Published on Web 07/19/2005
Total Synthesis of Thiostrepton. Assembly of Key Building
Blocks and Completion of the Synthesis
K. C. Nicolaou,* Mark Zak, Brian S. Safina, Anthony A. Estrada,
Sang Hyup Lee, and Marta Nevalainen
Contribution from the Department of Chemistry and The Skaggs Institute for Chemical Biology,
The Scripps Research Institute, 10550 North Torrey Pines Road, La Jolla, California 92037, and
Department of Chemistry and Biochemistry, UniVersity of California, San Diego,
9500 Gilman DriVe, La Jolla, California 92093
Received May 4, 2005; E-mail: kcn@scripps.edu
Abstract: The completion of the total synthesis of thiostrepton (1) is described. The synthesis proceeded
from key building blocks 2-5, which were assembled into a growing substrate that finally led to the target
molecule. Thus, the dehydropiperidine peptide core 2 was, after appropriate manipulation, coupled to the
thiazoline-thiazole fragment 3, and the resulting product was advanced to intermediate 11 possessing the
thiazoline-thiazole macrocycle. The bis-dehydroalanine tail equivalent 4 and the quinaldic acid fragment
5 were then sequentially incorporated, and the products so obtained were further elaborated to forge the
second macrocycle of the molecule. Several roadblocks encountered along the way were systematically
investigated and overcome, finally opening the way, through intermediates 20, 32, 44, 45, and 46, to the
targeted natural product, 1.
Introduction
rocycle 11, a challenge that was met only partially. Thus, under
the best conditions (Me3SnOH in 1,2-dichloroethane at 50 °C),2
In the preceding article1 we described the retrosynthetic
analysis of thiostrepton (1, Figure 1) and the construction of
the key building blocks (2-5) required for its projected total
synthesis. In this paper we discuss the assembly of these
fragments and the elaboration of the resulting advanced
intermediates into the final target (1), including a description
of some of the intriguing setbacks and obstacles that we
encountered, and finally overcame, en route to the destination.
we were able to convert bis-methyl ester 8 to a ca. 2:1 mixture
of monoacids (9 + 9′), in 52% combined yield, accompanied
by 14% of the corresponding diacid and 28% of recovered
starting material (8), both of which were, of course, recyclable.
Even though the two monoacids 9 and 9′ were not separable
by chromatography, nor could the major regioisomer be defined
at this stage, we nevertheless pressed forward in the hope of
achieving a separation at a later stage. Thus, reduction of the
mixture (9 + 9′) with PMe3 in the presence of H2O at 0 °C led
to the corresponding amino acids (10 + 10′), which were sub-
jected to high dilution macrolactamization conditions [HATU,
HOAt, i-Pr2NEt, DMF (0.002 M), 25 °C, 65 h] to afford, in
32% overall yield from acids 9 and 9′, a single macrolactam.
These results indicated that one regiosomer of the amino acid
(10 or 10′) was unable to cyclize upon activation, being instead
consumed during the reaction through polymerization or de-
composition pathways. Although at this juncture we were unable
to definitively establish that the macrocyclic product formed in
this reaction possessed the correct (and desired) regioisomeric
structure, we hoped that an intrinsic preference to form
macrocycle 11 existed due to its presence in the naturally
occurring thiostrepton (1). Indeed, molecular models (manual)
revealed unfavorable strain interactions for the alternative
macrolactamization reaction resulting from amino acid 10′.
Results and Discussion: Assembly of Building Blocks
and Total Synthesis
According to the designed plan, our first order of business
was the coupling of dehydropiperidine peptide fragment 2 with
the thiazoline segment 3 and the forging of the thiazoline-
containing macrocycle 11, a task that proceeded smoothly, as
summarized in Scheme 1. Thus, diastereomerically pure amine
21 was converted to its N-Alloc derivative 6 by reaction with
allyl chloroformate and i-Pr2NEt in the presence of 4-DMAP
as a catalyst (92% yield), and thence to N-Alloc 1,2-amino
alcohol 7 with TFA, whose action caused collapse of both the
N-Boc and acetonide masking devices. This amino alcohol (7)
was then joined to thiazoline building block 31 through an amide
bond-forming reaction promoted by HATU, HOAt, and i-Pr2-
NEt, furnishing peptide bis-methyl ester 8 in 73% overall yield
from N-Boc acetonide 6. The next task called for regioselective
hydrolysis of compound 8 to form the desired precursor
(monoacid 9) to the 26-membered thiazoline-containing mac-
(2) (a) Nicolaou, K. C.; Estrada, A. A.; Zak, M.; Lee, S. H.; Safina, B. S.
Angew. Chem., Int. Ed. 2005, 44, 1378-1382. (b) Furlan, R. L. E.; Mata,
E. G.; Mascaretti, O. A. J. Chem. Soc., Perkin Trans. 1 1998, 355-358.
(c) Furlan, R. L. E.; Mata, E. G.; Mascaretti, O. A.; Pena, C.; Coba, M. P.
Tetrahedron 1998, 54, 13023-13034. (d) Furlan, R. L. E.; Mascaretti, O.
A. Aldrichim. Acta 1997, 30, 55-69. (e) Furlan, R. L. E.; Mata, E. G.;
Mascaretti, O. A. Tetrahedron Lett. 1996, 37, 5229-5232.
(1) Nicolaou, K. C.; Safina, B. S.; Zak, M.; Lee, S. H.; Nevalainen, M.; Bella,
M.; Estrada, A. A.; Funke, C.; Ze´cri, F. J.; Bulat, S. J. Am. Chem. Soc.
9
11176
J. AM. CHEM. SOC. 2005, 127, 11176-11183
10.1021/ja052934z CCC: $30.25 © 2005 American Chemical Society
