S. Goksu, H. Sec¸en / Tetrahedron 61 (2005) 6801–6807
6805
(tt, 1H, H-2, JZ6.6, 4.2 Hz), 3.85 (s, 6H, 2!OCH3), 3.18
(A part of AB system, dd, 2H, JZ15.8, 6.6 Hz), 2.93 (B part
of AB system, dd, 2H, JZ15.8, 4.2 Hz). 13C NMR
(50 MHz, CDCl3) d 148.5, 131.6, 107.8, 62.0, 56.0, 38.9.
IR (CDCl3) 3070, 2997, 2937, 2833, 2110, 1610, 1504,
1465, 1454, 1313, 1265, 1230, 1189, 1089.
of AB system, dd, 1H, JZ16.5, 5.9 Hz), 2.88 (B part of AB
system, dd, 1H, JZ16.5, 3.1 Hz), 2.84 (B part of AB
system, dd, 1H, JZ16.6, 3.2 Hz), 2.05 (bs, 1H, OH). 13C
NMR (50 MHz, CDCl3) d 143.3, 139.8, 129.7, 128.1, 126.4,
120.3, 73.1, 42.6, 42.2. IR (KBr) 3295, 3064, 2948, 2894,
2817, 1601, 1574, 1474, 1420, 1412, 1343, 1293, 1258,
1197, 1162. Anal. Calcd for C9H9BrO (213.1): C, 50.73; H,
4.26; Found: C, 50.52; H, 4.11. EI-MS: 214.0 (MC, 40%),
212.0 (MC, 42%), 185.0 (MC, 98%), 183.0 (100%), 115.0
(30%), 105.1 (32%), 104.1 (22%), 77.0 (24%).
4.1.7. 2-Amino-5,6-dimethoxyindan hydrochloride (16).
Into a 100-mL flask were placed Pd–C (50 mg) and 2-azido-
5,6-dimethoxyindan (15) (1.00 g, 4.6 mmol) in MeOH
(35 mL) and CHCl3 (2 mL). A balloon filled with H2 gas
(3 L) was fitted to the flask. The mixture was deoxygenated
by flushing with H2 and then hydrogenated at rt for 20 h.
The catalyst was removed by filtration. Recrystallization of
the residue from MeOH–Et2O gave 2-amino-5,6-
dimethoxyindan hydrochloride (16) (1.00 g, 95%). Color-
less crystal. Mp 287–289 8C (from MeOH–Et2O), lit.3 Mp
288–290 8C (from 2-PrOH–Et2O). 1H NMR (200 MHz,
D2O) d 6.97 (s, 2H, H-4 and H-7). 4.23 (tt, 1H, H-2, JZ7.3,
3.7 Hz), 3.83 (s, 6H, 2!OCH3), 3.35 (A part of AB system,
dd, 2H, JZ16.9, 7.3 Hz), 2.98 (B part of AB system, dd, 2H,
JZ16.9, 3.7 Hz). 13C NMR (50 MHz, D2O) d 152.2, 135.7,
112.8, 60.2, 56.4, 41.6. Anal. Calcd for C11H16NO2Cl
(229.7): C, 67.52; H, 7.02; N, 6.10 Found: C, 57.85; H, 7.12;
N, 5.91.
4.1.10. Mitsunobu reaction of 5-bromo-indan-2-ol (18):
2-azido-5-bromoindan (19). The literature procedure14a
described for the conversion of trans-diols to the corre-
sponding diazides was applied to 5-bromo-indan-2-ol (18).
To a stirred solution of PPh3 (3.2 g, 12.2 mmol) in THF
(20 mL) was added a solution of DEAD (1.97 g, 11.3 mmol)
in THF (10 mL) dropwise under N2 1a8tm at 0 8C. To this
mixture was added a solution of HN3 (12.6 mmol, 7 mL,
1.8 M) and a solution of 5-bromoindan-2-ol (18) (2.00 g,
9.4 mmol) in THF (15 mL). The reaction mixture was
stirred at 0 8C for 30 min and then stirred at rt for 12 h. The
solvent of the reaction mixture was evaporated at 30 8C. The
residue was dissolved in 100 mL of Et2O and left in a
refrigerator overnight. After the filtration of the precipitate,
the solvent was evaporated. Chromatography of the residue
on a silica gel column (15 g) eluting with hexane–Et2O–
CHCl3 (100:7:7) gave 2-azido-5-bromoindan (19) (1.88 g,
84%). Colorless oil. 1H NMR (200 MHz, CDCl3) d 7.40 (bs,
4.1.8. 5-Bromoindan-2-ol acetate (17). To a stirred
solution of indan-2-ol acetate (10) (10.00 g, 56.8 mmol) in
freshly distilled acetonitrile (300 mL) from P2O5 was added
N-bromo-succinimide (30.34 g, 170.4 mmol) at rt in dark-
ness. The mixture was stirred at rt in darkness for 7 days.
The solvent was evaporated and the mixture was dissolved
in 150 mL of CH2Cl2. The organic layer was washed with
saturated aqueous Na2CO3 solution (3!100 mL). The
organic layer was dried over Na2SO4 and the solvent was
evaporated. Chromatography of the crude product on a short
silica gel column (15 g), eluting with hexane–EtOAc (4:1),
gave 5-bromoindan-2-ol acetate (17). (12.00 g, 83%).
Colorless crystal. Mp 75–77 8C (from CH2Cl2–hexane).
1H NMR (200 MHz, CDCl3) d 7.30 (bs, 1H, H-4), 7.32 (A
part of AB system, dd, 1H, H-6, J6,7Z8.0 Hz, J4,6Z1.6 Hz),
7.11 (B part of AB system, 1H, H-7, d, J6,7Z8.0 Hz),
5.53 (m, 1H, H-2), 3.29 (A part of AB system, dd, 1H, JZ
17.2, 6.4 Hz), 3.26 (A part of AB system, dd, 1H, JZ17.2,
6.6 Hz), 3.01 (B part of AB system, dd, 1H, JZ17.2,
3.0 Hz), 2.97 (B part of AB system, dd, 1H, JZ17.2,
3.0 Hz), 2.04 (s, 3H). 13C NMR (50 MHz, CDCl3) d 170.7,
142.0, 139.4, 129.0, 127.8, 126.0, 120.5, 75.1, 39.5, 39.1,
22.1. IR (CH2Cl2) 2968, 2921, 1736, 1470, 1420, 1370,
1254, 1197 cmK1. Anal. Calcd for C11H11BrO2 (254.0): C,
51.79; H, 4.35; Found: C, 51.51; H, 4.32. EI-MS: 195.9
(MCKCH3COOH, 38%), 193.9 (MCKCH3COOH, 40%),
115.0 (100%).
1H, H-4), 7.35 (A part of AB system, dd, 1H, H-6, J6,7
Z
8.1 Hz, J4,6Z1.9 Hz), 7.14 (B part of AB system, d, 1H,
H-7, J6,7Z8.1 Hz), 4.38 (m, 1H, H-2), 3.24 (A part of AB
system, dd, 1H, JZ16.5, 7.5 Hz), 3.20 (A part of
AB system, dd, 1H, JZ16.5, 6.9 Hz), 3.01 (B part of AB
system, dd, 1H, JZ16.5, 4.1 Hz), 2.98 (B part of AB
system, dd, 1H, JZ16.5, 4.1 Hz). 13C NMR (50 MHz,
CDCl3) d 142.3, 139.0, 129.8, 127.6, 125.9, 120.4, 61.5,
38.7, 38.6. IR (film) 3068, 2941, 2837, 2110, 1601, 1470,
1431, 1316, 1266, 1208, 1170 cmK1
.
4.1.11. 2-Amino-5-bromoindan (7).13 (a) From 2-azido-5-
bromoindan (19). To a stirred solution of CuSO4$5H2O
(0.11 g, 0.042 mmol) in 12 mL of MeOH was added NaBH4
(0.046 g, 1.24 mmol) at 0 8C. The reaction mixture was
stirred at the same temperature for 15 min. To this mixture
was added a solution of 2-azido-5-bromoindan (19) (1.00 g,
4.2 mmol) in 10 mL of MeOH and then NaBH4 (0.114 g,
3.00 mmol) in four portions over 1.5 h. After the addition of
NaBH4 was completed, the stirring was continued and
monitored by TLC at rt for 3 h. After the precipitate was
filtered off, MeOH was evaporated and the mixture was
made sufficiently alkaline (pHZ12) with 3 M NaOH. The
organic phase was extracted with EtOAc (3!25 mL). The
drying of the organic layer over Na2SO4 and evaporation of
EtOAc gave oily 2-amino-5-bromoindan (7) (0.71 g, 80%).
4.1.9. 5-Bromoindan-2-ol (18). The hydrolysis procedure
above described for 5,6-dibromo-indan-2-ol acetate (11)
was applied to 5-bromoindan-2-ol acetate (17) to give
5-bromoindan-2-ol (18) (90%). Colorless crystal. Mp 115–
117 8C (from CH2Cl2–hexane). 1H NMR (200 MHz,
CDCl3) d 7.38 (bs, 1H, H-4), 7.31 (A part of AB system,
dd, 1H, H-6, J6,7Z8.1 Hz, J4,6Z2.1 Hz), 7.12 (B part of AB
system, d, 1H, H-7, J6,7Z8.1 Hz), 4.68 (m, 1H, H-2), 3.19
(A part of AB system, dd, 1H, JZ16.6, 5.8 Hz), 3.14 (A part
(b) From 2-azido-5,6-dibromoindan (21). The procedure
above was applied to 2-azido-5,6-dibromoindan (21) using
2 equiv NaBH4 to give 2-amino-5-bromoindan (7) in a yield
of 75%.
For 7: 1H NMR (200 MHz, DMSO-d6) d 7.48 (bs, 1H, H-4),
7.37 (A part of AB system, d, 1H, H-6, J6,7Z8.1 Hz), 7.23
