF. Direct spectroscopic
51. Mattiza JT, Fohrer JGG, Duddeck H, Gardiner MG, Ghanem A. Optimiz-
ing dirhodium(II) tetrakiscarboxylates as chiral NMR auxiliaries. Org
Biomol Chem 2011;9:6542–6550.
52. Tsutsui H, Abe T, Nakamura S, Anada M, Hashimoto S. Practical
synthesis of dirhodium(II) Tetrakis[N-phthaloyl-(S)-tert-leucinate]. Chem
Pharm Bull 2005;53:1366–1368.
characterization of
a transitory dirhodium donor-acceptor carbene
complex. Science 2013;342:351–354.
53. Ghanem A, Aboul-Enein HY, Muller P. One-pot synthesis and chiral
32. Doyle MP, McKervey MA, Ye T. Modern catalytic methods for organic
synthesis with diazo compounds: from cyclopropanes to ylides. New York:
Wiley; 1998.
analysis of cyclopropane derivatives. Chirality 2005;17:44–50.
54. Tomioka H, Miyagawa H. Photochemical addition of tertiary amines to
electrophilic cyclopropanes via single electron transfer. J Chem Soc Chem
Commun 1988:1183–1184.
33. Hansen J, Davies HML. High symmetry dirhodium(II) paddlewheel
complexes as chiral catalysts. Coord Chem Rev 2008;252:545–555.
Chirality DOI 10.1002/chir

ASYMMETRIC SYNTHESIS OF CHIRAL CYCLOPROPYLPHOSPHONATES
55. Davies HML, Lee GH. Enantioselective Synthesis of cyclopropyl-
63. Muller P, Ghanem A. Rh(II)-Catalyzed enantioselective cyclopropanation
of olefins with dimethyl malonate via in situ generated phenyliodonium
ylide. Org Lett 2004;6:4347–4350.
phosphonates containing quaternary stereocenters using a D2-symmetric
chiral catalyst Rh2(S-biTISP)2. Org Lett 2004;6:2117–2120.
56. Davies HML, Panaro SA. Novel dirhodium tetraprolinate catalysts con-
taining bridging prolinate ligands for asymmetric carbenoid reactions.
Tetrahedron Lett 1999;40:5287–5290.
64. Anada M, Kitagaki S, Hashimoto S. Double stereodifferentiation in
intramolecular C-H insertion reaction toward the synthesis of 1β-
methylcarbapenem antibiotics. Heterocycles 2000;52:875–883.
57. Chepiga KM, Qin C, Alford JS, Chennamadhavuni S, Gregg TM, Olson
JP, Davies HML. Guide to enantioselective dirhodium(II)-catalyzed
cyclopropanation with aryldiazoacetates. Tetrahedron 2013;69:5765–5771.
65. Nadeau E, Ventura DL, Brekan JA, Davies HML. Controlling factors for
C-H functionalization versus cyclopropanation of dihydronaphthalenes. J
Org Chem 2010;75:1927–1939.
58. Davies HML, Bruzinski PR, Lake DH, Kong N, Fall MJ. Asymmetric
cyclopropanations by rhodium(II) N-(Arylsulfonyl)prolinate catalyzed
decomposition of vinyldiazomethanes in the presence of alkenes. Practical
enantioselective synthesis of the four stereoisomers of 2-
phenylcyclopropan-1-amino acid. J Am Chem Soc 1996;118:6897–6907.
59. Lee YR, Choi JH. Rh2(Opiv)4-catalyzed reactions of diazo compound
derived from Meldrum’s acid and styrenes. Efficient synthesis of
cyclopropanes. Bull Korean Chem Soc 2006;27:503–507.
60. Ghanem A, Lacrampe F, Aboul-Enein HY, Schurig V. Diazo compounds
and phenyliodonium ylides in inter- and intramolecular cyclopropanations
catalyzed by dirhodium(II). Synthesis and chiral resolution by GC versus
HPLC. Monatsh Chem 2005;136:1205–1219.
66. DeAngelis A, Dmitrenko O, Yap GPA, Fox JM. Chiral crown conformation
of Rh2(PTTL)4: Enantioselective cyclopropanation with a-alkyl-a-
diazoesters. J Am Chem Soc 2009;131:7230–7231.
67. DeAngelis A, Boruta DT, Lubin J-B, Plampin JN, Yap GPA, Fox JM. The
chiral crown conformation in paddlewheel complexes. Chem Commun
2010;46:4541–4543.
68. Lindsay VNG, Nicolas C, Charette AB. Asymmetric Rh(II)-catalyzed
cyclopropanation of alkenes with diacceptor diazo compounds: p-
methoxyphenyl ketone as a general stereoselectivity controlling group. J
Am Chem Soc 2011;133:8972–8981.
69. Lindsay VNG, Lin W, Charette AB. Experimental evidence for the all-up
reactive conformation of chiral rhodium(II) carboxylate catalysts:
enantioselective synthesis of cis-cyclopropane α-amino acids. J Am Chem
Soc 2009;131:16383–16385.
61. Hashimoto S-I, Watanabe N, Sato T, Shiro M, Ikegami S. Enhancement of
enantioselectivity in intramolecular C-H insertion reactions of a-diazo b-
keto esters catalyzed by chiral dirhodium(II) carboxylates. Tetrahedron
Lett 1993;34:5109–5112.
62. Ghanem A, Lacrampe F, Schurig V. Rhodium(II)-catalyzed inter- and
intramolecular cyclopropanations with diazo compounds and
phenyliodonium ylides: synthesis and chiral analysis. Helv Chim Acta
2005;88:216–239.
70. Goto T, Takada K, Shimada N, Nambu H, Anada M, Shiro M, Ando K,
Hashimoto S. Highly enantioselective cyclopropenation reaction reaction
of 1-Alkynes with a-alkyl-a-diazoesters catalyzed by rhodium(II) carboxyl-
ates. Angew Chem Int Ed Engl 2011;50:6803–6808.
71. Adly FG, Gardiner MG, Ghanem A. X-ray structure of Rh2(S-1,2-NTPA)4.
2013, Unpublished results.
Chirality DOI 10.1002/chir
