by TLC using Merk silica gel 60F-254 thin layer plates. Column
chromatography was carried out on SDS Chromagel 60 ACC,
40-63 µm. The HPLC analyses were carried out on a system
consisting of a Waters 600 system controller, a Jones chroma-
tography heater-chiller oven and a Waters 994 photodiode
array detector.
first triturated with 20 mL of cyclohexane. The cyclohexane
was decanted, and 20 mL of Et2O was added. The salt
crystallized and was washed with 10 mL of Et2O. Yield 87%,
mp 165-168 °C. 1H NMR (CDCl3): δ 4.11(s, 2H, CH2), 4.99
(br, 3H, NH), 7.23 (t, 1H, Hpyridyl), 7.38 (m, 2H, Hphenyl), 7.73
(dt, 2H, Hpyridyl), 7.94 (d, J ) 7.83 Hz, 2H Hphenyl), 8.61 (d, J )
4.08 Hz,1H, Hpyridyl), 8.7 (br s, 3H H3N). 13C NMR (DMSO-
d6): δ 41.28, 115.42 (q, JC-F ) 293 Hz), 120.16, 122.41, 126.49,
128.59, 134.41, 137.40, 137.43, 148.29, 154.29, 157.77 (q,
JC-C-F ) 35 Hz). Anal. (C16H14N2O4F6) Calc: C, 46.61; H,
3.42; N, 6.79; found: 46.84; H, 3.53; N, 6.43.
Synthesis of 6-Arylmethylamino-2-chloropurines. To a
solution of 1 (23 g, 0.1 mol) in 200 mL of n-BuOH were added
the primary amine (0.12 mol) and NEt3 (synthesis of 8a: 22.5
mL, 0.16 mol; synthesis of 8b: 70 mL, 0.50 mol). After 3 h
heating at 110 °C, the mixture was cooled to 20 °C, and the
solid was filtrated, washed with 5 mL of cold n-BuOH, and
dried in vacuo.
4-(2-Pyridyl)benzaldehyde Oxime (2). To a solution of 1
(36.6 g, 0.2 mol) in 50 mL of EtOH and 20 mL of H2O were
added hydroxylamine hydrochloride (15.27, 0.21 mol) and
AcONa, 3H2O (29.90 g, 0.21 mol). The resulting slurry was
stirred for 12 h at rt. The mixture was concentrated to dryness,
and the resulting solid was washed with H2O (2 × 5 mL) and
1
EtOH, (1 × 5 mL). Yield 97%, mp 138-139 °C: H NMR
(CDCl3): δ 7.16 (m, 1H, Hpyridyl), 7.60 (d, J ) 8.08 Hz 2H,
Hphenyl), 7.67 (m, 2H, Hpyridyl), 7.91 (d, J ) 8.08 Hz, 2H, Hphenyl),
8.08 (s, 1H, H-C)N), 8.61 (d, J ) 3.28 Hz, 1H, Hpyridyl), 10.70
(bs, 1H, OH). 13C NMR (CDCl3): δ 119.45, 121.49, 125.60,
125.95, 128.98, 132.60, 136.02, 138.74, 147.08, 148.54.
tert-Butyloxycarbonyl-4-(2-pyridyl)phenylmethylamine (4).
To a solution of 2 (19.8 g, 0.1 mol) in 200 mL of EtOH was
added 1 g of 10% Pd/C, and the suspension was submitted to
hydrogenation at 5 atm for 18 h at rt. The catalyst was filtered
on celite and washed with EtOH (2 × 20 mL). The solution
was concentrated in vacuo, and the resulting viscous oil, 3, was
used in the next step without any purification. The crude amine,
3, was dissolved in 150 mL of THF. The solution was cooled
to 0 °C; NEt3 (17 mL, 0.11 mol) and ditert-butyldicarbonate,
(Boc)2O (24 g, 0.11 mol) were added. The resulting solution
was stirred at rt for 4 h. The mixture was concentrated in vacuo
and triturated with 30 mL of Et2O. The resulting solid was
washed with Et2O (2 × 10 mL). Yield: 89%, mp 87-89 °C.
1H NMR (CDCl3): δ 1.47(s, 9H, C(CH3)3), 4.37(d, 2H J ) 5.3
Hz, CH2), 4.93 (br, 1H, NH), 7.22 (m, 1H, Hpyridyl), 7.38 (d, J
) 8.08 Hz, 2H, Hphenyl), 7.73 (m, 2H, Hpyridyl), 7.95 (d, 2H,
Hphenyl), 8.68 (d, J ) 4.08 Hz, 1H, Hpyridyl). 13C NMR (CDCl3):
δ 28.25, 44.15, 78.86, 120.05, 121.95, 126.87, 127.38, 136.59,
138.29, 139.65, 149.53, 155.49, 156.69. Anal. (C17H20N2O2)
Calc: C, 71.81; H, 7.09; N, 9.85; found: C, 71.45; H, 6.98; N,
9.66.
2-Chloro-6-phenylmethylaminopurine (8a): yield 95%;
1
mp > 250 °C. H NMR (DMSO-d6): δ 4.80 (s, 2H, CH2),
7.45-7.70(m, 5H, Hphenyl), 7.91(s, 1H, H-8). (Solubility in
DMSOd6 or in CD3OD was to low for recording a 13C NMR
spectrum). Anal. (C12H10N5Cl) Calc: C, 55.50; H, 3.88; N,
26.97; found: C, 55.81; H, 3.73; N, 26.41.
2-Chloro-6-[4-(2-pyridyl)phenylmethylamino]purine (8b):
yield 93%; mp > 250 °C. 1H NMR (DMSO-d6): δ 4.80 (s, 2H,
CH2), 7.20 (m, 1Η, Ηpyridyl), 7.45 (d, 2H, J ) 8 Hz, Hphenyl),
7.72 (m, 2H, Hpyridyl), 7.95 (m, 3H, Hphenyl and H-8), 8.54 (d,
1H, J ) 4.8 Hz, Hpyridyl). Anal. (C17H13N6Cl) Calc: C, 60.63;
H, 3.89; N, 24.95; found: C, 60.80; H, 3.98; N, 24.61.
Alkylation of Chloropurines 9. To a solution of 8 (0.08
mol) in DMSO (100 mL) at 18-20 °C were added K2CO3
(35.52 g, 0.24 mol) and 2-bromopropane (19 mL, 0.2 mol).
After 5 h stirring at 18-20 °C, 2-bromopropane (4.7 mL, 0.05
mL) was added, and the stirring continued at the same
temperature for 5 h. After addition of 200 mL of cold (5 °C)
H2O, the mixture was extracted with EtOAc (3 × 100 mL, and
the combined organic layers were washed with brine (3 × 50
mL), dried, and dried over Na2SO4. Derivatives 9, which
crystallized upon concentration, were triturated once with 5 mL
of 2-propanol and were collected by filtration.
tert-Butyloxycarbonyl-4-(2-piperidyl)benzylamine (5). In
the reduction step 1 molar equiv of CH3COOH was added.
Otherwise, the procedure was accomplished according to the
method described in the preceding section. Compound 4 did
not crystallize and was purified by column chromatography
using CH2Cl2/MeOH/NEt3 (98:2:0.1) as eluent. Yield 65%, oil.
1H NMR (CDCl3): δ 1.44 (s, 9H, tert-Bu), 1.43-1.93 (m, 6H,
Hpiperidyl), 2.78 (td, 1H, J ) 11.6, 3.1 Hz, Hpiperidyl), 3.19 (d, 1H,
J ) 11.6 Hz, Hpiperidyl), 3.58 (dd, 1H, J ) 10.4, 2.4 Hz, Hpiperidyl),
4.24 (d, 2H, J ) 5.8 Hz, CH2), 4.81 (br, 1H, NH), 7.19 (d, J )
7.5 Hz, 2H, Hphenyl), 7.38 (d, 2H, Hphenyl); 13C NMR (CDCl3):
δ 5.2, 25.7, 28.33, 30.22, 34.8, 44.3, 47.65, 61.92, 126.85,
127.41, 137.58, 144.49, 155.83. Anal. (C17H26N2O2) Calc: C,
70.31; H, 9.02; N, 9.65; found: C, 70.39; H, 9.24; N, 9.48.
4-(2-Pyridyl)benzylamine Ditrifluoroacetate (6). To a
cooled (0 °C) solution of 3 (18 g, 0.063 mol) in 85 mL of
CH2Cl2 was added 85 mL of anhydrous CF3COOH. The cooling
bath was removed, and the mixture was stirred at rt for 2 h.
The mixture was evaporated to dryness, and the residue was
2-Chloro-6-phenylmethylamino-9-iso-propylpurine (9a):
1
yield 85%, mp 180-182 °C. H NMR (DMSO): δ 1.58 (d,
6H, J ) 6.8 Hz, CH(CH3)2), 4.90 (hept, 1H, CH(CH3)2),
6-7.25-7.50 (m, 5H, Hphenyl), 8.16 (s, 1H, H-8). 13C NMR
(DMSO): δ 21.81, 43.19, 46.04, 117.98, 126.44, 126.85, 127.67,
137.03, 137.97, 148.93, 153.03, 154.45. Anal. (C15H16N5Cl)
Calc: C, 59.70; H, 5.34; N, 23.21; found: C, 59.60; H, 5.22; N,
23.36.
2-Chloro-6-[4-(2-pyridyl)phenylmethylamino]-9-iso-pro-
pylpurine (9b): yield 86%, mp 187-189 °C. 1H NMR
(CDCl3): δ 1.58 (d, 6H, J ) 6.8 Hz, CH(CH3)2), 4.79 (hept,
1H, CH(CH3)2), 4.85 (bs, 2H, NHCH2), 6.59 (bs, 1H, NHCH2),
7.20-7.23 (m, 1H, Hpyridyl), 7.49 (d, 2H, J ) 8 Hz, Hphenyl),
7.73-7.71 (m, 2H, Hpyridyl), 7.79 (s, 1H, H-8), 7.98 (d, 2H,
Hphenyl), 8.71 (d, 1H, J ) 4.8 Hz, Hpyridyl). 22.52, 44.07, 46.78,
118.72, 120.25, 122.08, 127.01, 128.04, 136.66, 137.67, 138.54,
